All posts by Helen Lynn

Designing distinctive Raspberry Pi products

Post Syndicated from Helen Lynn original https://www.raspberrypi.org/blog/designing-distinctive-raspberry-pi-products/

If you have one of our official cases, keyboards or mice, or if you’ve visited the Raspberry Pi Store in Cambridge, UK, then you know the work of Kinneir Dufort. Their design has become a part of our brand that’s recognised the world over. Here’s an account from the team there of their work with us.

Over the last six years, our team at Kinneir Dufort have been privileged to support Raspberry Pi in the design and development of many of their products and accessories. 2019 has been another landmark year in the incredible Raspberry Pi story, with the opening of the Raspberry Pi store in February, the launch of the official keyboard and mouse in April, followed by the launch of Raspberry Pi 4 in June.



We first met Eben, Gordon and James in 2013 when we were invited to propose design concepts for an official case for Raspberry Pi Model B. For the KD team, this represented a tremendously exciting opportunity: here was an organisation with a clear purpose, who had already started making waves in the computing and education market, and who saw how design could be a potent ingredient in the presentation and communication of the Raspberry Pi proposition.

Alongside specific design requirements for the Model B case, the early design work also considered the more holistic view of what the 3D design language of Raspberry Pi should be. Working closely with the team, we started to define some key design principles which have remained as foundations for all the products since:

  • Visibility of the board as the “hero” of the product
  • Accessibility to the board, quickly and simply, without tools
  • Adaptability for different uses, including encouragement to “hack” the case
  • Value expressed through low cost and high quality
  • Simplicity of form and detailing
  • Boldness to be unique and distinctively “Raspberry Pi”

Whilst maintaining a core of consistency in the product look and feel, these principles have been applied with different emphases to suit each product’s needs and functions. The Zero case, which started as a provocative “shall we do this?” sketch visual sent to the team by our Senior Designer John Cowan-Hughes after the original case had started to deliver a return on investment, was all about maximum simplicity combined with adaptability via its interchangeable lids.

Photo of three Raspberry Pi Zero cases from three different angles, showing the lid of a closed case, the base of a closed case, and an open case with an apparently floating lid and a Raspberry Pi Zero visible inside.

The ‘levitating lid’ version of the Zero case is not yet publically available

Later, with the 3A+ case, we started with the two-part case simplicity of the Zero case and applied careful detailing to ensure that we could accommodate access to all the connectors without overcomplicating the injection mould tooling. On Raspberry Pi 4, we retained the two-part simplicity in the case, but introduced new details, such as the gloss chamfer around the edge of the case, and additional material thickness and weight to enhance the quality and value for use with Raspberry Pi’s flagship product.

After the success of the KD design work on Raspberry Pi cases, the KD team were asked to develop the official keyboard and mouse. Working closely with the Raspberry Pi team, we explored the potential for adding unique features but, rightly, chose to do the simple things well and to use design to help deliver the quality, value and distinctiveness now integrally associated with Raspberry Pi products. This consistency of visual language, when combined with the Raspberry Pi 4 and its case, has seen the creation of a Raspberry Pi as a new type of deconstructed desktop computer which, in line with Raspberry Pi’s mission, changes the way we think about, and engage with, computers.


The launch of the Cambridge store in February – another bold Raspberry Pi move which we were also delighted to support in the early planning and design stages – provides a comprehensive view of how all the design elements work together to support the communication of the Raspberry Pi message. Great credit should go to the in-house Raspberry Pi design team for their work in the development and implementation of the visual language of the brand, so beautifully evident in the store.

Small tabletop model of the side walls, rear walls, front windows, and floor of the Raspberry Pi Store. The model is annotated with handwritten Post-It notes in a variety of colours.

An early sketch model of the Raspberry Pi Store

In terms of process, at KD we start with a brief – typically discussed verbally with the Raspberry Pi team – which we translate into key objectives and required features. From there, we generally start to explore ideas with sketches and basic mock-ups, progressively reviewing, testing and iterating the concepts.

Top-down photo of a desk covered with white paper on which are a couple of Raspberry Pis and several cases. The hands of someone sketching red and white cases on the paper are visible. Also visible are the hands of someone measuring something with digital calipers, beside a laptop on the screen of which is a CAD model of a Raspberry Pi case.

Sketching and modelling and reviewing

For evaluating designs for products such as the cases, keyboard and mouse, we make considerable use of our in-house 3D printing resources and prototyping team. These often provide a great opportunity for the Raspberry Pi team to get hands on with the design – most notably when Eben took a hacksaw to one of our lovingly prepared 3D-printed prototypes!

Phone photo of Eben sitting at a desk and hacksawing a white 3D-printed prototype Raspberry Pi case

EBEN YOUR FINGERS

Sometimes, despite hours of reviewing sketches and drawings, and decades of experience, it’s not until you get hands-on with the design that you can see further improvements, or you suddenly spot a new approach – what if we do this? And that’s the great thing about how our two teams work together: always seeking to share and exchange ideas, ultimately to produce better products.

Photo of three people sitting at a table in an office handling and discussing 3D-printed Raspberry Pi case prototypes

There’s no substitute for getting hands-on

Back to the prototype! Once the prototype design is agreed, we work with 3D CAD tools and progress the design towards a manufacturable solution, collaborating closely with injection moulding manufacturing partners T-Zero to optimise the design for production efficiency and quality of detailing.

One important aspect that underpins all our design work is that we always start with consideration for the people we are designing for – whether that’s a home user setting up a media centre, an IT professional using Raspberry Pi as a web server, a group of schoolchildren building a weather station, or a parent looking to encourage their kid to code.

Engagement with the informed, proactive and enthusiastic online Raspberry Pi community is a tremendous asset. The instant feedback, comments, ideas and scrutiny posted on Raspberry Pi forums is powerful and healthy; we listen and learn from this, taking the insight we gain into each new product that we develop. Of course, with such a wide and diverse community, it’s not easy to please everyone all of the time, but that won’t stop us trying – keep your thoughts and feedback coming to [email protected]!

If you’d like to know more about KD, or the projects we work on, check out our blog posts and podcasts at www.kinneirdufort.com.

The post Designing distinctive Raspberry Pi products appeared first on Raspberry Pi.

Estefannie’s Jurassic Park goggles

Post Syndicated from Helen Lynn original https://www.raspberrypi.org/blog/estefannies-jurassic-park-goggles/

When we invited Estefannie Explains It All to present at Coolest Projects International, she decided to make something cool with a Raspberry Pi to bring along. But being Estefannie, she didn’t just make something a little bit cool. She went ahead and made Raspberry Pi Zero-powered Jurassic Park goggles, or, as she calls them, the world’s first globally triggered, mass broadcasting, photon-emitting and -collecting head unit.

