How to Easily Apply Amazon Cloud Directory Schema Changes with In-Place Schema Upgrades

Post Syndicated from Mahendra Chheda original https://aws.amazon.com/blogs/security/how-to-easily-apply-amazon-cloud-directory-schema-changes-with-in-place-schema-upgrades/

Now, Amazon Cloud Directory makes it easier for you to apply schema changes across your directories with in-place schema upgrades. Your directory now remains available while Cloud Directory applies backward-compatible schema changes such as the addition of new fields. Without migrating data between directories or applying code changes to your applications, you can upgrade your schemas. You also can view the history of your schema changes in Cloud Directory by using version identifiers, which help you track and audit schema versions across directories. If you have multiple instances of a directory with the same schema, you can view the version history of schema changes to manage your directory fleet and ensure that all directories are running with the same schema version.

In this blog post, I demonstrate how to perform an in-place schema upgrade and use schema versions in Cloud Directory. I add additional attributes to an existing facet and add a new facet to a schema. I then publish the new schema and apply it to running directories, upgrading the schema in place. I also show how to view the version history of a directory schema, which helps me to ensure my directory fleet is running the same version of the schema and has the correct history of schema changes applied to it.

Note: I share Java code examples in this post. I assume that you are familiar with the AWS SDK and can use Java-based code to build a Cloud Directory code example. You can apply the concepts I cover in this post to other programming languages such as Python and Ruby.

Cloud Directory fundamentals

I will start by covering a few Cloud Directory fundamentals. If you are already familiar with the concepts behind Cloud Directory facets, schemas, and schema lifecycles, you can skip to the next section.

Facets: Groups of attributes. You use facets to define object types. For example, you can define a device schema by adding facets such as computers, phones, and tablets. A computer facet can track attributes such as serial number, make, and model. You can then use the facets to create computer objects, phone objects, and tablet objects in the directory to which the schema applies.

Schemas: Collections of facets. Schemas define which types of objects can be created in a directory (such as users, devices, and organizations) and enforce validation of data for each object class. All data within a directory must conform to the applied schema. As a result, the schema definition is essentially a blueprint to construct a directory with an applied schema.

Schema lifecycle: The four distinct states of a schema: Development, Published, Applied, and Deleted. Schemas in the Published and Applied states have version identifiers and cannot be changed. Schemas in the Applied state are used by directories for validation as applications insert or update data. You can change schemas in the Development state as many times as you need them to. In-place schema upgrades allow you to apply schema changes to an existing Applied schema in a production directory without the need to export and import the data populated in the directory.

How to add attributes to a computer inventory application schema and perform an in-place schema upgrade

To demonstrate how to set up schema versioning and perform an in-place schema upgrade, I will use an example of a computer inventory application that uses Cloud Directory to store relationship data. Let’s say that at my company, AnyCompany, we use this computer inventory application to track all computers we give to our employees for work use. I previously created a ComputerSchema and assigned its version identifier as 1. This schema contains one facet called ComputerInfo that includes attributes for SerialNumber, Make, and Model, as shown in the following schema details.

Schema: ComputerSchema
Version: 1

Facet: ComputerInfo
Attribute: SerialNumber, type: Integer
Attribute: Make, type: String
Attribute: Model, type: String

AnyCompany has offices in Seattle, Portland, and San Francisco. I have deployed the computer inventory application for each of these three locations. As shown in the lower left part of the following diagram, ComputerSchema is in the Published state with a version of 1. The Published schema is applied to SeattleDirectory, PortlandDirectory, and SanFranciscoDirectory for AnyCompany’s three locations. Implementing separate directories for different geographic locations when you don’t have any queries that cross location boundaries is a good data partitioning strategy and gives your application better response times with lower latency.

Diagram of ComputerSchema in Published state and applied to three directories

Legend for the diagrams in this post

The following code example creates the schema in the Development state by using a JSON file, publishes the schema, and then creates directories for the Seattle, Portland, and San Francisco locations. For this example, I assume the schema has been defined in the JSON file. The createSchema API creates a schema Amazon Resource Name (ARN) with the name defined in the variable, SCHEMA_NAME. I can use the putSchemaFromJson API to add specific schema definitions from the JSON file.

// The utility method to get valid Cloud Directory schema JSON
String validJson = getJsonFile("ComputerSchema_version_1.json")

String SCHEMA_NAME = "ComputerSchema";

String developmentSchemaArn = client.createSchema(new CreateSchemaRequest()
        .withName(SCHEMA_NAME))
        .getSchemaArn();

// Put the schema document in the Development schema
PutSchemaFromJsonResult result = client.putSchemaFromJson(new PutSchemaFromJsonRequest()
        .withSchemaArn(developmentSchemaArn)
        .withDocument(validJson));

The following code example takes the schema that is currently in the Development state and publishes the schema, changing its state to Published.

String SCHEMA_VERSION = "1";
String publishedSchemaArn = client.publishSchema(
        new PublishSchemaRequest()
        .withDevelopmentSchemaArn(developmentSchemaArn)
        .withVersion(SCHEMA_VERSION))
        .getPublishedSchemaArn();

// Our Published schema ARN is as follows
// arn:aws:clouddirectory:us-west-2:XXXXXXXXXXXX:schema/published/ComputerSchema/1

The following code example creates a directory named SeattleDirectory and applies the published schema. The createDirectory API call creates a directory by using the published schema provided in the API parameters. Note that Cloud Directory stores a version of the schema in the directory in the Applied state. I will use similar code to create directories for PortlandDirectory and SanFranciscoDirectory.

String DIRECTORY_NAME = "SeattleDirectory";

CreateDirectoryResult directory = client.createDirectory(
        new CreateDirectoryRequest()
        .withName(DIRECTORY_NAME)
        .withSchemaArn(publishedSchemaArn));

String directoryArn = directory.getDirectoryArn();
String appliedSchemaArn = directory.getAppliedSchemaArn();

// This code section can be reused to create directories for Portland and San Francisco locations with the appropriate directory names

// Our directory ARN is as follows
// arn:aws:clouddirectory:us-west-2:XXXXXXXXXXXX:directory/XX_DIRECTORY_GUID_XX

// Our applied schema ARN is as follows
// arn:aws:clouddirectory:us-west-2:XXXXXXXXXXXX:directory/XX_DIRECTORY_GUID_XX/schema/ComputerSchema/1

Revising a schema

Now let’s say my company, AnyCompany, wants to add more information for computers and to track which employees have been assigned a computer for work use. I modify the schema to add two attributes to the ComputerInfo facet: Description and OSVersion (operating system version). I make Description optional because it is not important for me to track this attribute for the computer objects I create. I make OSVersion mandatory because it is critical for me to track it for all computer objects so that I can make changes such as applying security patches or making upgrades. Because I make OSVersion mandatory, I must provide a default value that Cloud Directory will apply to objects that were created before the schema revision, in order to handle backward compatibility. Note that you can replace the value in any object with a different value.

I also add a new facet to track computer assignment information, shown in the following updated schema as the ComputerAssignment facet. This facet tracks these additional attributes: Name (the name of the person to whom the computer is assigned), EMail (the email address of the assignee), Department, and department CostCenter. Note that Cloud Directory refers to the previously available version identifier as the Major Version. Because I can now add a minor version to a schema, I also denote the changed schema as Minor Version A.

