For those who follow Backblaze, you’ll know that QNAP was an early integrator for our B2 Cloud Storage service. The popular storage company sells solutions for almost any use case where local storage is needed, and with their Hybrid Backup Sync software, you can easily sync that data to the cloud. For years, we’ve helped QNAP users like Yoga International and SoCo Systems back up and archive their data to B2. But QNAP never stops innovating, so we wanted to share some recent updates that will have both current and potential users excited about the future of our integrations.
Hybrid Backup Sync 3.0
Current QNAP and B2 users are used to having Hybrid Backup Sync (HBS) quickly and reliably sync their data to the cloud. With the HBS 3.0 update, the feature has become far more powerful. The latest update adds true backup capability for B2 users with features like version control, client-side encryption, and block-level deduplication. QNAP’s operating system, QTS, continues to deliver innovation and add thrilling new features. In the QTS 4.4.1 update, you also have the ability to preview backed up files using the QuDedup Extract Tool, allowing QNAP users to save on bandwidth costs.
The QTS 4.4.1 update is now available (you can download it here) and the HBS 3.0 update is currently available in the App Center on your QNAP device.
Hybrid Mount and VJBOD Cloud
The new Hybrid Mount and VJBOD Cloud apps will allow QNAP users to designate a drive in their system to function as a cache while accessing their B2 Cloud Storage. This allows users to interact with B2 just like you would a folder on your QNAP device while using B2 as an active storage location.
Hybrid Mount and VJBOD Cloud are both included in the QTS 4.4.1 update and function as a storage gateway on a file-based or block-based level, respectively. Hybrid Mount enables B2 to be used as a file server and is ideal for online collaboration and file-level data analysis. VJBOD Cloud is ideal for a large number of small files or singular massively large files (think databases!) since it’s able to update and change files on a block-level basis. Both apps offer the ability to connect to B2 via popular protocols to fit any environment, including SMB, AFP, NFS, FTP and WebDAV.
QuDedup introduces client-side deduplication to the QNAP ecosystem. This helps users at all levels to save on space on their NAS by avoiding redundant copies in storage. B2 users have something to look forward to as well since these savings carry over to cloud storage via the HBS 3.0 update.
QNAP continues to innovate and unlock the potential of B2 in the NAS ecosystem. We’re huge fans of these new updates and whatever else may come down the pipeline in the future. We’ll be sure to highlight any other exciting updates as they become available.
Backblaze’s data centers may not be the biggest in the world of data storage, but thanks to some chutzpah, transparency, and wily employees, we’re able to punch well above our weight when it comes to purchasing hard drives. No one knows this better than our Director of Supply Chain, Ariel Ellis.
As the person on staff ultimately responsible for sourcing the drives our data centers need to run—some 117,658 by his last count—Ariel knows a thing or two about purchasing petabytes-worth of storage. So we asked him to share his insights on the evaluation and purchasing process here at Backblaze. While we’re buying at a slightly larger volume than some of you might be, we hope you find Ariel’s approach useful and that you’ll share your own drive purchasing philosophies in the comments below.
An Interview with Ariel Ellis, Director of Supply Chain at Backblaze
Sourcing and Purchasing Drives
Backblaze: Thanks for making time, Ariel—we know staying ahead of the burn rate always keeps you busy. Let’s start with the basics: What kinds of hard drives do we use in our data centers, and where do we buy them?
Ariel: In the past, we purchased both consumer and enterprise hard drives. We bought the drives that gave us the best performance and longevity for the price, and we discovered that, in many cases, those were consumer drives.
Today, our purchasing volume is large enough that consumer drives are no longer an option. We simply can’t get enough. High capacity drives in high volume are only available to us in enterprise models. But, by sourcing large volume and negotiating prices directly with each manufacturer, we are able to achieve lower costs and better performance than we could when we were only buying in the consumer channel. Additionally, buying directly gives us five year warranties on the drives, which is essential for our use case.
We began to purchase direct around the launch of our Vault architecture, in 2015. Each Vault contains 1,200 drives and we have been deploying two to four, or more, Vaults each month. 4,800 drives are just not available through consumer distribution. So we now purchase drives from all three hard drive manufacturers: Western Digital, Toshiba, and Seagate.
Backblaze: Of the drives we’re purchasing, are they all 7200 RPM and 3.5” form factor? Is there any reason we’d consider slower drives or 2.5” drives?
Ariel: We use drives with varying speeds, though some power-conserving drives don’t disclose their drive speed. Power draw is a very important metric for us and the high speed enterprise drives are expensive in terms of power cost. We now total around 1.5 megawatts in power consumption in our centers, and I can tell you that every watt matters for reducing costs.
As far as 2.5″ drives, I’ve run the math and they’re not more cost effective than 3.5″ drives, so there’s no incentive for us to use them.
Backblaze: What about other drive types and modifications, like SSD, or helium enclosures, or SMR drives? What are we using and what have we tried beyond the old standards?
Ariel: When I started at Backblaze, SSDs were more than ten times the cost of conventional hard drives. Now they’re about three times the cost. But for Backblaze’s business, three times the cost is not viable for the pricing targets we have to meet. We do use some SSDs as boot drives, as well as in our backend systems, where they are used to speed up caching and boot times, but there are currently no flash drives in our Storage Pods—not in HDD or M.2 formats. We’ve looked at flash as a way to manage higher densities of drives in the future and we’ll continue to evaluate their usefulness to us.
Helium has its benefits, primarily lower power draw, but it makes drive service difficult when that’s necessary. That said, all the drives we have purchased that are larger than 8 TB have been helium—they’re just part of the picture for us. Higher capacity drives, sealed helium drives, and other new technologies that increase the density of the drives are essential to work with as we grow our data centers, but they also increase drive fragility, which is something we have to manage.
SMR would give us a 10-15% capacity-to-dollar boost, but it also requires host-level management of sequential data writing. Additionally, the new archive type of drives require a flash-based caching layer. Both of these requirements would mean significant increases in engineering resources to support and thereby even more investment. So all-in-all, SMR isn’t cost-effective in our system.
Soon we’ll be dealing with MAMR and HAMR drives as well. We plan to test both technologies in 2020. We’re also testing interesting new tech like Seagate’s MACH.2 Multi Actuator, which allows the host to request and receive data simultaneously from two areas of the drive in parallel, potentially doubling the input/output operations per second (IOPS) performance of each individual hard drive. This offsets issues of reduced data availability that would otherwise arise with higher drive capacities. The drive also can present itself as two independent drives. For example, a 16 TB drive can appear as two independent 8 TB drives. A Vault using 60 drives per pod could present as 120 drives per pod. That offers some interesting possibilities.
Backblaze: What does it take to deploy a full vault, financially speaking? Can you share the cost?
Ariel: The cost to deploy a single vault varies between $350,000 to $500,000, depending on the drive capacities being used. This is just the purchase price though. There is also the cost of data center space, power to house and run the hardware, the staff time to install everything, and the bandwidth used to fill it. All of that should be included in the total cost of filling a vault.
Evaluating and Testing New Drive Models
Backblaze: Okay, so when you get to the point where the tech seems like it will work in the data center, how do you evaluate new drive models to include in the Vaults?
Ariel: First, we select drives that fit our cost targets. These are usually high capacity drives being produced in large volumes for the cloud market. We always start with test batches that are separate from our production data storage. We don’t put customers’ data on the test drives. We evaluate read/write performance, power draw, and generally try to understand how the drives will behave in our application. Once we are comfortable with the drive’s performance, we start adding small amounts to production vaults, spread across tomes in a way that does not sacrifice parity. As drive capacities increase, we are putting more and more effort into this qualification process.
We used to be able to qualify new drive models in thirty days. Now we typically take several months. On one hand, this is because we’ve added more steps to pre- and post-production testing. As we scale up, we need to scale up our care, because the effect of any issues with drives increases in line with bigger and bigger implementations. Additionally, from a simple physics perspective, a vault that uses high capacity drives takes longer to fill and we want to monitor the new drive’s performance throughout the entire fill period.
Backblaze: When it comes to the evaluation of the cost, is there a formula for $/terabyte that you follow?
Ariel: My goal is to reduce cost per terabyte on a quarterly basis—in fact, it’s a part of how my job performance is evaluated. Ideally, I can achieve a 5-10% cost reduction per terabyte per quarter, which is a number based on historical price trends and our performance for the past 10 years. That savings is achieved in three primary ways: 1) lowering the actual cost of drives by negotiating with vendors, 2) occasionally moving to higher drive densities, and 3) increasing the slot density of pod chassis. (We moved from 45 drives to 60 drives in 2016, and as we look toward our next Storage Pod version we’ll consider adding more slots per chassis).
Meeting Storage Demand
Backblaze: When it comes to how this actually works in our operating environment, how do you stay ahead of the demand for storage capacity?
Ariel: We maintain several months of the drive space that we would need to meet capacity based on predicted demand from current customers as well as projected new customers. Those buffers are tied to what we expect will be the fill-time of our Vaults. As conditions change, we could decide to extend those buffers. Demand could increase unexpectedly, of course, so our goal is to reduce the fill-time for Vaults so we can bring more storage online as quickly as possible, if it’s needed.
Backblaze: Obviously we don’t operate in a vacuum, so do you worry about how trade challenges, weather, and other factors might affect your ability to obtain drives?
Ariel: (Laughs) Sure, I’ve got plenty to worry about. But we’ve proved to be pretty resourceful in the past when we’re challenged. For example: During the worldwide drive shortage, due to flooding in Southeast Asia, we recruited an army of family and friends to buy drives all over and send them to us. That kept us going during the shortage.
We are vulnerable, of course, if there’s a drive production shortage. Some data center hardware is manufactured in China, and I know that some of those prices have gone up. That said, all of our drives are manufactured in Thailand or Taiwan. Our Storage Pod chassis are made in the U.S.A. Big picture, we try to anticipate any shortages and plan accordingly if we can.
Backblaze: Time for a personal question… What does data durability mean to you? What do you do to help boost data durability, and spread drive hardware risk and exposure?
Ariel: That is personal. (Laughs). But also a good question, and not really personal at all: Everyone at Backblaze contributes to our data durability in different ways.
My role in maintaining eleven nines of durability is, first and foremost: Never running out of space. I achieve this by maintaining close relationships with manufacturers to ensure production supply isn’t interrupted; by improving our testing and qualification processes to catch problems before drives ever enter production; and finally by monitoring performance and replacing drives before they fail. Otherwise it’s just monitoring the company’s burn rates and managing the buffer between our drive capacity and our data under management.
When we are in a good state for space considerations, then I need to look to the future to ensure I’m providing for more long-term issues. This is where iterating on and improving our Storage Pod design comes in. I don’t think that gets factored into our durability calculus, but designing for the future is as important as anything else. We need to be prepared with hardware that can support ever-increasing hard drive capacities—and the fill- and rebuild times that come with those increases—effectively.
Backblaze: That begs the next question: As drive sizes get larger, rebuild times get longer when it’s necessary to recover data on a drive. Is that still a factor, given Backblaze’s durability architecture?
Ariel: We attempt to identify and replace problematic drives before they actually fail. When a drive starts failing, or is identified for replacement, the team always attempts to restore as much data as possible off of it because that ensures we have the most options for maintaining data durability. The rebuild times for larger drives are challenging, especially as we move to 16TB and beyond. We are looking to improve the throughput of our Pods before making the move to 20TB in order to maintain fast enough rebuild times.
And then, supporting all of this is our Vault architecture, which ensures that data will be intact even if individual drives fail. That’s the value of the architecture.
Longer term, one thing we’re looking toward is phasing out SATA controller/port multiplier combo. This might be more technical than some of our readers want to go, but: SAS controllers are a more commonly used method in dense storage servers. Using SATA drives with SAS controllers can provide as much as a 2x improvement in system throughput vs SATA, which is important to me, even though serial ATA (SATA) port multipliers are slightly less expensive. When we started our Storage Pod construction, using SATA controller/port multiplier combo was a great way to keep costs down. But since then, the cost for using SAS controllers and backplanes has come down significantly.
But now we’re preparing for how we’ll handle 18 and 20 TB drives, and improving system throughput will be extremely important to manage that density. We may even consider using SAS drives even though they are slightly more expensive. We need to consider all options in order to meet our scaling, durability and cost targets.
Backblaze’s Relationship with Drive Manufacturers
Backblaze: So, there’s an elephant in the room when it comes to Backblaze and hard drives: Our quarterly Hard Drive Stats reports. We’re the only company sharing that kind of data openly. How have the Drive Stats blog posts affected your purchasing relationship with the drive manufacturers?
Ariel: Due to the quantities we need and the visibility of the posts, drive manufacturers are motivated to give us their best possible product. We have a great purchasing relationship with all three companies and they update us on their plans and new drive models coming down the road.
Backblaze: Do you have any sense for what the hard drive manufacturers think of our Drive Stats blog posts?
Ariel: I know that every drive manufacturer reads our Drive Stats reports, including very senior management. I’ve heard stories of company management learning of the release of a new Drive Stats post and gathering together in a conference room to read it. I think that’s great.
Ultimately, we believe that Drive Stats is good for consumers. We wish more companies with large data centers did this. We believe it helps keep everyone open and honest. The adage is that competition is ultimately good for everyone, right?
It’s true that Western Digital, at one time, was put off by the visibility Drive Stats gave into how their models performed in our data centers (which we’ve always said is a lot different from how drives are used in homes and most businesses). Then they realized the marketing value for them—they get a lot of exposure in the blog posts—and they came around.
Backblaze: So, do you believe that the Drive Stats posts give Backblaze more influence with drive manufacturers?
Ariel: The truth is that most hard drives go directly into tier-one and -two data centers, and not into smaller data centers, homes, or businesses. The manufacturers are stamping out drives in exabyte chunks. A single tier-one data center consumes maybe 500,000 times what Backblaze does in drives. We can’t compare in purchasing power to those guys, but Drive Stats does give us visibility and some influence with the manufacturers. We have close communications with the manufacturers and we get early versions of new drives to evaluate and test. We’re on their radar and I believe they value their relationship with us, as we do with them.
Backblaze: A final question. In your opinion, are hard drives getting better?
Ariel: Yes. Drives are amazingly durable for how hard they’re used. Just think of the forces inside a hard drive, how hard they spin, and how much engineering it takes to write and read the data on the platters. I came from a background in precision optics, which requires incredibly precise tolerances, and was shocked to learn that hard drives are designed in an equally precise tolerance range, yet are made in the millions and sold as a commodity. Despite all that, they have only about a 2% annual failure rate in our centers. That’s pretty good, I think.
Thanks, Ariel. Here’s hoping the way we source petabytes of storage has been useful for your own terabyte, petabyte, or… exabyte storage needs? If you’re working on the latter, or anything between, we’d love to hear about what you’re up to in the comments.
In this blog series, we explore how you can master the nomadic life—whether for a long weekend, an extended working vacation, or maybe even the rest of your career. We profile professionals we’ve met who are stretching the boundaries of what (and where) an office can be, and glean lessons along the way to help you to follow in their footsteps. In our first post in the series, we provided practical tips for working on the road. In this edition, we profile Chris Aguilar, Amphibious Filmmaker.
There are people who do remote filming assignments, and then there’s Chris, the Producer/Director of Fin Films. For him, a normal day might begin with gathering all the equipment he’ll need—camera, lenses, gear, cases, batteries, digital storage—and securing it in a waterproof Pelican case which he’ll then strap to a paddleboard for a long swim to a race boat far out on the open ocean.
This is because Chris, a one-man team, is the preeminent cinematographer of professional paddleboard racing. When your work day involves operating from a beachside hotel, and being on location means bouncing up and down in a dinghy some 16 miles from shore, how do you succeed? We interviewed Chris to figure out.
Getting Ready for a Long Shoot
To save time in the field, Chris does as much prep work as he can. Knowing that he needs to be completely self-sufficient all day—he can’t connect to power or get additional equipment—he gathers and tests all of the cameras he’ll need for all the possible shots that might come up, packs enough SD camera cards, and grabs an SSD external drive large enough to store an entire day’s footage.
Chris edits in Adobe Premiere, so he preloads a template on his MacBook Pro to hold the day’s shots and orders everything by event so that he can drop his content in and start editing it down as quickly as possible. Typically, he chooses a compatible format that can hold all of the different content he’ll shoot. He builds a 4K timeline at 60 frames per second that can take clips from multiple cameras yet can export to other sizes and speeds as needed for delivery.
Days in the Life
Despite being in one of the most exotic and glamorous locations in the world (Hawaii), covering a 32-mile open-ocean race is grueling. Chris’s days start as early as 5AM with him grabbing shots as contestants gather, then filming as many as 35 interviews on race-day eve. He does quick edits of these to push content out as quickly as possible for avid fans all over the world.
The next morning, before race time, he double-checks all the equipment in his Pelican case, and, when there’s no dock, he swims out to the race- or camera boat. After that, Chris shoots as the race unfolds, constantly swapping out SD cards. When he’s back on dry land his first order of business is copying over all of the content to his external SSD drive.
Even after filming the race’s finish, awards ceremonies, and wrap-up interviews, he’s still not done: By 10PM he’s back at the hotel to cut a highlight reel of the day’s events and put together packages that sports press can use, including the Australian press that needs content for their morning sports shows.
For streaming content in the field, Chris relies on Google Fi through his phone because it can piggyback off of a diverse range of carriers. His backup network solution is a Verizon hotspot that usually covers him where Google Fi cannot. For editing and uploading, he’s found that he can usually rely on his hotel’s network. When that doesn’t work, he defaults to his hotspot, or a coffee shop. (His pro tip is that, for whatever reason, the Starbucks in Hawaii typically have great internet.)
