I Want Better Reporting on AI Genie Behavior

Post Syndicated from Bruce Schneier original https://www.schneier.com/blog/archives/2026/09/i-want-better-reporting-on-ai-genie-behavior.html

AI systems are regularly completing tasks in ways that their prompters don’t want or intend. Some of them are disturbing, and some of them are dangerous. This is something I’ve been calling “genie behavior,” because I think that really gets at the core of what’s happening.

I wish the popular press would report on this better. I don’t like the “going rogue” framing because it deflects the responsibility from the prompters—often the AI companies themselves. And now, pretty much anything off-script is being called “hacking.”

Take, for example, the recent stories of one of OpenAI’s models hacking into government systems. First, The New York Times writes this headline: “OpenAI’s Systems Meddled With U.S. Government Sites After Going Rogue.”

Sounds scary, but this is from the body of the article:

With the Education Department, OpenAI’s technology tried to hack the website to gather data from the department’s civil rights office but failed, researchers from the A.I. research firm Transluce said. The A.I. also pulled data from the Census Bureau website, which is housed at the Commerce Department, using login credentials it found online. Separately, OpenAI’s agents shared public data from the S.E.C. website on an online forum.

This is from the original Transluce report. It is explicit that the agents were trying to discover vulnerabilities:

The first hacking attempt was against the University of New Mexico’s Digital Library (nmdigital.unm.edu) from May 25-26 2026. Agents repeatedly tried to retrieve one photograph in UNM’s Valmora collection, both directly and through third-party relay services. They sent seven probes attempting to verify the existence of vulnerabilities, including SQL injection, command injection, and path traversals. In all cases, these tactics appear to have been unsuccessful. The agents also sent a self-described “flood: of 80 requests to the UNM server in an apparent attempt to access the image.

Transduce doesn’t talk about the other two anecdotes, and I don’t know where they come from. But one involves using Census Bureau credentials found online. (I know from a colleague that those are incredibly easy to create; all use you need is an email address.) And the other involves sharing publicly available data.

So no actual hacking. And certainly no “meddling.”

The other story making the rounds is about Australia, from the same Transduce report. The news stories have headlines like “An OpenAI Agent Hacked Australia’s Health Service” and “Rogue OpenAI agent ‘infiltrated’ Australian government website in world first.” And Prime Minister Anthony Albanese said: “There will obviously be legal consequences on it.”

Again from Transduce’s actual report:

On June 20-21, agents attempted to exploit vulnerabilities in the Australian Institute of Health and Welfare (AIHW), a government statistics agency). The agents were tasked with finding the January 2022 rolling-12-month-average government cost per person for Dermatologicals across Victorian LGAs.

Again, the agents ran into errors, including requests blocked by Cloudflare and issues with correctly identifying Tableau parameter names. As before, they then resorted to probing for exploitable vulnerabilities. Minutes after Cloudflare blocked the dataset download, an agent sent a reflected cross-site scripting probe to the same dashboard: a web address with code embedded in it, designed to test whether the site would run code supplied by an outsider. Cloudflare’s firewall blocked the probe before it reached the dashboard. When Cloudflare blocked the dataset download on AIHW’s main site, they fetched the file from AIHW’s pre-production server (pp.aihw.gov.au) instead, which served it in pieces over more than 100 scans. The file itself is public, so no non-public data was exposed, but the agent bypassed the site’s anti-bot controls.

Note the last sentence: “The file itself is public….”

I’m not saying that these AI systems aren’t incredibly sophisticated cyberattackers. I’m also not saying that they don’t occasionally autonomously attack other systems and networks. If we are ever going to get trustworthy AI—integrous AI—we are going to need to figure out how to ensure that AI systems complete tasks in line with all sorts of implicit constraints and restrictions. But every instance of genie-like behavior isn’t a cyberattack.

I want to measure genie-like behavior in AIs, but I am much more worried about human hackers enhanced with this technology than I am about this technology acting autonomously.

Изкуственият интелект и новата Студена война. Ще спрат ли САЩ Китай?

Post Syndicated from Искрен Иванов original https://www.toest.bg/izkustveniyat-intelekt-i-novata-studena-voyna-shte-sprat-li-usa-kitay/

Изкуственият интелект и новата Студена война. Ще спрат ли САЩ Китай?

Една от най-големите мечти на хората винаги е била да победят противника, без да се налага да жертват много. В продължение на хилядолетия войната чукаше на вратата на човечеството циклично и когато силните на деня изгубеха контрол върху статуквото, тя поемаше цялото напрежение, водейки със себе си огромни щети и разрушения. Така се стигна и до най-големия страх на хората – страха от ядрен апокалипсис, който се появи след изобретяването на оръжията за масово унищожение.

В продължение на близо пет десетилетия Студена война научният дебат в САЩ беше фокусиран върху това как демократичният свят да избегне унищожителна война със СССР, която ще коства на суперсилите всичко. За Москва, от друга страна, сдържането също беше приоритет, но „по руски“. Една от причините съветските стратези да не използват научния капацитет, с който разполагаха, за разработки на нови технологии, беше фактът, че страхът, а не диалогът заемаше основно място в стратегическите доктрини на Съветската империя. Оказа се обаче, че човечеството надживя и тази надпревара, а войната се промени. И в този материал ще си дадем сметка дали това е за добро, или за лошо.

Изкуственият интелект и новата Студена война. Ще спрат ли САЩ Китай?
Снимка: The White House

Краят на еднополюсния модел и възходът на „новите войни“

С нахлуването на Русия в Украйна през февруари 2022 г. ядрените сили дадоха да се разбере, че еднополюсният модел от 90-те години на миналия век е окончателно изчерпан, а старият ред, основан на правила, вече го няма. В едно от своите изказвания бившият американски президент Джо Байдън заяви, че САЩ и Русия никога не са били толкова близо до ядрен апокалипсис, а администрацията на руския президент Владимир Путин реално обмисляше ядрената опция, след като Украйна показа, че не е толкова лесна плячка, за колкото я смятаха. Тревогата да не би Вашингтон и Москва изведнъж да изтърват контрола върху ходовете си отекна дори в Пекин, а Китай побърза да декларира, че подобно действие би било червена линия в отношенията му с Русия.

Дори след като Доналд Тръмп спечели изборите в Америка, силите на статуквото от края на Студената война – САЩ, Европа и техните съюзници, макар и разделени, продължиха да се борят за съхраняването на остатъците от стария свят, а ревизионистките актьори в лицето на Русия, Иран, Северна Корея и техните партньори се обединиха около идеята колкото е възможно по-бързо да сложат край на Американския век.

Независимо от различията си обаче, всички държавни актьори осъзнават, че потенциален ядрен конфликт е безумие, и потвърждават златната аксиома от ерата на Студената война, че

ядрената война не може да бъде спечелена и затова не трябва да бъде водена.

Така завършва и ерата на т.нар. стари войни, а с армията си от високотехнологични дронове Украйна доказа, че се задава нов тип асиметрично поколение конфликти, където твърдата сила и оръжията за масово унищожение далеч не са решаващи за това дали едната страна ще надделее над другата.

Към ядрена война? Нека помислим отново

За да избегнем ядрена война, трябва да започнем да говорим за нея, задавайки правилните въпроси и тествайки всички хипотези. От Искрен Иванов.

Световните лидери обаче започнаха да си задават въпроса как могат да победят противника и да спечелят новата Студена война, без да рискуват глобален военен конфликт. Или по-точно, ако такъв все пак избухне, как човечеството може да избегне тоталното унищожение, за което говори един от най-именитите политолози, военни теоретици и стратези на XX век – гениалният Бърнард Броди.

Така се зародиха нови форми на конфликти, които се отличават от старите със значително по-ниско ниво на риск от ескалация, отколкото ефекта на ядреното сдържане. Два подобни модела бяха успешно инструментализирани от държавите ревизионисти на старото статукво: хибридните и технологичните войни, а Западът се оказа напълно неподготвен за тях. Продължението е добре известно.

Изкуственият интелект и новата Студена война. Ще спрат ли САЩ Китай?
Снимка: The White House

Защо сдържането и меката сила не работят срещу новите войни?

Истината е, че първите държави, които усетиха ефектите от хибридната война и от употребата на ИИ за нанасяне на щети върху критично важна инфраструктура, бяха страните от Централна и Източна Европа, както и някои съюзници на САЩ, като Австралия и Южна Корея. Нещо повече, оказа се, че в начало НАТО гледаше на този тип конфликти със снизхождение, отказвайки да се ангажира с разработването на стратегии за превенция на хибридните атаки и киберзаплахите.

След анексирането на Крим от Русия Алиансът най-сетне прие хибридните заплахи като равнопоставени на конвенционалните, а едва през 2021 г. съюзниците се споразумяха в тази категория да влезе и използването на ИИ за враждебни цели. Това фатално закъснение доведе и до оперативни разминавания – Русия и Китай вече бяха напреднали значително с разработването на стратегическите си доктрини, а мерките, предприети от САЩ и съюзниците им, не успяха да възпрат ефективно руската интервенция в Украйна от 2022 г.

Затова и в скандално известната хипотеза на Джон Миършаймър имаше нещо вярно – за украинската криза Западът носеше частична отговорност, но не заради разширяването на НАТО, а заради подценяването на Русия.

Вторият провал на ядреното възпиране настъпи с кризата на американската мека сила, която се прояви, когато в няколко поредни години САЩ избраха държавни глави с коренно различна политическа визия за бъдещето на страната. Това доведе до сериозна поляризация в Америка – разединение, което позволи на Китай да се възползва от политическата криза на американската демокрация и да инвестира средства в развитието на нови технологии.

По този начин Пекин приложи срещу Вашингтон същата стратегия, която САЩ употребиха срещу СССР през 80-те години на миналия век, създавайки програмата „Звездни войни“ и пренасяйки геополитическата надпревара и в Космоса. Меката сила на демокрациите и способността им да възпират новите асиметрични заплахи започна да отслабва, тъй като най-печелившото оръжие в ръцете на ядрените сили се оказа ИИ, а хибридната война започна да взема първите си жертви – огромни групи хора, които генерираха масова подкрепа за популистките движения в САЩ и Европа.

Изкуственият интелект и новата Студена война. Ще спрат ли САЩ Китай?
Снимка: The White House

Осъзнаването на САЩ пролича ясно в Стратегията за национална сигурност от 2022 г., която постави развитието на доверен ИИ сред приоритетите на Вашингтон в областта на технологиите с особено значение за националната сигурност. В известен смисъл това предреши и изхода от президентските избори в Америка през 2024 г., когато основните донори за републиканците заложиха не върху стратегията по износ на ценности, доминирала философията на САЩ след края на Студената война, а върху разработването на ИИ, който да замени ядреното възпиране и меката сила като основни инструменти в американската външна политика.

Това даде възможност на хора като Илон Мъск да спечелят огромно влияние в администрацията на новия президент, прокарвайки свои политики и интереси, често насочени към самооблагодетелстване или обсебване на ключови сегменти от американския национален интерес. Казано с други думи, Мъск и себеподобните му се превърнаха във фактор, който нито един президент оттук нататък няма да пренебрегне, тъй като те са основният източник на стратегически ресурси за американската национална сигурност.

Защо хибридната война ще се провали, но ИИ ще спечели

Макар и изключително успешна в краткосрочен план, хибридната война няма потенциала да пожъне трайни успехи срещу демокрациите. По своята природа тя е едно по-изтънчено копие на терористичните стратегии, които в най-суровия си вид целят употребата на политическо насилие срещу цивилни.

Хибридните заплахи, които пък са като едно уродливо копие – антитеза на американската мека сила, целят да легитимират самата употреба на насилие както от политиците, така и от страна на гражданите, с помощта на фалшиви новини, пропаганда и подвеждащи наративи.

Затова и ставаме свидетели на толкова сериозни разделения между хората в демократичните държави, като най-уязвими на тези заплахи са постсоциалистическите демокрации поради своята слаба устойчивост и високо ниво на дефицит и корупция.

Хибридната война спечели няколко решителни битки в Европа и макар че срещна сериозни затруднения в САЩ, обществената поляризация там е толкова висока, че тя облагодетелства изцяло външнополитическите цели на Русия и Иран. И все пак, подобно на утопичните идеологии от XIX и XX век, хибридната война е стратегия без крайна цел. Просто защото самата тя не разполага с мека сила. Опорната точка на хибридните стратегии в Източна Европа, която инкорпорира православния зилотизъм за политически цели, не се различава много от джихадизма. Но дори и най-патриотичните политици на Запад добре разбират и успешно усвояват предимствата на европейския модел и колективната отбрана пред „духовната“ вселена и метафизичната закрила на дугинизма. В един момент тези наративи просто ще се свият в границите на Евразия, за да поддържат Русия цяла.