Schema: ComputerSchema
Major Version: 1
Minor Version: A

Facet: ComputerInfo
Attribute: SerialNumber, type: Integer
Attribute: Make, type: String
Attribute: Model, type: Integer
Attribute: Description, type: String, required: NOT_REQUIRED
Attribute: OSVersion, type: String, required: REQUIRED_ALWAYS, default: "Windows 7"

Facet: ComputerAssignment
Attribute: Name, type: String
Attribute: EMail, type: String
Attribute: Department, type: String
Attribute: CostCenter, type: Integer

The following diagram shows the changes that were made when I added another facet to the schema and attributes to the existing facet. The highlighted area of the diagram (bottom left) shows that the schema changes were published.

Diagram showing that schema changes were published

The following code example revises the existing Development schema by adding the new attributes to the ComputerInfo facet and by adding the ComputerAssignment facet. I use a new JSON file for the schema revision, and for the purposes of this example, I am assuming the JSON file has the full schema including planned revisions.

// The utility method to get a valid CloudDirectory schema JSON
String schemaJson = getJsonFile("ComputerSchema_version_1_A.json")

// Put the schema document in the Development schema
PutSchemaFromJsonResult result = client.putSchemaFromJson(
        new PutSchemaFromJsonRequest()
        .withSchemaArn(developmentSchemaArn)
        .withDocument(schemaJson));

Upgrading the Published schema

The following code example performs an in-place schema upgrade of the Published schema with schema revisions (it adds new attributes to the existing facet and another facet to the schema). The upgradePublishedSchema API upgrades the Published schema with backward-compatible changes from the Development schema.

// From an earlier code example, I know the publishedSchemaArn has this value: "arn:aws:clouddirectory:us-west-2:XXXXXXXXXXXX:schema/published/ComputerSchema/1"

// Upgrade publishedSchemaArn to minorVersion A. The Development schema must be backward compatible with
// the existing publishedSchemaArn.

String minorVersion = "A"

UpgradePublishedSchemaResult upgradePublishedSchemaResult = client.upgradePublishedSchema(new UpgradePublishedSchemaRequest()
        .withDevelopmentSchemaArn(developmentSchemaArn)
        .withPublishedSchemaArn(publishedSchemaArn)
        .withMinorVersion(minorVersion));

String upgradedPublishedSchemaArn = upgradePublishedSchemaResult.getUpgradedSchemaArn();

// The Published schema ARN after the upgrade shows a minor version as follows
// arn:aws:clouddirectory:us-west-2:XXXXXXXXXXXX:schema/published/ComputerSchema/1/A

Upgrading the Applied schema

The following diagram shows the in-place schema upgrade for the SeattleDirectory directory. I am performing the schema upgrade so that I can reflect the new schemas in all three directories. As a reminder, I added new attributes to the ComputerInfo facet and also added the ComputerAssignment facet. After the schema and directory upgrade, I can create objects for the ComputerInfo and ComputerAssignment facets in the SeattleDirectory. Any objects that were created with the old facet definition for ComputerInfo will now use the default values for any additional attributes defined in the new schema.

Diagram of the in-place schema upgrade for the SeattleDirectory directory

I use the following code example to perform an in-place upgrade of the SeattleDirectory to a Major Version of 1 and a Minor Version of A. Note that you should change a Major Version identifier in a schema to make backward-incompatible changes such as changing the data type of an existing attribute or dropping a mandatory attribute from your schema. Backward-incompatible changes require directory data migration from a previous version to the new version. You should change a Minor Version identifier in a schema to make backward-compatible upgrades such as adding additional attributes or adding facets, which in turn may contain one or more attributes. The upgradeAppliedSchema API lets me upgrade an existing directory with a different version of a schema.

// This upgrades ComputerSchema version 1 of the Applied schema in SeattleDirectory to Major Version 1 and Minor Version A
// The schema must be backward compatible or the API will fail with IncompatibleSchemaException

UpgradeAppliedSchemaResult upgradeAppliedSchemaResult = client.upgradeAppliedSchema(new UpgradeAppliedSchemaRequest()
        .withDirectoryArn(directoryArn)
        .withPublishedSchemaArn(upgradedPublishedSchemaArn));

String upgradedAppliedSchemaArn = upgradeAppliedSchemaResult.getUpgradedSchemaArn();

// The Applied schema ARN after the in-place schema upgrade will appear as follows
// arn:aws:clouddirectory:us-west-2:XXXXXXXXXXXX:directory/XX_DIRECTORY_GUID_XX/schema/ComputerSchema/1

// This code section can be reused to upgrade directories for the Portland and San Francisco locations with the appropriate directory ARN

Note: Cloud Directory has excluded returning the Minor Version identifier in the Applied schema ARN for backward compatibility and to enable the application to work across older and newer versions of the directory.

The following diagram shows the changes that are made when I perform an in-place schema upgrade in the two remaining directories, PortlandDirectory and SanFranciscoDirectory. I make these calls sequentially, upgrading PortlandDirectory first and then upgrading SanFranciscoDirectory. I use the same code example that I used earlier to upgrade SeattleDirectory. Now, all my directories are running the most current version of the schema. Also, I made these schema changes without having to migrate data and while maintaining my application’s high availability.

Diagram showing the changes that are made with an in-place schema upgrade in the two remaining directories

Schema revision history

I can now view the schema revision history for any of AnyCompany’s directories by using the listAppliedSchemaArns API. Cloud Directory maintains the five most recent versions of applied schema changes. Similarly, to inspect the current Minor Version that was applied to my schema, I use the getAppliedSchemaVersion API. The listAppliedSchemaArns API returns the schema ARNs based on my schema filter as defined in withSchemaArn.

I use the following code example to query an Applied schema for its version history.

// This returns the five most recent Minor Versions associated with a Major Version
ListAppliedSchemaArnsResult listAppliedSchemaArnsResult = client.listAppliedSchemaArns(new ListAppliedSchemaArnsRequest()
        .withDirectoryArn(directoryArn)
        .withSchemaArn(upgradedAppliedSchemaArn));

// Note: The listAppliedSchemaArns API without the SchemaArn filter returns all the Major Versions in a directory

The listAppliedSchemaArns API returns the two ARNs as shown in the following output.

arn:aws:clouddirectory:us-west-2:XXXXXXXXXXXX:directory/XX_DIRECTORY_GUID_XX/schema/ComputerSchema/1
arn:aws:clouddirectory:us-west-2:XXXXXXXXXXXX:directory/XX_DIRECTORY_GUID_XX/schema/ComputerSchema/1/A

The following code example queries an Applied schema for current Minor Version by using the getAppliedSchemaVersion API.

// This returns the current Applied schema's Minor Version ARN

GetAppliedSchemaVersion getAppliedSchemaVersionResult = client.getAppliedSchemaVersion(new GetAppliedSchemaVersionRequest()
	.withSchemaArn(upgradedAppliedSchemaArn));

The getAppliedSchemaVersion API returns the current Applied schema ARN with a Minor Version, as shown in the following output.

arn:aws:clouddirectory:us-west-2:XXXXXXXXXXXX:directory/XX_DIRECTORY_GUID_XX/schema/ComputerSchema/1/A

If you have a lot of directories, schema revision API calls can help you audit your directory fleet and ensure that all directories are running the same version of a schema. Such auditing can help you ensure high integrity of directories across your fleet.