Building a Case
After years of shooting open-ocean events, Chris has settled on a tried and true combination of gear—and it all fits in a single, waterproof Pelican 1510 case. His kit has evolved to be as simple and flexible as possible, allowing him to cover multiple shooting roles in a hostile environment including sand, extreme sun-glare on the water, haze, fog, and of course, the ever-present ocean water.
At the same time, his gear needs to accommodate widely varied shooting styles: Chris needs to be ready to capture up close and personal interviews; wide, dramatic shots of the pre-race ceremonies; as well as a combination of medium shots of several racers on the ocean and long, telephoto shots of individuals—all from a moving boat bobbing on the ocean. Here’s his “Waterproof Kit List”:
The Case Pelican 1510
Chris likes compact, rugged camcorders from Panasonic. They have extremely long battery life, and the latest generation have large sensor sizes, wide dynamic range and even built-in ND filter wheels to compensate for the glare on the water. He’ll also bring other cameras for special shots, like an 8mm film camera for artistic shots, or a GoPro for the classic ‘from under the sea to the waterline’ shots.
Primary Interview Camera
Panasonic EVA1 5.7K Compact Cinema Camcorder 4K 10b 4:2:2 with EF lens-mount (with rotating lens kit depending on the event)
Action Camera and B-Roll
Panasonic AG-CX350 (or EVA1 kitted out similarly if the CX350 isn’t available)
Stills and Video
Panasonic GH5 20.3MP and 4K 60fps 4:2:2 10-b Mirrorless ILC camera
Special Purpose and B-Roll Shots
Eumig Nautica Super 8 film self-sealed waterproof camera
4K GoPro in a waterproof dome housing
As a one-person show, Chris invests in enough SD cards for his cameras that can cover the entire day’s shooting without having to reuse cards. Chris will then copy all of those card’s content to a bus-powered SSD drive.
8-12 64GB or 128GB SD cards
1 TB SSD Glyph or G-Tech SSD drive
Multiple Neutral Density filters. These filters reduce the intensity of all wavelengths without affecting color. With ND filters the operator can dial in combinations of aperture, exposure time and sensor sensitivity without being overexposed, and delivers more ‘filmic’ looks, setting the aperture to a low value for sharper images, or wide open for a shallow depth-of-field
Extra batteries. Needless to say having extra batteries for his cameras and his phone is critical when he may not be able to recharge for 12 hours or more.
Now, The Real Work Begins
When wrapping up an event’s coverage, all of the content captured needs to be stored and managed. Chris’s previous workflow required transferring the raw and finished files to external drives for storage. That added up to a lot of drives. Chris estimates that over the years he had stored about 20 terabytes of footage on paddleboarding alone.
Managing all those drives proved to be too big of a task for someone who is rarely in his production office. Chris needed access to his files from wherever he was, and a way to view, catalog, and share the content with collaborators.
As he got his approach dialed to accommodate remote broadband speed, storage drive wrangling, inexpensive cloud storage, and cloud-based digital asset management systems, putting all his content into the cloud became an option for Chris. Using Backblaze’s B2 Cloud Storage along with iconik content management software, what used to take several days in the office searching through hard drives for specific footage to edit or share with a collaborator now involves just a few keyword searches and a matter of minutes to share via iconik.
For a digital media nomad like Chris, digitally native solutions based in the cloud make a lot of sense. Plus, Chris knows that the content is safely and securely stored, and not exposed to transport challenges, accidents (including those involving water), and other difficulties that could spoil both his day and that of his clients.
Learn More About How Chris Works Remotely
You can learn more about Chris, Fin Film Company, and how he works from the road in our case study on Fin Films. We’ve also linked to Chris’s Kit Page for those of you who just can’t get enough of this gear…
We’d Love to Hear Your Digital Nomad Stories
If you consider yourself a digital nomad and have an interesting story about using Backblaze Cloud Backup or B2 Cloud Storage from the road (or wherever), we’d love to hear about it, and perhaps feature your story on the blog. Tell us what you’ve been doing on the road at email@example.com.
You can view all the posts in this series on the Digital Nomads page in our Blog Archives.
Everything that makes working at a creative agency exciting also makes it challenging. With each new client, creative teams are working on something different. One day they’re on site, shooting a video for a local business, the next they’re sifting through last year’s concert footage for highlights to promote this year’s event. When their juices are flowing, it’s as easy for them to lose track of the files they need as it is for them to lose track of time.
If you’re tasked with making sure a team’s content is protected every day, as well as ensuring that it’s organized and saved for the future, we have some tips to make your job easier. Because we know you’d rather be working on your own projects, not babysitting backups or fetching years-old content from a dusty archive closet.
Since we’re sure you’re not making obvious mistakes—like expecting creatives to manually archive their own content, or not having a 3-2-1 backup strategy—we’ll focus on the not-so-obvious tips. Many of these come straight from our own creative agency customers who learned the hard way, before they rolled out a cloud-based backup and archive solution.
Tip #1—Save everything when a client’s project is completed
For successful creative agencies, there’s no such thing as “former” clients, only clients that you haven’t worked with lately. That means your job managing client data isn’t over when the project is delivered. You need to properly archive everything: not just the finished videos, images or layouts, but all the individual assets created for the project and all the raw footage.
It’s not unusual for clients to request raw footage, even years after the project is complete. If you only saved master copies and can’t send them all of their source footage, your client may question how you manage their content, which could impact their trust in you for future projects.
The good news is that if you have an organized, accessible content archive, it’s easy to send a drive or even a download link to a client. It may even be possible for you to charge clients to retrieve and deliver their content to them.
Tip #2—Stop using external drives for backup or archive
If your agency uses external disk drives to back up or archive your projects, you’re not alone. Creative teams do it because it’s dead simple: you plug the drive in, copy project files to it, unplug the drive, and put it on a shelf or in a drawer. But there are some big problems with this.
First, since external drives are removable, they’re easily misplaced. It’s not unusual for someone to take a drive offsite to work on a project and forget to return it. Second, removable drives can fail over time after being damaged by physical impacts, water, magnetic fields, or even “bit rot” from just sitting on a shelf. Finally, locating client files in a stack of drives can be like finding a needle in a haystack, especially if the editor who worked on the project has left the agency.
Tip #3—Organize your archive for self-service access
Oh, the frustration of knowing you already have a clip that would be perfect for a new project, but… who knows where it is? With the right tools in place, a producer’s frustration doesn’t mean you’ll have to drop everything and join their search party. Even if you’re not sure you need a full-featured MAM, your time would be well-spent to find a solution that allows creatives to search and retrieve files from the archive on their own.
Look for software that lets them browse through thumbnails and proxies instead of file names, and allows them to search based on metadata. Your archive storage shouldn’t force you to be on site and instantly available to load LTO tapes and retrieve those clips the editor absolutely and positively has to have today.
Tip #4—Schedule regular tests for backup restores and archive retrievals
When you first set up your backup system, I’m sure you checked that the backups were firing off on schedule, and tested restoring files and folders. But have you done it lately? Since the last time you checked, any number of things could have changed that would break your backups.
Maybe you added another file share that wasn’t included in the initial set up. Perhaps your backup storage has reached capacity. Maybe an operating system upgrade on a workstation is incompatible with your backup software. Perhaps the automated bill payment for a backup vendor failed. Bad things can happen when you’re not looking, so it’s smart to schedule time at least once a month to test your backups and restores. Ditto for testing your archives.
Tip #5 – Plan for long-term archive media refresh
If your agency has been in business more than a handful of years, you probably have content stored on media that’s past its expiration date. (Raise your hand if you still have client content stored on Betacam.) Drive failures increase significantly after 4 years (see our data center’s latest hard drive stats), and tape starts to degrade around 15 years. Even if the media is intact, file formats and other technologies can become obsolete quicker than you can say LTO-8. The only way to ensure access to archived content is to migrate it to newer media and/or technologies. This unglamorous task sounds simple—reading the data off the old media and copying it to new media—but the devil is in the details.
Of course, if you backup or archive to Backblaze B2 cloud storage, we’ll migrate your data to newer disk drives for you as needed over time. It all happens behind the scenes so you don’t ever need to think about it. And it’s included free with our service.
Want to see how all these tips works together? Join our live webinar co-hosted with Archiware on Tuesday, December 10, and we’ll show you how Baron & Baron, the agency behind the world’s top luxury brands from Armani to Zara, solved their backup and archive challenges.
As of September 30, 2019, Backblaze had 115,151 spinning hard drives spread across four data centers on two continents. Of that number, there were 2,098 boot drives and 113,053 data drives. We’ll look at the lifetime hard drive failure rates of the data drive models currently in operation in our data centers, but first we’ll cover the events that occurred in Q3 that potentially affected the drive stats for that period. As always, we’ll publish the data we use in these reports on our Hard Drive Test Data web page and we look forward to your comments.
Hard Drive Stats for Q3 2019
At this point in prior hard drive stats reports we would reveal the quarterly hard drive stats table. This time we are only going to present the Lifetime Hard Drive Failure table, which you can see if you jump to the end of this report. For the Q3 table, the data which we typically use to create that report may have been indirectly affected by one of our utility programs which performs data integrity checks. While we don’t believe the long-term data is impacted, we felt you should know. Below, we will dig into the particulars in an attempt to explain what happened in Q3 and what we think it all means.
What is a Drive Failure?
Over the years we have stated that a drive failure occurs when a drive stops spinning, won’t stay as a member of a RAID array, or demonstrates continuous degradation over time as informed by SMART stats and other system checks. For example, a drive that reports a rapidly increasing or egregious number of media read errors is a candidate for being replaced as a failed drive. These types of errors are usually seen in the SMART stats we record as non-zero values for SMART 197 and 198 which log the discovery and correctability of bad disk sectors, typically due to media errors. We monitor other SMART stats as well, but these two are the most relevant to this discussion.
What might not be obvious is that changes in some SMART attributes only occur when specific actions occur. Using SMART 197 and 198 as examples again, these values are only affected when a read or write operation occurs on a disk sector whose media is damaged or otherwise won’t allow the operation. In short, SMART stats 197 and 198 that have a value of zero today will not change unless a bad sector is encountered during normal disk operations. These two SMART stats don’t cause read and writes to occur, they only log aberrant behavior from those operations.
Protecting Stored Data
When a file, or group of files, arrives at a Backblaze data center, the file is divided into pieces we call shards. For more information on how shards are created and used in the Backblaze architecture, please refer to Backblaze Vault and Backblaze Erasure Coding blog posts. For simplicity’s sake, let’s say a shard is a blob of data that resides on a disk in our system.
As each shard is stored on a hard drive, we create and store a one-way hash of the contents. For reasons ranging from media damage to bit rot to gamma rays, we check the integrity of these shards regularly by recomputing the hash and comparing it to the stored value. To recompute the shard hash value, a utility known as a shard integrity check reads the data in the shard. If there is an inconsistency between the newly computed and the stored hash values, we rebuild the shard using the other shards as described in the Backblaze Vault blog post.
Shard Integrity Checks
The shard integrity check utility runs as a utility task on each Storage Pod. In late June, we decided to increase the rate of the shard integrity checks across the data farm to cause the checks to run as often as possible on a given drive while still maintaining the drive’s performance. We increased the frequency of the shard integrity checks to account for the growing number of larger-capacity drives that had been deployed recently.
The Consequences for Drive Stats
Once we write data to a disk, that section of disk remains untouched until the data is read by the user, the data is read by the shard integrity check process to recompute the hash, or the data is deleted and written over. As a consequence, there are no updates regarding that section of disk sent to SMART stats until one of those three actions occur. By speeding up the frequency of the shard integrity checks on a disk, the disk is read more often. Errors discovered during the read operation of the shard integrity check utility are captured by the appropriate SMART attributes. Putting together the pieces, a problem that would have been discovered in the future—under our previous shard integrity check cadence—would now be captured by the SMART stats when the process reads that section of disk today.
By increasing the shard integrity check rate, we potentially moved failures that were going to be found in the future into Q3. While discovering potential problems earlier is a good thing, it is possible that the hard drive failures recorded in Q3 could then be artificially high as future failures were dragged forward into the quarter. Given that our Annualized Failure Rate calculation is based on Drive Days and Drive Failures, potentially moving up some number of failures into Q3 could cause an artificial spike in the Q3 Annualized Failure Rates. This is what we will be monitoring over the coming quarters.
There are a couple of things to note as we consider the effect of the accelerated shard integrity checks on the Q3 data for Drive Stats:
The number of drive failures over the lifetime of a given drive model should not increase. At best we just moved the failures around a bit.
It is possible that the shard integrity checks did nothing to increase the number of drive failures that occurred in Q3. The quarterly failure rates didn’t vary wildly from previous quarters, but we didn’t feel comfortable publishing them at this time given the discussion above.
Lifetime Hard Drive Stats through Q3 2019
Below are the lifetime failure rates for all of our drive models in service as of September 30, 2019.
The lifetime failure rate for the drive models in production rose slightly, from 1.70% at the end of Q2 to 1.73% at the end of Q3. This trivial increase would seem to indicate that the effect of the potential Q3 data issue noted above is minimal and well within a normal variation. However, we’re not satisfied that is true yet and we have a plan for making sure as we’ll see in the next section.
What’s Next for Drive Stats?
We will continue to publish our Hard Drive Stats each quarter, and next quarter we expect to include the quarterly (Q4) chart as well. For the foreseeable future, we will have a little extra work to do internally as we will be tracking two different groups of drives. One group will be the drives that “went through the wormhole,” so to speak, as they were present during the accelerated shard integrity checks. The other group will be those drives that were placed into production after the shard integrity check setting was reduced. We’ll compare these two datasets to see if there was indeed any effect of the increased shard integrity checks on the Q3 hard drive failure rates. We’ll let you know what we find in subsequent drive stats reports.
The Hard Drive Stats Data
The complete data set used to create the information used in this review is available on our Hard Drive Test Data web page. You can download and use this data for free for your own purpose. All we ask are three things: 1) You cite Backblaze as the source if you use the data, 2) You accept that you are solely responsible for how you use the data, and, 3) You do not sell this data to anyone; it is free. Good luck and let us know what you find.
As always, we look forward to your thoughts and questions in the comments.
Editor’s Note: Since 2013, Backblaze has published statistics and insights based on the hard drives in our data centers. Why? Well, we like to be helpful, and we thought sharing would help others who rely on hard drives but don’t have reliable data on performance to make informed purchasing decisions. We also hoped the data might aid manufacturers in improving their products. Given the millions of people who’ve read our Hard Drive Stats posts and the increasingly collaborative relationships we have with manufacturers, it seems we might have been right.
But we don’t only share our take on the numbers, we also provide the raw data underlying our reports so that anyone who wants to can reproduce them or draw their own conclusions, and many have. We love it when people reframe our reports, question our logic (maybe even our sanity?), and provide their own take on what we should do next. That’s why we’re featuring Ryan Smith today.
Ryan has held a lot of different roles in tech, but lately he’s been dwelling in the world of storage as a product strategist for Hitachi. On a personal level, he explains that he has, “passion for data, finding insights from data, and helping others see how easy and rewarding it can be to look under the covers.” It shows.
A few months ago we happened on a post by Ryan with an appealing header featuring our logo with an EXPOSED stamp superimposed in red over our humble name. It looked like we had been caught in a sting operation. As a company that loves transparency, we were delighted. Reading on we found a lot to love and plenty to argue over, but more than anything, we appreciated how Ryan took data we use to analyze hard drive failure rates and extrapolated out all sorts of other gleanings about our business. As he puts it, “it’s not the value at the surface but the story that can be told by tying data together.” So, we thought we’d share his original post with you to (hopefully) incite some more arguments and some more tying together of data.
While we think his conclusions are reasonable based on the data available to him, the views and analysis below are entirely Ryan’s. We appreciate how he flagged some areas of uncertainty, but thought it most interesting to share his thoughts without rebuttal. If you’re curious about how he reached them, you can find his notes on process here. He doesn’t have the full story, but we think he did amazing work with the public data.
Our 2019 Q3 Hard Drive Stats post will be out in a few weeks, and we hope some of you will take Ryan’s lead and do your own deep dive into the reporting when it’s public. For those of you who can’t wait, we’re hoping this will tide you over for a little while.
If you’re interested in taking a look at the data yourselves, here’s our Hard Drive Data and Stats webpage that has links to all our past Hard Drive Stats posts and zip files of the raw data.
Ryan Smith Uses Backblaze’s SMART Stats to Illustrate the Power of Data
It is now common practice for end-customers to share telemetry (call home) data with their vendors. My analysis below shares some insights about your business that vendors might gain from seemingly innocent data that you are sending them every day.
On a daily basis, Backblaze (a cloud backup and storage provider) logs all its drive health data (aka SMART data) for over 100,000 of its hard drives. With 100K+ records a day, each year can produce over 30 million records. They share this raw data on their website, but most people probably don’t really dig into it much. I decided to see what this data could tell me and what I found was fascinating.
Rather than looking at nearly 100 million records, I decided to only look at just over one million which consisted of the last day of every quarter from Q1’16 to Q1’19. This would give me enough granularity to see what is happening inside Backblaze’s cloud backup storage business. For those interested, I used MySQL to import and transform the data into something easy to work with (see more details on my SQL query); I then imported the data into Excel where I could easily pivot the data and look for insights. Below are the results of this effort.