Make your own Jurassic Park goggles using a Raspberry Pi // MAKE SOMETHING

Is it heavy? Yes. But these goggles are not expensive. Follow along as I make the classic Jurassic Park Goggles from scratch!! The 3D Models: https://www.thingiverse.com/thing:3732889 My code: https://github.com/estefanniegg/estefannieExplainsItAll/blob/master/makes/JurassicGoggles/jurassic_park.py Thank you Coolest Projects for bringing me over to speak in Ireland!! https://coolestprojects.org/ Thank you Polymaker for sending me the Polysher and the PolySmooth filament!!!!

3D-printing, sanding, and sanding

Estefannie’s starting point was the set of excellent 3D models of the iconic goggles that Jurassicpaul has kindly made available on Thingiverse. There followed several 3D printing attempts and lots of sanding, sanding, sanding, spray painting, and sanding, then some more printing with special Polymaker filament that can be ethanol polished.

Adding the electronics and assembling the goggles

Estefannie soldered rings of addressable LEDs and created custom models for 3D-printable pieces to fit both them and the goggles. She added a Raspberry Pi Zero, some more LEDs and buttons, an adjustable headgear part from a welding mask, and – importantly – four circles of green acetate. After quite a lot of gluing, soldering, and wiring, she ended up with an entirely magnificent set of goggles.

Here, they’re modelled magnificently by Raspberry Pi videographer Brian. I think you’ll agree he cuts quite a dash.

Coding and LED user interface

Estefannie wrote a Python script to interact with Twitter, take photos, and provide information about the goggles’ current status via the LED rings. When Estefannie powers up the Raspberry Pi, it runs a script on startup and connects to her phone’s wireless hotspot. A red LED on the front of the goggles indicates that the script is up and running.

Once it’s running, pressing a button at the back of the head unit makes the Raspberry Pi search Twitter for mentions of @JurassicPi. The LEDs light up green while it searches, just like you remember from the film. If Estefannie’s script finds a mention, the LEDs flash white and the Raspberry Pi camera module takes a photo. Then they light up blue while the script tweets the photo.




All the code is available on Estefannie’s GitHub. I love this project – I love the super clear, simple user experience provided by the LED rings, and there’s something I really appealing about the asynchronous Twitter interaction, where you mention @JurassicPi and then get an image later, the next time googles are next turned on.

Extra bonus Coolest Projects

If you read the beginning of this post and thought, “wait, what’s Coolest Projects?” then be sure to watch to the end of Estefannie’s video to catch her excellentCoolest Projects mini vlog. And then sign up for updates about Coolest Projects events near you, so you can join in next year, or help a team of young people to join in.

The post Estefannie’s Jurassic Park goggles appeared first on Raspberry Pi.

Growth Monitor pi: an open monitoring system for plant science

Post Syndicated from Helen Lynn original https://www.raspberrypi.org/blog/growth-monitor-pi-an-open-monitoring-system-for-plant-science/

Plant scientists and agronomists use growth chambers to provide consistent growing conditions for the plants they study. This reduces confounding variables – inconsistent temperature or light levels, for example – that could render the results of their experiments less meaningful. To make sure that conditions really are consistent both within and between growth chambers, which minimises experimental bias and ensures that experiments are reproducible, it’s helpful to monitor and record environmental variables in the chambers.

A neat grid of small leafy plants on a black plastic tray. Metal housing and tubing is visible to the sides.

Arabidopsis thaliana in a growth chamber on the International Space Station. Many experimental plants are less well monitored than these ones.
(“Arabidopsis thaliana plants […]” by Rawpixel Ltd (original by NASA) / CC BY 2.0)

In a recent paper in Applications in Plant Sciences, Brandin Grindstaff and colleagues at the universities of Missouri and Arizona describe how they developed Growth Monitor pi, or GMpi: an affordable growth chamber monitor that provides wider functionality than other devices. As well as sensing growth conditions, it sends the gathered data to cloud storage, captures images, and generates alerts to inform scientists when conditions drift outside of an acceptable range.

The authors emphasise – and we heartily agree – that you don’t need expertise with software and computing to build, use, and adapt a system like this. They’ve written a detailed protocol and made available all the necessary software for any researcher to build GMpi, and they note that commercial solutions with similar functionality range in price from $10,000 to $1,000,000 – something of an incentive to give the DIY approach a go.

GMpi uses a Raspberry Pi Model 3B+, to which are connected temperature-humidity and light sensors from our friends at Adafruit, as well as a Raspberry Pi Camera Module.

The team used open-source app Rclone to upload sensor data to a cloud service, choosing Google Drive since it’s available for free. To alert users when growing conditions fall outside of a set range, they use the incoming webhooks app to generate notifications in a Slack channel. Sensor operation, data gathering, and remote monitoring are supported by a combination of software that’s available for free from the open-source community and software the authors developed themselves. Their package GMPi_Pack is available on GitHub.

With a bill of materials amounting to something in the region of $200, GMpi is another excellent example of affordable, accessible, customisable open labware that’s available to researchers and students. If you want to find out how to build GMpi for your lab, or just for your greenhouse, Affordable remote monitoring of plant growth in facilities using Raspberry Pi computers by Brandin et al. is available on PubMed Central, and it includes appendices with clear and detailed set-up instructions for the whole system.

The post Growth Monitor pi: an open monitoring system for plant science appeared first on Raspberry Pi.

Tracking the Brecon Beacons ultramarathon with a Raspberry Pi Zero

Post Syndicated from Helen Lynn original https://www.raspberrypi.org/blog/tracking-the-brecon-beacons-ultramarathon-with-a-raspberry-pi-zero/

On my holidays this year I enjoyed a walk in the Brecon Beacons. We set out nice and early, walked 22km through some of the best scenery in Britain, got a cup of tea from the snack van on the A470, and caught our bus home. “I enjoyed that walk,” I thought, “and I’d like to do one like it again.” What I DIDN’T think was, “I’d like to do that walk again, only I’d like it to be nearly three times as long, and it definitely ought to have about three times more ascent, or else why bother?”

Alan Peaty is a bit more hardcore than me, so, a couple of weekends ago, he set out on the Brecon Beacons 10 Peaks Ultramarathon: “10 peaks; 58 kilometres; 3000m of ascent; 24 hours”. He went with his friend Neil and a Raspberry Pi Zero in an eyecatching 3D-printed case.

A green 3D-printed case with a Raspberry Pi sticker on it, on a black backpack leaning against a cairn. In the background are a sunny mountain top, distant peaks, and a blue sky with white clouds.

“The brick”, nestling on a backpack, with sunlit Corn Du and Pen y Fan in the background

The Raspberry Pi Zero ensemble – lovingly known as the brick or, to give it its longer name, the Rosie IoT Brick or RIoT Brick – is equipped with a u-blox Neo-6 GPS module, and it also receives GPS tracking info from some smaller trackers built using ESP32 microcontrollers. The whole lot is powered by a “rather weighty” 20,000mAh battery pack. Both the Raspberry Pi and the ESP32s were equipped with “all manner of additional sensors” to track location, temperature, humidity, pressure, altitude, and light level readings along the route.