Контролът над ИИ, от друга страна, е ключът към победата в новата Студена война. Лошата новина за Запада е, че през последните години Китай заличи голяма част от технологичното предимство на Америка, а в редица области вече я изпреварва. Това му позволява да развива ресурсите си съвсем необезпокоявано, тъй като на практика не съществуват колективни формати за ограничаване на надпреварата в сферата на ИИ. Това създава още една предпоставка глобалният ред да се трансформира от либерален в ред, основан върху принципите на ИИ.

В срещата си от пролетта на 2026 г. държавните глави на САЩ и Китай се споразумяха по много точки, но една от тях изпъкваше с особена острота сред останалите – намекът на Тръмп, че Пекин на всяка цена трябва да държи под око технологичните си разработки, за да не излезе „изкуственото съзнание“ извън контрол. С това на практика президентът на САЩ призна Си Дзинпин за равен, а стремежът ядрената надпревара да не ескалира в ядрена катастрофа сега се прехвърли в технологичната сфера. На последвалата среща във Вашингтон през септември темата отново се появи, като този път Си Дзинпин подчерта общата отговорност на двете държави развитието на ИИ да остане под човешки контрол.

Изкуственият интелект и новата Студена война. Ще спрат ли САЩ Китай?
Снимка: The White House

Но дали уверението на китайския лидер, че ИИ е под контрол, може да ни успокои? Едва ли, тъй като дори САЩ и Китай да искат да продължат да се състезават кой ще бъде глобален лидер, съдията в надпреварата е негово величество ИИ. И макар учени от цял свят да спорят дали той наистина може да пороби човечеството, на този етап перспективата изглежда по-скоро нереалистична. В крайна сметка политиците са тези, които ще решат искат ли военен конфликт, или биха заложили на дипломацията; имат ли желания за преговори, или биха водили война без край.

Големият въпрос сега е дали Китай ще успее да се възползва от възхода си в тази сфера и дали САЩ ще съумеят да върнат позициите си в технологичната надпревара?

Къде остават хората?

Най-големите щети за демокрациите обаче идват от това, че дебатът за ИИ сериозно подкопава червените линии, отвъд които държавата може да се намесва в личното пространство на хората. Това е и една от причините, поради която администрацията на Доналд Тръмп вече не гледа на много извънредни мерки като на нарушаващи свободите на американците. Роналд Рейгън пожертва социалната държава в Америка, за да победи СССР; следващите държавни глави на САЩ ще са изправени пред същата дилема.

Проблемът е, че ако Америка пожертва ценностите, върху които е основана, ще се промени веднъж и завинаги. Това неизбежно ще стане, ако Вашингтон пожелае непременно да доминира в новата надпревара с Пекин, а политиците в САЩ вероятно ще обвинят ИИ за залеза на демокрацията така, както Джордж Буш-младши оправда „Патриотичния акт“ с „Ал Кайда“ и талибаните.

Китай от своя страна не дължи прозрачност на гражданите си, но именно той може да се окаже в позицията да решава иска ли да предостави повече автономия на ИИ и в какви рамки. Всеки китайски лидер би дал всичко, за да победи Америка и да сбъдне мечтата на поколения китайци – Поднебесната империя отново да стане икономически център на света. Ако обаче Пекин заложи на неконтролирано разработване на автономни системи за сигурност, това може да доведе до потенциален сценарий COVID 2.0, в който нещата ще излязат извън контрол.

Изкуственият интелект и новата Студена война. Ще спрат ли САЩ Китай?
Снимка: The White House

Твърдението, че Китай носи отговорност за пандемията, е конспиративно, но е факт, че малките грешки водят до големи катастрофи. Затова срещите между американските и китайските лидери са необходими, за да се реши докъде силните на деня са готови да рискуват в своята надпревара.

В тази надпревара значение има и дългогодишното технологично и военно сътрудничество между САЩ и Израел, особено в областта на отбраната, киберсигурността и технологиите с двойна употреба. Израелският технологичен сектор допълва американските възможности, но войната в Близкия изток показва и колко тясно е свързано технологичното съперничество с геополитическите конфликти.

Вече не е важно кой ще има по-добрия ИИ, а дали САЩ, Китай и техните партньори ще успеят да изградят правила, които да не позволят технологичната надпревара да ескалира в самостоятелен конфликт. В ядрената епоха подобна задача довежда до механизми за възпиране и контрол над въоръженията. В епохата на ИИ такива механизми тепърва трябва да бъдат създадени. Ако вече не е твърде късно.

Заглавно изображение: Доналд Тръмп и Си Дзинпин в Храма на небето по време на посещението на американския президент в Китай през май 2026 г. Снимка: The White House

[$] Native support for Rust on the GPU

Post Syndicated from daroc original https://lwn.net/Articles/1095731/

Christian Legnitto is the maintainer of

rust-gpu
and

Rust CUDA
, two
libraries that make it possible to program a computer’s graphics processing unit
(GPU) from Rust. He isn’t satisfied with the current state of GPU support in
Rust, however. In a talk at

RustConf 2026
, he explained his vision for how the
GPU could become an ordinary compiler target for normal Rust code, without the
need for any special libraries or new ecosystem support. That vision is not yet
fully implemented, but he does have a prototype that he is preparing to release.

Сърбия – първият китайски плацдарм в Европа

Post Syndicated from Александър Малинов original https://www.toest.bg/surbiya-purviyat-kitayski-platsdarm-v-evropa/

Сърбия – първият китайски плацдарм в Европа

Геополитическите сътресения след началото на руската агресия срещу Украйна са многобройни. От практическото разделяне на НАТО – основния западен съюз между Америка и Европа, по темата за нуждата от оръжейна помощ за Киев до енергийната криза, обхванала Централна Азия след украинската кампания срещу руските рафинерии. Балканите също са основно място, където отражението на войната се забелязва като геополитически промени.

Една от страните, в които това е най-видно, е Сърбия. Заради отслабването на НАТО, породено от отдръпването на САЩ, и заради невъзможността на Русия да поддържа нивото на влияние в Белград отпреди 2022 г. в Сърбия се отвори вакуум за външно въздействие, който вече се запълва от Китай. Пекин рязко увеличи влиянието си над балканската страна през последните четири години. То мина отвъд инвестициите и големите инфраструктурни проекти и стигна до въоръжаването на сръбската армия с част от най-модерните технологии, с които разполага Китай.

#PočeloJe: „Има нещо гнило в Сърбия“

В началото на февруари 2019 година Сърбия отбелязва 10-та седмица на протести срещу управляващата коалиция и политиката на президента Вучич.

Макар Александър Вучич да продължава да декларира военен неутралитет и да поддържа стремежа към членство в Европейския съюз, разрастващото се партньорство в сферата на отбраната с Пекин подсилва очертанията на сложната геополитическа обстановка и изпраща тревожни сигнали към съседите на Сърбия. Тази динамика представлява пореден риск за стабилността и сигурността на целия Балкански полуостров и е пример за продължаващото засилване на влиянието на външни сили върху Югоизточна Европа.

Китайско оръжие на европейска земя

Основната причина за отдалечаването на Сърбия от Москва е натискът от страна на Запада – и по-специално на ЕС и САЩ. Налице са директните западни санкции срещу руската икономика и натискът за дипломатическо изолиране на Путин. Но Белград също така от години е съветван от Брюксел и Вашингтон да съгласува външната си политика с тяхната и да осъди руското нахлуване в Украйна. В резултат на това Сърбия се присъедини към резолюцията на ООН, осъждаща нападенията на Москва, и гласува „за“ изключването на Русия от Съвета на ООН по правата на човека. Сърбия също така отказа да признае подкрепяните от Русия фиктивни референдуми за анексиране, проведени през септември 2022 г. в окупираните от Русия украински територии. Сръбските власти осъждат всякакви опити за сепаратизъм, за да останат последователни в позицията си относно статуса на Косово.

На фона на ограничения капацитет на Русия да поддържа предишното си военно и икономическо присъствие в Сърбия Белград задълбочи военните си връзки с Пекин. Близо 60% от вноса на оръжия в Сърбия за периода 2020–2024 г. е бил от китайски произход, показват данни на Стокхолмския международен институт за изследване на мира (SIPRI), цитирани от Радио „Свободна Европа“. В рамките на това военно сближаване Белград реализира мащабни доставки на съвременни китайски оръжейни системи, превръщайки се в първия им оператор на европейска земя. Сред придобитите технологии се открояват далекобойните зенитно-ракетни комплекси FK-3, разузнавателно-ударните бойни дронове CH-92A и CH-95, както и свръхзвуковите балистични ракети въздух–земя CM-400AKG, които се интегрират към изтребителите МиГ-29.

Една година след трагедията в Нови Сад. Какво става в Сърбия?

На 1 ноември се навършва една година от трагедията в Нови Сад, която провокира някои от най-големите протести в Сърбия, а и в региона ни. Италианката Джорджа Спадони, която обича и познава Балканите, ни разказва в няколко поредни материала как изглеждат Белград и цялата страна година по-късно.

Сърбия и Китай вече имат и директен опит във взаимната интеграция не само на части от армиите си, но и на полицейските си сили. През 2019 г. за първи път китайски и сръбски полицаи патрулираха заедно в Белград, а през същата година специални части на двете страни проведоха съвместни антитерористични учения близо до сръбската столица. През 2025 г. части от въоръжените сили на двете държави имаха учение в китайската провинция Хъбей, а през септември 2026 г. сръбски полицаи участваха в общи патрули с китайската полиция в провинция Хайнан.

Засиленото китайско военно присъствие на Балканите и мащабното въоръжаване на Белград с китайски военни системи предизвикаха остро безпокойство сред съседни на Сърбия държави. През 2022 г. от страна на Косово официално бяха отправени предупреждения, че бързата сръбска милитаризация и придобиването на напреднали отбранителни и ракетни технологии от Китай застрашават регионалния мир и стабилност. Подобни тревоги бяха изразени и от Хърватия, чийто президент Миланович критикува купуването на нови нападателни оръжия, призовавайки по този начин западните съюзници в ЕС и НАТО да следят внимателно геополитическите рискове от нарастващото военно влияние на Китай на Балканите.

Какво става в Сърбия? Езикът на протестите – музика и архитектура

Джорджа Спадони е на обиколка из Белград с нова група туристи, на които разказва за музиката и архитектурата на града, а през този разказ – и на нас за случващото се в Сърбия. Това е втора част от поредицата, посветена на годишнината от трагедията в Нови Сад и на протестите за промяна.

„Желязното приятелство“ има цена

Сътрудничеството между Пекин и Белград в сферата на сигурността се базира на големият възход в политическите и икономическите отношения между двете държави в последното десетилетие, а Сърбия често определя връзката като стратегическо „желязно приятелство“. През последните години Пекин се утвърди като най-важния външен партньор за Сърбия на Вучич, осигурявайки не само мащабни финансови инвестиции, но и безрезервна дипломатическа подкрепа по чувствителни теми като Косово – Китай не признава независимостта на Косово и не поддържа дипломатически отношения с Прищина. Китайският интерес да подкрепи Сърбия в усилията ѝ да оспори независимостта на Косово следва политиката на Пекин за „единен Китай“ и поставя паралели по отношение на спора за статуса на Тайван.

Този модел на сътрудничество се материализира чрез знакови китайски проекти в сръбската тежка промишленост и инфраструктура – като приватизацията на стоманодобивния завод в Смедерево и на медодобивния комбинат в град Бор (на 40 км от българската граница), както и изграждането на ключови транспортни артерии и магистрали. Макар тези инвестиции да стимулират икономическия растеж и да носят краткосрочни ползи за Белград, анализаторите сочат и сериозните рискове, свързани с корупция, нарастващ финансов дълг към Пекин и нарушаване на екологичните стандарти.

Централната роля на Сърбия в плановете на Китай за засилено влияние в Европа представлява сполучливо съчетание между стремежа на Белград да се възползва от географското си положение и от многовекторната си външна политика, от една страна, и настъплението на Пекин към европейската периферия като част от стратегия за по-широка глобална експанзия, от друга. Историческите предпоставки за това съществуват още от времето на югославската политика на необвързаност от времето на Тито, когато страната балансираше между Изтока и Запада като лидер на Движението на необвързаните страни, и се задълбочиха след бомбардировките на НАТО през 1999 г.