User Data vs Physical Capacity
I grabbed the publicly posted “Petabytes stored” that BackBlaze claims on their website (“User Petabytes”) and compared that to the total capacity from the SMART data they log (“Physical Petabytes”) and then compared them against each other to see how much overhead or unused capacity they have. The Theoretical Max (green line) is based on their ECC protection scheme (13+2 and/or 17+3) that they use to protect user data. If the “% User Petabytes” is below that max then this means Backblaze either has unused capacity or they didn’t update their website with the actual data stored.
Data Read/Written vs Capacity Growth
Looking at the last two years, by quarter, you can see a healthy amount of year-over-year growth in their write workload; roughly 80% over the last four quarters! This is good since writes likely correlate with new user data, which means broader adoption of their offering. For some reason their read workloads spiked in Q2’17 and have maintained a higher read workload since then (as indicated by the YoY spikes from Q2’17 to Q1’18, and then settling back to less than 50% YoY since); my guess is this was likely driven by a change to their internal workload rather than a migration because I didn’t see subsequent negative YoY reads.
Now let’s look at some performance insights. A quick note: Only Seagate hard drives track the needed information in their SMART data in order to get insights about performance. Fortunately, roughly 80% of Backblaze’s drive population (both capacity and units) are Seagate so it’s a large enough population to represent the overall drive population. Going forward, it does look like the new 12 TB WD HGST drive is starting to track bytes read/written.
Pod (Storage Enclosure) Performance
Looking at Power-on-hours of each drive, I was able to calculate the vintage of each drive and the number of drives in each “pod” (this is the terminology that Backblaze gives to its storage enclosures). This lets me calculate the number of pods that Backblaze has in its data centers. Their original pods stored 45 drives and this improved to 60 drives in ~Q2’16 (according to past blog posts by Backblaze). The power-on-date allowed me to place the drive into the appropriate enclosure type and provide you with pod statistics like the Mbps per pod. This is definitely an educated guess as some newer vintage drives are replacement drives into older enclosures but the overall percentage of drives that fail is low enough to where these figures should be pretty accurate.
Overall, Backblaze’s data centers are handling over 100 GB/s of throughput across all their pods which is quite an impressive figure. This number keeps climbing and is a result of new pods as well as overall higher performance per pod. From quick research, this is across three different data centers (Sacramento x 2, Phoenix x 1) and maybe a fourth on its way in Europe.
Hard Drive Performance
Since each pod holds between 45 and 60 drives, with an overall max pod performance of 1 Gbps, I wasn’t surprised to see such average low drive performance. You can see that Backblaze’s workload is read heavy with less than 1 MB/s and writes only a third of that. Just to put that in perspective, these drives can deliver over 100 MB/s, so Backblaze is not pushing the limits of these hard drives.
As discussed earlier, you can also see how the read workload changed significantly in Q2’17 and has not reverted back since.
As I expected, the read and write performance is highly correlated to the drive capacity point. So, it appears that most of the growth in read/write performance per drive is really driven by the adoption of higher density drives. This is very typical of public storage-as-a-service (STaaS) offerings where it’s really about $/GB, IOPS/GB, MBs/GB, etc.
As a side note, the black dashed lines (average between all densities) should correlate with the previous chart showing overall read/write performance per drive.
Switching gears, let’s look at Backblaze’s purchasing history. This will help suppliers look at trends within Backblaze to predict future purchasing activities. I used power-on-hours to calculate when a drive entered the drive population.
Hard Drives Purchased by Density, by Year
This chart helps you see how Backblaze normalized on 4 TB, 8 TB, and now 12 TB densities. The number of drives that Backblaze purchases every year has been climbing until 2018 where it saw its first decline in units. However, this is mainly due to the efficiencies of the capacity per drive.
A question to ponder: Did 2018 reach a point where capacity growth per HDD surpassed the actual demand required to maintain unit growth of HDDs? Or is this trend limited to Backblaze?
Petabytes Purchased by Quarter
This looks at the number of drives purchased over the last five years, along with the amount of capacity added. It’s not quite regular enough to spot a trend, but you can quickly spot that the amount of capacity purchased over the last two years has grown dramatically compared to previous years.
HDD Vendor Market Share
Western Digital/WDC, Toshiba/TOSYY, Seagate/STX
Seagate is definitely the preferred vendor, capturing almost 100% of the market share save for a few quarters where WD HGST wins 50% of the business. This information could be used by Seagate or its competitors to understand where it stands within the account for future bids. However, the industry is monopolistic so it’s not hard to guess who won the business if a given HDD vendor didn’t.
Drive Population by Quarter
This shows the total drive population over the past three years. Even though the number of drives being purchased has been falling lately, the overall drive population is still growing.
You can quickly see that 4 TB drives saw its peak population in Q1’17 and has rapidly declined. In fact, let’s look at the same data but with a different type of chart.
That’s better. We can see that 12 TBs really had a dramatic effect on both 4 TB and 8 TB adoption. In fact, Backblaze has been proactively retiring 4 TB drives. This is likely due to the desire to slow the growth of their data center footprint which comes with costs (more on this later).
As a drive vendor, I could use this data to use the 4 TB trend to calculate how much drive replacement will be occurring next quarter, along with natural PB growth. I will look more into Backblaze’s drive/pod retirement later.
Current Drive Population, by Deployed Date
Be careful when interpreting this graph. What we are looking at here is the Q1’19 drive population where the date on the x-axis is the date the drive entered the population. This helps you see of all the drives in Backblaze’s population today, in which the oldest drives are from 2015 (with the exception of a few stragglers).
This indicates that the useful life of drives within Backblaze’s data centers are ~4 years. In fact, a later chart will look at how drives/pods are phased out, by year.
Along the top of the chart, I noted when the 60-drive pods started entering into the mix. The rack density is much more efficient with this design (rather than the 45-drive pod). Combine this, along with the 4 TB to 12 TB efficiency, Backblaze has aggressively been retiring its 4 TB/45-drive enclosures. There is still a large population of these remaining so expect some further migration to occur.
Boot Drive Population
This is the overall boot drive population over time. You can see that it is currently dominated by the 500 GB with only a few remaining smaller densities in the population today. For some reason, Toshiba has been the preferred vendor with Seagate only recently gaining some new business.
The boot drive population is also an interesting data point to use for verifying the number of pods in the population. For example, there were 1,909 boot drives in Q1’19 and my calculation of pods based on the 45/60-drive pod mix was 1,905. I was able to use the total boot drives each quarter to double check my mix of pods.
Pods (Drive Enclosures)
As discussed earlier, pods are the drive enclosures that house all of Backblaze’s hard drives. Let’s take a look at a few more trends that show what’s going on within the walls of their data center.
Pods Population by Deployment Date
This one is interesting. Each line in the graph indicates a particular snapshot in time of the total population. And the x-axis represents the vintage of the pods for that snapshot. By comparing snapshots, this allows you to see changes over time to the population. Namely, new pods being deployed and old pods being retired. To capture this, I looked at the last day of Q1 data for the last four years and calculated the date the drives entered the population. Using the “Power On Date” I was able to deduce the type of pod (45 or 60 drive) it was deployed in.
Some insights from this chart:
From Q2’16 to Q1’17, they retired some pods from 2010-11
From Q2’17 to Q1’18, they retired a significant number of pods from 2011-14
From Q2’18 to Q1’19, they retired pods from 2013-2015
Pods that were deployed since late 2015 have been untouched (you can tell this by seeing the lines overlap with each other)
The most pods deployed in a quarter was 185 in Q2’16
Since Q2’16, the number of pods deployed has been declining, on average; this is due to the increase in # of drives per pod and density of each drive
There are still a significant number of 45-drive pods to retire
Totaling up all the new pods being deployed and retired, it is easier to see the yearly changes happening within Backblaze’s operation. Keep in mind that these are all calculations and may erroneously include drive replacements as new pods; but I don’t expect it to vary significantly from what is shown here.
The data shows that any new pods that have been deployed in the past few years have mainly been driven by replacing older, less dense pods. In fact, the pod population has plateaued at around 1,900 pods.
Based on blog posts, Backblaze’s pods are all designed at 4U (4 rack units) and pictures on their site indicate 10 pods fit in a rack; this equates to 40U racks. Using this information, along with the drive population and the power-on-date, I was able to calculate the number of pods on any given date as well as the total number of racks. I did not include their networking racks in which I believe they have two of these racks per row in their data center.
You can quickly see that Backblaze has done a great job at slowing the growth of the racks in their data center. This all results in lower costs for their customers.
What interested me when looking at Backblaze’s SMART data was the fact that drives were being retired more than they were failing. This means the cost of failures is fairly insignificant in the scheme of things. It is actually efficiencies driven by technology improvements such as drive and enclosure densities that drove most of the costs. However, the benefits must outweigh the costs. Being that Backblaze uses Sungard AS for its data centers, let’s try to visualize the benefit of retiring drives/pods.
Colocation Costs, Assuming a Given Density
This shows the total capacity over time in Backblaze’s data centers, along with the colocation costs assuming all the drives were a given density. As you can see, in Q1’19 it would take $7.7M a year to pay for colocating costs of 861 PB if all the drives were 4 TB in size. By moving the entire population to 12 TB this can be reduced to $2.6M. So, just changing the drive density can have significant impacts on Backblaze’s operational costs. I did assume $45/RU costs in the analysis which their costs may be as low as $15/RU based on the scale of their operation.
I threw in 32 TB densities to illustrate a hypothetical SSD-type density so you can see the colocation cost savings by moving to SSDs. Although lower, the acquisition costs are far too high at the moment to justify a move to SSDs.
Break-Even Analysis of Retiring Pods
This chart helps illustrate the math behind deciding to retire older drives/pods based on the break-even point.
Let’s break down how to read this chart:
This chart is looking at whether Backblaze should replace older drives with the newer 12 TB drives
Assuming a cost of $0.02/GB for a 12 TB drive, that is a $20/TB acquisition cost you see on the far left
Each line represents the cumulative cost over time (acquisition + operational costs)
The grey lines (4 TB and 8 TB) all assume they were already acquired so they only represent operational costs ($0 acquisition cost) since we are deciding on replacement costs
The operational costs (incremental yearly increase shown) is calculated off of the $45 per RU colocation cost and how many of this drive/enclosure density fits per rack unit. The more TBs you can cram into a rack unit, the lower your colocation costs are
Assuming you are still with me, this shows that the break-even point for retiring 4 TB 4U45 pods is just over two years! And 4 TB 4U60 pods at 3 years! It’s a no brainer to kill the 4 TB enclosures and replace them with 12 TB drives. Remember that this assumes a $45RU colocation cost so the break-even point will shift to the right if the colocation costs are lower (which they surely are). You can see that the math to replace 8 TB drives with 12 TB doesn’t make as much sense so we may see Backblaze’s retirement strategy slow down dramatically after it retires the 4 TB capacity points.
As hard drive densities get larger and $/GB decreases, I expect the cumulative costs to start lower (less acquisition cost) and rise slower (less RU operational costs) making future drive retirements more attractive. Eyeballing it, it would be once $/GB approaches $0.01/GB to $0.015/GB.
Things Backblaze Should Look Into
Top of mind, Backblaze should look into these areas:
The architecture around performance is not balanced; investigate having a caching tier to handle bursts and put more drives behind each storage node to reduce “enclosure/slot tax” costs.
Look into designs like 5U84 from Seagate/Xyratex providing 16.8 drives per RU versus the 15 being achieved on Backblaze’s own 4U60 design; Another 12% efficiency!
5U allows for 8 pods to fit per rack versus the 10.
Look at when SSDs will be attractive to replace HDDs at a given $/GB, density, idle costs, # of drives that fit per RU (using 2.5” drives instead of 3.5”) so that they can stay on top of this trend [there is no rush on this one].
Performance and endurance of SSDs is irrelevant since the performance requirements are so low and the WPD is almost non-existence, making QLC and beyond a great candidate.
Look at allowing pods to be more flexible in handling different capacity drives to handle drive failures more cost efficiently without having to retire pods. Having concepts of “virtual pods” that don’t have physical limits will better accommodate the future that Backblaze has where it won’t be retiring pods as aggressively, yet still let them grow their pod densities seamlessly.
It is kind of ironic that the reason Backblaze posted all their SMART data is to share insights around failures when I didn’t even analyze failures once! There is much more analysis that could be done around this data set which I may revisit as time permits.
As you can see, even simple health data from drives, along with a little help from other data sources, can help expose a lot more than you would initially think. I have long felt that people have yet to understand the full power of giving data freely to businesses (e.g. Facebook, Google Maps, LinkedIn, Mint, Personal Capital, News Feeds, Amazon). I often hear things like, “I have nothing to hide,” which indicates the lack of value they assign to their data. It’s not the value at its surface but the story that can be told by tying data together.
Until next time, Ryan Smith.
• • •
Ryan Smith is currently a product strategist at Hitachi Vantara. Previously, he served as the director of NAND product marketing at Samsung Semiconductor, Inc. He is extremely passionate about uncovering insights from just about any data set. He just likes to have fun by making a notable difference, influencing others, and working with smart people.
Backblaze likes to talk about hard drive failures — a lot. What we haven’t talked much about is how we deal with those failures: the daily dance of temp drives, replacement drives, and all the clones that it takes to keep over 100,000 drives healthy. Let’s go behind the scenes and take a look at that dance from the eyes of one Backblaze hard drive.
After sitting still for what seemed like forever, ZCH007BZ was on the move. ZCH007BZ, let’s call him Zach, is a Seagate 12 TB hard drive. For the last few weeks, Zach and over 6,000 friends were securely sealed inside their protective cases in the ready storage area of a Backblaze data center. Being a hard disk drive, Zach’s modest dream was to be installed in a system, spin merrily, and store data for many years to come. And now the wait was nearly over, or was it?
The Life of Zach
Zach was born in a factory in Singapore and shipped to the US, eventually finding his way to Backblaze, but he didn’t know that. He had sat sealed in the dark for weeks. Now Zach and boxes of other drives were removed from their protective cases and gently stacked on a cart. Zack was near the bottom of the pile, but even he could see endless columns of beautiful red boxes stacked seemingly to the sky. “Backblaze!” one of the drives on the cart whispered. All the other drives gasped with recognition. Thank goodness the noise-cancelling headphones worn by all Backblaze Data Center Techs covered the drives’ collective excitement.
While sitting in the dark, the drives had gossiped about where they were: a data center, a distribution warehouse, a Costco, or Best Buy. Backblaze came up a few times, but that was squashed — they couldn’t be that lucky. After all, Backblaze was the only place where a drive could be famous. Before Backblaze, hard drives labored in anonymity. Occasionally, one or two would be seen in a hard drive tear down article, but even that sort of exposure had died out a couple of years ago. But Backblaze publishes everything about their drives, their model numbers, their serial numbers, heck even their S.M.A.R.T. statistics. There was a rumor that hard drives worked extra hard at Backblaze because they knew they would be in the public eye. With red Backblaze Storage Pods as far as the eye could see, Zach and friends were about to find out.
The cart Zach and his friends were on glided to a stop at the production build facility. This is where storage pods are filled with drives and tested before being deployed. The cart stopped by the first of twenty V6.0 Backblaze Storage Pods that together would form a Backblaze Vault. At each Storage Pod station 60 drives were unloaded from the cart. The serial number of each drive was recorded along with the Storage Pod ID and drive location in the pod. Finally, each drive was fitted with a pair of drive guides and slid into its new home as a production drive in a Backblaze Storage Pod. “Spin long and prosper,” Zach said quietly each time the lid of a Storage Pod snapped in place covering the 60 giddy hard drives inside. The process was repeated for the remaining 19 Storage Pods, and when it was done Zach remained on the cart. He would not be installed in a production system today.
The Clone Room
Zach and the remaining drives on the cart were slowly wheeled down the hall. Bewildered, they were rolled in the clone room. “What’s a clone room,” Zach asked to himself? The drives on the cart were divided into two groups, with one group being placed on the clone table, and the other being placed on the test table. Zach was on the test table.
Almost as soon as Zach was placed on the test table, the DC Tech picked him up again and placed him and several other drives into a machine. He was about to get formatted. The entire formatting process only took a few minutes for Zach, as it did for all of the other drives on the test table. Zach counted 25 drives, including himself.
Still confused and a little sore from the formatting, Zach and two other drives were picked up from the bench by a different DC Tech. She recorded their vitals — serial number, manufacturer, and model — and left the clone room with all three drives on a different cart.
Dreams of a Test Drive
The three drives were back on the data center floor with red Storage Pods all around. The DC Tech had maneuvered Luigi, the local Storage Pod lift unit, to hold a Storage Pod she was sliding from a data center rack. The lid was opened, the tech attached a grounding clip, and then removed one of the drives in the Storage Pod. She recorded the vitals of the removed drive. While she was doing so, Zach could hear the removed drive breathlessly mumble something about media errors, but before Zach could respond, the tech picked him up, attached drive guides to his frame and gently slide him into the Storage Pod. The tech updated her records, closed the lid, and slide the pod back into place. A few seconds later, Zach felt a jolt of electricity pass through his circuits and he and 59 other drives spun to life. Zach was now part of a production Backblaze Storage Pod.
First, Zach was introduced to the other 19 members of his tome. There are 20 drives in a tome, with each living in a separate Storage Pod. Files are divided (sharded) across these 20 drives using Backblaze’s open-sourced erasure code algorithm.
Zach’s first task was to rebuild all of the files that were stored on the drive he replaced. He’d do this by asking for pieces (shards) of all the files from the 19 other drives in his tome. He only needed 17 of the pieces to rebuild a file, but he asked everyone in case there was a problem. Rebuilding was hard work, and the other drives were often busy with reading files, performing shard integrity checks, and so on. Depending on how busy the system was, and how full the drives were, it might take Zach a couple of weeks to rebuild the files and get him up to speed with his contemporaries.