Summary

You can use in-place schema upgrades to make changes to your directory schema as you evolve your data set to match the needs of your application. An in-place schema upgrade allows you to maintain high availability for your directory and applications while the upgrade takes place. For more information about in-place schema upgrades, see the in-place schema upgrade documentation.

If you have comments about this blog post, submit them in the “Comments” section below. If you have questions about implementing the solution in this post, start a new thread in the Directory Service forum or contact AWS Support.

– Mahendra



Presenting AWS IoT Analytics: Delivering IoT Analytics at Scale and Faster than Ever Before

Post Syndicated from Tara Walker original https://aws.amazon.com/blogs/aws/launch-presenting-aws-iot-analytics/

One of the technology areas I thoroughly enjoy is the Internet of Things (IoT). Even as a child I used to infuriate my parents by taking apart the toys they would purchase for me to see how they worked and if I could somehow put them back together. It seems somehow I was destined to end up the tough and ever-changing world of technology. Therefore, it’s no wonder that I am really enjoying learning and tinkering with IoT devices and technologies. It combines my love of development and software engineering with my curiosity around circuits, controllers, and other facets of the electrical engineering discipline; even though an electrical engineer I can not claim to be.

Despite all of the information that is collected by the deployment of IoT devices and solutions, I honestly never really thought about the need to analyze, search, and process this data until I came up against a scenario where it became of the utmost importance to be able to search and query through loads of sensory data for an anomaly occurrence. Of course, I understood the importance of analytics for businesses to make accurate decisions and predictions to drive the organization’s direction. But it didn’t occur to me initially, how important it was to make analytics an integral part of my IoT solutions. Well, I learned my lesson just in time because this re:Invent a service is launching to make it easier for anyone to process and analyze IoT messages and device data.



Hello, AWS IoT Analytics!  AWS IoT Analytics is a fully managed service of AWS IoT that provides advanced data analysis of data collected from your IoT devices.  With the AWS IoT Analytics service, you can process messages, gather and store large amounts of device data, as well as, query your data. Also, the new AWS IoT Analytics service feature integrates with Amazon Quicksight for visualization of your data and brings the power of machine learning through integration with Jupyter Notebooks.

Benefits of AWS IoT Analytics

  • Helps with predictive analysis of data by providing access to pre-built analytical functions
  • Provides ability to visualize analytical output from service
  • Provides tools to clean up data
  • Can help identify patterns in the gathered data

Be In the Know: IoT Analytics Concepts

  • Channel: archives the raw, unprocessed messages and collects data from MQTT topics.
  • Pipeline: consumes messages from channels and allows message processing.
    • Activities: perform transformations on your messages including filtering attributes and invoking lambda functions advanced processing.
  • Data Store: Used as a queryable repository for processed messages. Provide ability to have multiple datastores for messages coming from different devices or locations or filtered by message attributes.
  • Data Set: Data retrieval view from a data store, can be generated by a recurring schedule.

Getting Started with AWS IoT Analytics

First, I’ll create a channel to receive incoming messages.  This channel can be used to ingest data sent to the channel via MQTT or messages directed from the Rules Engine. To create a channel, I’ll select the Channels menu option and then click the Create a channel button.

I’ll name my channel, TaraIoTAnalyticsID and give the Channel a MQTT topic filter of Temperature. To complete the creation of my channel, I will click the Create Channel button.

Now that I have my Channel created, I need to create a Data Store to receive and store the messages received on the Channel from my IoT device. Remember you can set up multiple Data Stores for more complex solution needs, but I’ll just create one Data Store for my example. I’ll select Data Stores from menu panel and click Create a data store.



I’ll name my Data Store, TaraDataStoreID, and once I click the Create the data store button and I would have successfully set up a Data Store to house messages coming from my Channel.

Now that I have my Channel and my Data Store, I will need to connect the two using a Pipeline. I’ll create a simple pipeline that just connects my Channel and Data Store, but you can create a more robust pipeline to process and filter messages by adding Pipeline activities like a Lambda activity.

To create a pipeline, I’ll select the Pipelines menu option and then click the Create a pipeline button.

I will not add an Attribute for this pipeline. So I will click Next button.

As we discussed there are additional pipeline activities that I can add to my pipeline for the processing and transformation of messages but I will keep my first pipeline simple and hit the Next button.

The final step in creating my pipeline is for me to select my previously created Data Store and click Create Pipeline.

All that is left for me to take advantage of the AWS IoT Analytics service is to create an IoT rule that sends data to an AWS IoT Analytics channel.  Wow, that was a super easy process to set up analytics for IoT devices.

If I wanted to create a Data Set as a result of queries run against my data for visualization with Amazon Quicksight or integrate with Jupyter Notebooks to perform more advanced analytical functions, I can choose the Analyze menu option to bring up the screens to create data sets and access the Juypter Notebook instances.

Summary

As you can see, it was a very simple process to set up the advanced data analysis for AWS IoT. With AWS IoT Analytics, you have the ability to collect, visualize, process, query and store large amounts of data generated from your AWS IoT connected device. Additionally, you can access the AWS IoT Analytics service in a myriad of different ways; the AWS Command Line Interface (AWS CLI), the AWS IoT API, language-specific AWS SDKs, and AWS IoT Device SDKs.

AWS IoT Analytics is available today for you to dig into the analysis of your IoT data. To learn more about AWS IoT and AWS IoT Analytics go to the AWS IoT Analytics product page and/or the AWS IoT documentation.

Tara

Write and Read Multiple Objects in Amazon Cloud Directory by Using Batch Operations

Post Syndicated from Vineeth Harikumar original https://aws.amazon.com/blogs/security/write-and-read-multiple-objects-in-amazon-cloud-directory-by-using-batch-operations/

Amazon Cloud Directory is a hierarchical data store that enables you to build flexible, cloud-native directories for organizing hierarchies of data along multiple dimensions. For example, you can create an organizational structure that you can navigate through multiple hierarchies for reporting structure, location, and cost center.

In this blog post, I demonstrate how you can use Cloud Directory APIs to write and read multiple objects by using batch operations. With batch write operations, you can execute a sequence of operations atomically—meaning that all of the write operations must occur, or none of them do. You also can make your application efficient by reducing the number of required round trips to read and write objects to your directory. I have used the AWS SDK for Java for all the sample code in this blog post, but you can use other language SDKs or the AWS CLI in a similar way.

Using batch write operations

To demonstrate batch write operations, let’s say that AnyCompany’s warehouses are organized to determine the fastest methods to ship orders to its customers. In North America, AnyCompany plans to open new warehouses regularly so that the company can keep up with customer demand while continuing to meet the delivery times to which they are committed.

The following diagram shows part of AnyCompany’s global network, including Asian and European warehouse networks.

Let’s take a look at how I can use batch write operations to add NorthAmerica to AnyCompany’s global network of warehouses, with the first three warehouses in New York City (NYC), Las Vegas (LAS), and Phoenix (PHX).

Adding NorthAmerica to the global network

To add NorthAmerica to the global network, I can use a batch write operation to create and link all the objects in the existing network.