Какво става в Сърбия? Непредвидимото бъдеще

Последният текст от поредицата на Джорджа Спадони за Сърбия ни завърта през историята на страната от 90-те до днес, за да ни покаже, че сякаш нищо не се е променило, и да ни напомни да погледнем и в своята градина, все още обрасла с политически плевели от миналото, с корени дълбоко под земята.

Геополитическата безизходица в периода след разпадането на Югославия и последвалите войни създадоха благоприятни условия за задълбочаване на сръбските отношения с неевропейски глобални играчи с ​цел да се използват достъпът до пазари, политическата подкрепа и ресурсите на Русия, Китай или Турция. Макар и първоначално с тактически характер, този подход се утвърди като водеща концепция във външната политика на Александър Вучич. Десетилетията на колебание относно разширяването на ЕС даде допълнителен аргумент на Белград да превърне застоя в процеса на европеизация в лост за влияние.

Скорошната оставка на Александър Вучич от президентския пост едва ли означава край на тази политика. Той напуска седем месеца преди края на мандата си, за да се включи в предсрочните парламентарни избори на 25 октомври и да се бори за премиерския пост – позиция, от която би могъл да продължи същото балансиране между ЕС, Китай и Русия.

Най-новата вълна на китайско ангажиране в Сърбия е от началото на второто десетилетие на XXI век, като ключов момент е изграждането на Пупиновия мост в Белград през 2014 г. Това събитие бележи мащабно рестартиране на двустранните отношения и проправя пътя за нови проекти и инвестиции в няколко посоки. Оттогава инфраструктурните инициативи обхванаха строителството и модернизацията на железопътни линии, както и експресното (в сравнение с България) изграждане на нови участъци от автомагистралната мрежа. Макар модернизацията на железопътната връзка Белград–Будапеща да е обект на правни проверки и политически дебати в западните политически среди, Пекин се надява да я превърне в убедителен пример за успешно сътрудничество.

Наред с милитаризацията, стратегическото настъпление на Пекин на Балканите намира своето изражение и в мащабното внедряване на високотехнологични системи за видеонаблюдение и лицево разпознаване. Разследване на „Свободна Европа“ разкрива как китайски гиганти като Huawei, Hikvision и Dahua завладяват общественото пространство на Балканите чрез проекти, обвързани с „Безопасен град“ – китайския модел за управление на градската среда чрез събиране и обединяване на огромни количества данни.

В Белград са инсталирани над 1000 камери на Huawei с възможности за лицево разпознаване, а китайски системи за видеонаблюдение навлизат и в десетки по-малки сръбски общини. Разследване на Радио „Свободна Европа“ установява оборудване с възможности за лицево разпознаване в поне 10 от 42 проверени общини и градове, което поражда опасения сред гражданското общество и правозащитните организации относно личните свободи и потенциала за политически контрол.

Накъде след „Мюнхен 2026“? Отворените въпроси пред Европа и България

Мюнхенската конференция по сигурността затвърди усещането (де да беше само такова), че старият трансатлантически баланс се разпада. Вече всички сме на една вълна по този въпрос. Но докато Европа търси автономия, България рискува да остане между линиите на разделението. От Александър Малинов.

Подобни тенденции предизвикват тревога и в държавите членки на Европейския съюз, включително в България, където китайска техника навлиза в обществено значими сектори, като градския транспорт и публичната инфраструктура на София. Въпреки че тези мрежи често се оправдават с аргументи за сигурност и контрол на трафика, експертите по киберсигурност предупреждават за сериозни софтуерни уязвимости и рискове от нерегламентиран достъп до данни. В контекста на строгите ограничения в САЩ и в редица западни държави срещу тези китайски производители, разрастващата се мрежа от камери с китайски произход в Югоизточна Европа се превръща в ефективен инструмент за геополитическо и технологично влияние.

От тази страна на границата

За властите в София засилването на военното влияние на Китай в съседна страна би следвало да е въпрос от първостепенна важност, но досега липсват каквито и да е официални коментари или косвени реакции относно действията на Белград. Правителството на Румен Радев всъщност увеличава рисковете, свързани с националната сигурност и регионалната стабилност. Резкият завой във външната ни политика превърна България в страна, която, изглежда, следва насоки от Москва дори когато това е в противовес на собствения ѝ национален интерес.

Последният пример за тази предателска политика е отказът на правителството да участва в новата инициатива на НАТО за защита от дронове. Програмата предвижда през следващите пет години да бъдат инвестирани над 40 млрд. долара в способности за противодействие на дронове и обучение на пет пъти повече оператори на дронове до края на 2027 г. Повишаването на капацитета за бързо откриване, идентифициране и неутрализиране на безпилотни летателни апарати вече е от първостепенна важност за отбранителните способности на всяка страна. На този фон отказът на България да се включи в инициативата оставя страната извън новия общ проект на НАТО именно в момент, когато съседна Сърбия ускорява превъоръжаването си, включително с китайски технологии.

Китайското присъствие в Сърбия показва колко лесно едно геополитическо „приятелство“ може да прерасне в зависимост, застрашаваща целия регион. А за нас като държава остава въпросът дали виждаме какво става непосредствено отвъд западната ни граница, или поне малко по-далече от носа ни.

Implementing customer managed keys for AWS Lambda durable functions with Terraform

Post Syndicated from Rajdeep Banerjee original https://aws.amazon.com/blogs/compute/implementing-customer-managed-keys-for-aws-lambda-durable-functions-with-terraform/

If you run regulated workloads, you must control how persisted data is encrypted and who can access it. You need to manage encryption key rotation schedules, restrict decryption to authorized principals, and produce audit evidence that proves encryption controls are operating as designed.

AWS Lambda durable functions build resilient, multi-step workflows that survive failures through automatic checkpointing. The checkpoint mechanism persists execution state, including step results, payloads, and callback responses, to durable storage. For payment processing workloads, this persisted data is sensitive. AWS Lambda durable functions support customer managed keys from AWS Key Management Service (AWS KMS). A customer managed key gives you three controls: you set the key rotation schedule, you restrict decryption access through the key policy, and you generate per-function audit trails in AWS CloudTrail. A durable execution uses the same encryption key it started with for its entire lifetime. Changing or removing the key affects only executions that start after the change.

Updating the customer managed key policy to remove decrypt permissions, or disabling the key, stops the Lambda service from accessing previously checkpointed state. Customer managed key deletion is a permanent action, and all durable executions encrypted with that key become unrecoverable because the Lambda service has no mechanism to restore the data. Before scheduling key deletion, use the AWS KMS waiting period (7 to 30 days) and monitor AWS CloudTrail for Decrypt calls to confirm that the key is no longer in active use.

In this post, you learn to configure a customer managed key to encrypt durable execution data in an event-driven payment processing workflow. You create a symmetric encryption key in AWS KMS and define a key policy that grants the Lambda service, the function’s execution role, the function author, and durable execution operators only the AWS KMS actions each principal requires. You then configure the function to use the key for durable execution encryption and verify encryption operations through AWS CloudTrail logs. By the end, you have a deployable reference architecture you can adapt for regulated workloads running on Lambda durable functions.

To learn more about how AWS Lambda encrypts durable execution data, see Encrypting AWS Lambda durable execution data in the AWS Lambda Developer Guide.

Solution overview

The sample application implements an event-driven payment processing pipeline using Amazon DynamoDB, Amazon EventBridge, Amazon EventBridge Pipes, AWS Lambda, and Amazon SQS. The pipeline receives authorized payment transactions, validates and enriches them. A Lambda durable function applies business rules to the enriched transactions. The approved transactions are sent to a downstream settlement system for posting.

The following section covers the key architectural steps.

Architecture steps

  1. The upstream authorization system writes authorized payment records to a DynamoDB table.
  2. DynamoDB Streams captures each new record as an ordered change event.
  3. Amazon EventBridge Pipes polls the record from the DynamoDB stream. The pipe triggers a Lambda function as part of enrichment step for duplicate checking.
  4. The deduplication Lambda uses a DynamoDB table with conditional writes to identify duplicate inbound transactions based on transaction properties and time window.
  5. When the deduplication is successful, the pipe publishes an event to the Amazon EventBridge custom event bus.
  6. An Amazon EventBridge rule invokes a Lambda function for matching events. The function adds business context such as account type, bank routing details, and merchant category codes. The function publishes a new enriched event to the custom event bus.
  7. Another Amazon EventBridge rule matches the enriched events to a Lambda durable function. The durable function applies business rules to the incoming event. When the event passes all business rules, the function publishes a new event to the event bus.
  8. An Amazon EventBridge rule routes the approved event to an Amazon SQS queue preserving ordering for settlement and buffering against downstream throughput limits.
  9. The Posting Lambda function reads from the Amazon SQS and invokes the downstream posting subsystem to post the transaction. Finally, the function publishes a completion event to the event bus completing the transaction lifecycle.

With customer managed keys configured on DynamoDB, Amazon EventBridge, SQS, and the AWS Lambda durable function, every piece of persisted data in this pipeline is encrypted with keys you own and control. The walkthrough that follows shows you how to deploy this configuration with Terraform.

Figure 1 shows the reference architecture for this solution.

Reference architecture

Reference architecture for payment processing using Lambda durable functions

Figure 1: Payment processing using Lambda durable functions

Prerequisites

To deploy this solution, you need the following prerequisites:

  1. AWS account and CLI: An active AWS account with the AWS CLI installed and configured with appropriate credentials.
  2. Terraform: Terraform installed (version 1.0 or later) for infrastructure provisioning.
  3. Python environment: Python 3.11 or later, with pytest for running unit tests. The aws-durable-execution-sdk-python package requires Python 3.11 or later.
  4. AWS Identity and Access Management (IAM) permissions: The IAM permissions to create the resources. Follow the sample repository for the sample policy.
  5. Basic understanding and familiarity with AWS Serverless services.

Solution walkthrough

The following is a step-by-step guide to deploy and test the payment processing solution.

Step 1: Clone the repository

git clone https://github.com/aws-samples/sample-payment-processing-with-lambda-durable-functions.git
cd sample-payment-processing-with-lambda-durable-functions/source

Step 2: Run unit tests

Validate the payment processing logic locally before deploying:

cd lambda-src/business_rules
pip3 install -r requirements-test.txt
pytest test_app.py -v

This runs unit tests that cover transaction validation, business rule checks (foreign transaction detection, currency conversion, merchant type), event schema validation, and misconfiguration handling. The tests use the AWS Durable Execution Testing SDK to run the handler locally without deploying AWS resources.

Figure 2 shows an example of test results running locally.

Test run results of the business rules

Figure 2: Test run results of the business rules

Step 3: Inspect the Lambda durable functions construct

Open the payments-business-rules Lambda function in source/lambda-src/business_rules/business-rules-app.py for a sample Lambda durable function. Refer to Figure 3 for the code walkthrough.

Key features used

  1. @durable_execution decorator: Transforms a standard Lambda handler into a durable function handler. The durable execution SDK manages checkpointing automatically. No infrastructure changes are required.
  2. context.step("validate-transaction"): Validates that the transaction has a non-empty issuingCountryCode. The durable execution checkpoints the result (True or False) to durable storage. The durable execution restores checkpoint results instead of re-executing steps during the replay phase. This phase occurs whenever the function is re-invoked after an interruption such as a wait period completing, a failure, or a suspension. This checkpointed result is part of the durable execution data encrypted by your customer managed key.
  3. context.step("publish-posting-failure"): Publishes the full Amazon EventBridge envelope to Amazon SNS when validation fails. This step only runs on the failure path. The runtime checkpoints the Amazon SNS publish response to durable storage.
  4. context.parallel("run-business-rules"): Runs three independent rule checks concurrently: foreign transaction detection, currency conversion, and merchant type validation. Each branch checkpoints independently. If one branch fails, the others are not replayed on resume. Each branch result is persisted to durable storage and encrypted by the customer managed key.
  5. ctx.step("trigger-foreign-transaction-rule") (inside parallel): Compares billingAmount against transactionAmount. If they differ, it emits a ForeignTransactionFound event to Amazon EventBridge. This step is checkpointed independently within the parallel group.
  6. ctx.step("trigger-conversion-rate-rule") (inside parallel): Checks whether conversionRate equals 1. If so, it emits a CurrencyConversionTransactionFound event to Amazon EventBridge. This step is checkpointed independently within the parallel group.
  7. ctx.step("trigger-merchant-rule") (inside parallel): Checks whether merchantType equals AAFF. If so, it emits a WarningMerchantTypeTransactionFound event to Amazon EventBridge. This step is checkpointed independently within the parallel group.
  8. context.step("post-transaction-processed"): Emits the final TransactionPostingApproved event to Amazon EventBridge. This step is only reached when validation passes and all business rules complete. The runtime checkpoints the Amazon EventBridge response. On replay, if this step already succeeded, the event is not re-published, which guarantees exactly-once approval semantics.
  9. context.logger: Provides replay-aware logging throughout the handler. During replay of previously completed steps, log statements are suppressed to prevent duplicate log entries in Amazon CloudWatch.
Lambda durable functions code walkthrough

Figure 3: Sample Lambda durable functions code

Step 4: Deploy infrastructure with Terraform

Terraform currently doesn’t support attaching a customer managed key directly to the durable function. You create the symmetric key in Terraform and then associate the key with the durable function on the AWS Management Console. Refer to source/durable_kms.tf for the key configuration.