Nightmares of a Test Drive
Little did he know, but at this point, Zach was still considered a temp replacement drive. The dysfunctional drive that he replaced was making its way back to the clone room where a pair of cloning units, named Harold and Maude in this case, waited. The tech would attempt to clone the contents of the failed drive to a new drive assigned to the clone table. The primary reason for trying to clone a failed drive was recovery speed. A drive can be cloned in a couple of days, but as noted above, it can take up to a couple of weeks to rebuild a drive, especially large drives on busy systems. In short, a successful clone would speed up the recovery process.
For nearly two days straight, Zach was rebuilding. He barely had time to meet his pod neighbors, Cheryl and Carlos. Since they were not rebuilding, they had plenty of time to marvel at how hard Zach was working. He was 25 % done and going strong when the Storage Pod powered down. Moments later, the pod was slid out of the rack and the lid popped open. Zach assumed that another drive in the pod had failed, when he felt the spindly, cold fingers of the tech grab him and yank firmly. He was being replaced.
Zach had done nothing wrong. It was just that the clone was successful, with nearly all the files being copied from the previous drive to the smiling clone drive that was putting on Zach’s drive guides and gently being inserted in Zach’s old slot. “Goodbye,” he managed to eek out as he was placed on the cart and watched the tech bring the Storage Pod back to life. Confused, angry, and mostly exhausted, Zach quickly fell asleep.
Zach woke up just in time to see he was in the formatting machine again. The data he had worked so hard to rebuild was being ripped from his platters and replaced randomly with ones and zeroes. This happened multiple times and just as Zach was ready to scream, it stopped, and he was removed from his torture and stacked neatly with a few other drives.
After a while he looked around, and once the lights went out the stories started. Zach wasn’t alone. Several of the other temp drives had pretty much the same story; they thought they had found a home, only to be replaced by some uppity clone drive. One of the temp drives, Lin, said she had been in three different systems only to be replaced each time by a clone drive. No one wanted to believe her, but no one knew what was next either.
The Day the Clone Died
Zach found out the truth a few days later when he was selected, inspected, and injected as a temp drive into another Storage Pod. Then three days later he was removed, wiped, reformatted, and placed back in the temp pool. He began to resign himself to life as a temp drive. Not exactly glamorous, but he did get his serial number in the Backblaze Drive Stats data tables while he was a temp. That was more than the millions of other drives in the world that would forever be unknown.
On his third temp drive stint, he was barely in the pod a day when the lid opened and he was unceremoniously removed. This was the life of temp drive, and when the lid opened on the fourth day of his fourth temp drive shift, he just closed his eyes and waited for his dream to end again. Except, this time, the tech’s hand reached past him and grabbed a drive a few slots away. That unfortunate drive had passed the night before, a full-fledged crash. Zach, like all the other drives nearby, had heard the screams.
Another temp drive Zach knew from the temp table replaced the dead drive, then the lid was closed, the pod slid back into place, and power was restored. With that Zach, doubled down on getting rebuilt — maybe if he could get done before the clone was finished then he could stay. What Zach didn’t know was that the clone process for the drive he had replaced had failed. This happens about half the time. Zach was home free; he just didn’t know it.
In a couple of days, Zach was finished rebuilding and become a real member of a production Backblaze Storage Pod. He now spends his days storing and retrieving data, getting his bits tested by shard integrity checks, and having his S.M.A.R.T. stats logged for the Backblaze Drive Stats. His hard drive life is better than he ever dreamed.
The only problem: both hosted storage (through existing cloud services) and purchased hardware (buying servers from Dell or Microsoft) were too expensive to hit this price point. Enter Tim Nufire, aka: The Podfather.
Tim led the effort to build what we at Backblaze call the Storage Pod: The physical hardware our company has relied on for data storage for more than a decade. On the occasion of the decade anniversary of the open sourcing of our Storage Pod 1.0 design, we sat down with Tim to relive the twists and turns that led from a crew of backup enthusiasts in an apartment in Palo Alto to a company with four data centers spread across the world holding 2100 storage pods and closing in on an exabyte of storage.
✣ ✣ ✣
Editors: So Tim, it all started with the $5 price point. I know we did market research and that was the price at which most people shrugged and said they’d pay for backup. But it was so audacious! The tech didn’t exist to offer that price. Why do you start there?
Tim Nufire: It was the pricing given to us by the competitors, they didn’t give us a lot of choice. But it was never a challenge of if we should do it, but how we would do it. I had been managing my own backups for my entire career; I cared about backups. So it’s not like backup was new, or particularly hard. I mean, I firmly believe Brian Wilson’s (Backblaze’s Chief Technical Officer) top line: You read a byte, you write a byte. You can read the byte more gently than other services so as to not impact the system someone is working on. You might be able to read a byte a little faster. But at the end of the day, it’s an execution game not a technology game. We simply had to out execute the competition.
E: Easy to say now, with a company of 113 employees and more than a decade of success behind us. But at that time, you were five guys crammed into a Palo Alto apartment with no funding and barely any budget and the competition — Dell, HP, Amazon, Google, and Microsoft — they were huge! How do you approach that?
TN: We always knew we could do it for less. We knew that the math worked. We knew what the cost of a 1 TB hard drive was, so we knew how much it should cost to store data. We knew what those markups were. We knew, looking at a Dell 2900, how much the margin was in that box. We knew they were overcharging. At that time, I could not build a desktop computer for less than Dell could build it. But I could build a server at half their cost.
I don’t think Dell or anyone else was being irrational. As long as they have customers willing to pay their hard margins, they can’t adjust for the potential market. They have to get to the point where they have no choice. We didn’t have that luxury.
So, at the beginning, we were reluctant hardware manufacturers. We were manufacturing because we couldn’t afford to pay what people were charging, not because we had any passion for hardware design.
E: Okay, so you came on at that point to build a cloud. Is that where your title comes from? Chief Cloud Officer? The pods were a little ways down the road, so Podfather couldn’t have been your name yet. …
TN: This was something like December, 2007. Gleb (Budman, the Chief Executive Officer of Backblaze) and I went snowboarding up in Tahoe, and he talked me into joining the team. … My title at first was all wrong, I never became the VP of Engineering, in any sense of the word. That was never who I was. I held the title for maybe five years, six years before we finally changed it. Chief Cloud Officer means nothing, but it fits better than anything else.
E: It does! You built the cloud for Backblaze with the Storage Pod as your water molecule (if we’re going to beat the cloud metaphor to death). But how does it all begin? Take us back to that moment: the podception.
TN: Well, the first pod, per se, was just a bunch of USB drives strapped to a shelf in the data center attached to two Dell 2900 towers. It didn’t last more than an hour in production. As soon as it got hit with load, it just collapsed. Seriously! We went live on this and it lasted an hour. It was a complete meltdown.
Two things happened: The bus was completely unstable, so the USB drives were unstable. Second, the DRDB (Distributed Replicated Block Device) — which is designed to protect your data by live mirroring it between the two towers — immediately fell apart. You implement a DRDB not because it works in a well-running situation, but because it covers you in the failure mode. And in failure mode it just unraveled — in an hour. It went into a split-brain mode under the hardware failures that the USB drives were causing. A well-running DRDB is fully mirrored, and split-brained mode is when the two sides simply give up and start acting autonomously because they don’t know what the other side is doing and they’re not sure who is boss. The data is essentially inconsistent at that point because you can choose A or B but the two sides are not in agreement.
While the USB specs say you can connect something like 256 or 128 drives to a hub, we were never able to do more than like, five. After something like five or six, the drives just start dropping out. We never really figured it out because we abandoned the approach. I just took the drives out and shoved them inside of the Dells, and those two became pods number 0 and 1. The Dells had room for 10 or 8 drives apiece, and so we brought that system live.
That was what the first six years of this company was like, just a never-ending stream of those kind of moments — mostly not panic inducing, mostly just: you put your head down and you start working through the problems. There’s a little bit of adrenaline, that feeling before a big race of an impending moment. But you have to just keep going.
E: Wait, so this wasn’t in testing? You were running this live?
TN: Totally! We were in friends-and-family beta at the time. But the software was all written. We didn’t have a lot of customers, but we had launched, and we managed to recover the files: whatever was backed up. The system has always had self healing built into the client.
E: So where do you go from there? What’s the next step?
TN: These were the early days. We were terrified of any commitments. So I think we had leased a half cabinet at the 365 Main facility in San Francisco, because that was the most we could imagine committing to in a contract: We committed to a year’s worth of this tiny little space.
We had those first two pods — the two Dell Towers (0 and 1) — which we eventually built out using external exclosures. So those guys had 40 or 45 drives by the end, with these little black boxes attached to them.
Pod number 2 was the plywood pod, which was another moment of sitting in the data center with a piece of hardware that just didn’t work out of the gate. This was Chris Robertson’s prototype. I credit him with the shape of the basic pod design, because he’s the one that came up with the top loaded 45 drives design. He mocked it up in his home woodshop (also known as a garage).
E: Wood in a data center? Come on, that’s crazy, right?
TN: It was what we had! We didn’t have a metal shop in our garage, we had a woodshop in our garage, so we built a prototype out of plywood, painted it white, and brought it to the data center. But when I went to deploy the system, I ended up having to recable and rewire and reconfigure it on the fly, sitting there on the floor of the data center, kinda similar to the first day.
The plywood pod was originally designed to be 45 drives, top loaded with port multipliers — we didn’t have backplanes. The port multipliers were these little cards that took one set of cables in and five cables out. They were cabled from the top. That design never worked. So what actually got launched was a fifteen drive system that had these little five drive enclosures that we shoved into the face of the plywood pod. It came up as a 15 drive, traditionally front-mounted design with no port multipliers. Nothing fancy there. Those boxes literally have five SATA connections on the back, just a one-to-one cabling.
E: What happened to the plywood pod? Clearly it’s cast in bronze somewhere, right?
TN: That got thrown out in the trash in Palo Alto. I still defend the decision. We were in a small one-bedroom apartment in Palo Alto and all this was cruft.
E: Brutal! But I feel like this is indicative of how you were working. There was no looking back.
TN: We didn’t have time to ask the question of whether this was going to work. We just stayed ahead of the problems: Pods 0 and 1 continued to run, pod 2 came up as a 15 drive chassis, and runs.
The next three pods are the first where we worked with Protocase. These are the first run of metal — the ones where we forgot a hole for the power button, so you’ll see the pried open spots where we forced the button in. These are also the first three with the port-multiplier backplane. So we built a chassis around that, and we had horrible drive instability.
We were using the Western Digital Green, 1 TB drives. But we couldn’t keep them in the RAID. We wrote these little scripts so that in the middle of the night, every time a drive dropped out of the array, the script would put it back in. It was this constant motion and churn creating a very unstable system.
We suspected the problem was with power. So we made the octopus pod. We drilled holes in the bottom, and ran it off of three PSUs beneath it. We thought: “If we don’t have enough power, we’ll just hit it with a hammer.” Same thing on cooling: “What if it’s getting too hot?” So we put a box fan on top and blew a lot of air into it. We were just trying to figure out what it was that was causing trouble and grief. Interestingly, the array in the plywood pod was stable, but when we replaced the enclosure with steel, it became unstable as well!
We slowly circled in on vibration as the problem. That plywood pod had actual disk enclosure with caddies and good locking mechanisms, so we thought the lack of caddies and locking mechanisms could be the issue. I was working with Western Digital at the time, too, and they were telling me that they also suspected vibration as the culprit. And I kept telling them, ‘They are hard drives! They should work!’
At the time, Western Digital was pushing me to buy enterprise drives, and they finally just gave me a round of enterprise drives. They were worse than the consumer drives! So they came over to the office to pick up the drives because they had accelerometers and lot of other stuff to give us data on what was wrong, and we never heard from them again.
We learned later that, when they showed up in an office in a one bedroom apartment in Palo Alto with five guys and a dog, they decided that we weren’t serious. It was hard to get a call back from them after that … I’ll admit, I was probably very hard to deal with at the time. I was this ignorant wannabe hardware engineer on the phone yelling at them about their hard drives. In hindsight, they were right; the chassis needed work.
But I just didn’t believe that vibration was the problem. It’s just 45 drives in a chassis. I mean, I have a vibration app on my phone, and I stuck the phone on the chassis and there’s vibration, but it’s not like we’re trying to run this inside a race car doing multiple Gs around corners, it was a metal box on a desk with hard drives spinning at 5400 or 7200 rpm. This was not a seismic shake table!
The early hard drives were secured with EPDM rubber bands. It turns out that real rubber (latex) turns into powder in about two months in a chassis, probably from the heat. We discovered this very quickly after buying rubber bands at Staples that just completely disintegrated. We eventually got better bands, but they never really worked. The hope was that they would secure a hard drive so it couldn’t vibrate its neighbors, and yet we were still seeing drives dropping out.
At some point we started using clamp down lids. We came to understand that we weren’t trying to isolate vibration between the drives, but we were actually trying to mechanically hold the drives in place. It was less about vibration isolation, which is what I thought the rubber was going to do, and more about stabilizing the SATA connector on the backend, as in: You don’t want the drive moving around in the SATA connector. We were also getting early reports from Seagate at the time. They took our chassis and did vibration analysis and, over time, we got better and better at stabilizing the drives.
We started to notice something else at this time: The Western Digital drives had these model numbers followed by extension numbers. We realized that drives that stayed in the array tended to have the same set of extensions. We began to suspect that those extensions were manufacturing codes, something to do with which backend factory they were built in. So there were subtle differences in manufacturing processes that dictated whether the drives were tolerant of vibration or not. Central Computer was our dominant source of hard drives at the time, and so we were very aggressively trying to get specific runs of hard drives. We only wanted drives with a certain extension. This was before the Thailand drive crisis, before we had a real sense of what the supply chain looked like. At that point we just knew some drives were better than others.
E: So you were iterating with inconsistent drives? Wasn’t that insanely frustrating?
TN: No, just gave me a few more gray hairs. I didn’t really have time to dwell on it. We didn’t have a choice of whether or not to grow the storage pod. The only path was forward. There was no plan B. Our data was growing and we needed the pods to hold it. There was never a moment where everything was solved, it was a constant stream of working on whatever the problem was. It was just a string of problems to be solved, just “wheels on the bus.” If the wheels fall off, put them back on and keep driving.
E: So what did the next set of wheels look like then?
TN: We went ahead with a second small run of steel pods. These had a single Zippy power supply, with the boot drive hanging over the motherboard. This design worked until we went to 1.5TB drives and the chassis would not boot. Clearly a power issue, so Brian Wilson and I sat there and stared at the non-functioning chassis trying to figure out how to get more power in.
The issue with power was not that we were running out of power on the 12V rail. The 5V rail was the issue. All the high end, high-power PSUs give you more and more power on 12V because that’s what the gamers need — it’s what their CPUs and the graphics card need, so you can get a 1000W or a 1500W power supply and it gives you a ton of power on 12V, but still only 25 amps on 5V. As a result, it’s really hard to get more power on the 5V rail, and a hard drive takes 12V and 5V: 12V to spin the motor and 5V to power the circuit board. We were running out of the 5V.
So our solution was two power supplies, and Brian and I were sitting there trying to visually imagine where you could put another power supply. Where are you gonna put it? We can put it were the boot drive is, and move the boot drive to the side, and just kind of hang the PSU up and over the motherboard. But the biggest consequence with this was, again, vibration. Mounting the boot drive to the side of a vibrating chassis isn’t the best place for a boot drive. So we had higher than normal boot drive failures in those nine.
So the next generation, after pod number 8, was the beginning of Storage Pod 1.0. We were still using rubber bands, but it had two power supplies, 45 drives, and we built 20 of them, total. Casey Jones, as our designer, also weighed in at this point to establish how they would look. He developed the faceplate design and doubled down on the deeper shade of red. But all of this was expensive and scary for us: We’re gonna spend $10 grand!? We don’t have much money. We had been two years without salary at this point.
We talked to Ken Raab from Sonic Manufacturing, and he convinced us that he could build our chassis, all in, for less than we were paying. He would take the task off my plate, I wouldn’t have to build the chassis, and he would build the whole thing for less than I would spend on parts … and it worked. He had better backend supplier connections, so he could shave a little expense off of everything and was able to mark up 20%.
We fixed the technology and the human processes. On the technology side, we were figuring out the hardware and hard drives, we were getting more and more stable. Which was required. We couldn’t have the same failure rates we were having on the first three pods. In order to reduce (or at least maintain) the total number of problems per day, you have to reduce the number of problems per chassis, because there’s 32 of them now.
We were also learning how to adapt our procedures so that the humans could live. By “the Humans,” I mean me and Sean Harris who joined me in 2010. There are physiological and psychological limits to what is sustainable and we were nearing our wits end.… So, in addition to stabilizing the chassis design, we got better at limiting the type of issues that would wake us up in the middle of the night.
E: So you reached some semblance of stability in your prototype and in your business. You’d been sprinting with no pay for a few years to get to this point and then … you decide to give away all your work for free? You open sourced Storage Pod 1.0 on September 9th, 2009. Were you a nervous wreck that someone was going to run away with all your good work?
TN: Not at all. We were dying for press. We were ready to tell the world anything they would listen to. We had no shame. My only regret is that we didn’t do more. We open sourced our design before anyone was doing that, but we didn’t build a community around it or anything.
Remember, we didn’t want to be a manufacturer. We would have killed for someone to build our pods better and cheaper than we could. Our hope from the beginning was always that we would build our own platform until the major vendors did for the server market what they did in the personal computing market. Until Dell would sell me the box that I wanted at the price I could afford, I was going to continue to build my chassis. But I always assumed they would do it faster than a decade.