Charts showing temperature, humidity & pressure, altitude, and light levels along the route, together with a route map

Where the route crosses over itself is the most fervently appreciated snack van in Wales

Via LoRa and occasional 3G/4G from the many, many peaks along the route, all this data ends up on Amazon Web Services. AWS, among other things, hosts an informative website where family members were able to keep track of Alan’s progress along windswept ridges and up 1:2 gradients, presumably the better to appreciate their cups of tea and central heating. Here’s a big diagram of how the kit that completed the ultramarathon fits together; it’s full of arrows, dotted lines, and acronyms.

Alan, Neil, the brick, and the rest of their gear completed the event in an impressive 18 hours and one minute, for which they got a medal.

The brick, a small plastic box full of coloured jumper leads and other electronics; the lid of the box; and a medal consisting of the number 10 in large plastic characters on a green ribbon

Well earned

You can follow the adventures of this project, its antecedents, and the further evolutions that are doubtless to come, on the Rosie the Red Robot Twitter feed. And you can find everything to do with the project in this GitHub repository, so you can complete ultramarathons while weighed down with hefty power bricks and bristling with homemade tracking devices, too, if you like. Alan is raising money for Alzheimer’s Research UK with this event, and you can find his Brecon Beacons 10 Peaks JustGiving page here.

The post Tracking the Brecon Beacons ultramarathon with a Raspberry Pi Zero appeared first on Raspberry Pi.

A low-cost, open-source, computer-assisted microscope

Post Syndicated from Helen Lynn original https://www.raspberrypi.org/blog/a-low-cost-open-source-computer-assisted-microscope/

Low-cost open labware is a good thing in the world, and I was particularly pleased when micropalaeontologist Martin Tetard got in touch about the Raspberry Pi-based microscope he is developing. The project is called microscoPI (what else?), and it can capture, process, and store images and image analysis results. Martin is engaged in climate research: he uses microscopy to study tiny fossil remains, from which he gleans information about the environmental conditions that prevailed in the far-distant past.

microscoPI: a microcomputer-assisted microscope

microscoPI a project that aims to design a multipurpose, open-source and inexpensive micro-computer-assisted microscope (Raspberry PI 3). This microscope can automatically take images, process them, and save them altogether with the results of image analyses on a flash drive. It it multipurpose as it can be used on various kinds of images (e.g.

Martin repurposed an old microscope with a Z-axis adjustable stage for accurate focusing, and sourced an inexpensive X/Y movable stage to allow more accurate horizontal positioning of samples under the camera. He emptied the head of the scope to install a Raspberry Pi Camera Module, and he uses an M12 lens adapter to attach lenses suitable for single-specimen close-ups or for imaging several specimens at once. A Raspberry Pi 3B sits above the head of the microscope, and a 3.5-inch TFT touchscreen mounted on top of the Raspberry Pi allows the user to check images as they are captured and processed.

The Raspberry Pi runs our free operating system, Raspbian, and free image-processing software ImageJ. Martin and his colleagues use a number of plugins, some developed themselves and some by others, to support the specific requirements of their research. With this software, microscoPI can capture and analyse microfossil images automatically: it can count particles, including tiny specimens that are touching, analyse their shape and size, and save images and results before prompting the user for the name of the next sample.

microscoPI is compact – less than 30cm in height – and it’s powered by a battery bank secured under the base of the microscope, so it’s easily portable. The entire build comes in at under 160 Euros. You can find out more, and get in touch with Martin, on the microscoPI website.

The post A low-cost, open-source, computer-assisted microscope appeared first on Raspberry Pi.

An in-flight entertainment system that isn’t terrible

Post Syndicated from Helen Lynn original https://www.raspberrypi.org/blog/an-in-flight-entertainment-system-that-isnt-terrible/

No Alex today; she’s tragically germ-ridden and sighing weakly beneath a heap of duvets on her sofa. But, in spite of it all, she’s managed to communicate that I should share Kyle‘s Raspberry Pi in-flight entertainment system with you.

I made my own IN-FLIGHT entertainment system! ft. Raspberry Pi

Corsair Ironclaw RGB Gaming Mouse: http://bit.ly/2vFwYw5 From poor A/V quality to lackluster content selection, in-flight entertainment centers are full of compromises. Let’s create our own using a Raspberry Pi 3 B+!

Kyle is far from impressed with the in-flight entertainment on most planes: the audio is terrible, the touchscreens are annoyingly temperamental, and the movie selection is often frustratingly limited. So, the night before a morning flight to visit family (congrats on becoming an uncle, Kyle! We trust you’ll use your powers only for good!), he hit upon the idea of building his own in-flight entertainment system, using stuff he already had lying around.

Yes, we know, he could just have taken a tablet with him. But we agree with him that his solution is way funner. It’s way more customisable too. Kyle’s current rushed prototype features a Raspberry Pi 3B+ neatly cable-tied into a drilled Altoids tin lid, which is fixed flush to the back of a 13.3-inch portable monitor with adhesive Velcro. He’s using VLC Media Player, which comes with Raspbian and supports a lot of media control functions straight out of the box; this made using his mouse and mini keyboard a fairly seamless experience. And a handy magnetic/suction bracket lets him put the screen in the back of the seat in front to the best possible use: as a mounting surface.

As Kyle says, “Is it ridiculous? I mean, yes, obviously it’s ridiculous, but would you ever consider doing something like this?”

The post An in-flight entertainment system that isn’t terrible appeared first on Raspberry Pi.

Remembering Andy Baker

Post Syndicated from Helen Lynn original https://www.raspberrypi.org/blog/remembering-andy-baker/

We are immensely sad to learn of the death, on 1 June, of Andy Baker, joint founder and organiser of the brilliant Cotswold Raspberry Jam. Andy had been suffering from brain cancer.

andy baker pistuffing

Together with co-founder Andrew Oakley, Andy worked incredibly hard to make the Cotswold Jam one of the most exciting Jams of all, with over 150 people of all ages attending its most popular events. He started working with Raspberry Pis back in 2012, and developed a seriously impressive degree of technical expertise: among his projects were a series of Pi-powered quadcopters, no less, including an autonomous drone. Many of us will forever associate Andy with a memorably fiery incident at the Raspberry Pi Big Birthday Weekend in 2016, which he handled with grace and good humour that eludes most of us:

Raspberry Pi Party Autonomous drone demo + fire

At the Raspberry Pi IV party and there is a great demo of an Autonomous drone which is very impressive with only using a Pi. However it caught on fire. But i believe it does actually work.