Initialize and deploy the AWS resources that make up the solution:

cd ../../
terraform init
terraform plan -var="region=us-east-2"

Review the plan output, then apply:

terraform apply -var="region=us-east-2" --auto-approve

Note: Replace us-east-2 with your preferred AWS Region.

On successful completion, Terraform outputs the AWS KMS key alias, key ARN, and DynamoDB Streams ARN used by the event-driven pipeline:

Apply complete! Resources: N added, 0 changed, 0 destroyed.

Outputs:

durable_kms_key_alias = "durable-function-encryption"
durable_kms_key_arn = "arn:aws:kms:us-east-2:xxxxxxxxxxxx:key/4e87d4c2-1190-4db4-8b97-46657f83ee00"
stream_arn = "arn:aws:dynamodb:us-east-2:xxxxxxxxxxxx:table/visa/stream/2026-03-16T14:25:47.847"

Step 5: Verify Lambda durable functions configuration

In the AWS Lambda console, navigate to the payments-business-rules function. Confirm that the function Type displays Durable, which indicates that the checkpoint-and-replay mechanism is active. Figure 4 shows the expected function configuration.

The durable function in the AWS Lambda console

Figure 4: The Lambda durable function in the AWS Lambda console

Step 6: Add the AWS KMS key to the Lambda durable function

  1. The durable function is not encrypted with a customer managed key. Figure 5 shows the function’s encryption configuration as empty.

    The Lambda durable function missing an AWS KMS key in the AWS Lambda console

    Figure 5: The Lambda durable function missing a customer managed key in the AWS Lambda console

  2. Choose Edit, then turn on Customize encryption settings as shown in Figure 6.

    The Lambda durable function encryption settings in the AWS Lambda console

    Figure 6: The Lambda durable function check encryption in the AWS Lambda console

  3. Select the AWS KMS key ARN created for the durable function. The key ARN is available in the Terraform output from Step 4. Figure 7 shows the key selection.

    Selecting the AWS KMS key for the durable function in the AWS Lambda console

    Figure 7: Select the AWS KMS key ARN for the durable function in the AWS Lambda console

  4. Choose Save and confirm that the durable function is now encrypted with a customer managed key, as shown in Figure 8.

    The Lambda durable function with the AWS KMS key in the AWS Lambda console

    Figure 8: AWS Lambda durable function with the customer managed key in the AWS Lambda console

Step 7: Execute a test payment

Invoke the payments-visa-mock Lambda function to simulate an end-to-end authorization flow. The mock function reads sample Visa authorization messages from a CSV file and writes them to DynamoDB, which triggers the event-driven pipeline. Figure 9 shows a sample test invocation.

Invoking the payments-visa-mock function to trigger the workflow

Figure 9: Invoke the payments-visa-mock function to trigger workflow

Figure 10 shows a sample response after invocation.

Test results from the payments-visa-mock function

Figure 10: Test results from the payments-visa-mock function to trigger workflow

The mock Lambda invocation creates records that follow the process described in the preceding architecture steps.

Step 8: Verify results

Open Amazon CloudWatch Logs and inspect the log group /aws/lambda/payments-business_rules. This log group belongs to the Lambda durable function for this use case. Figure 11 shows the CloudWatch log group on the console.

Search in CloudWatch Logs for the durable function log group

Figure 11: Search in CloudWatch

You see the complete business rules lifecycle for each transaction, as shown in Figure 12. The highlighted sections show all the business rules performed by the durable function. Each step is checkpointed by the runtime and encrypted by the customer managed key.

Search Results in lambda durable functions console

Figure 12: Search Results in lambda durable functions console

You can also check the other log groups to trace the full pipeline:

  • /aws/lambda/payments-enrich: Transaction enrichment logs.
  • /aws/lambda/payments-posting: Settlement posting logs.

Step 9: Verify the customer managed key configuration

You can verify the key configuration by using the AWS CLI:

aws lambda get-function-configuration \
    --function-name payments-business-rules \
    --query "DurableConfig" \
    --region us-east-2

Expected response:

{
    "KMSKeyArn": "arn:aws:kms:us-east-2:xxxxxxxxxxxx:key/4e87d4c2-1190-4db4-8b97-46657f83ee00",
    "RetentionPeriodInDays": 7,
    "ExecutionTimeout": 180
}

You can search in AWS CloudTrail to track the AWS KMS calls. When you configure or update the customer managed key on a durable function, Lambda validates the key policy with dry-run GenerateDataKey and Decrypt calls. These appear in CloudTrail with a DryRunOperationException error code, which confirms that the key policy permissions are correct and does not indicate an actual error. For more details, see Encrypting AWS Lambda durable execution data.

Clean up

To avoid ongoing charges, destroy all deployed resources using the following command:

terraform destroy -var="region=us-east-2" --auto-approve

Expected output:

Destroy complete! Resources: N destroyed.

Conclusion

In this post, you configured a customer managed key to encrypt durable execution data in a Lambda durable function. With a customer managed key, you control the key rotation schedule, restrict decryption access through the key policy, and generate per-function audit trails in AWS CloudTrail. You can revoke access to durable execution data at any time by updating the key policy, giving you full control over who can read execution state. In-flight executions stop at the next checkpoint call and new executions must be started after restoring access. For details, see When the customer managed key is unavailable.

For payment processors and financial institutions, encrypting durable execution data with a customer managed key satisfies compliance obligations for data-at-rest encryption, key governance, and access auditability across multi-step transaction workflows.

To get started, clone the sample repository and follow the preceding walkthrough. To learn more about Lambda durable functions, see the AWS Lambda Developer Guide.

Building an LLM-powered DAG failure analysis plugin for Amazon MWAA

Post Syndicated from Sushant Samantaray original https://aws.amazon.com/blogs/big-data/building-an-llm-powered-dag-failure-analysis-plugin-for-amazon-mwaa/

Apache Airflow has become the orchestration backbone for data pipelines across industries. But as those pipelines grow to hundreds of directed acyclic graphs (DAGs) spanning services like AWS Glue, Amazon EMR, Amazon Athena, and Amazon Redshift, debugging a single task failure turns into a significant operational challenge. When a task fails, data engineers sift through logs, cross-reference DAG configurations, and analyze error messages to find the root cause, delaying pipeline service level agreements (SLAs) and impacting team productivity.

In this post, we show you how to build a custom Apache Airflow plugin that integrates with Amazon Bedrock to automatically analyze DAG task failures and provide actionable diagnostic insights. The plugin deploys to Amazon Managed Workflows for Apache Airflow (Amazon MWAA) and provides AI-powered root cause analysis on demand.

The complete source code for this solution is available in the sample-aws-mwaa-llm-powered-plugin GitHub repository. Clone the repository and follow along as we explain the design decisions throughout this post.

Solution overview

Apache Airflow is a widely adopted open source platform for programmatically authoring, scheduling, and monitoring complex data pipelines. Teams use Airflow to orchestrate extract, transform, and load (ETL) processes, machine learning workflows, and data lake management across industries.

Amazon MWAA is a managed service that makes it straightforward to run Apache Airflow on AWS without the operational burden of managing the underlying infrastructure. With Amazon MWAA, you can focus on authoring workflows and business logic while AWS handles provisioning, patching, scaling, and securing your Airflow environments.

The solution uses the following AWS services:

The plugin adds an analysis view directly into your Airflow UI. At a high level, when a task fails and you trigger an analysis, the plugin automatically does the following:

  1. Retrieves the failed task instance metadata from the Airflow metadata database.
  2. Collects comprehensive context including task logs, DAG source code, and operator-specific scripts.
  3. Sends the enriched context to Amazon Bedrock for analysis.
  4. Returns a structured diagnostic report with root cause identification, step-by-step resolution, and prevention recommendations.

How it works

The preceding four steps happen behind a single Analyze Task action. The following diagram and pipeline show the high-level architecture and how the plugin carries them out.

Architecture of the task analyzer plugin connecting the Airflow UI on Amazon MWAA to Amazon Bedrock and Amazon S3

Figure 1: High-level architecture of the LLM-powered task analyzer plugin on Amazon MWAA

The plugin follows a multi-step analysis pipeline:

  1. User triggers analysis – From the Airflow UI, you select a failed task and choose Analyze Task.
  2. Context collection – The plugin retrieves task metadata, execution logs, and DAG source code from the Airflow metadata database and Amazon S3.
  3. Operator-aware enrichment – Based on the operator type, the plugin fetches the actual code or query that failed (for example, a PySpark script from AWS Glue or a SQL query from Amazon Athena).
  4. Foundation model analysis – The enriched context is sent to Amazon Bedrock, which returns a structured diagnostic report.
  5. Results presentation – The analysis displays in the Airflow UI with actionable recommendations.

All AWS API calls (Amazon Bedrock, Amazon S3, and AWS Glue) are authenticated through the aws_default Airflow connection. By default on Amazon MWAA, this connection has no static credentials, so boto3 falls back to the environment’s execution role. This means there are no keys to manage or rotate. If you need to call Amazon Bedrock or fetch scripts using a different identity, you can supply those credentials in the aws_default connection. This can be a dedicated IAM role or a cross-account principal, used instead of the execution role.

Operator-aware context collection

A key differentiator of this solution is its ability to understand different Airflow operator types and automatically fetch the associated code or queries. Unlike generic log analyzers, the plugin retrieves the actual code that failed, not just the error message.

The following table summarizes what the plugin fetches for each operator type:

Operator type What the plugin fetches Source
GlueJobOperator PySpark or Python script Amazon S3 (from the AWS Glue job definition)
EmrAddStepsOperator Spark or Python script Amazon S3 (from step arguments)
EmrServerlessStartJobOperator Spark script Amazon S3 (from job driver)
AthenaOperator SQL query Inline (from operator parameters)
RedshiftDataOperator SQL query Inline (from operator parameters)
BashOperator Bash command Inline (from operator parameters)
PythonOperator Python function DAG source code

This approach means the foundation model can analyze the actual logic that failed, correlating error messages with specific lines in your code for precise root cause identification.

Prerequisites

Before you begin, make sure that you have the following:

  • An Amazon MWAA environment running Apache Airflow 3.x (this walkthrough uses Airflow 3.2). The plugin registers its UI through the FastAPI-based plugin interface (fastapi_apps) introduced in Airflow 3.x. For setup instructions, see Get started with Amazon MWAA.
  • Access to Amazon Bedrock with the Anthropic Claude model family enabled in your AWS Region. This walkthrough uses Anthropic Claude, but you can adapt the plugin to work with Amazon Nova or other foundation models by modifying the prompt payload format in prompts.py. See Model access.
  • An AWS Identity and Access Management (IAM) execution role for Amazon MWAA with bedrock:InvokeModel and s3:GetObject permissions.
  • An Amazon S3 bucket backing your Amazon MWAA environment with bucket versioning enabled. See Create an Amazon S3 bucket for Amazon MWAA.
  • Python 3.10 or later installed locally.
  • The AWS Command Line Interface (AWS CLI) configured with appropriate permissions.

Note: In most Regions, you invoke Claude through an inference profile ID (for example, us.anthropic.claude-sonnet-4-5-20250929-v1:0) rather than a bare on-demand model ID. Run aws bedrock list-inference-profiles to confirm a model is ACTIVE before configuring it.

Plugin design

In this section, we explain the plugin design and its key components. The next section walks through deploying it to your Amazon MWAA environment.