Supermicro tried to give us a complete chassis at one point, but their problem wasn’t high margin; they were targeting too high of performance. I needed two things: Someone to sell me a box and not make too much profit off of me, and I needed someone who would wrap hard drives in a minimum performance enclosure and not try to make it too redundant or high performance. Put in one RAID controller, not two; daisy chain all the drives; let us suffer a little! I don’t need any of the hardware that can support SSDs. But no matter how much we ask for barebones servers, no one’s been able to build them for us yet.
So we’ve continued to build our own. And the design has iterated and scaled with our business. So we’ll just keep iterating and scaling until someone can make something better than we can.
E: Which is exactly what we’ve done, leading from Storage Pod 1.0 to 2.0, 3.0, 4.0, 4.5, 5.0, to 6.0 (if you want to learn more about these generations, check out our Pod Museum), preparing the way for more than 800 petabytes of data in management.
✣ ✣ ✣
But while Tim is still waiting to pass along the official Podfather baton, he’s not alone. There was the early help from Brian Wilson, Casey Jones, Sean Harris, and a host of others, and then in 2014, Ariel Ellis came aboard to wrangle our supply chain. He grew in that role over time until he took over the responsibility over charting the future of the Pod via Backblaze Labs, becoming the Podson, so to speak. Today, he’s sketching the future of Storage Pod 7.0, and — provided no one builds anything better in the meantime — he’ll tell you all about it on our blog.
This post is for all of the storage geeks out there who have followed the adventures of Backblaze and our Storage Pods over the years. The rest of you are welcome to come along for the ride.
It has been 10 years since Backblaze introduced our Storage Pod to the world. In September 2009, we announced our hulking, eye-catching, red 4U storage server equipped with 45 hard drives delivering 67 terabytes of storage for just $7,867 — that was about $0.11 a gigabyte. As part of that announcement, we open-sourced the design for what we dubbed Storage Pods, telling you and everyone like you how to build one, and many of you did.
Backblaze Storage Pod version 1 was announced on our blog with little fanfare. We thought it would be interesting to a handful of folks — readers like you. In fact, it wasn’t even called version 1, as no one had ever considered there would be a version 2, much less a version 3, 4, 4.5, 5, or 6. We were wrong. The Backblaze Storage Pod struck a chord with many IT and storage folks who were offended by having to pay a king’s ransom for a high density storage system. “I can build that for a tenth of the price,” you could almost hear them muttering to themselves. Mutter or not, we thought the same thing, and version 1 was born.
Tim, the “Podfather” as we know him, was the Backblaze lead in creating the first Storage Pod. He had design help from our friends at Protocase, who built the first three generations of Storage Pods for Backblaze and also spun out a company named 45 Drives to sell their own versions of the Storage Pod — that’s open source at its best. Before we decided on the version 1 design, there were a few experiments along the way:
The original Storage Pod was prototyped by building a wooden pod or two. We needed to test the software while the first metal pods were being constructed.
The Octopod was a quick and dirty response to receiving the wrong SATA cables — ones that were too long and glowed. Yes, there are holes drilled in the bottom of the pod.
The original faceplate shown above was used on about 10 pre-1.0 Storage Pods. It was updated to the three circle design just prior to Storage Pod 1.0.
Why are Storage Pods red? When we had the first ones built, the manufacturer had a batch of red paint left over that could be used on our pods, and it was free.
Back in 2007, when we started Backblaze, there wasn’t a whole lot of affordable choices for storing large quantities of data. Our goal was to charge $5/month for unlimited data storage for one computer. We decided to build our own storage servers when it became apparent that, if we were to use the other solutions available, we’d have to charge a whole lot more money. Storage Pod 1.0 allowed us to store one petabyte of data for about $81,000. Today we’ve lowered that to about $35,000 with Storage Pod 6.0. When you take into account that the average amount of data per user has nearly tripled in that same time period and our price is now $6/month for unlimited storage, the math works out about the same today as it did in 2009.
We Must Have Done Something Right
The Backblaze Storage Pod was more than just affordable data storage. Version 1.0 introduced or popularized three fundamental changes to storage design: 1) You could build a system out of commodity parts and it would work, 2) You could mount hard drives vertically and they would still spin, and 3) You could use consumer hard drives in the system. It’s hard to determine which of these three features offended and/or excited more people. It is fair to say that ten years out, things worked out in our favor, as we currently have about 900 petabytes of storage in production on the platform.
Over the last 10 years, people have warmed up to our design, or at least elements of the design. Starting with 45 Drives, multitudes of companies have worked on and introduced various designs for high density storage systems ranging from 45 to 102 drives in a 4U chassis, so today the list of high-density storage systems that use vertically mounted drives is pretty impressive:
Exos AP 4U100
Thunder SX FA100-B7118
Viking Enterprise Solutions
Viking Enterprise Solutions
Viking Enterprise Solutions
Another driver in the development of some of these systems is the Open Compute Project (OCP). Formed in 2011, they gather and share ideas and designs for data storage, rack designs, and related technologies. The group is managed by The Open Compute Project Foundation as a 501(c)(6) and counts many industry luminaries in the storage business as members.
What Have We Done Lately?
In technology land, 10 years of anything is a long time. What was exciting then is expected now. And the same thing has happened to our beloved Storage Pod. We have introduced updates and upgrades over the years twisting the usual dials: cost down, speed up, capacity up, vibration down, and so on. All good things. But, we can’t fool you, especially if you’ve read this far. You know that Storage Pod 6.0 was introduced in April 2016 and quite frankly it’s been crickets ever since as it relates to Storage Pods. Three plus years of non-innovation. Why?
If it ain’t broke, don’t fix it. Storage Pod 6.0 is built in the US by Equus Compute Solutions, our contract manufacturer, and it works great. Production costs are well understood, performance is fine, and the new higher density drives perform quite well in the 6.0 chassis.
Disk migrations kept us busy. From Q2 2016 through Q2 2019 we migrated over 53,000 drives. We replaced 2, 3, and 4 terabyte drives with 8, 10, and 12 terabyte drives, doubling, tripling and sometimes quadrupling the storage density of a storage pod.
Lots of data kept us busy. In Q2 2016, we had 250 petabytes of data storage in production. Today, we have 900 petabytes. That’s a lot of data you folks gave us (thank you by the way) and a lot of new systems to deploy. The chart below shows the challenge our data center techs faced.
In other words, our data center folks were really, really busy, and not interested in shiny new things. Now that we’ve hired a bunch more DC techs, let’s talk about what’s next.
Storage Pod Version 7.0 — Almost
Yes, there is a Backblaze Storage Pod 7.0 on the drawing board. Here is a short list of some of the features we are looking at:
Updating the motherboard
Upgrade the CPU and consider using an AMD CPU
Updating the power supply units, perhaps moving to one unit
Upgrading from 10Gbase-T to 10GbE SFP+ optical networking
Upgrading the SATA cards
Modifying the tool-less lid design
The timeframe is still being decided, but early 2020 is a good time to ask us about it.
“That’s nice,” you say out loud, but what you are really thinking is, “Is that it? Where’s the Backblaze in all this?” And that’s where you come in.
The Next Generation Backblaze Storage Pod
We are not out of ideas, but one of the things that we realized over the years is that many of you are really clever. From the moment we open sourced the Storage Pod design back in 2009, we’ve received countless interesting, well thought out, and occasionally odd ideas to improve the design. As we look to the future, we’d be stupid not to ask for your thoughts. Besides, you’ll tell us anyway on Reddit or HackerNews or wherever you’re reading this post, so let’s just cut to the chase.
Build or Buy
The two basic choices are: We design and build our own storage servers or we buy them from someone else. Here are some of the criteria as we think about this:
Cost: We’d like the cost of a storage server to be about $0.030 – $0.035 per gigabyte of storage (or less of course). That includes the server and the drives inside. For example, using off-the-shelf Seagate 12 TB drives (model: ST12000NM0007) in a 6.0 Storage Pod costs about $0.032-$0.034/gigabyte depending on the price of the drives on a given day.
Maintenance: Things should be easy to fix or replace — especially the drives.
Commodity Parts: Wherever possible, the parts should be easy to purchase, ideally from multiple vendors.
Racks: We’d prefer to keep using 42” deep cabinets, but make a good case for something deeper and we’ll consider it.
Possible Today: No DNA drives or other wistful technologies. We need to store data today, not in the year 2061.
Scale: Nothing in the solution should limit the ability to scale the systems. For example, we should be able to upgrade drives to higher densities over the next 5-7 years.
Other than that there are no limitations. Any of the following acronyms, words, and phrases could be part of your proposed solution and we won’t be offended: SAS, JBOD, IOPS, SSD, redundancy, compute node, 2U chassis, 3U chassis, horizontal mounted drives, direct wire, caching layers, appliance, edge storage units, PCIe, fibre channel, SDS, etc.
The solution does not have to be a Backblaze one. As the list from earlier in this post shows, Dell, HP, and many others make high density storage platforms we could leverage. Make a good case for any of those units, or any others you like, and we’ll take a look.
What Will We Do With All Your Input?
We’ve already started by cranking up Backblaze Labs again and have tried a few experiments. Over the coming months we’ll share with you what’s happening as we move this project forward. Maybe we’ll introduce Storage Pod X or perhaps take some of those Storage Pod knockoffs for a spin. Regardless, we’ll keep you posted. Thanks in advance for your ideas and thanks for all your support over the past ten years.
Prost!Skål!Cheers! Celebrate with us as we travel to Amsterdam for IBC, the premier conference and expo for media and entertainment technology in Europe. The show gives us a chance to raise a glass with our partners, customers, and future customers across the pond. And we’re especially pleased that IBC coincides with the opening of our new European data center.
How will we celebrate? With the Backblaze Partner Crawl, a rolling series of parties on the show floor from 13-16 September. Four of our Europe-based integration partners have graciously invited us to co-host drinks and bites in their stands throughout the show.
If you can make the trip to IBC, you’re invited to toast us with a skål! with our Swedish friends at Cantemo on Friday, a prost! with our German friends at Archiware on Saturday, or a cheers! with UK-based friends at Ortana and GB Labs on Sunday or Monday, respectively. Or drop in every day and keep the Backblaze Partner Crawl rolling. And if you can’t make it to IBC this time, we encourage you to raise a glass and toast anyway.
Skål! on Friday With Cantemo
Cantemo’s iconik media management makes sharing and collaborating on media effortless, regardless of wherever you want to do business. Cantemo announced the integration of iconik with Backblaze’s B2 Cloud Storage last fall, and since then we’ve been amazed by customers like Everwell, who replaced all their on-premises storage with a fully cloud-based production workflow. For existing Backblaze customers, iconik can speed up your deployment by ingesting content already uploaded to B2 without having to download files and upload them again. You can also stop by the Cantemo booth anytime during IBC to see a live demo of iconik and Backblaze in action. Or schedule an appointment and we’ll have a special gift waiting for you.
Join us at Cantemo on Friday 13 September from 16:30-18:00 at Hall 7 — 7.D67
Prost! on Saturday With Archiware
With the latest release of their P5 Archive featuring B2 support, Archiware makes archiving to the cloud even easier. Archiware customers with large existing archives can use the Backblaze Fireball to rapidly import archived content directly to their B2 account. At IBC, we’re also unveiling our latest joint customer, Baron & Baron, a creative agency that turned to P2 and B2 to back up and archive their dazzling array of fashion and luxury brand content.
Join us at Archiware on Saturday 14 September from 16:30-18:00 at Hall 7 — 7.D35
Cheers! on Sunday With Ortana
Ortana integrated their Cubix media asset management and orchestration platform with B2 way back in 2016 during B2’s beta period, making them among our first media workflow partners. More recently, Ortana joined our Migrate or Diewebinar and blog series, detailing strategies for how you can migrate archived content from legacy platforms before they go extinct.
Join us at Ortana on Sunday 15 September from 16:30-18:00 at Hall 7 — 7.C63
Cheers! on Monday With GB Labs
If you were at the NAB Show last April, you may have heard GB Labs was integrating their automation tools with B2. It’s official now, as detailed in their announcement in June. GB Labs’ automation allows you to streamline tasks that would otherwise require tedious and repetitive manual processes, and now supports moving files to and from your B2 account.
Join us at GB Labs Monday 16 September from 17:00-18:00 at Hall 7 — 7.B26
Say Hello Anytime to Our Friends at CatDV
CatDV media asset management helps teams organize, communicate, and collaborate effectively, including archiving content to B2. CatDV has been integrated with B2 for over two years, allowing us to serve customers like UC Silicon Valley, who built an end-to-end collaborative workflow for a 22 member team creating online learning videos.
Stop by CatDV anytime at Hall 7 — 7.A51
But we’re not the only ones making a long trek to Amsterdam for IBC. While you’re roaming around Hall 7, be sure to stop by our other partners traveling from near and far to learn what our joint solutions can do for you:
EditShare (shared storage with MAM) Hall 7 — 7.A35
ProMax (shared storage with MAM) Hall 7 — 7.D55
StorageDNA (smart migration and storage) Hall 7 — 7.A32
FileCatalyst (large file transfer) Hall 7 — 7.D18
eMAM (web-based DAM) Hall 7 — 7.D27
Facilis Technology (shared storage) Hall 7 — 7.B48
GrayMeta (metadata extraction and insight) Hall 7 — 7.D25
Hedge (backup software) Hall 7 — 7.A56
axle ai (asset management) Hall 7 — 7.D33
Tiger Technology (tiered data management) Hall 7 — 7.B58
We’re hoping you’ll join us for one or more of our Partner Crawl parties. If you want a quieter place and time to discuss how B2 can streamline your workflow, please schedule an appointment with us so we can give you the attention you need.
Finally, if you can’t join us in Amsterdam, open a beer, pour a glass of wine or other drink, and toast to our new European data center, wherever you are, in whatever language you speak. As we say here in the States, Bottoms up!
Imagine a globe spinning (or simply look at the top of this blog post). When you start out on a data center search, you could consider almost any corner of the globe. For Backblaze, we knew we wanted to find an anchor location in the European Union. For a variety of reasons, we quickly narrowed in on Amsterdam, Brussels and Dublin as the most likely locations. While we were able to generate a list of 40 qualified locations, narrowed it down to ten for physical visits, and then narrowed it yet again to three finalists, the question remained: How would we choose our ultimate partner? Data center searches have changed a lot since 2012 when we circulated our RFP for a previous expansion.
The good news is we knew our top line requirements would be met. Thinking back to the 2×2 that our Chief Cloud Officer, Tim Nufire, had drawn on the board at the early stages of our search, we felt good that we had weighed the tradeoffs appropriately.
Similarly to hiring an employee, after the screening and the interviews, one runs reference checks. In the case of data centers, that means both validating certain assertions and going into the gory details on certain operational capabilities. For example, in our second post in the EU DC series, we mentioned environmental risks. If one is looking to reduce the probability of catastrophe, making sure that your DC is outside of a flood zone is generally advisable. Of course, the best environmental risk factor reports are much more nuanced and account for changes in the environment.
To help us investigate those sorts of issues, we partnered with PTS Consulting. By engaging with third party experts, we get dispassionate, unbiased, thorough reporting about the locations we are considering. Based on PTS’s reporting, we eliminated one of our finalists. To be clear, there was nothing inherently wrong with the finalist, but it was unlikely that particular location would sustainably meet our long term requirements without significant infrastructure upgrades on their end.
In our prior posts, we mentioned another partner, UpStack. Their platform helped us with the sourcing and narrowing down to a list of finalists. Importantly, their advisory services were crucial in this final stage of diligence. Specifically, UpStack brought in electrical engineering expertise to give us a deep, detailed assessment of the electrical mechanical single line diagrams. For those less versed in the aspects of DC power, that means UpStack was able to go into incredible granularity in looking at the reliability and durability of the power sources of our DCs.
Ultimately, it came down to two finalists:
DC 3: Interxion Amsterdam
DC 4: The pre-trip favorite
DC four had a lot of things going for it. The pricing was the most affordable and the facility had more modern features and functionality. The biggest downsides were open issues around sourcing and training what would become our remote hands team.
Which gets us back to our matrix of tradeoffs. While more expensive than DC three, Interxion facility graded out equally well during diligence. Ultimately, the people at Interxion and confidence in the ability to build out a sturdy remote hands team made the choice of Interxion clear.
Looking back at Tim’s 2×2, DC four presented as financially more affordable, but operationally a little more risky (since we had questions about our ability to effectively operate on a day to day basis).
Interxion, while a little more financially expensive, reduced our operational risks. When thinking of our anchor location in Europe, that felt like the right tradeoff to be making.
Ready, Set, More Work!
The site selection only represented part of the journey. In parallel, our sourcing team has had to learn how to get pods and drives into Europe. Our Tech Ops & Engineering teams have worked through any number of issues around latency, performance, and functionality. Finance & Legal has worked through the implications of having a physical international footprint. And that’s just to name a few things.
If you’re in the EU, we’ll be at IBC 2019 in Amsterdam from September 13 to September 17. If you’re interested in making an appointment to chat further, use our form to reserve a time at IBC, or drop by stand 7.D67 at IBC (our friends from Cantemo are hosting us). Or, if you prefer, feel free to leave any questions in the comments below!
Ten locations, three countries, three days. Even the hardest working person in show business wouldn’t take on challenges like that. But for our COO, John Tran, and UpStack’s CEO, Chris Trapp, that’s exactly what they decided to do.