First, I set up a helper method, which performs repetitive tasks, for the getBatchCreateOperation object. The following lines of code help me create an NA object for NorthAmerica and then attach the three city-related nodes: NYC, LAS, and PHX. Because AnyCompany is planning to grow its network, I add a suffix of _1 to each city code (such as PHX_1), which will be helpful hierarchically when the company adds more warehouses within a city.

    private BatchWriteOperation getBatchCreateOperation(
            String warehouseName,
            String directorySchemaARN,
            String parentReference,
            String linkName) {

        SchemaFacet warehouse_facet = new SchemaFacet()
            .withFacetName("warehouse")
            .withSchemaArn(directorySchemaARN);

        AttributeKeyAndValue kv = new AttributeKeyAndValue()
            .withKey(new AttributeKey()
                .withFacetName("warehouse")
                .withName("name")
                .withSchemaArn(directorySchemaARN))
            .withValue(new TypedAttributeValue()
                .withStringValue(warehouseName);

        List<SchemaFacet> facets = Lists.newArrayList(warehouse_facet);
        List<AttributeKeyAndValue> kvs = Lists.newArrayList(kv);

        BatchCreateObject createObject = new BatchCreateObject();

        createObject.withParentReference(new ObjectReference()
            .withSelector(parentReference));
        createObject.withLinkName(linkName);

        createObject.withBatchReferenceName(UUID.randomUUID().toString());
        createObject.withSchemaFacet(facets);
        createObject.withObjectAttributeList(kvs);

        return new BatchWriteOperation().withCreateObject
                                       (createObject);
    }

The parameters of this helper method include:

  • warehouseName – The name of the warehouse to create in the getBatchCreateOperation object.
  • directorySchemaARN – The Amazon Resource Name (ARN) of the schema applied to the directory.
  • parentReference – The object reference of the parent object.
  • linkName – The unique child path from the parent reference where the object should be attached.

I then use this helper method to set up multiple create operations for NorthAmerica, NewYork, Phoenix, and LasVegas. For the sake of simplicity, I use airport codes to stand for the cities (for example, NYC stands for NewYork).

   BatchWriteOperation createObjectNA = getBatchCreateOperation(
                      "NA",
                      directorySchemaARN,
                      "/",
                      "NorthAmerica");
   BatchWriteOperation createObjectNYC = getBatchCreateOperation(
                      "NYC_1",
                      directorySchemaARN,
                      "/NorthAmerica",
                      "NewYork");
   BatchWriteOperation createObjectPHX = getBatchCreateOperation(
                       "PHX_1",
                       directorySchemaARN,
                       "/NorthAmerica",
                       "Phoenix");
   BatchWriteOperation createObjectLAS = getBatchCreateOperation(
                      "LAS_1",
                      directorySchemaARN,
                      "/NorthAmerica",
                      "LasVegas");

   BatchWriteRequest request = new BatchWriteRequest();
   request.setDirectoryArn(directoryARN);
   request.setOperations(Lists.newArrayList(
       createObjectNA,
       createObjectNYC,
       createObjectPHX,
       createObjectLAS));

   client.batchWrite(request);

Running the preceding code results in a hierarchy for the network with NA added to the network, as shown in the following diagram.

Using batch read operations

Now, let’s say that after I add NorthAmerica to AnyCompany’s global network, an analyst wants to see the updated view of the NorthAmerica warehouse network as well as some information about the newly introduced warehouse configurations for the Phoenix warehouses. To do this, I can use batch read operations to get the network of warehouses for NorthAmerica as well as specifically request the attributes and configurations of the Phoenix warehouses.

To list the children of the NorthAmerica warehouses, I use the BatchListObjectChildren API to get all the children at the path, /NorthAmerica. Next, I want to view the attributes of the Phoenix object, so I use the BatchListObjectAttributes API to read all the attributes of the object at /NorthAmerica/Phoenix, as shown in the following code example.

    BatchListObjectChildren listObjectChildrenRequest = new BatchListObjectChildren()
        .withObjectReference(new ObjectReference().withSelector("/NorthAmerica"));
    BatchListObjectAttributes listObjectAttributesRequest = new BatchListObjectAttributes()
        .withObjectReference(new ObjectReference()
            .withSelector("/NorthAmerica/Phoenix"));
    BatchReadRequest batchRead = new BatchReadRequest()
        .withConsistencyLevel(ConsistencyLevel.EVENTUAL)
        .withDirectoryArn(directoryArn)
        .withOperations(Lists.newArrayList(listObjectChildrenRequest, listObjectAttributesRequest));

    BatchReadResult result = client.batchRead(batchRead);

Exception handling

Batch operations in Cloud Directory might sometimes fail, and it is important to know how to handle such failures, which differ for write operations and read operations.

Batch write operation failures

If a batch write operation fails, Cloud Directory fails the entire batch operation and returns an exception. The exception contains the index of the operation that failed along with the exception type and message. If you see RetryableConflictException, you can try again with exponential backoff. A simple way to do this is to double the amount of time you wait each time you get an exception or failure. For example, if your first batch write operation fails, wait 100 milliseconds and try the request again. If the second request fails, wait 200 milliseconds and try again. If the third request fails, wait 400 milliseconds and try again.

Batch read operation failures

If a batch read operation fails, the response contains either a successful response or an exception response. Individual batch read operation failures do not cause the entire batch read operation to fail—Cloud Directory returns individual success or failure responses for each operation.

Limits of batch operations

Batch operations are still constrained by the same Cloud Directory limits as other Cloud Directory APIs. A single batch operation does not limit the number of operations, but the total number of nodes or objects being written or edited in a single batch operation have enforced limits. For example, a total of 20 objects can be written in a single batch operation request to Cloud Directory, regardless of how many individual operations there are within that batch. Similarly, a total of 200 objects can be read in a single batch operation request to Cloud Directory. For more information, see limits on batch operations.

Summary

In this post, I have demonstrated how you can use batch operations to operate on multiple objects and simplify making complicated changes across hierarchies. In my next post, I will demonstrate how to use batch references within batch write operations. To learn more about batch operations, see Batches, BatchWrite, and BatchRead.

If you have comments about this post, submit them in the “Comments” section below. If you have implementation questions, start a new thread on the Directory Service forum.

– Vineeth

Building Loosely Coupled, Scalable, C# Applications with Amazon SQS and Amazon SNS

Post Syndicated from Tara Van Unen original https://aws.amazon.com/blogs/compute/building-loosely-coupled-scalable-c-applications-with-amazon-sqs-and-amazon-sns/


Stephen Liedig, Solutions Architect



One of the many challenges professional software architects and developers face is how to make cloud-native applications scalable, fault-tolerant, and highly available.

Fundamental to your project success is understanding the importance of making systems highly cohesive and loosely coupled. That means considering the multi-dimensional facets of system coupling to support the distributed nature of the applications that you are building for the cloud.

By that, I mean addressing not only the application-level coupling (managing incoming and outgoing dependencies), but also considering the impacts of of platform, spatial, and temporal coupling of your systems. Platform coupling relates to the interoperability, or lack thereof, of heterogeneous systems components. Spatial coupling deals with managing components at a network topology level or protocol level. Temporal, or runtime coupling, refers to the ability of a component within your system to do any kind of meaningful work while it is performing a synchronous, blocking operation.