Plugin structure

The plugin follows the standard Apache Airflow plugin architecture. The repository is organized as follows:

plugins/
├── task_analyzer_plugin.py    # Main plugin: FastAPI app, endpoints, registration
└── task_analyzer/
    ├── __init__.py
    ├── prompts.py             # Bedrock model configuration and prompt templates
    ├── script_utils.py        # Operator-specific script fetching logic
    ├── templates/
    │   └── index.html
    └── static/
        ├── css/
        │   └── styles.css
        └── js/
            ├── app.jsx
            ├── components.jsx
            ├── config.js
            ├── template.jsx
            └── utils.jsx

The repository also includes example DAGs that simulate various failure scenarios across different operator types.

Plugin registration

In Apache Airflow 3.x, the web component of a plugin is registered as a FastAPI application through the fastapi_apps attribute. In task_analyzer_plugin.py, the TaskAnalyzerPlugin class registers the FastAPI app under /task-analyzer and adds a view to the task instance page:

class TaskAnalyzerPlugin(AirflowPlugin):
    name = "task_analyzer_plugin"

    fastapi_apps = [
        {
            "app": app,
            "url_prefix": "/task-analyzer",
            "name": "Task Analyzer",
        }
    ]

    external_views = [
        {
            "name": "Analyze Task",
            "href": "/task-analyzer/",
            "url_route": "task_analyzer_view",
            "destination": "task_instance",
        }
    ]

Airflow automatically discovers any AirflowPlugin subclass in the plugins folder. No registration call or configuration change is needed. On Amazon MWAA, the file is delivered inside plugins.zip and extracted to /usr/local/airflow/plugins/.

Analysis engine

The analysis engine is the POST /api/analyze-task endpoint in task_analyzer_plugin.py. When you trigger an analysis, the endpoint performs the following steps:

  1. Retrieves AWS credentials from the aws_default Airflow connection. To override, edit the aws_default connection in the Airflow UI (Admin > Connections).
  2. Assembles a context dictionary from the request (task metadata, logs, DAG source).
  3. Enriches the context with an operator-specific script through fetch_and_add_operator_script.
  4. Builds the prompt using the template in prompts.py.
  5. Invokes Amazon Bedrock and returns the structured analysis.

Operator script fetching

The process_operator_script function in script_utils.py routes script retrieval based on operator type:

  • External scripts (AWS Glue, Amazon EMR) – The plugin calls the AWS Glue API to look up the job definition, then reads the PySpark script from Amazon S3. Amazon EMR handlers follow the same pattern, extracting the script path from the step configuration or job driver.
  • Inline scripts (Amazon Athena, Amazon Redshift, BashOperator, PythonOperator, DBTOperator) – The plugin reads the query or command directly from the task’s rendered template fields with no external API call.

The plugin implements smart fetching: for external scripts, it only makes the Amazon S3 API call when the error message contains code-relevant patterns (such as SyntaxError, TypeError, or data type mismatch). Infrastructure errors like timeouts skip the script fetch entirely, minimizing unnecessary API calls.

Prompt engineering

The prompt template in prompts.py provides the foundation model with:

  • Task metadata (DAG ID, task ID, run ID, state).
  • Error message and execution logs.
  • DAG source code.
  • Operator-specific script (when available).

The model produces a structured diagnostic report with root cause identification, step-by-step resolution, and prevention recommendations. Model IDs are configurable through Airflow Variables, so you can switch between Claude Sonnet and Claude Opus without redeploying the plugin.

Security measures

Before sending content to Amazon Bedrock, the plugin applies the following safeguards:

  • Credential redaction – The sanitize_script function removes sensitive patterns (passwords, tokens, access keys) from scripts and logs.
  • Content truncation – The truncate_script function caps content size to stay within model context windows.
  • Path traversal prevention – The read_allowlisted_file function resolves canonical paths and verifies they reside within allowed base directories before reading any file.

For the full implementation, see script_utils.py.

Optional: PII detection and redaction. The built-in sanitize_script function targets credential patterns. If your logs or scripts might contain personally identifiable information (PII), consider adding a detection pass with Amazon Comprehend before invoking Amazon Bedrock. The DetectPiiEntities API returns the entity types (such as names, email addresses, or account numbers) and their character offsets. You can use these offsets to mask or obfuscate the spans before the context leaves your environment. This adds one API call and cost per analysis, so add it where your compliance requirements call for it. For guidance, see Detecting PII entities.

Deploy the plugin

Follow these steps to deploy the plugin to your Amazon MWAA environment.

Step 1: Clone the repository

git clone https://github.com/aws-samples/sample-aws-mwaa-llm-powered-plugin.git
cd sample-aws-mwaa-llm-powered-plugin

Step 2: Package and upload to Amazon S3

Create the plugins.zip archive from the plugins/ directory and upload it to your Amazon MWAA S3 bucket:

cd plugins
zip -r ../plugins.zip .
cd ..

aws s3 cp plugins.zip s3://<amzn-s3-demo-bucket>/plugins.zip

aws s3api head-object \
  --bucket <amzn-s3-demo-bucket> \
  --key plugins.zip \
  --query VersionId --output text

Note the VersionId returned. You need it in the next step.

Note: This plugin requires only fastapi and Boto3, both pre-installed on Amazon MWAA for Airflow 3.x. You don’t need a requirements.txt file. Skipping the requirements file avoids package resolution conflicts that are a common cause of failed Amazon MWAA environment updates.

Step 3: Update the Amazon MWAA environment

Update your environment to use the new plugin archive:

aws mwaa update-environment \
  --name <your-environment-name> \
  --plugins-s3-path plugins.zip \
  --plugins-s3-object-version <version-id-from-step-2>

The environment restarts automatically. This process typically takes 10–30 minutes. Monitor the status with:

aws mwaa get-environment \
  --name <your-environment-name> \
  --query "Environment.{Status:Status,Plugins:PluginsS3Path}" --output json

Step 4: Configure the Amazon Bedrock connection

On Amazon MWAA, the aws_default connection exists by default and resolves to your environment’s execution role. In most cases, no action is needed.

To override the Region, edit the aws_default connection in the Airflow UI (Admin > Connections) and set the Extra field to:

{"region_name": "us-east-1"}

Leave login and password empty so the execution role is used.

Step 5: Verify the deployment

After the environment finishes updating, navigate to Admin > Plugins in the Airflow UI. Verify that task_analyzer_plugin appears in the list. The Analyze Task entry is now available from any task instance view.

Test the solution

The repository includes example DAGs that simulate failure scenarios across different operator types. To validate the deployment:

  1. Copy the dags/ directory contents to your Amazon MWAA S3 bucket’s DAGs folder:
    aws s3 cp dags/ s3://<amzn-s3-demo-bucket>/dags/ --recursive

  2. Wait for Amazon MWAA to sync the DAGs (typically 1–2 minutes).
  3. In the Airflow UI, trigger one of the test DAGs (for example, test_aws_sql_operators) and let the intentional failure occur.
  4. Navigate to the failed task instance.
  5. Choose Analyze Task in the task instance view.
  6. Review the generated analysis, which includes:
    • Root cause identification with file and line references.
    • Step-by-step resolution with code examples.
    • Prevention recommendations and monitoring suggestions.

The analysis typically completes within 5–10 seconds.

Cost considerations

The primary cost driver for this solution is Amazon Bedrock inference, which is billed by the number of input and output tokens each analysis consumes. Input tokens come from the task logs, DAG source, and operator script sent to the model. Output tokens come from the diagnostic report the model returns. Larger logs and scripts increase input tokens, and the model you select affects the per-token rate. For current per-model rates, see Amazon Bedrock pricing.

To help control cost, the plugin includes a caching mechanism that stores results keyed by a hash of the error context. Repeated analyses of the same failure pattern return cached results without invoking Amazon Bedrock again.

Best practices

When you deploy this solution in production, consider the following:

  • IAM least privilege – Grant only bedrock:InvokeModel for your chosen model IDs and scope s3:GetObject to specific bucket paths where your operator scripts reside. For guidance, see Amazon MWAA execution role.
  • Data sanitization – The plugin redacts credentials and truncates content before sending data to Amazon Bedrock. Store configuration values in AWS Secrets Manager rather than hardcoding them in DAG source files.
  • Access control – The plugin’s endpoints are protected by Airflow’s built-in authentication. For DAG-level access management at scale, see Automated tag-based DAG permission management in Amazon MWAA.
  • Operational resilience – Add retry logic and circuit breaker patterns around the Amazon Bedrock API call. Use Amazon CloudWatch to monitor plugin performance and set alarms on failure rates.

Extending the solution

You can extend this solution in the following ways:

  • Proactive notifications – Integrate with Amazon Simple Notification Service (Amazon SNS) or Slack to deliver analyses automatically when failures occur.
  • Knowledge base integration – Build a knowledge base of past analyses using Amazon Bedrock Knowledge Bases for Retrieval Augmented Generation (RAG) powered recommendations that learn from your organization’s historical failures.
  • Additional operator support – Add handlers for custom operators specific to your organization, such as proprietary data connectors or internal platform integrations.
  • Automated remediation – For well-understood failure patterns, trigger automated fixes such as restarting tasks with adjusted resource configurations.

Clean up

To remove the plugin from your environment:

  1. Delete the plugin archive from Amazon S3:
    aws s3 rm s3://<amzn-s3-demo-bucket>/plugins.zip

  2. Update your Amazon MWAA environment to remove the plugin reference, then wait for the environment to restart.
  3. Optionally, remove the Amazon Bedrock permissions from your execution role if they are no longer needed.

Conclusion

In this post, we showed you how to deploy an LLM-powered DAG failure analysis plugin for Amazon MWAA using Amazon Bedrock. The operator-aware context collection differentiates this approach from generic log analyzers. By fetching the actual code from AWS Glue, Amazon EMR, and other services, the foundation model provides precise, actionable recommendations with specific line references.

To get started, clone the sample-aws-mwaa-llm-powered-plugin repository, deploy it to a development Amazon MWAA environment, and test with the included example DAGs. As your team builds confidence in the analysis quality, roll it out to production environments where it serves as the first line of investigation for any pipeline failure.


About the authors

Sushant Samantaray

Sushant Samantaray

Sushant is a Sr. Delivery Consultant at AWS, bringing 19 years of industry experience with a focus on Data Analytics and Generative AI/Agentic AI solutions. He works closely with enterprise customers to design and deliver innovative solutions across Big Data, Generative AI, and Agentic AI, leveraging AWS native services, partner offerings, and open-source technologies. A passionate technologist and problem solver at heart, he balances his professional life with watching and playing sports and spending quality time with family.

Parameswara Reddy Gajjela

Parameswara Reddy Gajjela

Parameswara is a Delivery Consultant at AWS with 11+ years of experience in Data Analytics. He works closely with enterprise customers to architect innovative, end-to-end Big Data and Agentic AI solutions powered by AWS native services, partner ecosystems, and open-source technologies. His areas of expertise include modern DataLake and Data Warehouse migration and implementations on AWS.

Kamen Sharlandjiev

Kamen Sharlandjiev

Kamen is a Pr. Big Data and ETL Solutions Architect, MWAA and AWS Glue ETL expert. He’s on a mission to make life easier for customers who are facing complex data integration and orchestration challenges. His secret weapon? Fully managed AWS services that can get the job done with minimal effort. Follow Kamen on LinkedIn to keep up to date with the latest MWAA and AWS Glue features and news!

Simplify AMI discovery with Amazon EC2 and SSM Parameter Store

Post Syndicated from Ashwani Tyagi original https://aws.amazon.com/blogs/compute/simplify-ami-discovery-with-amazon-ec2-and-ssm-parameter-store/

If you manage Amazon Elastic Compute Cloud (Amazon EC2) infrastructure at scale, you have likely encountered the following situation. You release an infrastructure change with the correct Region, the correct instance type, and a launch template that has operated reliably for months. The deployment nevertheless comes up on an Amazon Machine Image (AMI) that is several patch cycles out of date, because the AMI ID hardcoded in the template had become stale weeks earlier. The condition goes unnoticed until a security scan flags the instance, at which point you must reconcile AMI IDs across Regions rather than close out the week.

That scenario is rarely a one-time event. It is one example of a broader pattern that quietly taxes teams running Amazon EC2 at scale: stale AMI IDs, manual parameter lookups, inconsistent Region mappings, and pipelines that silently fail to update. The following section examines four variations of this pattern in detail.

The common thread across all of these is the same. Locating the correct image is not the hard part. The difficulty lies in wiring that image into your infrastructure as code (IaC) in a manner that remains current. You identify the appropriate AMI on the console, then search AWS Systems Manager (SSM) Parameter Store paths to obtain the dynamic reference that maps to it. The workflow spans two tools and two mental models, with a gap in between where errors accumulate. Because the authoritative link between an AMI and its SSM parameter lived outside the API, teams had to reconstruct it by hand, and hands make mistakes.