Andy maintained his involvement with the Raspberry Pi community, and especially the Cotswold Jam, for several years while living with a brain tumour, and shared his skills and enthusiasm with hundreds of others. He was at the heart of the Raspberry Pi community. When our patron, His Royal Highness the Duke of York, kindly hosted a reception at St. James’s Palace in October 2016 to recognise the Raspberry Pi community, Andy joined us to celebrate in style:

Cotswold Jam on Twitter

@ben_nuttall @DougGore @PiStuffing @rjam_chat Cheers, Ben! Fab photo of Prince Andrew being ignored by @davejavupride & Andy Baker @PiStuffing who are too busy drinking… “It’s what he would have wanted…” 🙂 https://t.co/FK7sk1CoDs

Andy suggested that, if people would like to make a donation in his name, they support his local school’s IT department, somewhere else he used to volunteer. The department isn’t able to accept online donations, but cheques in pounds sterling can be made out to “Gloucestershire County Council” and posted to a local funeral director who will collect and forward them:

Andy Baker memorial fund
c/o Blackwells of Cricklade
Thames House
Thames Lane
Cricklade
SN6 6BH

We owe Andy immense gratitude for all his work to help people learn and have a great time with Raspberry Pi. We were very lucky indeed to have him as part of our community. We will miss him.

The post Remembering Andy Baker appeared first on Raspberry Pi.

Argon ONE: a super case for your Raspberry Pi

Post Syndicated from Helen Lynn original https://www.raspberrypi.org/blog/argon-one-raspberry-pi-case/

The friendly people at Argon40, one of our Approved Resellers in Hong Kong, have an already-successful Kickstarter on the go for their Argon ONE Raspberry Pi case. I’ve got one of them on my desk at the moment. It’s a very pleasing object. “That’s quite nice,” enthuses Gordon, who isn’t very good at enthusing.

The Argon ONE: look at the shiny!

The Argon ONE is a nifty little aluminium-alloy case that offers well thought-through cable, power, and temperature management. We chatted to Joseph from Argon40 about the team’s development process, and he explained:

When we started the project, we initially designed the product to suit our needs based on our experiences of playing around with the Raspberry Pi. We wanted a case that is nice to look and at the same time has all the basic features that we loved about the Raspberry Pi: small footprint, access to GPIO, low power consumption. Then we looked into the nice-to-have stuff like good heat dissipation for better performance, a proper shut-down, and a form factor that is elegant but not extravagant.

Clicky magnets

What I find particularly satisfying about the Argon ONE is its GPIO access. It has a neat recess with clear pin labels and access to an inbuilt, colour-coded header that connects to your Pi’s GPIO pins. When you’re not using the pins, you probably want to keep them away from dust, spilled coffee, and the gross candy-corn M&Ms that Alex sometimes throws at you for literally no reason. The Argon ONE helps you out here: a cover fits perfectly over the GPIO recess, held in place by magnets that are just exactly strong enough for the job. Being a fidgeter, I find that this lends itself to compulsive clicking.

*click* *click* *click*

Injection moulding

We like the build quality here, especially at this price point (it’s HK$157, US$20, or GB£15, and early-bird pledges are cheaper). The Argon40 team was keen to use alumnium for the upper part of the case, for robustness and durability along with good looks; that proved a challenge, given that they wanted to keep the case affordable. “Fortunately, we found a factory that allowed us to do aluminum-alloy injection instead of going for the CNC option,” says Joseph.

“Have you tried turning if off and on again?”

The Raspberry Pi doesn’t have a power button, and we hear a lot from people who’d like it to. Happily, our community has come up with lots of ways to add one: this case, for example. Once you install Argon40’s shutdown script in Raspbian, pressing the case’s power button will run the script to shut the Pi down cleanly, then cut the power.

Find out more on Kickstarter — this campaign is well worth a look if you’re after a decent case. Back to Joseph for the last word, with which we heartily agree:

At the end of the day, our goal is for people to have their Raspberry Pis on top of their work desks, study tables, and workstations and in their living rooms, instead of keeping their barebones Pi tucked inside a drawer. Because as the saying goes, “Out of sight, out of mind,” which means that if they don’t see their Raspberry Pi, they won’t be able to tinker around with it or play with it to create projects.

The post Argon ONE: a super case for your Raspberry Pi appeared first on Raspberry Pi.

Take a photo of yourself as an unreliable cartoon

Post Syndicated from Helen Lynn original https://www.raspberrypi.org/blog/take-a-photo-of-yourself-unreliable-cartoon/

Take a selfie, wait for the image to appear, and behold a cartoon version of yourself. Or, at least, behold a cartoon version of whatever the camera thought it saw. Welcome to Draw This by maker Dan Macnish.

Dan has made code, instructions, and wiring diagrams available to help you bring this beguiling weirdery into your own life.

raspberry pi cartoon polaroid camera

Neural networks, object recognition, and cartoons

One of the fun things about this re-imagined polaroid is that you never get to see the original image. You point, and shoot – and out pops a cartoon; the camera’s best interpretation of what it saw. The result is always a surprise. A food selfie of a healthy salad might turn into an enormous hot dog, or a photo with friends might be photobombed by a goat.

OK. Let’s take this one step at a time.

Pi + camera + button + LED

Draw This uses a Raspberry Pi 3 and a Camera Module, with a button and a useful status LED connected to the GPIO pins via a breadboard. You press the button, and the camera captures a still image while the LED comes on and stays lit for a couple of seconds while the Pi processes the image. So far, so standard Pi camera build.

Interpreting and re-interpreting the camera image

Dan uses Python to process the captured photograph, employing a pre-trained machine learning model from Google to recognise multiple objects in the image. Now he brings the strangeness. The Pi matches the things it sees in the photo with doodles from Google’s huge open-source Quick, Draw! dataset, and generates a new image that represents the objects in the original image as doodles. Then a thermal printer connected to the Pi’s GPIO pins prints the results.

A 28 x 14 grid of kangaroo doodles in dark grey on a white background

Kangaroos from the Quick, Draw! dataset (I got distracted)

Potential for peculiar

Reading about this build leaves me yearning to see its oddest interpretation of a scene, so if you make this and you find it really does turn you or your friend into a goat, please do share that with us.

And as you can see from my kangaroo digression above, there is a ton of potential for bizarro makes that use the Quick, Draw! dataset, object recognition models, or both; it’s not just the marsupials that are inexplicably compelling (I dare you to go and look and see how long it takes you to get back to whatever you were in the middle of). If you’re planning to make this, or something inspired by this, check out Dan’s cartoonify GitHub repo. And tell us all about it in the comments.

The post Take a photo of yourself as an unreliable cartoon appeared first on Raspberry Pi.

Enchanting images with Inky Lines, a Pi‑powered polargraph

Post Syndicated from Helen Lynn original https://www.raspberrypi.org/blog/enchanting-images-inky-lines-pi-powered-polargraph/

A hanging plotter, also known as a polar plotter or polargraph, is a machine for drawing images on a vertical surface. It does so by using motors to control the length of two cords that form a V shape, supporting a pen where they meet. We’ve featured one on this blog before: Norbert “HomoFaciens” Heinz’s video is a wonderfully clear introduction to how a polargraph works and what you have to consider when you’re putting one together.

Today, we look at Inky Lines, by John Proudlock. With it, John is creating a series of captivating and beautiful pieces, and with his most recent work, each rendering of an image is unique.