In yesterday’s post, we discussed the path to getting 40 bids from vendors that could meet our criteria for our new European data center (DC). This was a remarkable accomplishment in itself, but still only part way to our objective of actually opening a DC. We needed to narrow down the list.
With help from UpStack, we began to filter the list based on some qualitative characteristics: vendor reputation, vendor business focus, etc. Chris managed to get us down to a list of 10. The wonders of technology today, like the UpStack platform, help people get more information and cast wider nets then at any other time in human history. The downside of that is you get a lot of information on paper, but that is a poor substitute to what you can gather in person. If you’re looking for a good, long term partner then understanding things like how they operate and their company DNA is imperative to finding the right match. So, to find our newest partner, we needed to go for a trip.
Chris took the lead on booking appointments. The majority of the shortlist clustered in the Netherlands and Ireland. The others were in Belgium and with the magic of Google Maps, one could begin to envision an efficient trip to all three countries. The feeling was it could all be done with just three days on the ground in Europe. Going in, they knew it would be a compressed schedule and that they would be on the move. As experienced travelers, they brought small bags that easily fit in the overhead and the right power adapters.
Hitting the Road
On July 23rd, 2018, John left San Francisco International Airport (SFO) at 7:40 a.m. on a non-stop to Amsterdam. Taking into account the 5,448 miles between the two cities and the time change, John landed at Amsterdam Airport Schiphol (AMS) hours at 7:35 a.m. on July 24th. He would land back home on July 27th at 6:45 p.m.
Tuesday (Day One)
The first day officially started when John’s redeye touched down in Amsterdam at 7:35 a.m. local. Thankfully, Chris’ flight from New York’s La Guardia was also on time. With both flights on time, they were able to meet at the airport: literally, for they had never met before.
Both adjourned to the airport men’s room to change out of their travel clothes and into their suits — choosing a data center is serious business, after all. While airport bathroom changes are best left for spy novels, John and Chris made short work of it and headed to the rental car area.
That day, they’ll ended up touring four DCs. One of the biggest takeaways of the trip was that it turned out visiting data centers is similar to wine tasting. While some of the differences can be divined from the specs on paper, when trying to figure out the difference between A and B, it’s very helpful to compare side by side. Also similar to wine tasting, there’s a fine line between understanding nuances between multiple things and it all starting to blend together. In both cases, after a full day of doing it, you feel like you probably shouldn’t operate heavy machinery.
On day one, our team saw a wide range of options. The physical plant is itself one area of differentiation. While we have requirements for things like power, bandwidth, and security, there’s still a lot of room for tradeoffs among those DCs that exceed the requirement. And that’s just the physical space. The first phase of successful screening (discussed in our prior post) is being effective at examining non-emotional decision variables — specs, price, reputation — but not the people. Every DC is staffed by human beings and cultural fit is important with any partnership. Throughout the day, one of the biggest differences we noticed was the culture of each specific DC.
The third stop of the day was Interxion Amsterdam. While we didn’t know it at the time, they would end up being our partner of choice. On paper, it was clear that Interxion would be a contender. Its impressive facility meets all our requirements and, by happenstance, happens to have a footprint available that is almost exactly to the spec of what we were looking for. During our visit, the facility was impressive, as expected. But the connection we felt with the team there would prove to be the thing that would ultimately be the difference.
After leaving the last DC tour around 7pm, our team drove from Amsterdam to Brussels. Day 2 would be another morning start and, after arriving in Brussels a little after 9pm, they had earned some rest!
Insider Tip:Earlier in his career, John had spent a good amount of time in Europe and, specifically, Brussels. One of his favorite spots is the Grand Place (Brussels’ Central Market). If in the neighborhood, he recommends you go and enjoy a Belgium beer sitting at one of the restaurants in the market. The smart move is to take the advice. Chris, newer to Brussels, gave John’s tour a favorable TripAdvisor rating.
Wednesday (Day Two)
After getting a well-deserved couple hours of sleep, the day officially started with an 8:30 a.m. meeting for the first DC of the day. Major DC operators generally have multiple locations and DCs five and six are operated by companies that also operate sites visited on day one. It was remarkable, culturally, to compare the teams and operational variability across multiple locations. Even within the same company, teams at different locations have unique personalities and operating styles, which all serves to reinforce the need to physically visit your proposed partners before making a decision.
After two morning DC visits, John and Chris hustled to the Brussels airport to catch their flight to Dublin. At some point during the drive, it was realized that tickets to Dublin hadn’t actually been purchased. Smartphones and connectivity are transformative on road trips like this.
The flight itself was uneventful. When they landed, they got to the rental car area and their car was waiting for them. Oh, by the way, minor detail but the steering wheel was on the wrong side of the car! Chris buckled in tightly and John had flashbacks of driver’s ed having never driven on the right side of the car. Shortly after leaving the airport, it was realized that one also drives on the left side of the road in Ireland. Smartphones and connectivity were not required for this discovery. Thankfully, the drive was uneventful and the hotel was reached without incident. After work and family check ins, another day was put on the books.
Our team checked into their hotel and headed over to the Brazenhead for dinner. Ireland’s oldest pub is worth the visit. It’s here that we come across our it really is a small world nomination for the trip. After starting a conversation with their neighbors at dinner, our team was asked what they were doing in Dublin. John introduced himself as Backblaze’s COO and the conversation seemed to cool a bit. Apparently their neighbor was someone from another large cloud storage provider. Apparently, not all companies like sharing information as much as we do.
Thursday (Day Three)
The day again started with an 8:30 a.m. hotel departure. Bear in mind, during all of this, John and Chris both had their day jobs and families back home to stay in touch with. Today would feature four DC tours. One interesting note about the trip: operating a data center requires a fair amount of infrastructure. In a perfect world, power and bandwidth come in at multiple locations from multiple vendors. This often causes DCs to cluster around infrastructure hubs. Today’s first two DCs were across the street from one another. We’re assuming, but could not verify, a fierce inter-company football rivalry.
While walking across the street was interesting, in the case of the final two DCs, they literally shared the same space; the smaller provider subleasing space from the larger. Here, again, the operating personalities differentiated the companies. It’s not necessarily that one was worse than the other, it is a question of whom you think will be a better partnership match for your own style. In this case, the smaller of the two providers stood out because of the passion and enthusiasm we felt from the team there, and it didn’t hurt that they are long time Hard Drive Stats enthusiasts (flattery will get you everywhere!).
While the trip, and this post, were focused on finding our new DC location, opening up our first physical operations outside of the U.S. had any number of business ramifications. As such, John made sure to swing by the local office of our global accounting firm to take the opportunity to get to know them.
The meeting wrapped up just in time for Chris and John to make it to the Guinness factory by 6:15 p.m. Upon arrival, it was then realized that the last entry into the Guinness factory is 6 p.m. Smartphones and connectivity really can be transformative on road trips like this. All that said, without implicating any of the specific actors, our fearless travelers managed to finagle their way in and could file the report home that they were able to grab a pint or two at St. James’ place.
The team would leave for their respective homes early the next morning. John made it back to California in time for a (late) dinner with his family and a well earned weekend.
After a long, productive trip, we had our list of the three finalists. Tomorrow, we’ll discuss how we narrowed it down from three to one. Until then, slainte (cheers)!
There’s an old saying, “How do you eat an elephant? One bite at a time.” The best way to tackle big problems is to simplify as much as you can.
In our case, with almost an exabyte of customer data under management and customers in over 160 countries, expanding the geographic footprint of our data centers (DCs) has been a frequently discussed topic. Prior to opening up EU Central, we had three DCs, but all in the western U.S. The topic of opening a DC in Europe is not a new one within Backblaze, but going from idea to storing customer data can be a long journey.
As our team gathered to prioritize the global roadmap, the first question was an obvious one: Why do we want to open a DC in Europe? The answer was simple: Customer demand.
While nearly 15 percent of our existing customer base already resides in Europe, the requests for an EU DC come from citizens around the globe. Why?
Customers like keeping data in multiple geographies. Doing so is in line with the best practices of backup (long before there was a cloud, there was still 3-2-1).
Geopolitical/regulatory concerns. For any number of reasons, customers may prefer or be required to store data in certain physical locations.
Performance concerns. While we enjoy a debate about the effects of latency for most storage use cases, the reality is many customers want a copy of their data as physically close to where it’s being used as possible.
With the need established, the next question was predictably obvious: How are we going to go about this? Our three existing DCs are all in the same timezone as our California headquarters. Logistically, opening and operating a DC that has somewhere around an eight hour time difference from our headquarters felt like a significant undertaking.
Organizing the Search for the Right Data Center
To help get us organized, our co-founder and Chief Cloud Officer, Tim Nufire, drew the following on a whiteboard.
This basic matrix frames the challenge well. If one were willing to accept infinite risk (have customers write to scrolls and “upload” via sealed bottle transported across the ocean), we’d have low financial and effort investments outlays to open the data enter. However, we’re not in the business of accepting infinite risk. So we wanted to achieve a low risk environment for data storage while sustaining our cost advantage for our customers.
But things get much more nuanced once you start digging in.
There are multiple risk factors to consider when selecting a DC. Some of the leading ones are:
Environmental: One could choose a DC in the middle of a floodplain, but, with few exceptions, most DCs don’t work well underwater. We needed to find an area to minimize adverse environmental impact.
Political: DCs are physical places. Physical places are governed by some form of nation state. Some customers want (or need) their data to be stored within certain regulatory or diplomatic parameters. In the case of the requests for opening a DC in Europe, many of our customers want their data to be inside of the European Union (EU). That requirement strikes Switzerland off our list. For similar reasons, another requirement we imposed was operating inside of a country that is a NATO member. Regrettably, that eliminated any location inside of Finland. Our customers want EU, not Europe.
Financial: By opening a DC in Europe, we will be conducting business with a partner that expects to be paid in euros. As an American company, we primarily operate in dollars. So now the simple timing of when we pay our bills may change the cost (depending on exchange rate fluctuations).
The other dimension on the board was costs, expressed as Affordable to Expensive. Costs can be thought of both as financial as well as effort:
Operating Efficiency: Generally speaking, the climate of the geography will have an effect on the heating/cooling costs. We needed to understand climate nuances across a broad geographic area.
Cost of Inputs: Power costs vary widely, often due to fuel sources having different availability at a local level. For example, nuclear power is generally cheaper than fossil fuel, but may not be available in a given region. Complicating things is that power source X may cost one thing in the first country, but something totally different in the next. Our DC negotiations may be for physical space, but we needed to understand our total cost of ownership.
Staffing: Some DCs provide remote hands (contract labor) while others expect us to provide our own staffing. We needed to get up to speed on labor laws and talent pools in desired regions.
Trying to Push Forward
We’re fortunate to have a great team of Operations people that have earned expertise in the field. So with the desire to find a DC in the EU, a working group formed to explore our options. A little while later, when the internal memo circulated, the summary in the body of the email jumped out:
“It could take 6-12 months from project kick-off to bring a new EU data center online.”
That’s a significant project for any company. In addition, the time range was sufficiently wide to indicate the number of unknowns in play. We were faced with a difficult decision: How can we move forward on a project with so many unknowns?
While this wouldn’t be our first data center search, prior experience told us we had many more unknowns in front of us. Our most recent facility searches mainly involved coordinating with known vendors to obtain facility reports and pricing for comparison. Even with known vendors, this process involved significant resources from Backblaze to relay requirements to various DC sales reps and to take disparate quotes and create some sort of comparison. All DCs with quote you $/Kilowatt Hour or $/kWh, but there is no standard definition of what is and isn’t included in that. Generally speaking, a DC contract has unit costs that decline as usage goes up. So is the $/kWh in a given quote the blended lifetime cost? Year one? Year five? Adding to this complexity would be all the variables discussed above (and more).
Interested in learning more about the initial assessment of the project? Here is a copy of the internal memo referenced. Because of various privacy agreements, we needed to redact small pieces of the original. Very little has been changed and, if you’re interested in the deep dive, we hope you’ll enjoy!
Serendipity Strikes: UpStack
Despite the obstacles in our path, our team committed to finding a location inside the EU that makes sense for both our customers’ needs and our business model. We have an experienced team that has demonstrated the ability to source and vet DCs already. That said, our experienced team were already quite busy with their day jobs. This project looked to come at a significant opportunity cost as it would fully occupy a number of people for an extended period of time.
At the same time as we were trying to work through the internal resource planning, our CEO happened across an interesting article from our friends at Data Center Knowledge; they were covering a startup called UpStack (“Kayak for data center services”). The premise was intriguing — the UpStack platform is designed to gather and normalize quotes from qualified vendors for relevant opportunities. Minimizing friction for bidding DCs and Backblaze would enable both sides to find the right fit. Intrigued, we reached out to their CEO, Chris Trapp.
UpStack is a free, vendor-neutral data center sourcing platform that allows businesses to analyze and compare level-set pricing and specifications in markets around the world. Find them at upstack.com.
We were immediately impressed with how easy the user experience was on our side. Knowing how much effort goes into normalizing the data from various DCs, having a DC shopping experience comparable to that of searching for plane tickets was mind blowing. With a plane ticket, you might search for number of stops and layover airports. With UpStack, we were able to search for connectivity to existing bandwidth providers, compliance certifications, and location before asking for pricing.
Once vendors returned pricing, UpStack’s application made it easy to compare specifications and pricing on an apples-to-apples basis. This price normalization was a huge advantage for us as it saved many hours of work usually spent converting quotes into pricing models simply for comparison sake. We have the expertise to do what UpStack does, but we also know how much time that takes us. Being able to leverage a trusted partner was a tremendous value add for Backblaze.
Narrowing Down The Options
With the benefit of the UpStack platform, we were able to cast a much wider net than would have been viable hopping on phone calls from California.
We specified our load ramp. There’s a finite amount of data that will flow into the new DC on day one, and it only grows from there. So part of the pricing negotiation is agreeing to deploy a minimum amount of racks on day one, a minimum by the end of year one, and so on. In return for the guaranteed revenue, the DCs return pricing based on those deployments. Based on the forecasted storage needs, UpStack’s tool then translates that into estimated power needs so vendors can return bids based on estimated usage. This is an important change from how things are usually done; many quotes otherwise price based on the top estimated usage or a vendor-imposed minimum. By basing quotes off of one common forecast, we could get the pricing that fits our needs.
There are many more efficiencies that UpStack provides us and we’d encourage you to visit their site at https://upstack.com to learn more. The punchline is that we were able to create a shortlist of the DCs that fit our requirements; we received 40 quotes provided by 40 data centers in 10 markets for evaluation. This was a blessing and a curse, as we were able to cast a wider net and learn about more qualified vendors than we thought possible, but a list of 40 needed to be narrowed down.
Based on our cost/risk framework, we narrowed it down to the 10 DCs that we felt gave us our best shot to end up with a low cost, low risk partner. With all the legwork done, it was time to go visit. To learn more about our three country trip to 10 facilities that lasted less than 72 hours, tune in tomorrow. Same bat time, same bat station.
Big news: Our first European data center, in Amsterdam, is open and accepting customer data!
This is our fourth data center (DC) location and the first outside of the western United States. As longtime readers know, we have two DCs in the Sacramento, California area and one in the Phoenix, Arizona area. As part of this launch, we are also introducing the concept of regions.
When creating a Backblaze account, customers can choose whether that account’s data will be stored in the EU Central or US West region. The choice made at account creation time will dictate where all of that account’s data is stored, regardless of product choice (Computer Backup or B2 Cloud Storage). For customers wanting to store data in multiple regions, please read this knowledge base article on how to control multiple Backblaze accounts using our (free) Groups feature.
Whether you choose EU Central or US West, your pricing for our products will be unchanged:
For B2 Cloud Storage — it’s $0.005/GB/Month. For comparison, storing your data in Amazon S3’s Ireland region will cost ~4.5x more
For Computer Backup — $60/Year/Computer is the monthly cost of our industry leading, unlimited data backup for desktops/laptops
Later this week we will be publishing more details on the process we undertook to get to this launch. Here’s a sneak preview:
Wednesday, August 28:Getting Ready to Go (to Europe). How do you even begin to think about opening a DC that isn’t within any definition of driving distance? For the vast majority of companies on the planet, simply figuring out how to get started is a massive undertaking. We’ll be sharing a little more on how we thought about our requirements, gathered information, and the importance of NATO in the whole equation.
Thursday, August 29: The Great European (Non) Vacation. With all the requirements done, research gathered, and preliminary negotiations held, there comes a time when you need to jump on a plane and go meet your potential partners. For John & Chris, that meant 10 data center tours in 72 hours across three countries — not exactly a relaxing summer holiday, but vitally important!
Friday, August 30: Making a Decision. After an extensive search, we are very pleased to have found our partner in Interxion! We’ll share a little more about the process of narrowing down the final group of candidates and selecting our newest partner.
Q: Does the new DC mean Backblaze has multi-region storage? A: Yes, by leveraging our Groups functionality. When creating an account, users choose where their data will be stored. The default option will store data in US West, but to choose EU Central, simply select that option in the pull-down menu.
If you create a new account with EU Central selected and have an existing account that’s in US West, you can put both of them in a Group, and manage them from there! Learn more about that in our Knowledge Base article.
Q: I’m an existing customer and want to move my data to Europe. How do I do that? A: At this time, we do not support moving existing data within Backblaze regions. While it is something on our roadmap to support, we do not have an estimated release date for that functionality. However, any customer can create a new account and upload data to Europe. Customers with multiple accounts can administer those accounts via our Groups feature. For more details on how to do that, please see this Knowledge Base article. Existing customers can create a new account in the EU Central region and then upload data to it; they can then either keep or delete the previous Backblaze account in US West.