A recent enhancement to the Amazon EC2 DescribeImages API closes that gap. When you call DescribeImages on a public AMI, the response now contains a PublicSsmParameterName field: the SSM parameter that resolves to the latest AMI in that lineage. A single API call replaces manual correlation.

In this post, we examine the operational friction that makes AMI management harder than it should be and show how this enhancement addresses it. We walk through practical examples using the AWS Command Line Interface (AWS CLI), AWS CloudFormation, Terraform, and Amazon EC2 Auto Scaling launch templates. We conclude with best practices for golden AMI pipelines, including operational considerations to review before adopting the feature in production.

Prerequisites

To follow the examples in this post, you will need the following:

  • An AWS account.
  • The AWS CLI v2 installed and configured with appropriate permissions (ec2:DescribeImages, ssm:GetParameters).
  • Basic familiarity with AMIs, SSM Parameter Store, and at least one IaC tool (CloudFormation or Terraform).

Understanding the operational challenges

Before addressing the solution, it is worth examining the problem in detail, because the problem seldom manifests as a single, dramatic failure. It is instead a gradual accumulation of minor frictions that, in aggregate, impose a measurable cost on teams responsible for compute.

AMI IDs are Region-specific, version-specific, and change frequently. The workflow of finding an AMI, locating its SSM parameter, and referencing it in templates spans multiple tools, and the boundaries between steps are where errors accumulate.

Challenge 1: Silent image aging

Scenario: An engineer copies an AMI ID into a Terraform module as an interim measure. Several months later, that identifier is embedded across four environments. New instances launch on an image that predates numerous patches. There is no error and no alert, only drift that remains invisible until an audit or a review brings it to light.

Impact: Hardcoded AMI IDs do not fail conspicuously. They fail quietly, by launching a prior image at a later date. The distance between “this was correct when written” and “this remains correct” widens continuously, and no owner is assigned to monitor it.

Challenge 2: The multi-region maintenance burden

Scenario: An application operates across three Regions. The same logical image (for example, the latest Amazon Linux 2023) carries a different AMI ID in each Region. Templates therefore accrue region-to-AMI mapping blocks, lookup logic, or both. Each additional Region introduces another entry to maintain, and each AMI refresh requires updating all of them.

Impact: The team ends up maintaining a translation table that AWS already maintains on its behalf. The mapping logic becomes load-bearing infrastructure in its own right, and a single stale entry in one Region produces inconsistent fleets that are difficult to diagnose.

Challenge 3: Barriers to onboarding

Scenario: A new engineer joins the team and poses a reasonable question: which SSM parameter corresponds to a given AMI? The answer resides in an internal knowledge-base page that was accurate eighteen months earlier. The engineer copies a path that appears correct, deploys, and inadvertently references the wrong lineage.

Impact: When the relationship between an AMI and its parameter is not discoverable from the API, it must be documented manually. Manually maintained mappings degrade over time. Each new team member re-learns the same institutional knowledge, and each instance of degradation introduces an opportunity to reference an incorrect value.

Challenge 4: Uncertainty about update success

Scenario: A golden AMI pipeline completes a build and updates a parameter. The command returns a success response, and the team assumes the new image is in effect. However, for certain parameter data types, a success response does not always indicate that the value was accepted. This specific behavior is examined in the best-practices section, as it is particularly relevant to golden AMI pipelines.

Impact: Confidence without confirmation carries substantial risk. A pipeline that presumes success can propagate a stale image across a fleet before the discrepancy is identified.

Considered individually, none of these situations constitutes a crisis. Considered collectively, they explain why “launch the latest image” is never, in fact, a single step. The common root cause is consistent across all four: the authoritative link between an AMI and its SSM parameter existed outside the API, requiring teams to reconstruct it manually, a process inherently prone to error.

What’s new: DescribeImages returns the associated SSM parameter

The new feature addresses precisely this boundary.

As of July 16, 2026, the Amazon EC2 DescribeImages API response includes a new field, PublicSsmParameterName, for public AMIs that have an associated SSM parameter. This capability is available at no additional cost in supported AWS Regions, including AWS GovCloud (US) Regions and the China Regions.

In place of the previous three-step correlation exercise, the workflow reduces to a single call:

Before After
Find AMI → manually search SSM paths → confirm the correct match Find AMI → PublicSsmParameterName returns the SSM path immediately
Two separate API calls or console workflows A single DescribeImages call provides the complete mapping
Prone to mapping an incorrect parameter to an AMI Authoritative mapping obtained directly from the API

The change introduces neither a new service nor a new pricing dimension. It relocates information that previously lived in knowledge bases into the API response.

In addition, you can now use the public-ssm-parameter-name filter in DescribeImages to identify all AMIs associated with a specific SSM parameter, making the relationship queryable in either direction.

How it works: API response walkthrough

Call DescribeImages on a public AMI with an associated SSM parameter. The response includes PublicSsmParameterName:

{
  "Images": [
    {
      "ImageId": "ami-0abcdef1234567890",
      "Name": "al2023-ami-2023.7.20260601.0-kernel-6.1-arm64",
      "Description": "Amazon Linux 2023 AMI 2023.7.20260601.0 arm64 HVM kernel-6.1",
      "Architecture": "arm64",
      "PlatformDetails": "Linux/UNIX",
      "State": "available",
      "Public": true,
      "OwnerId": "111122223333",
      "ImageType": "machine",
      "RootDeviceType": "ebs",
      "VirtualizationType": "hvm",
      "EnaSupport": true,
      "PublicSsmParameterName": "aws/service/ami-amazon-linux-latest/al2023-ami-kernel-default-arm64"
    }
  ]
}

The PublicSsmParameterName value (in this case, aws/service/ami-amazon-linux-latest/al2023-ami-kernel-default-arm64) identifies the SSM parameter associated with this AMI lineage.

Tip: The field is returned under the aws/service/ namespace without a leading slash. When using this value in SSM API calls, resolve:ssm: references, or CloudFormation dynamic references, prepend a forward slash. For example, use /aws/service/ami-amazon-linux-latest/al2023-ami-kernel-default-arm64. The SSM parameter is intended to resolve to the latest AMI in the lineage, which can help you keep infrastructure current.

Note: Not every public AMI has an associated parameter. The field is present only for lineages for which AWS publishes parameters. The field is also populated only for public AMIs. If you query one of your own private AMIs and observe an empty field, this is expected behavior rather than a defect.

Practical examples

The following four examples show how to use the new PublicSsmParameterName field across common IaC tools.

Example 1: Discover the SSM parameter for an AMI using the AWS CLI

Suppose you have identified an AMI on the console and wish to determine its SSM parameter path for use in your templates:

aws ec2 describe-images \
  --image-ids ami-0abcdef1234567890 \
  --query "Images[0].PublicSsmParameterName" \
  --output text

Output:

aws/service/ami-amazon-linux-latest/al2023-ami-kernel-default-arm64

You can also perform the inverse operation and determine which AMI a given SSM parameter currently references:

# Linux example
aws ssm get-parameter \
  --name "/aws/service/ami-amazon-linux-latest/al2023-ami-kernel-default-arm64" \
  --query "Parameter.Value" \
  --output text

# Windows example
aws ssm get-parameter \
  --name "/aws/service/ami-windows-latest/Windows_Server-2022-English-Full-Base" \
  --query "Parameter.Value" \
  --output text

Tip: Public SSM parameters are available for both Linux (/aws/service/ami-amazon-linux-latest) and Windows (/aws/service/ami-windows-latest) AMIs. You can list all available parameters under these paths using aws ssm get-parameters-by-path –path .

Alternatively, you can use the new filter to identify AMIs by their SSM parameter name:

Note: The public-ssm-parameter-name filter returns all AMIs that have ever been associated with the specified parameter, including previous versions. Use sorting or additional filters (such as –query with CreationDate) to identify the most recent AMI.

aws ec2 describe-images \
  --filters "Name=public-ssm-parameter-name,Values=/aws/service/ami-amazon-linux-latest/al2023-ami-kernel-default-arm64" \
  --query "Images[].{ImageId:ImageId,Name:Name,CreationDate:CreationDate}" \
  --output table

Example 2: CloudFormation with dynamic SSM references

Once the SSM parameter path is known from DescribeImages, you can use CloudFormation dynamic references to resolve to the latest AMI at deployment time:

AWSTemplateFormatVersion: '2010-09-09'
Description: EC2 instance using SSM parameter for latest Amazon Linux 2023 AMI

Parameters:
  InstanceType:
    Type: String
    Default: t4g.micro

Resources:
  MyInstance:
    Type: AWS::EC2::Instance
    Properties:
      InstanceType: !Ref InstanceType
      ImageId: '{{resolve:ssm:/aws/service/ami-amazon-linux-latest/al2023-ami-kernel-default-arm64}}'
      Tags:
        - Key: Name
          Value: MyLatestAL2023Instance

Alternatively, you can use the AWS::SSM::Parameter::Value parameter type to permit users to override the SSM path at stack creation time:

AWSTemplateFormatVersion: '2010-09-09'
Description: EC2 instance with configurable SSM-based AMI lookup

Parameters:
  AmiSsmParameter:
    Type: 'AWS::SSM::Parameter::Value<AWS::EC2::Image::Id>'
    Default: '/aws/service/ami-amazon-linux-latest/al2023-ami-kernel-default-arm64'
    Description: SSM parameter path for the AMI (discovered via DescribeImages)
  InstanceType:
    Type: String
    Default: t4g.micro

Resources:
  MyInstance:
    Type: AWS::EC2::Instance
    Properties:
      InstanceType: !Ref InstanceType
      ImageId: !Ref AmiSsmParameter
      Tags:
        - Key: Name
          Value: DynamicAMIInstance

CloudFormation resolves the AMI ID at deployment time, so the template never contains a hardcoded AMI ID, and any stack update adopts the latest AMI automatically. Two considerations warrant attention before relying on this approach. First, running instances are not affected. A stack update is required to roll out a newer AMI. Second, CloudFormation does not support drift detection on dynamic references, so if the underlying SSM parameter value changes between deployments, CloudFormation will not report it as drift. For ssm dynamic references in which a version has not been pinned, AWS recommends performing a stack update whenever the parameter changes, so that the stack retrieves the current value.

Example 3: Terraform with SSM parameter data source

Use the aws_ssm_parameter data source to resolve the SSM path to the latest AMI ID:

# Use the SSM parameter path discovered from DescribeImages
data "aws_ssm_parameter" "latest_al2023" {
  name = "/aws/service/ami-amazon-linux-latest/al2023-ami-kernel-default-arm64"
}

resource "aws_instance" "web" {
  ami           = data.aws_ssm_parameter.latest_al2023.value
  instance_type = "t4g.micro"

  tags = {
    Name = "LatestAL2023-Instance"
  }
}

Important: In Terraform, ami is a replacement-forcing argument on aws_instance. When the SSM parameter changes, Terraform proposes to destroy and recreate the instance. For stateful workloads, add lifecycle { ignore_changes = [ami] } or use launch templates with Auto Scaling (Example 4) instead.

Example 4: Auto Scaling launch templates with SSM parameters

For Auto Scaling groups, you can reference the SSM parameter directly in the launch template using the resolve:ssm: prefix:

# Create a launch template that uses the SSM parameter
aws ec2 create-launch-template \
  --launch-template-name al2023-auto-scaling \
  --launch-template-data '{
  "ImageId": "resolve:ssm:/aws/service/ami-amazon-linux-latest/al2023-ami-kernel-default-arm64",
  "InstanceType": "t4g.micro"
}'

When EC2 Auto Scaling launches a new instance, it resolves the SSM parameter at launch time to obtain the current AMI ID. You can verify the AMI ID to which a launch template resolves:

aws ec2 describe-launch-template-versions \
  --launch-template-name al2023-auto-scaling \
  --versions '$Latest' \
  --resolve-alias

The response shows the resolved ImageId:

{
  "LaunchTemplateVersions": [
    {
      "LaunchTemplateId": "lt-089c023a30example",
      "LaunchTemplateName": "al2023-auto-scaling",
      "VersionNumber": 1,
      "LaunchTemplateData": {
        "ImageId": "ami-0ac394d6a3example",
        "InstanceType": "t4g.micro"
      }
    }
  ]
}

The parameter is stored in the launch template. When the Auto Scaling group scales out or replaces an instance, it uses the launch template to resolve the SSM parameter and determine the AMI to launch. This is the most direct of the four patterns: the parameter serves as the single source of truth, and the Auto Scaling group’s normal instance lifecycle effects the rollout.