The Inky Lines plotter draws a flock of seagulls in blue ink on white paper. The print head is suspended near the bottom left corner of the image, as the pen inks the wing of a gull

An evolving project

The project isn’t new – John has been working on it for at least a couple of years – but it is constantly evolving. When we first spotted it, John had just implemented code to allow the plotter to produce mesmeric, spiralling patterns.

A blue spiral pattern featuring overlapping "bubbles"
A dense pink spiral pattern, featuring concentric circles and reminiscent of a mandala
A blue spirograph-type pattern formed of large overlapping squares, each offset from its neighbour by a few degrees, producing a four-spiral-armed "galaxy" shape where lines overlap. The plotter's print head is visible in a corner of the image

But we’re skipping ahead. Let’s go back to the beginning.

From pixels to motor movements

John starts by providing an image, usually no more than 100 pixels wide, to a Raspberry Pi. Custom software that he wrote evaluates the darkness of each pixel and selects a pattern of a suitable density to represent it.

The two cords supporting the plotter’s pen are wound around the shafts of two stepper motors, such that the movement of the motors controls the length of the cords: the program next calculates how much each motor must move in order to produce the pattern. The Raspberry Pi passes corresponding instructions to two motor circuits, which transform the signals to a higher voltage and pass them to the stepper motors. These turn by very precise amounts, winding or unwinding the cords and, very slowly, dragging the pen across the paper.

A Raspberry Pi in a case, with a wide flex connected to a GPIO header
The Inky Lines plotter's print head, featuring cardboard and tape, draws an apparently random squiggle
A large area of apparently random pattern drawn by the plotter

John explains,

Suspended in-between the two motors is a print head, made out of a new 3-d modelling material I’ve been prototyping called cardboard. An old coat hanger and some velcro were also used.

(He’s our kind of maker.)

Unique images

The earlier drawings that John made used a repeatable method to render image files as lines on paper. That is, if the machine drew the same image a number of times, each copy would be identical. More recently, though, he has been using a method that yields random movements of the pen:

The pen point is guided around the image, but moves to each new point entirely at random. Up close this looks like a chaotic squiggle, but from a distance of a couple of meters, the human eye (and brain) make order from the chaos and view an infinite number of shades and a smoother, less mechanical image.

An apparently chaotic squiggle

This method means that no matter how many times the polargraph repeats the same image, each copy will be unique.

A gallery of work

Inky Lines’ website and its Instagram feed offer a collection of wonderful pieces John has drawn with his polargraph, and he discusses the different techniques and types of image that he is exploring.

A 3 x 3 grid of varied and colourful images from inkylinespolargraph's Instagram feed

They range from holiday photographs, processed to extract particular features and rendered in silhouette, to portraits, made with a single continuous line that can be several hundred metres long, to generative images spirograph images like those pictured above, created by an algorithm rather than rendered from a source image.

The post Enchanting images with Inky Lines, a Pi‑powered polargraph appeared first on Raspberry Pi.

Naturebytes’ weatherproof Pi and camera case

Post Syndicated from Helen Lynn original https://www.raspberrypi.org/blog/naturebytes-weatherproof-pi-and-camera-case/

Naturebytes are making their weatherproof Wildlife Cam Case available as a standalone product for the first time, a welcome addition to the Raspberry Pi ecosystem that should take some of the hassle out of your outdoor builds.

A robin on a bird feeder in a garden with a Naturebytes Wildlife Cam mounted beside it

Weatherproofing digital making projects

People often use Raspberry Pis and Camera Modules for outdoor projects, but weatherproofing your set-up can be tricky. You need to keep water — and tiny creatures — out, but you might well need access for wires and cables, whether for power or sensors; if you’re using a camera, it’ll need something clear and cleanable in front of the lens. You can use sealant, but if you need to adjust anything that you’ve applied it to, you’ll have to remove it and redo it. While we’ve seen a few reasonable options available to buy, the choice has never been what you’d call extensive.

The Naturebytes case

For all these reasons, I was pleased to learn that Naturebytes, the wildlife camera people, are releasing their Wildlife Cam Case as a standalone product for the first time.

Naturebytes case open

The Wildlife Cam Case is ideal for nature camera projects, of course, but it’ll also be useful for anyone who wants to take their Pi outdoors. It has weatherproof lenses that are transparent to visible and IR light, for all your nature observation projects. Its opening is hinged to allow easy access to your hardware, and the case has waterproof access for cables. Inside, there’s a mount for fixing any model of Raspberry Pi and camera, as well as many other components. On top of all that, the case comes with a sturdy nylon strap to make it easy to attach it to a post or a tree.

Naturebytes case additional components

Order yours now!

At the moment, Naturebytes are producing a limited run of the cases. The first batch of 50 are due to be dispatched next week to arrive just in time for the Bank Holiday weekend in the UK, so get them while they’re hot. It’s the perfect thing for recording a timelapse of exactly how quickly the slugs obliterate your vegetable seedlings, and of lots more heartening things that must surely happen in gardens other than mine.

The post Naturebytes’ weatherproof Pi and camera case appeared first on Raspberry Pi.

UK soldiers design Raspberry Pi bomb disposal robot

Post Syndicated from Helen Lynn original https://www.raspberrypi.org/blog/uk-soldiers-design-raspberry-pi-bomb-disposal-robot/

Three soldiers in the British Army have used a Raspberry Pi to build an autonomous robot, as part of their Foreman of Signals course.

Meet The Soldiers Revolutionising Bomb Disposal

Three soldiers from Blandford Camp have successfully designed and built an autonomous robot as part of their Foreman of Signals Course at the Dorset Garrison.

Autonomous robots

Forces Radio BFBS carried a story last week about Staff Sergeant Jolley, Sergeant Rana, and Sergeant Paddon, also known as the “Project ROVER” team. As part of their Foreman of Signals training, their task was to design an autonomous robot that can move between two specified points, take a temperature reading, and transmit the information to a remote computer. The team comments that, while semi-autonomous robots have been used as far back as 9/11 for tasks like finding people trapped under rubble, nothing like their robot and on a similar scale currently exists within the British Army.

The ROVER buggy

Their build is named ROVER, which stands for Remote Obstacle aVoiding Environment Robot. It’s a buggy that moves on caterpillar tracks, and it’s tethered; we wonder whether that might be because it doesn’t currently have an on-board power supply. A demo shows the robot moving forward, then changing its path when it encounters an obstacle. The team is using RealVNC‘s remote access software to allow ROVER to send data back to another computer.

Applications for ROVER

Dave Ball, Senior Lecturer in charge of the Foreman of Signals course, comments that the project is “a fantastic opportunity for [the team] to, even only halfway through the course, showcase some of the stuff they’ve learnt and produce something that’s really quite exciting.” The Project ROVER team explains that the possibilities for autonomous robots like this one are extensive: they include mine clearance, bomb disposal, and search-and-rescue campaigns. They point out that existing semi-autonomous hardware is not as easy to program as their build. In contrast, they say, “with the invention of the Raspberry Pi, this has allowed three very inexperienced individuals to program a robot very capable of doing these things.”