The AWS messaging services, Amazon SQS and Amazon SNS, help you deal with these forms of coupling by providing mechanisms for:

  • Reliable, durable, and fault-tolerant delivery of messages between application components
  • Logical decomposition of systems and increased autonomy of components
  • Creating unidirectional, non-blocking operations, temporarily decoupling system components at runtime
  • Decreasing the dependencies that components have on each other through standard communication and network channels

Following on the recent topic, Building Scalable Applications and Microservices: Adding Messaging to Your Toolbox, in this post, I look at some of the ways you can introduce SQS and SNS into your architectures to decouple your components, and show how you can implement them using C#.

Walkthrough

To illustrate some of these concepts, consider a web application that processes customer orders. As good architects and developers, you have followed best practices and made your application scalable and highly available. Your solution included implementing load balancing, dynamic scaling across multiple Availability Zones, and persisting orders in a Multi-AZ Amazon RDS database instance, as in the following diagram.


In this example, the application is responsible for handling and persisting the order data, as well as dealing with increases in traffic for popular items.

One potential point of vulnerability in the order processing workflow is in saving the order in the database. The business expects that every order has been persisted into the database. However, any potential deadlock, race condition, or network issue could cause the persistence of the order to fail. Then, the order is lost with no recourse to restore the order.

With good logging capability, you may be able to identify when an error occurred and which customer’s order failed. This wouldn’t allow you to “restore” the transaction, and by that stage, your customer is no longer your customer.

As illustrated in the following diagram, introducing an SQS queue helps improve your ordering application. Using the queue isolates the processing logic into its own component and runs it in a separate process from the web application. This, in turn, allows the system to be more resilient to spikes in traffic, while allowing work to be performed only as fast as necessary in order to manage costs.


In addition, you now have a mechanism for persisting orders as messages (with the queue acting as a temporary database), and have moved the scope of your transaction with your database further down the stack. In the event of an application exception or transaction failure, this ensures that the order processing can be retired or redirected to the Amazon SQS Dead Letter Queue (DLQ), for re-processing at a later stage. (See the recent post, Using Amazon SQS Dead-Letter Queues to Control Message Failure, for more information on dead-letter queues.)

Scaling the order processing nodes

This change allows you now to scale the web application frontend independently from the processing nodes. The frontend application can continue to scale based on metrics such as CPU usage, or the number of requests hitting the load balancer. Processing nodes can scale based on the number of orders in the queue. Here is an example of scale-in and scale-out alarms that you would associate with the scaling policy.

Scale-out Alarm

aws cloudwatch put-metric-alarm --alarm-name AddCapacityToCustomerOrderQueue --metric-name ApproximateNumberOfMessagesVisible --namespace "AWS/SQS"
--statistic Average --period 300 --threshold 3 --comparison-operator GreaterThanOrEqualToThreshold --dimensions Name=QueueName,Value=customer-orders
--evaluation-periods 2 --alarm-actions <arn of the scale-out autoscaling policy>

Scale-in Alarm

aws cloudwatch put-metric-alarm --alarm-name RemoveCapacityFromCustomerOrderQueue --metric-name ApproximateNumberOfMessagesVisible --namespace "AWS/SQS"
 --statistic Average --period 300 --threshold 1 --comparison-operator LessThanOrEqualToThreshold --dimensions Name=QueueName,Value=customer-orders
 --evaluation-periods 2 --alarm-actions <arn of the scale-in autoscaling policy>

In the above example, use the ApproximateNumberOfMessagesVisible metric to discover the queue length and drive the scaling policy of the Auto Scaling group. Another useful metric is ApproximateAgeOfOldestMessage, when applications have time-sensitive messages and developers need to ensure that messages are processed within a specific time period.

Scaling the order processing implementation

On top of scaling at an infrastructure level using Auto Scaling, make sure to take advantage of the processing power of your Amazon EC2 instances by using as many of the available threads as possible. There are several ways to implement this. In this post, we build a Windows service that uses the BackgroundWorker class to process the messages from the queue.

Here’s a closer look at the implementation. In the first section of the consuming application, use a loop to continually poll the queue for new messages, and construct a ReceiveMessageRequest variable.

public static void PollQueue()
{
    while (_running)
    {
        Task<ReceiveMessageResponse> receiveMessageResponse;

        // Pull messages off the queue
        using (var sqs = new AmazonSQSClient())
        {
            const int maxMessages = 10;  // 1-10

            //Receiving a message
            var receiveMessageRequest = new ReceiveMessageRequest
            {
                // Get URL from Configuration
                QueueUrl = _queueUrl,
                // The maximum number of messages to return.
                // Fewer messages might be returned.
                MaxNumberOfMessages = maxMessages,
                // A list of attributes that need to be returned with message.
                AttributeNames = new List<string> { "All" },
                // Enable long polling.
                // Time to wait for message to arrive on queue.
                WaitTimeSeconds = 5
            };

            receiveMessageResponse = sqs.ReceiveMessageAsync(receiveMessageRequest);
        }

The WaitTimeSeconds property of the ReceiveMessageRequest specifies the duration (in seconds) that the call waits for a message to arrive in the queue before returning a response to the calling application. There are a few benefits to using long polling:

  • It reduces the number of empty responses by allowing SQS to wait until a message is available in the queue before sending a response.
  • It eliminates false empty responses by querying all (rather than a limited number) of the servers.
  • It returns messages as soon any message becomes available.

For more information, see Amazon SQS Long Polling.

After you have returned messages from the queue, you can start to process them by looping through each message in the response and invoking a new BackgroundWorker thread.

// Process messages
if (receiveMessageResponse.Result.Messages != null)
{
    foreach (var message in receiveMessageResponse.Result.Messages)
    {
        Console.WriteLine("Received SQS message, starting worker thread");

        // Create background worker to process message
        BackgroundWorker worker = new BackgroundWorker();
        worker.DoWork += (obj, e) => ProcessMessage(message);
        worker.RunWorkerAsync();
    }
}
else
{
    Console.WriteLine("No messages on queue");
}

The event handler, ProcessMessage, is where you implement business logic for processing orders. It is important to have a good understanding of how long a typical transaction takes so you can set a message VisibilityTimeout that is long enough to complete your operation. If order processing takes longer than the specified timeout period, the message becomes visible on the queue. Other nodes may pick it and process the same order twice, leading to unintended consequences.

Handling Duplicate Messages

In order to manage duplicate messages, seek to make your processing application idempotent. In mathematics, idempotent describes a function that produces the same result if it is applied to itself:

f(x) = f(f(x))

No matter how many times you process the same message, the end result is the same (definition from Enterprise Integration Patterns: Designing, Building, and Deploying Messaging Solutions, Hohpe and Wolf, 2004).

There are several strategies you could apply to achieve this:

  • Create messages that have inherent idempotent characteristics. That is, they are non-transactional in nature and are unique at a specified point in time. Rather than saying “place new order for Customer A,” which adds a duplicate order to the customer, use “place order <orderid> on <timestamp> for Customer A,” which creates a single order no matter how often it is persisted.
  • Deliver your messages via an Amazon SQS FIFO queue, which provides the benefits of message sequencing, but also mechanisms for content-based deduplication. You can deduplicate using the MessageDeduplicationId property on the SendMessage request or by enabling content-based deduplication on the queue, which generates a hash for MessageDeduplicationId, based on the content of the message, not the attributes.
var sendMessageRequest = new SendMessageRequest
{
    QueueUrl = _queueUrl,
    MessageBody = JsonConvert.SerializeObject(order),
    MessageGroupId = Guid.NewGuid().ToString("N"),
    MessageDeduplicationId = Guid.NewGuid().ToString("N")
};
  • If using SQS FIFO queues is not an option, keep a message log of all messages attributes processed for a specified period of time, as an alternative to message deduplication on the receiving end. Verifying the existence of the message in the log before processing the message adds additional computational overhead to your processing. This can be minimized through low latency persistence solutions such as Amazon DynamoDB. Bear in mind that this solution is dependent on the successful, distributed transaction of the message and the message log.