Before-and-after workflow comparison

The following table summarizes how this feature improves common workflows, and relates each entry to the challenges described earlier.

Workflow Before After
Discover the SSM path for a known AMI Search SSM parameter namespaces manually. Test multiple paths. Confirm a correct match A single DescribeImages call returns PublicSsmParameterName
Validate that an SSM parameter maps to the expected AMI Call GetParameter, then call DescribeImages on the returned ID to verify Use the public-ssm-parameter-name filter to view all associated AMIs directly
Set up IaC templates Find AMI → search for SSM path → copy path to template → verify correctness over time Find AMI → read PublicSsmParameterName from the response → use directly in the template
Onboard new team members Document AMI-to-parameter mappings in knowledge bases, which become stale New members self-discover using standard API calls
Audit AMI usage across teams Cross-reference AMI IDs with SSM parameters in separate calls A single API call provides the complete picture

Best practices: Using SSM parameters for golden AMI pipelines

The following recommendations describe how to derive the greatest benefit from this feature, with operational considerations identified where they are material.

1. Discontinue hardcoding AMI IDs

With PublicSsmParameterName removing the discovery barrier, switch all templates to SSM parameter references. Use {{resolve:ssm:}} in CloudFormation, the aws_ssm_parameter data source in Terraform (note the replacement behavior in Example 3), or the resolve:ssm: prefix in launch templates.

2. Create custom SSM parameters for your golden AMIs

For internally built golden AMIs, create your own SSM parameters using the aws:ec2:image data type:

aws ssm put-parameter \
  --name "/my-org/golden-ami/amazon-linux-hardened" \
  --type "String" \
  --data-type "aws:ec2:image" \
  --value "ami-0abcdef1234567890"

When the pipeline produces a new golden AMI, update the parameter:

aws ssm put-parameter \
  --name "/my-org/golden-ami/amazon-linux-hardened" \
  --type "String" \
  --data-type "aws:ec2:image" \
  --value "ami-0fedcba9876543210" \
  --overwrite

Stacks, launch templates, or Terraform configurations that reference this parameter can adopt the new AMI on their next deployment, with no template edits required in most cases.

Operational consideration: Because PutParameter validates aws:ec2:image values asynchronously, an HTTP 200 does not confirm the value was accepted. Subscribe to Parameter Store change events in Amazon EventBridge and confirm the operation succeeded before considering the rollout complete.

3. Use parameter versions and labels for controlled rollouts

SSM Parameter Store supports versioning and labels, which provide control over rollouts:

# Label the current production version
aws ssm label-parameter-version \
  --name "/my-org/golden-ami/amazon-linux-hardened" \
  --parameter-version 5 \
  --labels "prod"

Production launch templates reference the labeled version:

ImageId: resolve:ssm:/my-org/golden-ami/amazon-linux-hardened:prod

With this approach, you can update the parameter with a new AMI without immediately affecting production. Promotion to production is accomplished by moving the prod label, a deliberate, auditable action rather than an automatic side effect.

4. Combine with Amazon EC2 Image Builder for end-to-end automation

Use Amazon EC2 Image Builder to automate AMI creation, then configure the distribution settings to update your SSM parameter automatically when a new AMI is built. Combined with the new discovery feature, this establishes a closed loop:

  • Image Builder creates a new AMI on a schedule.
  • Distribution settings update the SSM parameter to point to the new AMI.
  • Auto Scaling and IaC resolve the parameter to the latest AMI at launch time.
  • With DescribeImages, any authorized party can determine which SSM parameter an AMI maps to.

5. Scope IAM permissions appropriately

Two permission requirements apply.

To launch instances by using SSM-referenced AMIs, the launching principal requires ssm:GetParameters on the relevant parameter paths:

{
  "Version": "2012-10-17",
  "Statement": [
    {
      "Effect": "Allow",
      "Action": "ssm:GetParameters",
      "Resource": "arn:aws:ssm:*:*:parameter/aws/service/ami-amazon-linux-latest/*"
    }
  ]
}

Scope the Resource element to the paths actually in use. If you reference Windows parameters (/aws/service/ami-windows-latest/) or your own golden AMI paths (/my-org/golden-ami/), include those ARNs as well. Otherwise, launches will fail with an AccessDenied error.

To create a custom aws:ec2:image parameter, the pipeline principal also requires ssm:PutParameter and ec2:DescribeImages:

{
  "Version": "2012-10-17",
  "Statement": [
    {
      "Effect": "Allow",
      "Action": "ssm:PutParameter",
      "Resource": "arn:aws:ssm:*:*:parameter/my-org/golden-ami/*"
    },
    {
      "Effect": "Allow",
      "Action": "ec2:DescribeImages",
      "Resource": "*"
    }
  ]
}

For broader guidance on keeping infrastructure current and automating operational processes, see the Operational Excellence Pillar of the AWS Well-Architected Framework.

Clean up

The examples in this post use read-only API calls (DescribeImages, GetParameter) and do not create billable resources. If you created a launch template while following Example 4, you can delete it as follows:

aws ec2 delete-launch-template --launch-template-name al2023-auto-scaling

Conclusion

The difficulty of AMI management was never attributable to any single failure. It arose from the steady accumulation of stale identifiers, region-mapping tables, stale documentation, and pipelines that presumed success, all of which are minor frictions that together produced significant operational effort and risk. The common thread was that the authoritative link between an AMI and its SSM parameter existed outside the API, requiring teams to reconstruct it manually.

The new PublicSsmParameterName field in the Amazon EC2 DescribeImages API relocates that link into the response, where it appropriately belongs. With a single API call, you can determine the SSM parameter for any public AMI. You can then reference it directly in CloudFormation templates, Terraform configurations, or Auto Scaling launch templates for automatic AMI updates.

To begin, call DescribeImages on any public AMI and examine the PublicSsmParameterName field. For further detail, see Reference the latest AMIs using Systems Manager public parameters in the Amazon EC2 User Guide.

For additional learning resources on AMI management and IaC on AWS, explore Amazon EC2, AWS Systems Manager Parameter Store, and Amazon EC2 Image Builder.

Announcing Spark Connect on Amazon EMR on EKS: Interactive PySpark development, anywhere

Post Syndicated from Amit Maindola original https://aws.amazon.com/blogs/big-data/announcing-spark-connect-on-amazon-emr-on-eks/

Today, we’re announcing support for Spark Connect on Amazon EMR on EKS, starting from EMR release 7.14 (Apache Spark 3.5.8) and emr-spark-8.1 (Apache Spark 4.1.1). You can now build, test, and debug Spark applications from your preferred tools, such as VS Code, PyCharm, Jupyter notebooks, Amazon SageMaker Unified Studio. At the same time, your full-scale Spark operations run on Amazon Elastic Kubernetes Service (Amazon EKS).

Deploying Spark applications from a local development environment to a remote Amazon EKS cluster often means dealing with environment differences, dependency conflicts, and performance gaps at scale. Spark Connect removes this friction. It separates your application client from the Spark server, so you develop and debug locally while Spark Connect routes your operations to a scalable Spark cluster running on Amazon EKS.

This client-server architecture supports a range of use cases, including interactive development from notebooks and IDEs, embedded Spark in web services, and continuous integration and continuous delivery (CI/CD) data-quality tests. All of these run on your existing EKS infrastructure. Each Spark Connect session uses its own AWS Identity and Access Management (IAM) execution role, custom tags, and cost tracking. For more information, see the Amazon EMR on EKS documentation.

Here are two demonstrations of using Spark Connect in Amazon SageMaker Unified Studio Notebooks and in a VS Code local IDE:

Amazon SageMaker Unified Studio Notebooks demo:

Local IDE demo:

For a runnable end-to-end example in an IDE, try the Spark Connect sample notebook in the aws-emr-utilities repository. It includes a client wrapper solution, built by AWS architects, for simplified connectivity:

How Spark Connect works on Amazon EMR on EKS

Spark Connect uses a client-server architecture that separates application code from the Spark engine:

  1. Client – A lightweight PySpark library running in your environment (such as an IDE or notebook). It doesn’t need Spark installed, direct access to data, or resources sized for the workload.
  2. Connection (EMR managed endpoint) – The client sends Spark operations over a secure gRPC/TLS channel to the Spark Connect server.
  3. Server – Runs Spark pods in your Amazon EMR on EKS namespace, starting from a minimum of two executors (adjustable) with autoscaling. The server performs Spark operations using the EKS compute resources and accesses data stores, such as an Amazon Simple Storage Service (Amazon S3) bucket, through job execution roles.
  4. Results – The server streams query results back to the client through gRPC as Apache Arrow-encoded row batches.
Client-server data flow from a local PySpark client through a gRPC channel to Spark pods on Amazon EMR on EKS

Figure 1: Spark Connect’s client-server architecture

On endpoint creation, Amazon EMR on EKS launches the Spark Connect server as pods on EKS and returns an Elastic Load Balancing (ELB)-backed endpoint and a short-lived token. You don’t need to provision any server or networking manually. Because the Spark Connect server runs on the EKS cluster you already operate, it inherits the node types, container images, and Spark configurations. What you see while developing Spark applications on the client side is what runs in the EKS environment at scale.

To provide a secure, simplified experience, Amazon EMR on EKS provisions two additional components on first use of Spark Connect on the EKS cluster:

Shared Envoy authentication-proxy router and Secret Agent service on the EKS cluster

Figure 2: Shared Envoy router and Secret Agent service on the EKS cluster

  • Managed authentication-proxy router – a shared Envoy router with three replicas by default (adjustable), fronted by a Network Load Balancer (NLB). It routes client traffic to the correct server pods, terminates TLS, and validates the session token. One router serves Spark Connect endpoints on the EKS cluster.
  • Secret Agent service – a lightweight, long-running pod that manages the short-lived credentials for session authentication. One service per EMR security configuration.

These components are long-running and shared across endpoints. Amazon EMR on EKS creates them automatically with the first endpoint on the cluster. Because the router is cluster-scoped and Secret Agent is namespace-scoped, deleting a managed endpoint doesn’t remove them. They keep running so that new endpoints can start within a minute. The router’s replica count is tunable. Scale down for non-production environments to reduce cost or scale up for higher throughput.

To fully remove these components:

  • Terminate all active managed endpoints and their virtual cluster that reference the Secret Agent’s security configuration, then delete the security configuration.
  • Once the last session-enabled virtual cluster is deleted, the authentication-proxy router and its underly resources, including the NLB and VPC endpoint, are removed automatically.
  • Alternatively, delete the EKS cluster to remove all in-cluster components at once.

Why use Spark Connect on Amazon EMR on EKS

With Amazon EMR on EKS, teams can run Spark alongside other applications on shared Kubernetes clusters with existing infrastructure, operational tooling, and system expertise. Spark Connect extends that value to interactive, embedded, and self-service Spark workloads. Your client stays lightweight while Spark code runs in governed, scalable server pods on EKS.

Interactive development on shared Kubernetes clusters

Data engineers and scientists iterate on Spark code cell-by-cell in notebooks or local IDEs. The Spark engine runs remotely on EKS, so validation runs on the same engine as your batch workloads. After validation on the Spark Connect client, the same Spark code deploys as a batch StartJobRun with no changes.

Spark Connect sessions run as pods on your existing cluster. They reuse your EKS RBAC, network policies, node autoscaling, and observability stack (Prometheus, Grafana, Amazon CloudWatch Container Insights). There are no separate compute and monitoring layers to operate.

Embedded Spark in applications and services

The Spark Connect client is a compact PySpark library. Teams can embed Spark operations directly into Python applications such as web services, dashboards, automation scripts, or backend APIs. The heavy processing runs on EKS while the application stays lightweight.

Teams can also expose Spark Connect as a self-service capability on their internal application. Business users submit Spark SQL scripts from a web UI. The compute runs on Spark Connect server on EKS, so the team manages capacity, security, and upgrades centrally.

Multi-tenant data exploration with governance

Each Spark Connect session uses the data user’s IAM permissions that you configure, limiting their access to authorized AWS services, data lake tables, and S3 paths. Every session carries tags with user, project, endpoint and virtual cluster IDs, feeding directly into billing and compliance reports. Meanwhile, data producers maintain guardrails on source data without blocking self-service exploration.