We make Raspberry Pi computers because we want building things with technology to be as accessible as possible. So it’s great to see a project like this, made by people who aren’t techy and don’t have a lot of computing experience, but who want to solve a problem and see that the Pi is an affordable and powerful tool that can help.

The post UK soldiers design Raspberry Pi bomb disposal robot appeared first on Raspberry Pi.

Mayank Sinha’s home security project

Post Syndicated from Helen Lynn original https://www.raspberrypi.org/blog/home-security/

Yesterday, I received an email from someone called Mayank Sinha, showing us the Raspberry Pi home security project he’s been working on. He got in touch particularly because, he writes, the Raspberry Pi community has given him “immense support” with his build, and he wanted to dedicate it to the commmunity as thanks.

Mayank’s project is named Asfaleia, a Greek word that means safety, certainty, or security against threats. It’s part of an honourable tradition dating all the way back to 2012: it’s a prototype housed in a polystyrene box, using breadboards and jumper leads and sticky tape. And it’s working! Take a look.

Asfaleia DIY Home Security System

An IOT based home security system. The link to the code: https://github.com/mayanksinha11/Asfaleia

Home security with Asfaleida

Asfaleia has a PIR (passive infrared) motion sensor, an IR break beam sensor, and a gas sensor. All are connected to a Raspberry Pi 3 Model B, the latter two via a NodeMCU board. Mayank currently has them set up in a box that’s divided into compartments to model different rooms in a house.

A shallow box divided into four labelled "rooms", all containing electronic components

All the best prototypes have sticky tape or rubber bands

If the IR sensors detect motion or a broken beam, the webcam takes a photo and emails it to the build’s owner, and the build also calls their phone (I like your ringtone, Mayank). If the gas sensor detects a leak, the system activates an exhaust fan via a small relay board, and again the owner receives a phone call. The build can also authenticate users via face and fingerprint recognition. The software that runs it all is written in Python, and you can see Mayank’s code on GitHub.

Of prototypes and works-in-progess

Reading Mayank’s email made me very happy yesterday. We know that thousands of people in our community give a great deal of time and effort to help others learn and make things, and it is always wonderful to see an example of how that support is helping someone turn their ideas into reality. It’s great, too, to see people sharing works-in-progress, as well as polished projects! After all, the average build is more likely to feature rubber bands and Tupperware boxes than meticulously designed laser-cut parts or expert joinery. Mayank’s YouTube channel shows earlier work on this and another Pi project, and I hope he’ll continue to document his builds.

So here’s to Raspberry Pi projects big, small, beginner, professional, endlessly prototyped, unashamedly bodged, unfinished or fully working, shonky or shiny. Please keep sharing them all!

The post Mayank Sinha’s home security project appeared first on Raspberry Pi.

Augmented-reality projection lamp with Raspberry Pi and Android Things

Post Syndicated from Helen Lynn original https://www.raspberrypi.org/blog/augmented-reality-projector/

If your day has been a little fraught so far, watch this video. It opens with a tableau of methodically laid-out components and then shows them soldered, screwed, and slotted neatly into place. Everything fits perfectly; nothing needs percussive adjustment. Then it shows us glimpses of an AR future just like the one promised in the less dystopian comics and TV programmes of my 1980s childhood. It is all very soothing, and exactly what I needed.

Android Things – Lantern

Transform any surface into mixed-reality using Raspberry Pi, a laser projector, and Android Things. Android Experiments – http://experiments.withgoogle.com/android/lantern Lantern project site – http://nordprojects.co/lantern check below to make your own ↓↓↓ Get the code – https://github.com/nordprojects/lantern Build the lamp – https://www.hackster.io/nord-projects/lantern-9f0c28

Creating augmented reality with projection

We’ve seen plenty of Raspberry Pi IoT builds that are smart devices for the home; they add computing power to things like lights, door locks, or toasters to make these objects interact with humans and with their environment in new ways. Nord ProjectsLantern takes a different approach. In their words, it:

imagines a future where projections are used to present ambient information, and relevant UI within everyday objects. Point it at a clock to show your appointments, or point to speaker to display the currently playing song. Unlike a screen, when Lantern’s projections are no longer needed, they simply fade away.

Lantern is set up so that you can connect your wireless device to it using Google Nearby. This means there’s no need to create an account before you can dive into augmented reality.

Lantern Raspberry Pi powered projector lamp

Your own open-source AR lamp

Nord Projects collaborated on Lantern with Google’s Android Things team. They’ve made it fully open-source, so you can find the code on GitHub and also download their parts list, which includes a Pi, an IKEA lamp, an accelerometer, and a laser projector. Build instructions are at hackster.io and on GitHub.

This is a particularly clear tutorial, very well illustrated with photos and GIFs, and once you’ve sourced and 3D-printed all of the components, you shouldn’t need a whole lot of experience to put everything together successfully. Since everything is open-source, though, if you want to adapt it — for example, if you’d like to source a less costly projector than the snazzy one used here — you can do that too.

components of Lantern Raspberry Pi powered augmented reality projector lamp

The instructions walk you through the mechanical build and the wiring, as well as installing Android Things and Nord Projects’ custom software on the Raspberry Pi. Once you’ve set everything up, an accelerometer connected to the Pi’s GPIO pins lets the lamp know which surface it is pointing at. A companion app on your mobile device lets you choose from the mini apps that work on that surface to select the projection you want.

The designers are making several mini apps available for Lantern, including the charmingly named Space Porthole: this uses Processing and your local longitude and latitude to project onto your ceiling the stars you’d see if you punched a hole through to the sky, if it were night time, and clear weather. Wouldn’t you rather look at that than deal with the ant problem in your kitchen or tackle your GitHub notifications?

What would you like to project onto your living environment? Let us know in the comments!

The post Augmented-reality projection lamp with Raspberry Pi and Android Things appeared first on Raspberry Pi.

This is a really lovely Raspberry Pi tricorder

Post Syndicated from Helen Lynn original https://www.raspberrypi.org/blog/raspberry-pi-tricorder-prop/

At the moment I’m spending my evenings watching all of Star Trek in order. Yes, I have watched it before (but with some really big gaps). Yes, including the animated series (I’m up to The Terratin Incident). So I’m gratified to find this beautiful The Original Series–style tricorder build.

Star Trek Tricorder with Working Display!

At this year’s Replica Prop Forum showcase, we meet up once again wtih Brian Mix, who brought his new Star Trek TOS Tricorder. This beautiful replica captures the weight and finish of the filming hand prop, and Brian has taken it one step further with some modern-day electronics!

A what now?

If you don’t know what a tricorder is, which I guess is faintly possible, the easiest way I can explain is to steal words that Liz wrote when Recantha made one back in 2013. It’s “a made-up thing used by the crew of the Enterprise to measure stuff, store data, and scout ahead remotely when exploring strange new worlds, seeking out new life and new civilisations, and all that jazz.”