Handling exceptions

Because of the distributed nature of SQS queues, it does not automatically delete the message. Therefore, you must explicitly delete the message from the queue after processing it, using the message ReceiptHandle property (see the following code example).

However, if at any stage you have an exception, avoid handling it as you normally would. The intention is to make sure that the message ends back on the queue, so that you can gracefully deal with intermittent failures. Instead, log the exception to capture diagnostic information, and swallow it.

By not explicitly deleting the message from the queue, you can take advantage of the VisibilityTimeout behavior described earlier. Gracefully handle the message processing failure and make the unprocessed message available to other nodes to process.

In the event that subsequent retries fail, SQS automatically moves the message to the configured DLQ after the configured number of receives has been reached. You can further investigate why the order process failed. Most importantly, the order has not been lost, and your customer is still your customer.

private static void ProcessMessage(Message message)
{
    using (var sqs = new AmazonSQSClient())
    {
        try
        {
            Console.WriteLine("Processing message id: {0}", message.MessageId);

            // Implement messaging processing here
            // Ensure no downstream resource contention (parallel processing)
            // <your order processing logic in here…>
            Console.WriteLine("{0} Thread {1}: {2}", DateTime.Now.ToString("s"), Thread.CurrentThread.ManagedThreadId, message.MessageId);

            // Delete the message off the queue.
            // Receipt handle is the identifier you must provide
            // when deleting the message.
            var deleteRequest = new DeleteMessageRequest(_queueName, message.ReceiptHandle);
            sqs.DeleteMessageAsync(deleteRequest);
            Console.WriteLine("Processed message id: {0}", message.MessageId);

        }
        catch (Exception ex)
        {
            // Do nothing.
            // Swallow exception, message will return to the queue when
            // visibility timeout has been exceeded.
            Console.WriteLine("Could not process message due to error. Exception: {0}", ex.Message);
        }
    }
}

Using SQS to adapt to changing business requirements

One of the benefits of introducing a message queue is that you can accommodate new business requirements without dramatically affecting your application.

If, for example, the business decided that all orders placed over $5000 are to be handled as a priority, you could introduce a new “priority order” queue. The way the orders are processed does not change. The only significant change to the processing application is to ensure that messages from the “priority order” queue are processed before the “standard order” queue.

The following diagram shows how this logic could be isolated in an “order dispatcher,” whose only purpose is to route order messages to the appropriate queue based on whether the order exceeds $5000. Nothing on the web application or the processing nodes changes other than the target queue to which the order is sent. The rates at which orders are processed can be achieved by modifying the poll rates and scalability settings that I have already discussed.

Extending the design pattern with Amazon SNS

Amazon SNS supports reliable publish-subscribe (pub-sub) scenarios and push notifications to known endpoints across a wide variety of protocols. It eliminates the need to periodically check or poll for new information and updates. SNS supports:

  • Reliable storage of messages for immediate or delayed processing
  • Publish / subscribe – direct, broadcast, targeted “push” messaging
  • Multiple subscriber protocols
  • Amazon SQS, HTTP, HTTPS, email, SMS, mobile push, AWS Lambda

With these capabilities, you can provide parallel asynchronous processing of orders in the system and extend it to support any number of different business use cases without affecting the production environment. This is commonly referred to as a “fanout” scenario.

Rather than your web application pushing orders to a queue for processing, send a notification via SNS. The SNS messages are sent to a topic and then replicated and pushed to multiple SQS queues and Lambda functions for processing.

As the diagram above shows, you have the development team consuming “live” data as they work on the next version of the processing application, or potentially using the messages to troubleshoot issues in production.

Marketing is consuming all order information, via a Lambda function that has subscribed to the SNS topic, inserting the records into an Amazon Redshift warehouse for analysis.

All of this, of course, is happening without affecting your order processing application.

Summary

While I haven’t dived deep into the specifics of each service, I have discussed how these services can be applied at an architectural level to build loosely coupled systems that facilitate multiple business use cases. I’ve also shown you how to use infrastructure and application-level scaling techniques, so you can get the most out of your EC2 instances.

One of the many benefits of using these managed services is how quickly and easily you can implement powerful messaging capabilities in your systems, and lower the capital and operational costs of managing your own messaging middleware.

Using Amazon SQS and Amazon SNS together can provide you with a powerful mechanism for decoupling application components. This should be part of design considerations as you architect for the cloud.

For more information, see the Amazon SQS Developer Guide and Amazon SNS Developer Guide. You’ll find tutorials on all the concepts covered in this post, and more. To can get started using the AWS console or SDK of your choice visit:

Happy messaging!

How to Create an Organizational Chart with Separate Hierarchies by Using Amazon Cloud Directory

Post Syndicated from Srikanth Mandadi original https://aws.amazon.com/blogs/security/how-to-create-an-organizational-chart-with-separate-hierarchies-by-using-amazon-cloud-directory/

Amazon Cloud Directory enables you to create directories for a variety of use cases, such as organizational charts, course catalogs, and device registries. Cloud Directory offers you the flexibility to create directories with hierarchies that span multiple dimensions. For example, you can create an organizational chart that you can navigate through separate hierarchies for reporting structure, location, and cost center.

In this blog post, I show how to use Cloud Directory APIs to create an organizational chart with two separate hierarchies in a single directory. I also show how to navigate the hierarchies and retrieve data. I use the Java SDK for all the sample code in this post, but you can use other language SDKs or the AWS CLI.

Define a schema

The first step in using Cloud Directory is to define a schema, which describes the data that will be stored in the directory that you will create later in this post. In this example, I define the schema by providing a JSON document. The schema has two facets: Employee and Group. I constrain the attributes within these facets by using various rules provided by Cloud Directory. For example, I specify that the Name attribute is of type STRING and must have a minimum length of 3 characters and maximum length of 100 characters. Similarly, I specify that the Status attribute is of type STRING and the value of this attribute must have one of the following three values: ACTIVE, INACTIVE, or TERMINATED. Having Cloud Directory handle these constraints means that I do not need to handle the validation of these constraints in my code, and it also lets multiple applications share the data in my directory without violating these constraints.

I also specify that the objectType of Employee is a LEAF_NODE. Therefore, employee objects cannot have any children, but can have multiple parents. The objectType of Group is NODE, which means group objects can have children, but they can only have one parent object. In the next section, I show you how to create a directory with this schema by using some sample Java code. Save the following JSON document to a file and provide the path to the file in the code for creating the schema in the next section.