Q: Finally! I’ve been waiting for this and am ready to get started. Can I use your rapid ingest device, the B2 Fireball? A: Yes! However, as of the publication of this post, all Fireballs will ship back to one of our U.S. facilities for secure upload (regardless of account location). By the end of the year, we hope to offer Fireball support natively in Europe (so a Fireball with a European customer’s data will never leave the EU).
Q: What are my payment options? A: All payments to Backblaze are made in U.S. dollars. To get started, you can enter your credit card within your account.
Q: What’s next? A: We’re actively working on region selection for individual B2 Buckets (instead of Backblaze region selection on an account basis), which should open up a lot more interesting workflows! For example, customers who want can create geographic redundancy for data within one B2 account (and for those who don’t want to set that up, they can sleep well knowing they have 11 nines of durability).
We like to develop the features and functionality that our customers want. The decision to open up a data center in Europe is directly related to customer interest. If you have requests or questions, please feel free to put them in the comment section below.
Anyone just starting out with the cloud is going to need answers to some basic questions.
The first, of course, is what exactly is the cloud? Put simply, the cloud is a collection of purpose built servers. These servers could perform one or more services (storage, compute, database, email, web, etc.) and could exist anywhere as long as they’re accessible to whomever needs to use them.
The next important question to ask is whether the servers are in a private cloud or a public cloud. This distinction is often tied to where the servers are located, but more precisely, it reflects who uses the servers and how they use them.
What is Private Cloud?
If the servers are owned by and dedicated to only one tenant (user) or group of related tenants, they are in a private cloud. The private cloud is typically on-site (or on-prem or on-premises in IT lingo), but it could be off-site, as well. The owner is responsible for the management and maintenance of the servers and for planning for future capacity and performance to meet the needs of its users. This planning usually involves long lead times to add additional hardware and services (electricity, broadband, cooling, etc.) to meet the future demand.
What is Public Cloud?
In a public cloud, the servers are shared between multiple unrelated tenants (users). A public cloud is off-site (or off-prem or off-premises). Public clouds are typically owned by a vendor who sells access to servers that are co-located with many servers providing services to many users. Users contract with the vendor for the services they need. The user isn’t responsible for capital expenses, data is backed up regularly, and customers only have to pay for the resources they use. If their needs change, they can add or remove capacity very quickly and easily by requesting changes from the vendor who reserves additional resources to meet demand from its clients.
Differences: Private Cloud vs Public Cloud
On-premises or off-premises
Capital cost to set up and maintain
No capital cost
High IT overhead
Low IT overhead
Fully private network
Possible under utilization
Scalable with demand
Which Cloud is Right For You?
If you’re a big company or organization with special computing needs, you know whether you need to keep your data in a private data center. For businesses in certain industries, for example, government or medical, the decision to host in a private or public cloud will be determined by regulation. These requirements could mandate the use of a private cloud, but there are more and more specialized off-premises clouds with the necessary security and management to support regulated industries.
The public cloud is the cloud of choice for those whose needs don’t yet include building a dedicated data center, or who like the flexibility, scalability, and cost of public cloud offerings. If the organization has a global reach, it also provides an easy way to connect with customers in diverse locations with minimal effort.
The growing number of vendors and variety of public cloud services indicate that the trend is definitely in favor of using the public cloud when possible. Even big customers are increasingly using the public cloud due to its undeniable advantages in rapid scaling, flexibility, and cost savings.
Enter Multi Cloud and Hybrid Cloud
For some, a combination of clouds could provide the best solution. Using multiple public cloud vendors (multi cloud) for independent tasks and duties can provide redundancy and cost savings. The data centers and infrastructure can be spread out geographically to decrease the risk of service loss or disaster, and it makes sense financially to store the second or third copy of data with an additional vendor that offers a good and reliable service at a lower cost.
Hybrid cloud refers to the presence of multiple deployment types (public or private) with some form of integration or orchestration between them. The hybrid cloud differs from multi cloud in that in the hybrid cloud the components work together while in the multi cloud they remain separate. An organization might choose the hybrid cloud to have the ability to rapidly expand its storage or computing when necessary for planned or unplanned spikes in demand, such as occur during holiday seasons for a retailer, or during a service outage at the primary data center. We wrote about the hybrid cloud in a previous post, Confused About the Hybrid Cloud? You’re Not Alone.
Choose the Best Cloud Model For Your Needs
For businesses in highly regulated industries, the decision to host in a private or public cloud will likely be determined by regulation. For most businesses and organizations, the important factors in selecting a cloud will be cost, accessibility, reliability, and scalability. Whether the private or public cloud, or some combination, offers the best solution for your needs will depend on your type of business, regulations, budget, and future plans. The good news is that there are a wide variety of choices to meet just about any use case or budget.
At the beginning of summer, we put B2 Copy File APIs into beta. We’re pleased to announce the end of the beta and that the APIs are all now public!
We had a number of people use the beta features and give us great feedback. In fact, because of the feedback, we were able to implement an incremental feature.
New Feature — Bucket to Bucket Copies
Initially, our guidance was that these new APIs were only to be used within the same B2 bucket, but in response to customer and partner feedback, we added the ability to copy files from one bucket to another bucket within the same account.
To use this new feature with b2_copy_file, simply pass in the destinationBucketId where the new file copy will be stored. If this is not set, the copied file will simply default to the same bucket as the source file. Within b2_copy_part, there is a subtle difference in that the Source File ID can belong to a different bucket than the Large File ID.
For the complete API documentation, refer to the Backblaze B2 docs online:
In a literal sense, the new capability enables you to create a new file (or new part of a large file) that is a copy of an existing file (or range of an existing file). You can either copy over the source file’s metadata or specify new metadata for the new file that is created. This all occurs without having to download or re-upload any data.
This has been one of our most requested features as it unlocks:
Rename/Re-organize. The new capabilities give customers the ability to re-organize their files without having to download and re-upload. This is especially helpful when trying to mirror the contents of a file system to B2.
Synthetic Backup. With the ability to copy ranges of a file, users can now leverage B2 for synthetic backup, i.e. uploading a full backup but then only uploading incremental changes (as opposed to re-uploading the whole file with every change). This is particularly helpful for applications like backing up VMs where re-uploading the entirety of the file every time it changes can be inefficient.
While many of our customers directly leverage our APIs, just as many use 3rd party software (B2 Integration Partners) to facilitate storage into B2. Our Integration Partners were very helpful and active in giving us feedback during the beta. Some highlights of those that are already supporting the copy_file feature:
Transmit: macOS file transfer/cloud storage application that supports high speed copying to data between your Mac and more than 15 different cloud services.
RClone: Rsync for cloud storage is a powerful command line tool to copy and sync files to and from local disk, SFTP servers, and many cloud storage providers.
Mountain Duck: Mount server and cloud storage as a disk (Finder on macOS; File Explorer on Windows). With Mountain Duck, you can also open remote files with any application as if the file were on a local volume.
Cyberduck: File transfer/cloud storage browser for Mac and Windows with support for more than 10 different cloud services.
At the end of Q2 2019, Backblaze was using 108,660 hard drives to store data. For our evaluation we remove from consideration those drives that were used for testing purposes and those drive models for which we did not have at least 60 drives (see why below). This leaves us with 108,461 hard drives. The table below covers what happened in Q2 2019.
Notes and Observations
If a drive model has a failure rate of 0 percent, it means there were no drive failures of that model during Q2 2019 — lifetime failure rates are later in this report. The two drives listed with zero failures in Q2 were the 4 TB and 14 TB Toshiba models. The Toshiba 4 TB drive doesn’t have a large enough number of drives or drive days to be statistically reliable, but only one drive of that model has failed in the last three years. We’ll dig into the 14 TB Toshiba drive stats a little later in the report.
There were 199 drives (108,660 minus 108,461) that were not included in the list above because they were used as testing drives or we did not have at least 60 of a given drive model. We now use 60 drives of the same model as the minimum number when we report quarterly, yearly, and lifetime drive statistics as there are 60 drives in all newly deployed Storage Pods — older Storage Pod models had a minimum of 45.
2,000 Backblaze Storage Pods? Almost…
We currently have 1,980 Storage Pods in operation. All are version 5 or version 6 as we recently gave away nearly all of the older Storage Pods to folks who stopped by our Sacramento storage facility. Nearly all, as we have a couple in our Storage Pod museum. There are currently 544 version 5 pods each containing 45 data drives, and there are 1436 version 6 pods each containing 60 data drives. The next time we add a Backblaze Vault, which consists of 20 Storage Pods, we will have 2,000 Backblaze Storage Pods in operation.
Goodbye Western Digital
In Q2 2019, the last of the Western Digital 6 TB drives were retired from service. The average age of the drives was 50 months. These were the last of our Western Digital branded data drives. When Backblaze was first starting out, the first data drives we deployed en masse were Western Digital Green 1 TB drives. So, it is with a bit of sadness to see our Western Digital data drive count go to zero. We hope to see them again in the future.
Hello “Western Digital”
While the Western Digital brand is gone, the HGST brand (owned by Western Digital) is going strong as we still have plenty of the HGST branded drives, about 20 percent of our farm, ranging in size from 4 to 12 TB. In fact, we added over 4,700 HGST 12 TB drives in this quarter.
This just in; rumor has it there are twenty 14 TB Western Digital Ultrastar drives getting readied for deployment and testing in one of our data centers. It appears Western Digital has returned: stay tuned.
Goodbye 5 TB Drives
Back in Q1 2015, we deployed 45 Toshiba 5 TB drives. They were the only 5 TB drives we deployed as the manufacturers quickly moved on to larger capacity drives, and so did we. Yet, during their four plus years of deployment only two failed, with no failures since Q2 of 2016 — three years ago. This made it hard to say goodbye, but buying, stocking, and keeping track of a couple of 5 TB spare drives was not optimal, especially since these spares could not be used anywhere else. So yes, the Toshiba 5 TB drives were the odd ducks on our farm, but they were so good they got to stay for over four years.
Hello Again Toshiba 14 TB Toshiba Drives
We’ve mentioned the Toshiba 14 TB drives in previous reports, now we can dig in a little deeper given that they have been deployed almost nine months and we have some experience working with them. These drives got off to a bit of a rocky start, with six failures in the first three months of being deployed. Since then, there has been only one additional failure, with no failures reported in Q2 2019. The result is that the lifetime annualized failure rate for the Toshiba 14 TB drives has decreased to a very respectable 0.78% as shown in the lifetime table in the following section.
Lifetime Hard Drive Stats
The table below shows the lifetime failure rates for the hard drive models we had in service as of June 30, 2019. This is over the period beginning in April 2013 and ending June 30, 2019.
The Hard Drive Stats Data
The complete data set used to create the information used in this review is available on our Hard Drive Test Data web page. You can download and use this data for free for your own purpose. All we ask are three things: 1) You cite Backblaze as the source if you use the data, 2) You accept that you are solely responsible for how you use the data, and, 3) You do not sell this data to anyone; it is free. Good luck and let us know if you find anything interesting.
Ah, the iconic 3.5″ hard drive, now approaching a massive 16TB of storage capacity. Backblaze storage pods fit 60 of these drives in a single pod, and with well over 750 petabytes of customer data under management in our data centers, we have a lot of hard drives under management.
Yet most of us have just one, or only a few of these massive drives at a time storing our most valuable data. Just how safe are those hard drives in your office or studio? Have you ever thought about all the awful, terrible things that can happen to a hard drive? And what are they, exactly?
It turns out there are a host of obvious physical dangers, but also other, less obvious, errors that can affect the data stored on your hard drives, as well.
Dividing by One
It’s tempting to store all of your content on a single hard drive. After all, the capacity of these drives gets larger and larger, and they offer great performance of up to 150 MB/s. It’s true that flash-based hard drives are far faster, but the dollars per gigabyte price is also higher, so for now, the traditional 3.5″ hard drive holds most data today.
However, having all of your precious content on a single, spinning hard drive is a true tightrope without a net experience. Here’s why.
Drivesaver Failure Analysis by the Numbers
I asked our friends at Drivesavers, specialists in recovering data from drives and other storage devices, for some analysis of the hard drives brought into their labs for recovery. What were the primary causes of failure?
Reason One: Media Damage
The number one reason, accounting for 70 percent of failures, is media damage, including full head crashes.
Modern hard drives stuff multiple, ultra thin platters inside that 3.5 inch metal package. These platters spin furiously at 5400 or 7200 revolutions per minute — that’s 90 or 120 revolutions per second! The heads that read and write magnetic data on them sweep back and forth only 6.3 micrometers above the surface of those platters. That gap is about 1/12th the width of a human hair and a miracle of modern technology to be sure. As you can imagine, a system with such close tolerances is vulnerable to sudden shock, as evidenced by Drivesavers’ results.
This damage occurs when the platters receive shock, i.e. physical damage from impact to the drive itself. Platters have been known to shatter, or have damage to their surfaces, including a phenomenon called head crash, where the flying heads slam into the surface of the platters. Whatever the cause, the thin platters holding 1s and 0s can’t be read.
It takes a surprisingly small amount of force to generate a lot of shock energy to a hard drive. I’ve seen drives fail after simply tipping over when stood on end. More typically, drives are accidentally pushed off of a desktop, or dropped while being carried around.
A drive might look fine after a drop, but the damage may have been done. Due to their rigid construction, heavy weight, and how often they’re dropped on hard, unforgiving surfaces, these drops can easily generate the equivalent of hundreds of g-forces to the delicate internals of a hard drive.
To paraphrase an old (and morbid) parachutist joke, it’s not the fall that gets you, it’s the sudden stop!
Reason Two: PCB Failure
The next largest cause is circuit board failure, accounting for 18 percent of failed drives. Printed circuit boards (PCBs), those tiny green boards seen on the underside of hard drives, can fail in the presence of moisture or static electric discharge like any other circuit board.
Reason Three: Stiction
Next up is stiction (a portmanteau of friction and sticking), which occurs when the armatures that drive those flying heads actually get stuck in place and refuse to operate, usually after a long period of disuse. Drivesavers found that stuck armatures accounted for 11 percent of hard drive failures.
It seems counterintuitive that hard drives sitting quietly in a dark drawer might actually contribute to its failure, but I’ve seen many older hard drives pulled from a drawer and popped into a drive carrier or connected to power just go thunk. It does appear that hard drives like to be connected to power and constantly spinning and the numbers seem to bear this out.
Reason Four: Motor Failure
The last, and least common cause of hard drive failure, is hard drive motor failure, accounting for only 1 percent of failures, testament again to modern manufacturing precision and reliability.
Mitigating Hard Drive Failure Risk
So now that you’ve seen the gory numbers, here are a few recommendations to guard against the physical causes of hard drive failure.
1. Have a physical drive handling plan and follow it rigorously
If you must keep content on single hard drives in your location, make sure your team follows a few guidelines to protect against moisture, static electricity, and drops during drive handling. Keeping the drives in a dry location, storing the drives in static bags, using static discharge mats and wristbands, and putting rubber mats under areas where you’re likely to accidentally drop drives can all help.
It’s worth reviewing how you physically store drives, as well. Drivesavers tells us that the sudden impact of a heavy drawer of hard drives slamming home or yanked open quickly might possibly damage hard drives!
2. Spread failure risk across more drives and systems
Improving physical hard drive handling procedures is only a small part of a good risk-reducing strategy. You can immediately reduce the exposure of a single hard drive failure by simply keeping a copy of that valuable content on another drive.This is a common approach for videographers moving content from cameras shooting in the field back to their editing environment. By simply copying content over from one fast drive to another, the odds of both drives failing at once are less likely. This is certainly better than keeping content on only a single drive, but definitely not a great long-term solution.
Multiple drive NAS and RAID systems reduce the impact of failing drives even further. A RAID 6 system composed of eight drives not only has much faster read and write performance than a single drive, but two of its drives can fail and still serve your files, giving you time to replace those failed drives.
Mitigating Data Corruption Risk
The Risk of Bit Flips
Beyond physical damage, there’s another threat to the files stored on hard disks: small, silent bit flip errors often called data corruption or bit rot.
Bit rot errors occur when individual bits in a stream of data in files change from one state to another (positive or negative, 0 to 1, and vice versa). These errors can happen to hard drive and flash storage systems at rest, or be introduced as a file is copied from one hard drive to another.
While hard drives automatically correct single-bit flips on the fly, larger bit flips can introduce a number of errors. This can either cause the program accessing them to halt or throw an error, or perhaps worse, lead you to think that the file with the errors is fine!
Flash drives are not immune either. Bianca Shroeder recently published a similar study of flash drives, Flash Reliability in Production: The Expected and the Unexpected, and found that “…between 20-63% of drives experienced at least one of the (unrecoverable read errors) during the time it was in production. In addition, between 2-6 out of 1,000 drive days were affected.”
“These UREs are almost exclusively due to bit corruptions that ECC cannot correct. If a drive encounters a URE, the stored data cannot be read. This either results in a failed read in the user’s code, or if the drives are in a RAID group that has replication, then the data is read from a different drive.”
Exactly how prevalent bit flips are is a controversial subject, but if you’ve ever retrieved a file from an old hard drive or RAID system and see sparkles in video, corrupt document files, or lines or distortions in pictures, you’ve seen the results of these errors.
Protecting Against Bit Flip Errors
There are many approaches to catching and correcting bit flip errors. From a system designer standpoint they usually involve some combination of multiple disk storage systems, multiple copies of content, data integrity checks and corrections, including error-correcting code memory, physical component redundancy, and a file system that can tie it all together.
Backblaze has built such a system, and uses a number of techniques to detect and correct file degradation due to bit flips and deliver extremely high data durability and integrity, often in conjunction with Reed-Solomon erasure codes.