A brief history of Picorders

We’ve seen other Raspberry Pi–based realisations of this iconic device. Recantha’s LEGO-cased tricorder delivered some authentic functionality, including temperature sensors, an ultrasonic distance sensor, a photosensor, and a magnetometer. Michael Hahn’s tricorder for element14’s Sci-Fi Your Pi competition in 2015 packed some similar functions, along with Original Series audio effects, into a neat (albeit non-canon) enclosure.

Brian Mix’s Original Series tricorder

Brian Mix’s tricorder, seen in the video above from Tested at this year’s Replica Prop Forum showcase, is based on a high-quality kit into which, he discovered, a Raspberry Pi just fits. He explains that the kit is the work of the late Steve Horch, a special effects professional who provided props for later Star Trek series, including the classic Deep Space Nine episode Trials and Tribble-ations.

A still from an episode of Star Trek: Deep Space Nine: Jadzia Dax, holding an Original Series-sylte tricorder, speaks with Benjamin Sisko

Dax, equipped for time travel

This episode’s plot required sets and props — including tricorders — replicating the USS Enterprise of The Original Series, and Steve Horch provided many of these. Thus, a tricorder kit from him is about as close to authentic as you can possibly find unless you can get your hands on a screen-used prop. The Pi allows Brian to drive a real display and a speaker: “Being the geek that I am,” he explains, “I set it up to run every single Original Series Star Trek episode.”

Even more wonderful hypothetical tricorders that I would like someone to make

This tricorder is beautiful, and it makes me think how amazing it would be to squeeze in some of the sensor functionality of the devices depicted in the show. Space in the case is tight, but it looks like there might be a little bit of depth to spare — enough for an IMU, maybe, or a temperature sensor. I’m certain the future will bring more Pi tricorder builds, and I, for one, can’t wait. Please tell us in the comments if you’re planning something along these lines, and, well, I suppose some other sci-fi franchises have decent Pi project potential too, so we could probably stand to hear about those.

If you’re commenting, no spoilers please past The Animated Series S1 E11. Thanks.

The post This is a really lovely Raspberry Pi tricorder appeared first on Raspberry Pi.

Whimsical builds and messing things up

Post Syndicated from Helen Lynn original https://www.raspberrypi.org/blog/whimsical-builds-and-messing-things-up/

Today is the early May bank holiday in England and Wales, a public holiday, and while this blog rarely rests, the Pi Towers team does. So, while we take a day with our families, our friends, and/or our favourite pastimes, I thought I’d point you at a couple of features from HackSpace magazine, our monthly magazine for makers.

To my mind, they go quite well with a deckchair in the garden, the buzz of a lawnmower a few houses down, and a view of the weeds I ought to have dealt with by now, but I’m sure you’ll find your own ambience.

Make anything with pencils – HackSpace magazine

If you want a unique piece of jewellery to show your love for pencils, follow Peter Brown’s lead. Peter glued twelve pencils together in two rows of six. He then measured the size of his finger and drilled a hole between the glued pencils using a drill bit.

First off, pencils. It hadn’t occurred to me that you could make super useful stuff like a miniature crossbow and a catapult out of pencils. Not only can you do this, you can probably go ahead and do it right now: all you need is a handful of pencils, some rubber bands, some drawing pins, and a bulldog clip (or, as you might prefer, some push pins and a binder clip). The sentence that really leaps out at me here is “To keep a handful of boys aged three to eleven occupied during a family trip, Marie decided to build mini crossbows to help their target practice.” The internet hasn’t helped me find out much about Marie, but I am in awe of her.

If you haven’t wandered off to make a stationery arsenal by now, read Lucy Rogers‘ reflections on making a right mess of things. I hope you do, because I think it’d be great if more people coped better with the fact that we all, unavoidably, fail. You probably won’t really get anywhere without a few goes where you just completely muck it all up.

A ceramic mug, broken into several pieces on the floor

Never mind. We can always line a plant pot with them.
“In Pieces” by dusk-photography / CC BY

This true of everything. Wet lab work and gardening and coding and parenting. And everything. You can share your heroic failures in the comments, if you like, as well as any historic weaponry you have fashioned from the contents of your desk tidy.

The post Whimsical builds and messing things up appeared first on Raspberry Pi.

A hedgehog cam or two

Post Syndicated from Helen Lynn original https://www.raspberrypi.org/blog/a-hedgehog-cam-or-two/

Here we are, hauling ourselves out of the Christmas and New Year holidays and into January proper. It’s dawning on me that I have to go back to work, even though it’s still very cold and gloomy in northern Europe, and even though my duvet is lovely and warm. I found myself envying beings that hibernate, and thinking about beings that hibernate, and searching for things to do with hedgehogs. And, well, the long and the short of it is, today’s blog post is a short meditation on the hedgehog cam.

A hedgehog in a garden, photographed in infrared light by a hedgehog cam

Success! It’s a hedgehog!
Photo by Andrew Wedgbury

Hedgehog watching

Someone called Barker has installed a Raspberry Pi–based hedgehog cam in a location with a distant view of a famous Alp, and as well as providing live views by visible and infrared light for the dedicated and the insomniac, they also make a sped-up version of the previous night’s activity available. With hedgehogs usually being in hibernation during January, you mightn’t see them in any current feed — but don’t worry! You’re guaranteed a few hedgehogs on Barker’s website, because they have also thrown in some lovely GIFs of hoggy (and foxy) divas that their camera captured in the past.

A Hedgehog eating from a bowl on a patio, captured by a hedgehog cam

Nom nom nom!
GIF by Barker’s Site

Build your own hedgehog cam

For pointers on how to replicate this kind of setup, you could do worse than turn to Andrew Wedgbury’s hedgehog cam write-up. Andrew’s Twitter feed reveals that he’s a Cambridge local, and there are hints that he was behind RealVNC’s hoggy mascot for Pi Wars 2017.

RealVNC on Twitter

Another day at the office: testing our #PiWars mascot using a @Raspberry_Pi 3, #VNC Connect and @4tronix_uk Picon Zero. Name suggestions? https://t.co/iYY3xAX9Bk

Our infrared bird box and time-lapse camera resources will also set you well on the way towards your own custom wildlife camera. For a kit that wraps everything up in a weatherproof enclosure made with love, time, and serious amounts of design and testing, take a look at Naturebytes’ wildlife cam kit.

Or, if you’re thinking that a robot mascot is more dependable than real animals for the fluffiness you need in order to start your January with something like productivity and with your soul intact, you might like to put your own spin on our robot buggy.

Happy 2018

While we’re on the subject of getting to grips with the new year, do take a look at yesterday’s blog post, in which we suggest a New Year’s project that’s different from the usual resolutions. However you tackle 2018, we wish you an excellent year of creative computing.

The post A hedgehog cam or two appeared first on Raspberry Pi.