{
  "facets" : {
    "Employee" : {
      "facetAttributes" : {
        "Name" : {
          "attributeDefinition" : {
            "attributeType" : "STRING",
            "isImmutable" : false,
            "attributeRules" : {
              "NameLengthRule" : {
                "parameters" : {
                  "min" : "3",
                  "max" : "100"
                },
                "ruleType": "STRING_LENGTH"
              }
            }
          },
          "requiredBehavior" : "REQUIRED_ALWAYS"
        },
        "EmailAddress" : {
          "attributeDefinition" : {
            "attributeType" : "STRING",
            "isImmutable" : true,
            "attributeRules" : {
              "NameLengthRule" : {
                "parameters" : {
                  "min" : "3",
                  "max" : "100"
                },
                "ruleType": "STRING_LENGTH"
              }
            }
          },
          "requiredBehavior" : "REQUIRED_ALWAYS"
        },
        "Status" : {
          "attributeDefinition" : {
            "attributeType" : "STRING",
            "isImmutable" : true,
            "attributeRules" : {
              "rule1" : {
                "parameters" : {
                  "allowedValues" : "ACTIVE, INACTIVE, TERMINATED"
                },
                "ruleType": "STRING_FROM_SET"
              }
            }
          },
          "requiredBehavior" : "REQUIRED_ALWAYS"
        }
      },
      "objectType" : "LEAF_NODE"
    },
    "Group" : {
      "facetAttributes" : {
        "Name" : {
          "attributeDefinition" : {
            "attributeType" : "STRING",
            "isImmutable" : true
          },
          "requiredBehavior" : "REQUIRED_ALWAYS"
        }
      },
      "objectType" : "NODE"
    }
  }
}

Create and publish the schema

Similar to other AWS services, I have to create the client for Cloud Directory to call the service APIs. To create a client, I use the following Java code.

    AWSCredentialsProvider credentials = null;
    try {
        credentials = new ProfileCredentialsProvider("default");
    } catch (Exception e) {
        throw new AmazonClientException(
            "Cannot load the credentials from the credential profiles file. " +
            "Please make sure that your credentials file is at the correct " +
            "location, and is in valid format.",
            e);
    }
    AmazonCloudDirectory client = AmazonCloudDirectoryClientBuilder.standard()
            .withRegion(Regions.US_EAST_1)
            .withCredentials(credentials)
            .build();

Now, I am ready to create the schema that I defined in the JSON file earlier in the post. When I create the schema, it is in the Development state. A schema in Cloud Directory can be in the Development, Published, or Applied state. When the schema is in the Development state, I can make more changes to the schema. In this case, however, I don’t want to make additional changes. Therefore, I will just publish the schema, which makes it available for creating directories (you cannot modify a schema in the Published state). I discuss the Applied state for schemas in the next section. In the following code, change the jsonFilePath variable to the file location where you saved the JSON schema in the previous step.

    //Read the JSON schema content from the file.
    String jsonFilePath = <Provide the location of the json schema file here>;
    String schemaDocument;
    try
    {
        schemaDocument = new String(Files.readAllBytes(Paths.get(jsonFilePath)));
    }
    catch(IOException e)
    {
        throw new RuntimeException(e);
    }

    //Create an empty schema with a schema name. The schema name needs to be unique
    //within an AWS account.
    CreateSchemaRequest createSchemaRequest = new CreateSchemaRequest()
        .withName("EmployeeSchema");
    String developmentSchemaArn =  client.createSchema(createSchemaRequest).getSchemaArn();

    //Load the previously defined JSON into the empty schema that was just created
    PutSchemaFromJsonRequest putSchemaRequest = new PutSchemaFromJsonRequest()
           .withDocument(schemaDocument)
           .withSchemaArn(developmentSchemaArn);
    PutSchemaFromJsonResult putSchemaResult =  client.putSchemaFromJson(putSchemaRequest);

    //No more changes needed for schema so publish the schema
    PublishSchemaRequest publishSchemaRequest = new PublishSchemaRequest()
        .withDevelopmentSchemaArn(developmentSchemaArn)
        .withVersion("1.0");
    String publishedSchemaArn =  client.publishSchema(publishSchemaRequest).getPublishedSchemaArn();

Create a directory by using the published schema

I am now ready to create a directory by using the schema I just published. When I create a directory, Cloud Directory copies the published schema to the newly created directory. The schema copied to this directory is in the Applied state, which means if I had a scenario in which a schema attached to a particular directory needed to be changed, I could make changes to the schema that is applied to that specific directory.

The following code creates the directory and receives the Applied schema ARN and directory ARN. This Applied schema ARN is useful if I need to make changes to the schema applied to this directory. The directory ARN will be used in all subsequent operations associated with the directory. Cloud Directory will use the directory ARN to identify the directory associated with incoming requests because a single customer can create multiple directories.

    //Create a directory using the published schema. Specify a directory name, which must be unique within an account.
    CreateDirectoryRequest createDirectoryRequest = new CreateDirectoryRequest()
        .withName("EmployeeDirectory")
        .withSchemaArn(publishedSchemaArn);
    CreateDirectoryResult createDirectoryResult =  client.createDirectory(createDirectoryRequest);
    String directoryArn = createDirectoryResult.getDirectoryArn();
    String appliedSchemaArn = createDirectoryResult.getAppliedSchemaArn();

How hierarchies are stored in a directory

The organizational chart I want to create has a simple hierarchy as shown in the following diagram. Anna belongs to both the ITStaff and Managers groups. This example demonstrates a capability of Cloud Directory that enables me to build multiple hierarchies in a single directory. These hierarchies can have their own structure and leaf nodes belonging to more than one hierarchy because lead nodes can have more than one parent.

Being able to create multiple hierarchies within a single directory gives me some flexibility in how I organize my employees. For example, I can create a hierarchy representing departments in my organization and add employees to their respective departments, as illustrated in the following diagram. I can create another hierarchy representing geographic locations and add employees to the geographic location where they work. The first step in creating this hierarchy is to create the ITStaff and Managers group objects, which is what I do in the next section.

Hierarchy diagram

Create group objects

I will now create the data representing my organizational chart in the directory that I created. The following code creates the ITStaff and Managers group objects, which are created under the root node of the directory.

    for (String groupName : Arrays.asList("ITStaff", "Managers")) {
        CreateObjectRequest request = new CreateObjectRequest()
            .withDirectoryArn(directoryArn)
           // The parent of the object we are creating. We are rooting the group nodes
           // under root object. The root object exists in all directories and the path
           // to the root node is always "/".
           .withParentReference(new ObjectReference().withSelector("/"))
           // The name attached to the link between the parent and the child objects.
           .withLinkName(groupName)
           .withSchemaFacets(new SchemaFacet()
               .withSchemaArn(appliedSchemaArn)
               .withFacetName("Group"))
               //We specify the attributes to attach to this object.
                .withObjectAttributeList(new AttributeKeyAndValue()
                    .withKey(new AttributeKey()
                             // Name attribute for the group
                             .withSchemaArn(appliedSchemaArn)
                             .withFacetName("Group")
                             .withName("Name"))
                        // We provide the attribute value. The type used here must match the type defined in schema
                             .withValue(new TypedAttributeValue().withStringValue(groupName)));
    client.createObject(request);
    }

Create employee objects

The group objects are now in the directory. Next, I create employee objects for Anna and Bob under the ITStaff group. The following Java code creates the Anna object. Creating the Bob object is similar. When creating the Bob object, I provide different attribute values for Name, EmailAddress, and the like.