Thanks to the way object storage and Backblaze B2 works, files written to B2 are always retrieved exactly as you originally wrote them. If a file ever changes from the time you’ve written it, say, due to bit flip errors, it will either be reproduced from a redundant copy of your file, or even mathematically reconstructed with erasure codes.
So the simplest, and certainly least expensive way to get bit flip protection for the content sitting on your hard drives is to simply have another copy on cloud storage.
With some thought, you can apply these protection steps to your environment and get the best of both worlds: the performance of your content on fast, local hard drives, and the protection of having a copy on object storage offsite with the ultimate data integrity.
When shopping for a cloud storage provider, customers should ask a few key questions of potential storage providers. In addition to inquiring about storage cost, data center location, and features and capabilities of the service, they’re going to want to know the numbers for two key metrics for measuring cloud storage performance: durability and availability.
Think of durability as a measurement of how healthy and resilient your data is. You want your data to be as intact and pristine on the day you retrieve it as it was on the day you stored it.
There are a number of ways that data can lose its integrity.
1. Data loss
Data loss can happen through human accident, natural or manmade disaster, or even malicious action out of your control. Whether you store data in your home, office, or with a cloud provider, that data needs to be protected as much as possible from any event that could damage or destroy it. If your data is on a computer, external drive, or NAS in a home or office, you obviously want to keep the computing equipment away from water sources and other environmental hazards. You also have to consider the likelihood of fire, theft, and accidental deletion.
Data center managers go to great lengths to protect data under their care. That care starts with locating a facility in as safe a geographical location as possible, having secure facilities with controlled access, and monitoring and maintaining the storage infrastructure (chassis, drives, cables, power, cooling, etc.)
2. Data corruption
Data on traditional spinning hard drive systems can degrade with time, have errors introduced during copying, or become corrupted in any number of ways. File and operating systems and utilities have ways to double check that data is handled correctly during common file and data handling operations, but corruption can sneak into a system if it isn’t monitored closely or if the storage system doesn’t specifically check for such errors such as is common with systems with ECC (Error Correcting Code) RAM. Object storage systems will commonly monitor for any changes in the data, and often will automatically repair or provide warnings when data has been changed.
How is Durability Measured?
Object storage providers express data durability as an annual percentage in nines, as in two nines before the decimal point and as many nines as warranted after the decimal point. For example, eleven nines of durability is expressed as 99.999999999%.
Of the major vendors, Azure claims 12 nines and even 16 nines durability for some services, while Amazon S3, Google Cloud Platform and Backblaze offer 11 nines, or 99.999999999% annual durability.
What this means is that those services are promising that your data will remain intact while it is under their care, and no more than 0.000000001 percent of your data will be lost in a year (in the case of eleven nines annual durability).
How is Durability Maintained?
Generally, there are two ways to maintain data durability. The first approach is to use software algorithms and metadata such as checksums to detect corruption of the data. If corruption is found, the data can be healed using the stored information. Examples of these approaches are erasure coding and Reed-Solomon coding.
Another tried and true method to ensure data integrity is to simply store multiple copies of the data in multiple locations. This is known as redundancy. This approach allows data to survive the loss or corruption of data in one or even multiple locations through accident, war, theft, or any manner of natural disaster or alien invasion. All that’s required is that at least one copy of the data remains intact. The odds for data survival increase with the number of copies stored, with multiple locations an important multiplying factor. If multiple copies (and locations) are lost, well, that means we’re all in a lot of trouble and perhaps there might be other things to think about than the data you have stored.
The best approach is a combination of the above two approaches. Home data storage appliances such as NAS can provide the algorithmic protection through RAID and other technologies. If you store at least one copy of your data in a different location than your office or home than you’ve got redundancy covered, as well. The redundant location can be as simple as a USB or hard drive you regularly drop off in your old bedroom’s closet at mom’s house or a data center in another state that gets a daily backup from your office computer or network.
What is Availability?
If durability can be compared to how well your picnic basket contents survived the automobile trip to the beach, then you might get a good understanding of availability if you subsequently stand and watch that basket being carried out to sea by a wave. The chicken salad sandwich in the basket might be in great shape but you won’t be enjoying it.
Availability is how much time the storage provider guarantees that your data and services are available to you. This is usually documented as a percent of time per year, e.g. 99.9% (or three nines) means that your data will be available to you from the data center and you will be unable to access the data for no more than about ten minutes per week, or 8.77 hours per year. Data centers often plan downtime for maintenance, which is acceptable as long as you have no immediate need of the data during those maintenance windows.
What availability is suitable for your data depends, of course, on how you’re using it. If you’re running an e-commerce site, reservation service, or a site that requires real-time transactions, then availability can be expressed in real dollars for any unexpected downtime. If you are simply storing backups, or serving media for a website that doesn’t get a lot of traffic, you probably can live with the service being unavailable on occasion.
There are of course no guarantees for connectivity issues that affect availability that are out of the control of the storage provider, such as internet outages, bad connections, or power losses affecting your connection to the storage provider.
Guarantees of Availability
Your cloud service provider should both publish and guarantee availability. Much like an insurance policy, the guarantee should be in terms that compensate you if the provider falls short of the guaranteed availability metrics. Naturally, the better the guarantee and the greater the availability, the more reliable and expensive the service will be.
Be sure to read the service level agreement (SLA) closely, to see how your vendor defines availability. A provider might define zero downtime if a single internet client can access even one service, while others might require that multiple internet service providers and countries can access all services to be defined as available.
The Bottom Line on Data Durability and Availability
The bottom line is that no number of nines can absolutely protect your data. Human error or acts of nature can always intercede to make the best plans to protect data go awry. The decision you should make is to decide how important the data is to you and whether you can afford to not have access to it temporarily or to lose it completely. That will guide what strategy or vendor you should use to protect that data.
Generally, having multiple copies of your data in different places, using reliable vendors for storage providers, and making sure that the infrastructure storing your data and your access to it will be supported (power, service payments, etc), will go a long way in ensuring that your data will continue to be stable and there when you need it.
A lot has changed in the four years since Brian Beach wrote a post announcing Backblaze Vaults, our software architecture for cloud data storage. Just looking at how the major statistics have changed, we now have over 100,000 hard drives in our data centers instead of the 41,000 mentioned in the post video. We have three data centers (soon four) instead of one data center. We’re approaching one exabyte of data stored for our customers (almost seven times the 150 petabytes back then), and we’ve recovered over 41 billion files for our customers, up from the 10 billion in the 2015 post.
In the original post, we discussed having durability of seven nines. Shortly thereafter, it was upped to eight nines. In July of 2018, we took a deep dive into the calculation and found our durability closer to eleven nines (and went into detail on the calculations used to arrive at that number). And, as followers of our Hard Drive Stats reports will be interested in knowing, we’ve just started using our first 16 TB drives, which are twice the size of the biggest drives we used back at the time of this post — then a whopping eight TB.
We’ve updated the details here and there in the text from the original post that was published on our blog on March 11, 2015. We’ve left the original 135 comments intact, although some of them might be non sequiturs after the changes to the post. We trust that you will be able to sort out the old from the new and make sense of what’s changed. If not, please add a comment and we’ll be happy to address your questions.
Storage Vaults form the core of Backblaze’s cloud services. Backblaze Vaults are not only incredibly durable, scalable, and performant, but they dramatically improve availability and operability, while still being incredibly cost-efficient at storing data. Back in 2009, we shared the design of the original Storage Pod hardware we developed; here we’ll share the architecture and approach of the cloud storage software that makes up a Backblaze Vault.
Backblaze Vault Architecture for Cloud Storage
The Vault design follows the overriding design principle that Backblaze has always followed: keep it simple. As with the Storage Pods themselves, the new Vault storage software relies on tried and true technologies used in a straightforward way to build a simple, reliable, and inexpensive system.
A Backblaze Vault is the combination of the Backblaze Vault cloud storage software and the Backblaze Storage Pod hardware.
Putting The Intelligence in the Software
Another design principle for Backblaze is to anticipate that all hardware will fail and build intelligence into our cloud storage management software so that customer data is protected from hardware failure. The original Storage Pod systems provided good protection for data and Vaults continue that tradition while adding another layer of protection. In addition to leveraging our low-cost Storage Pods, Vaults take advantage of the cost advantage of consumer-grade hard drives and cleanly handle their common failure modes.
Distributing Data Across 20 Storage Pods
A Backblaze Vault is comprised of 20 Storage Pods, with the data evenly spread across all 20 pods. Each Storage Pod in a given vault has the same number of drives, and the drives are all the same size.
Drives in the same drive position in each of the 20 Storage Pods are grouped together into a storage unit we call a tome. Each file is stored in one tome and is spread out across the tome for reliability and availability.
Every file uploaded to a Vault is divided into pieces before being stored. Each of those pieces is called a shard. Parity shards are computed to add redundancy, so that a file can be fetched from a vault even if some of the pieces are not available.
Each file is stored as 20 shards: 17 data shards and three parity shards. Because those shards are distributed across 20 Storage Pods, the Vault is resilient to the failure of a Storage Pod.
Files can be written to the Vault when one pod is down and still have two parity shards to protect the data. Even in the extreme and unlikely case where three Storage Pods in a Vault lose power, the files in the vault are still available because they can be reconstructed from any of the 17 pods that are available.
Each of the drives in a Vault has a standard Linux file system, ext4, on it. This is where the shards are stored. There are fancier file systems out there, but we don’t need them for Vaults. All that is needed is a way to write files to disk and read them back. Ext4 is good at handling power failure on a single drive cleanly without losing any files. It’s also good at storing lots of files on a single drive and providing efficient access to them.
Compared to a conventional RAID, we have swapped the layers here by putting the file systems under the replication. Usually, RAID puts the file system on top of the replication, which means that a file system corruption can lose data. With the file system below the replication, a Vault can recover from a file system corruption because a single corrupt file system can lose at most one shard of each file.
Creating Flexible and Optimized Reed-Solomon Erasure Coding
Just like RAID implementations, the Vault software uses Reed-Solomon erasure coding to create the parity shards. But, unlike Linux software RAID, which offers just one or two parity blocks, our Vault software allows for an arbitrary mix of data and parity. We are currently using 17 data shards plus three parity shards, but this could be changed on new vaults in the future with a simple configuration update.
The beauty of Reed-Solomon is that we can then re-create the original file from any 17 of the shards. If one of the original data shards is unavailable, it can be re-computed from the other 16 original shards, plus one of the parity shards. Even if three of the original data shards are not available, they can be re-created from the other 17 data and parity shards. Matrix algebra is awesome!
Handling Drive Failures
The reason for distributing the data across multiple Storage Pods and using erasure coding to compute parity is to keep the data safe and available. How are different failures handled?
If a disk drive just up and dies, refusing to read or write any data, the Vault will continue to work. Data can be written to the other 19 drives in the tome, because the policy setting allows files to be written as long as there are two parity shards. All of the files that were on the dead drive are still available and can be read from the other 19 drives in the tome.
When a dead drive is replaced, the Vault software will automatically populate the new drive with the shards that should be there; they can be recomputed from the contents of the other 19 drives.
A Vault can lose up to three drives in the same tome at the same moment without losing any data, and the contents of the drives will be re-created when the drives are replaced.
Handling Data Corruption
Disk drives try hard to correctly return the data stored on them, but once in a while they return the wrong data, or are just unable to read a given sector.
Every shard stored in a Vault has a checksum, so that the software can tell if it has been corrupted. When that happens, the bad shard is recomputed from the other shards and then re-written to disk. Similarly, if a shard just can’t be read from a drive, it is recomputed and re-written.
Conventional RAID can reconstruct a drive that dies, but does not deal well with corrupted data because it doesn’t checksum the data.
Each vault is assigned a number. We carefully designed the numbering scheme to allow for a lot of vaults to be deployed, and designed the management software to handle scaling up to that level in the Backblaze data centers.
The overall design scales very well because file uploads (and downloads) go straight to a vault, without having to go through a central point that could become a bottleneck.
There is an authority server that assigns incoming files to specific Vaults. Once that assignment has been made, the client then uploads data directly to the Vault. As the data center scales out and adds more Vaults, the capacity to handle incoming traffic keeps going up. This is horizontal scaling at its best.
We could deploy a new data center with 10,000 Vaults holding 16TB drives and it could accept uploads fast enough to reach its full capacity of 160 exabytes in about two months!
Backblaze Vault Benefits
The Backblaze Vault architecture has six benefits:
1. Extremely Durable
The Vault architecture is designed for 99.999999% (eight nines) annual durability (now 11 nines — Editor). At cloud-scale, you have to assume hard drives die on a regular basis, and we replace about 10 drives every day. We have published a variety of articles sharing our hard drive failure rates.
The beauty with Vaults is that not only does the software protect against hard drive failures, it also protects against the loss of entire Storage Pods or even entire racks. A single Vault can have three Storage Pods — a full 180 hard drives — die at the exact same moment without a single byte of data being lost or even becoming unavailable.
2. Infinitely Scalable
A Backblaze Vault is comprised of 20 Storage Pods, each with 60 disk drives, for a total of 1200 drives. Depending on the size of the hard drive, each vault will hold:
12TB hard drives => 12.1 petabytes/vault (Deploying today.) 14TB hard drives => 14.2 petabytes/vault (Deploying today.) 16TB hard drives => 16.2 petabytes/vault (Small-scale testing.) 18TB hard drives => 18.2 petabytes/vault (Announced by WD & Toshiba) 20TB hard drives => 20.2 petabytes/vault (Announced by Seagate)
At our current growth rate, Backblaze deploys one to three Vaults each month. As the growth rate increases, the deployment rate will also increase. We can incrementally add more storage by adding more and more Vaults. Without changing a line of code, the current implementation supports deploying 10,000 Vaults per location. That’s 90 exabytes of data in each location. The implementation also supports up to 1,000 locations, which enables storing a total of 90 zettabytes! (Also knowWithout changing a line of code, the current implementation supports deploying 10,000 Vaults per location. That’s 160 exabytes of data in each location. The implementation also supports up to 1,000 locations, which enables storing a total of 160 zettabytes! (Also known as 160,000,000,000,000 GB.)
3. Always Available
Data backups have always been highly available: if a Storage Pod was in maintenance, the Backblaze online backup application would contact another Storage Pod to store data. Previously, however, if a Storage Pod was unavailable, some restores would pause. For large restores this was not an issue since the software would simply skip the Storage Pod that was unavailable, prepare the rest of the restore, and come back later. However, for individual file restores and remote access via the Backblaze iPhone and Android apps, it became increasingly important to have all data be highly available at all times.
The Backblaze Vault architecture enables both data backups and restores to be highly available.
With the Vault arrangement of 17 data shards plus three parity shards for each file, all of the data is available as long as 17 of the 20 Storage Pods in the Vault are available. This keeps the data available while allowing for normal maintenance and rare expected failures.
4. Highly Performant
The original Backblaze Storage Pods could individually accept 950 Mbps (megabits per second) of data for storage.
The new Vault pods have more overhead, because they must break each file into pieces, distribute the pieces across the local network to the other Storage Pods in the vault, and then write them to disk. In spite of this extra overhead, the Vault is able to achieve 1,000 Mbps of data arriving at each of the 20 pods.
This capacity required a new type of Storage Pod that could handle this volume. The net of this: a single Vault can accept a whopping 20 Gbps of data.
Because there is no central bottleneck, adding more Vaults linearly adds more bandwidth.
5. Operationally Easier
When Backblaze launched in 2008 with a single Storage Pod, many of the operational analyses (e.g. how to balance load) could be done on a simple spreadsheet and manual tasks (e.g. swapping a hard drive) could be done by a single person. As Backblaze grew to nearly 1,000 Storage Pods and over 40,000 hard drives, the systems we developed to streamline and operationalize the cloud storage became more and more advanced. However, because our system relied on Linux RAID, there were certain things we simply could not control.
With the new Vault software, we have direct access to all of the drives and can monitor their individual performance and any indications of upcoming failure. And, when those indications say that maintenance is needed, we can shut down one of the pods in the Vault without interrupting any service.
6. Astoundingly Cost Efficient
Even with all of these wonderful benefits that Backblaze Vaults provide, if they raised costs significantly, it would be nearly impossible for us to deploy them since we are committed to keeping our online backup service affordable for completely unlimited data. However, the Vault architecture is nearly cost neutral while providing all these benefits.
When we were running on Linux RAID, we used RAID6 over 15 drives: 13 data drives plus two parity. That’s 15.4% storage overhead for parity.
With Backblaze Vaults, we wanted to be able to do maintenance on one pod in a vault and still have it be fully available, both for reading and writing. And, for safety, we weren’t willing to have fewer than two parity shards for every file uploaded. Using 17 data plus three parity drives raises the storage overhead just a little bit, to 17.6%, but still gives us two parity drives even in the infrequent times when one of the pods is in maintenance. In the normal case when all 20 pods in the Vault are running, we have three parity drives, which adds even more reliability.
Backblaze’s cloud storage Vaults deliver 99.999999% (eight nines) annual durability (now 11 nines — Editor), horizontal scalability, and 20 Gbps of per-Vault performance, while being operationally efficient and extremely cost effective. Driven from the same mindset that we brought to the storage market with Backblaze Storage Pods, Backblaze Vaults continue our singular focus of building the most cost-efficient cloud storage available anywhere.
• • •
Note: This post was updated from the original version posted on March 11, 2015.
The cookie settings on this website are set to "allow cookies" to give you the best browsing experience possible. If you continue to use this website without changing your cookie settings or you click "Accept" below then you are consenting to this.
