Three-factor authentication is the new two-factor authentication

Post Syndicated from Alex Bate original https://www.raspberrypi.org/blog/three-factor-authentication-raspberry-pi/

Two-factor authentication continues to provide our online selves with more security for our email and online banking. Meanwhile, in the physical world, protecting our valuables is now all about three-factor authentication.

A GIF of a thumbprint being scanned for authentication - three-factor authentication

Not sure what I mean? Here’s a video from Switched On Network that demonstrates how to use a Raspberry Pi to build a three-factor door lock comprised of an RFID keyring, 6-digit passcode, and one-time access code sent to your mobile phone.

Note that this is a fairly long video, so feel free to skip it for now and read my rather snazzy tl;dr. You can come back to the video later, with a cup of tea and 20 minutes to spare. It’ll be worth it, I promise.

Build a Raspberry Pi Smart Door Lock Security System with Three Factor Authentication!

https://amzn.to/2A98EaZ (UK) / https://amzn.to/2LDlxyc (US) – Get a free audiobook with a 30-day trial of Audible from Amazon! Build the ultimate door lock system, effectively turning your office or bedroom into a high-security vault!

The tl;dr of three-factor door locks by Alex Bate

To build Switched On Network’s three-factor door lock, you need to source a Raspberry Pi 3, a USB RFID reader and fob, a touchscreen, a electronic door strike, and a relay switch. You also need a few other extras, such as a power supply and a glue gun.

A screenshot from the three-factor authentication video of a glue gun

Once you’ve installed the appropriate drivers (if necessary) for your screen, and rotated the display by 90 degrees, you can skip ahead a few steps by installing the Python script from Switched On Network’s GitHub repo! Cheers!

A screenshot from the three-factor authentication video of the screen attached to the Pi in portrait mode

Then for the physical build: you need to attach the door strike, leads, and whatnot to the Pi — and all that together to the door and door frame. Again, I won’t go into the details, since that’s where the video excels.

A screenshot from the video of the components of the three-factor authentication door lock

The end result is a superior door lock that requires you to remember both your keys and your phone in order to open it. And while we’d never suggest using this tech to secure your house from the outside, it’s a perfect setup for inside doors to offices or basement lairs.

A GIF of Dexter from Dexter's Laboratory

Everyone should have a lair.

Now go watch the video!

The post Three-factor authentication is the new two-factor authentication appeared first on Raspberry Pi.