    CreateObjectRequest createAnna = new CreateObjectRequest()
                .withDirectoryArn(directoryArn)
                .withLinkName("Anna")
                .withParentReference(new ObjectReference().withSelector("/ITStaff"))
                .withSchemaFacets(new SchemaFacet()
                        .withSchemaArn(appliedSchemaArn)
                        .withFacetName("Employee"))
                .withObjectAttributeList(new AttributeKeyAndValue()
                        .withKey(new AttributeKey()
                                // Name attribute from employee facet
                                .withSchemaArn(appliedSchemaArn)
                                .withFacetName("Employee")
                                .withName("Name"))
                        .withValue(new TypedAttributeValue().withStringValue("Anna")),
                        new AttributeKeyAndValue()
                        .withKey(new AttributeKey()
                                // EmailAddress attribute from employee facet
                                .withSchemaArn(appliedSchemaArn)
                                .withFacetName("Employee")
                                .withName("EmailAddress"))
                        .withValue(new TypedAttributeValue().withStringValue("[email protected]")),
                        new AttributeKeyAndValue()
                        .withKey(new AttributeKey()
                                 // Status attribute from employee facet
                                .withSchemaArn(appliedSchemaArn)
                                .withFacetName("Employee")
                                .withName("Status"))
                        .withValue(new TypedAttributeValue().withStringValue("ACTIVE")));
     // CreateObject provides the object identifier of the object that was created.  An object identifier
       // is a globally unique, immutable identifier assigned to every object.
     String annasObjectId = client.createObject(createAnna).getObjectIdentifier();

Both the Bob and Anna objects are created under ITStaff, but Anna is also a manager and needs to be added under the Managers group. The following code does just that.

   AttachObjectRequest makeAnnaAManager = new AttachObjectRequest()
           .withDirectoryArn(directoryArn)
           .withLinkName("Anna")
           // Provide the parent object that Anna needs to be attached to using the path to the Managers object
           .withParentReference(new ObjectReference().withSelector("/Managers"))
           // Here we use the object identifier syntax to specify Anna's node. We could have used the
           // following path instead: /ITStaff/Anna. Both are equivalent.
           .withChildReference(new ObjectReference().withSelector("$" + annasObjectId));
   client.attachObject(makeAnnaAManager);

Retrieving objects in the directory

Now that I have populated my directory, I want to find a specific object. I can do that either by using the path to the object or the object identifier. I use the getObjectInformation API to first get the Anna object by specifying its path, and then I print the object identifiers of all the parents of the Anna object. I should print two parent object identifiers because Anna has both ITStaff and Managers as its parent. Here I am listing parents; however, I also can perform other operations on the object such as listing its children or its attributes. Using listChildren and listObjectAttributes, I can retrieve all the information stored in my directory.

    // First get the object for Anna
    GetObjectInformationRequest annaObjectRequest = new GetObjectInformationRequest()
           .withObjectReference(new ObjectReference().withSelector("/Managers/Anna"))
           .withDirectoryArn(directoryArn);
    GetObjectInformationResult annaObjectResult =  client.getObjectInformation(annaObjectRequest);
    // List parent objects for Anna to give her groups
    ListObjectParentsRequest annaGroupsRequest = new ListObjectParentsRequest()
           .withDirectoryArn(directoryArn)
           .withObjectReference(new ObjectReference().withSelector("$" + annaObjectResult.getObjectIdentifier()));
    ListObjectParentsResult annaGroupsResult =  client.listObjectParents(annaGroupsRequest);
    for(Map.Entry<String, String> entry : annaGroupsResult.getParents().entrySet())
    {
       System.out.println("Parent Object Identifier:" + entry.getKey());
       System.out.println("Link Name:" + entry.getValue());
    }

Summary

In this post, I showed how to use Cloud Directory APIs to create an organizational chart with multiple hierarchies. Keep in mind that Cloud Directory offers additional functionality such as batch operations and indexing that I have not covered in this blog post. For more information, see the Amazon Cloud Directory API Reference.

If you have questions or suggestions about this blog post, start a new thread on the Directory Service forum.

– Srikanth

FINAL REMINDER! systemd.conf 2016 CfP Ends on Monday!

Post Syndicated from Lennart Poettering original http://0pointer.net/blog/final-reminder-systemdconf-2016-cfp-ends-on-monday.html

Please note that the systemd.conf 2016
Call for Participation ends on Monday, on Aug. 1st! Please send
in your talk proposal by then! We’ve already got a good number of
excellent submissions, but we are very interested in yours, too!

We are looking for talks on all facets of systemd: deployment,
maintenance, administration, development. Regardless of whether you
use it in the cloud, on embedded, on IoT, on the desktop, on mobile,
in a container or on the server: we are interested in your
submissions!

In addition to proposals for talks for the main conference, we are
looking for proposals for workshop sessions held during our
Workshop Day (the first day of the conference). The workshop format
consists of a day of 2-3h training sessions, that may cover any
systemd-related topic you’d like. We are both interested in
submissions from the developer community as well as submissions from
organizations making use of systemd! Introductory workshop sessions
are particularly welcome, as the Workshop Day is intended to open up
our conference to newcomers and people who aren’t systemd gurus yet,
but would like to become more fluent.

For further details on the submissions we are looking for and the CfP
process, please consult the CfP
page
and
submit your proposal using the provided form!

ALSO: Please sign up for the conference soon! Only a
limited number of tickets are available, hence make sure to secure
yours quickly before they run out! (Last year we sold out.) Please
sign up here for the
conference!

AND OF COURSE: We are also looking for more sponsors for
systemd.conf! If you are working on systemd-related projects, or make
use of it in your company, please consider becoming a sponsor of
systemd.conf
2016
!
Without our sponsors we couldn’t organize systemd.conf 2016!

Thank you very much, and see you in Berlin!

REMINDER! systemd.conf 2016 CfP Ends in Two Weeks!

Post Syndicated from Lennart Poettering original http://0pointer.net/blog/reminder-systemdconf-2016-cfp-ends-in-two-weeks.html

Please note that the systemd.conf 2016
Call for Participation ends in less than two weeks, on Aug. 1st!
Please send in your talk proposal by then! We’ve already got a good
number of excellent submissions, but we are interested in yours even
more!

We are looking for talks on all facets of systemd: deployment,
maintenance, administration, development. Regardless of whether you
use it in the cloud, on embedded, on IoT, on the desktop, on mobile,
in a container or on the server: we are interested in your
submissions!

In addition to proposals for talks for the main conference, we are
looking for proposals for workshop sessions held during our
Workshop Day (the first day of the conference). The workshop format
consists of a day of 2-3h training sessions, that may cover any
systemd-related topic you’d like. We are both interested in
submissions from the developer community as well as submissions from
organizations making use of systemd! Introductory workshop sessions
are particularly welcome, as the Workshop Day is intended to open up
our conference to newcomers and people who aren’t systemd gurus yet,
but would like to become more fluent.

For further details on the submissions we are looking for and the CfP
process, please consult the CfP
page
and
submit your proposal using the provided form!

And keep in mind:

REMINDER: Please sign up for the conference soon! Only a
limited number of tickets are available, hence make sure to secure
yours quickly before they run out! (Last year we sold out.) Please
sign up here for the
conference!

AND OF COURSE: We are also looking for more sponsors for
systemd.conf! If you are working on systemd-related projects, or make
use of it in your company, please consider becoming a sponsor of
systemd.conf
2016
!
Without our sponsors we couldn’t organize systemd.conf 2016!

Thank you very much, and see you in Berlin!