Pimoroni’s ‘World’s Thinnest Raspberry Pi 3’

Post Syndicated from Helen Lynn original https://www.raspberrypi.org/blog/pimoroni-thinnest-pi/

The Raspberry Pi is not a chunky computer. Nonetheless, tech treasure merchants Pimoroni observed that at almost 20mm tall, it’s still a little on the large side for some applications. So, in their latest live-streamed YouTube Bilge Tank episode, they stripped a Pi 3 down to the barest of bones.

Pimoroni Thinnest Raspberry Pi 3 desoldered pi

But why?

The Raspberry Pi is easy to connect to peripherals. Grab a standard USB mouse, keyboard, and HDMI display, plug them in, and you’re good to go.

desoldered pi

But it’s possible to connect all these things without the bulky ports, if you’re happy to learn how, and you’re in possession of patience and a soldering iron. You might want to do this if, after prototyping your project using the Pi’s standard ports, you want to embed it as a permanent part of a slimmed-down final build. Safely removing the USB ports, the Ethernet port and GPIO pins lets you fit your Pi into really narrow spaces.

As Jon explains:

A lot of the time people want to integrate a Raspberry Pi into a project where there’s a restricted amount of space. but they still want the power of the Raspberry Pi 3’s processor

While the Raspberry Pi Zero and Zero W are cheaper and have a smaller footprint, you might want to take advantage of the greater power the Pi 3 offers.

How to slim down a Raspberry Pi 3

Removing components is a matter of snipping in the right places and desoldering with a hot air gun and a solder sucker, together with the judicious application of brute force. I should emphasise, as the Pimoroni team do, that this is something you should only do with care, after making sure you know what you’re doing.

Pimoroni Thinnest Raspberry Pi 3 desoldered pi

The project was set to take half an hour, though Jon and Sandy ended up taking slightly more time than planned. You can watch the entire process below.

Bilge Tank 107 – The World’s Slimmest Raspberry Pi 3

This week, we attempt to completely strip down a Raspberry Pi 3, removing the USB, Ethernet, HDMI, audio jack, CSI/DSI connectors, and GPIO header in an audacious attempt to create the world’s slimmest Raspberry Pi 3 (not officially ratified by the Guinness Book of World Records).

If Pimoroni’s video has given you ideas, you’ll also want to check out N-O-D-E‘s recent Raspberry Pi 3 Slim build. N-O-D-E takes a similar approach, and adds new micro USB connectors to one end of the board for convenience. If you decide to give something like this a go, please let us know how it went: tell us in the comments, or on Raspberry Pi’s social channels.

The post Pimoroni’s ‘World’s Thinnest Raspberry Pi 3’ appeared first on Raspberry Pi.

Open source energy monitoring using Raspberry Pi

Post Syndicated from Helen Lynn original https://www.raspberrypi.org/blog/open-source-energy-monitoring-raspberry-pi/

OpenEnergyMonitor, who make open-source tools for energy monitoring, have been using Raspberry Pi since we launched in 2012. Like Raspberry Pi, they manufacture their hardware in Wales and send it to people all over the world. We invited co-founder Glyn Hudson to tell us why they do what they do, and how Raspberry Pi helps.

Hi, I’m Glyn from OpenEnergyMonitor. The OpenEnergyMonitor project was founded out of a desire for open-source tools to help people understand and relate to their use of energy, their energy systems, and the challenge of sustainable energy.

Photo: an emonPi energy monitoring unit in an aluminium case with an aerial and an LCD display, a mobile phone showing daily energy use as a histogram, and a bunch of daffodils in a glass bottle

The next 20 years will see a revolution in our energy systems, as we switch away from fossil fuels towards a zero-carbon energy supply.

By using energy monitoring, modelling, and assessment tools, we can take an informed approach to determine the best energy-saving measures to apply. We can then check to ensure solutions achieve their expected performance over time.

We started the OpenEnergyMonitor project in 2009, and the first versions of our energy monitoring system used an Arduino with Ethernet Shield, and later a Nanode RF with an embedded Ethernet controller. These early versions were limited by a very basic TCP/IP stack; running any sort of web application locally was totally out of the question!

I can remember my excitement at getting hold of the very first version of the Raspberry Pi in early 2012. Within a few hours of tearing open the padded envelope, we had Emoncms (our open-source web logging, graphing, and visualisation application) up and running locally on the Raspberry Pi. The Pi quickly became our web-connected base station of choice (emonBase). The following year, 2013, we launched the RFM12Pi receiver board (now updated to RFM69Pi). This allowed the Raspberry Pi to receive data via low-power RF 433Mhz from our emonTx energy monitoring unit, and later from our emonTH remote temperature and humidity monitoring node.

Diagram: communication between OpenEnergyMonitor monitoring units, base station and web interface

In 2015 we went all-in with Raspberry Pi when we launched the emonPi, an all-in-one Raspberry Pi energy monitoring unit, via Kickstarter. Thanks to the hard work of the Raspberry Pi Foundation, the emonPi has enjoyed several upgrades: extra processing power from the Raspberry Pi 2, then even more power and integrated wireless LAN thanks to the Raspberry Pi 3. With all this extra processing power, we have been able to build an open software stack including Emoncms, MQTT, Node-RED, and openHAB, allowing the emonPi to function as a powerful home automation hub.

Screenshot: Emoncms Apps interface to emonPi home automation hub, with histogram of daily electricity use

Emoncms Apps interface to emonPi home automation hub

Inspired by the Raspberry Pi Foundation, we manufacture and assemble our hardware in Wales, UK, and ship worldwide via our online store.

All of our work is fully open source. We believe this is a better way of doing things: we can learn from and build upon each other’s work, creating better solutions to the challenges we face. Using Raspberry Pi has allowed us to draw on the expertise and work of many other projects. With lots of help from our fantastic community, we have built an online learning resource section of our website to help others get started: it covers things like basic AC power theory, Arduino, and the bigger picture of sustainable energy.

To learn more about OpenEnergyMonitor systems, take a look at our Getting Started User Guide. We hope you’ll join our community.

The post Open source energy monitoring using Raspberry Pi appeared first on Raspberry Pi.

A live-streaming Raspberry Pi nest cam: your essential Easter Monday viewing

Post Syndicated from Helen Lynn original https://www.raspberrypi.org/blog/live-streaming-raspberry-pi-nest-cam/

It’s Easter Monday, a public holiday here in the UK, and Pi Towers is still and silent. Even the continuous flight augering piler on the massive building site next door is, for a time, quiet. So here is the briefest of posts, to share with you a Raspberry Pi cam live-streaming from a blue tit nest in Alan McCullagh‘s parents’ garden in Kilkenny, Ireland. You’ll need to have Flash installed to watch.

BirdBoxKK1

BirdBoxKK1 @ USTREAM: . Birds

The eggs are expected to hatch 14 days after the last laid egg, and the mother was still laying on Thursday, so check in towards the end of the month to catch a first glimpse of the chicks. Alan’s set-up is based on our Infrared Bird Box learning resource; tell us in the comments if you’ve made something similar, or if you plan to.

The post A live-streaming Raspberry Pi nest cam: your essential Easter Monday viewing appeared first on Raspberry Pi.