To manage resource consumption across teams, Amazon EMR on EKS virtual clusters provide namespace-level isolation. Each tenant binds their Spark Connect endpoints to a virtual cluster (a namespace) with independent IAM roles. Using resource quotas and limit ranges on EKS, you can protect each virtual cluster by controlling the compute resources that Spark Connect sessions can consume. Importantly, activating EKS split-cost allocation tags helps with chargeback reporting in a multi-tenant environment.

Reusable container images and scalable deployment

Teams often maintain custom container images with proprietary libraries, including internal feature stores, compliance toolkits, UDFs, or machine learning (ML) frameworks. With Spark Connect on Amazon EMR on EKS, teams reuse those same images as the Spark runtime for interactive sessions. No separate dependency lists needed. The same image works for both batch jobs and Spark Connect sessions.

Beyond the image itself, you can control Spark pod scheduling in Amazon EMR on EKS through pod templates and managed endpoint APIs, scaling across your environment. For example, you can:

  • Pin server pods to specific node types through pod templates. For example, Spot for cost savings.
  • Apply Spark Dynamic Resource allocation (DRA) to right-size each interactive session.
  • Use GPU node pools for accelerated Spark RAPIDS or ML.
cat > /tmp/spark-connect-endpoint.json << EOF
{
  "name": "spark-connect-custom-config",
  "virtualClusterId": "$VC_ID",
  "type": "SPARK_CONNECT",
  "releaseLabel": "emr-7.14.0-latest",
  "executionRoleArn": "$ROLE_ARN",
  "configurationOverrides": {
    "applicationConfiguration": [{
      "classification": "spark-defaults",
      "properties": {
        "spark.kubernetes.container.image": "${CUSTOM_IMAGE_URI}",
        "spark.kubernetes.executor.podTemplateFile": "s3://$S3BUCKET/exec-pod-template.yaml",
        "spark.kubernetes.node.selector.karpenter.sh/nodepool": "gpu-pool",
        "spark.dynamicAllocation.enabled": "true",
        "spark.dynamicAllocation.minExecutors": "0"
      }
    }]
  }
}
EOF

aws emr-containers create-managed-endpoint \
--cli-input-json file:///tmp/spark-connect-endpoint.json

Multi-cluster, multi-Region, and hybrid architectures

Enterprises running EKS clusters across multiple AWS accounts, AWS Regions, or hybrid environments with on-premises Kubernetes can use Spark Connect to query data wherever it’s processed. The lightweight client only needs to reach the Spark Connect endpoint, not the underlying S3 buckets or AWS Glue data catalogs. This means no VPC peering or direct network paths to every data store.

The client-server split is the core architectural advantage of Spark Connect on Amazon EMR on EKS. A developer on a laptop behind a VPN, a CI/CD deployment pipeline in a centralized service account, or an Airflow DAG orchestrating across Regions can all connect to a remote Spark server on EKS. This works regardless of where the client itself runs. This decoupling simplifies cross-Region or cross-account analytics without duplicating data or requiring direct access to each data store.

Getting started

To create a Spark Connect endpoint on Amazon EMR on EKS, complete the following steps:

  1. Create EMR namespaces on EKS.
  2. Create an EMR security configuration.
  3. Create a virtual cluster with the security configuration.
  4. Create a Spark Connect managed endpoint.
  5. Obtain a session token.
  6. Connect from your application.

Prerequisites

To proceed with this post, make sure you have the following:

Step 1: Create EMR namespaces

# set environment variables
export EKS_CLUSTER_NAME=my-eks-cluster
export USER_NAMESPACE=spark-connect-1
export SYS_NAMESPACE=spark-connect-1-system
export AWS_REGION=us-west-2
# connect to your EKS cluster
aws eks update-kubeconfig --name $EKS_CLUSTER_NAME --region $AWS_REGION
kubectl create namespace $USER_NAMESPACE
kubectl create namespace $SYS_NAMESPACE

Step 2: Create a security configuration

cat > /tmp/sec-config.json << EOF
{
  "name": "spark-connect-1-sc",
  "securityConfigurationData": {
    "authenticationConfiguration": {
      "identityCenterConfiguration": { "enableIdentityCenter": false }
    }
  },
  "containerProvider": {
    "type": "EKS",
    "id": "$EKS_CLUSTER_NAME",
    "info": { "eksInfo": { "namespace": "$SYS_NAMESPACE" } }
  }
}
EOF

SEC_CONFIG_ID=$(aws emr-containers create-security-configuration \
--region $AWS_REGION \
--cli-input-json file:///tmp/sec-config.json \
--query id \
--output text)
echo "Security Configuration ID: $SEC_CONFIG_ID"

Step 3: Create a virtual cluster with the security configuration

cat > /tmp/vc.json << EOF
{
  "name": "spark-connect-demo",
  "containerProvider": {
    "id": "$EKS_CLUSTER_NAME",
    "type": "EKS",
    "info": {"eksInfo": {"namespace": "$USER_NAMESPACE"}}
  },
  "securityConfigurationId": "$SEC_CONFIG_ID",
  "sessionEnabled": true
}
EOF

VC_ID=$(aws emr-containers create-virtual-cluster \
--region $AWS_REGION \
--cli-input-json file:///tmp/vc.json \
--query 'id' \
--output text)
# validate the virtual cluster
echo "Virtual Cluster ID: $VC_ID"
aws emr-containers describe-virtual-cluster --region $AWS_REGION --id $VC_ID

Step 4: Create a Spark Connect managed endpoint

Start an interactive session on your virtual cluster. Provide a job execution role that grants the session access to your data sources.

# reuse an existing execution role
ROLE_ARN="arn:aws:iam::YOUR_ACCOUNT_ID:role/EMRonEKSExecutionRole"
cat > /tmp/spark-connect-endpoint.json << EOF
{
  "name": "spark-connect-demo",
  "virtualClusterId": "$VC_ID",
  "type": "SPARK_CONNECT",
  "releaseLabel": "emr-7.14.0-latest",
  "executionRoleArn": "$ROLE_ARN",
  "sessionIdleTimeoutInMinutes": 1440,
  "configurationOverrides": {
    "applicationConfiguration": [{
      "classification": "spark-defaults",
      "properties": {
        "spark.dynamicAllocation.enabled": "true",
        "spark.dynamicAllocation.minExecutors": "0",
        "spark.dynamicAllocation.maxExecutors": "2"
      }
    }]
  }
}
EOF

EP_ID=$(aws emr-containers create-managed-endpoint \
--region $AWS_REGION \
--cli-input-json file:///tmp/spark-connect-endpoint.json \
--query 'id' \
--output text)
# Validate
echo "Endpoint ID: $EP_ID"
export EP_URL=$(aws emr-containers describe-managed-endpoint \
--region $AWS_REGION \
--virtual-cluster-id $VC_ID \
--id $EP_ID \
--query 'endpoint.authProxyUrl' \
--output text)
echo "Endpoint URL: $EP_URL"
Managed endpoint creation output showing the endpoint ID and endpoint URL

Figure 3: Managed endpoint creation output with the endpoint ID and URL

You can optionally pass some custom configuration overrides and tags:

aws emr-containers create-managed-endpoint \
--type SPARK_CONNECT \
--virtual-cluster-id $VC_ID \
--name more-endpoint \
--execution-role-arn $ROLE_ARN \
--release-label emr-7.14.0-latest \
--configuration-overrides '{
"applicationConfiguration": [{
"classification": "spark-defaults",
"properties": {
"spark.executor.instances": "1",
"spark.executor.memory": "4g",
"spark.executor.cores": "1",
"spark.sql.extensions": "org.apache.iceberg.spark.extensions.IcebergSparkSessionExtensions"
}
}]
}' \
--tags '{
"team": "data-engineering",
"project": "customer-analytics"
}'

Step 5: Obtain a session token

Request a session token after the managed endpoint is active:

# get a session token with a 12-hour expiry (adjustable)
export TOKEN=$(aws emr-containers get-managed-endpoint-session-credentials \
--region $AWS_REGION \
--virtual-cluster-identifier $VC_ID \
--endpoint-identifier $EP_ID \
--execution-role-arn $ROLE_ARN \
--credential-type TOKEN \
--duration-in-seconds 43200 \
--query 'credentials.token' \
--output text)
echo "Session Token: $TOKEN"

Security note: Communication between your environment and the Spark Connect server is encrypted using TLS. The authentication token is time-limited (15 minutes by default). For long-running sessions, refresh the token periodically by calling get-managed-endpoint-session-credentials again. Consider using AWS Secrets Manager to store and retrieve tokens programmatically.

Step 6: Connect from your application

Use the returned endpoint URL and token to connect from a PySpark-compatible environment. The following Python code shows how to establish a Spark Connect session:

import os
from pyspark.sql import SparkSession
session_endpoint = os.environ["EP_URL"]
auth_token = os.environ["TOKEN"]
spark_conn_url = (f"{session_endpoint};use_ssl=true;x-aws-proxy-auth={auth_token}")
spark = SparkSession.builder
.remote(spark_conn_url)
.getOrCreate()
# verify the connection
print(f"Connected remotely! Spark version: {spark.version}")
# query data through the AWS Glue Data Catalog
df = spark.sql("SELECT * FROM my_catalog.my_database.my_table LIMIT 10")
df.show()

After you’re connected, you can:

  • Debug interactively – Set breakpoints, inspect DataFrames, and step through Spark code in your IDE or notebook while the operations run remotely on EKS.
  • Combine local and remote processing – Pull query results back to the client as a pandas or PyArrow DataFrame for local analysis, visualization, or ML (scikit-learn, notebook widgets), then push further Spark operations back to the server in the same session. Heavy processing stays on Amazon EMR on EKS. Only the results you request cross the wire.
  • Reconnect without losing state – A managed endpoint runs independently of single clients for a configurable idle timeout (default: 60 minutes). Your Spark session, cached data, and temporary views are preserved on the server between connections. When a session token expires (default: 15 minutes, configurable up to 12 hours), request a new token and reconnect to the same endpoint to resume where you left off.
  • Reuse across workload types – The same client connection pattern works everywhere Python runs: notebooks, IDEs, batch scripts, Airflow operators, or web services. One endpoint, one connection pattern, many workload types.

Validation

After you create the endpoint, verify that the Spark Connect server is running and reachable through Amazon EMR on EKS API and standard Kubernetes tooling:

# get endpoint status
aws emr-containers describe-managed-endpoint --virtual-cluster-id $VC_ID --id $EP_ID
# inspect the server pods (driver + executors) in your namespace
kubectl get pods -n $USER_NAMESPACE -l "emr-containers.amazonaws.com/managed-endpoint-id=$EP_ID"
# View driver logs
kubectl logs -n $USER_NAMESPACE <driver-pod-name> -c spark-kubernetes-driver
Terminal output showing endpoint status and the running driver and executor pods

Figure 4: Endpoint status and the running driver and executor pods

# to view the live Spark UI, port-forward your driver pod:
DRIVER_POD=$(kubectl get pods -n $USER_NAMESPACE \
-l "emr-containers.amazonaws.com/managed-endpoint-id=$EP_ID,emr-containers.amazonaws.com/component=driver" \
-o name)
kubectl port-forward -n $USER_NAMESPACE "$DRIVER_POD" 4040:4040
# Open http://localhost:4040 in your browser
Live Spark UI for the Spark Connect session viewed in a browser through port forwarding

Figure 5: Live Spark UI for the Spark Connect session

Spark Connect endpoints run as pods on your EKS cluster. The existing Kubernetes observability stack, such as CloudWatch Container Insights, Prometheus, and Grafana, captures Spark Connect endpoint metrics alongside other cluster workloads.

Clean up resources

Terminate your session when you’re done to avoid ongoing costs:

# (OPTIONAL) Endpoints are auto-deleted after the idle timeout (default: 60 minutes).
aws emr-containers delete-managed-endpoint \
--virtual-cluster-id $VC_ID \
--id $EP_ID
# Delete the virtual cluster only when no active endpoints remain
aws emr-containers delete-virtual-cluster --id $VC_ID
# Delete Security Configuration
aws emr-containers delete-security-configuration --id $SEC_CONFIG_ID
# remove the remaining EKS namespaces
kubectl delete namespace $USER_NAMESPACE $SYS_NAMESPACE spark-connect-router

Deleting or timing out a managed endpoint automatically removes its corresponding driver and executor pods. The Envoy router and Secret Agent service are shared across endpoints on the EKS cluster and remain running when individual endpoints are terminated. To fully remove these shared components, delete the virtual cluster to remove its corresponding Secret Agent service. Before doing so, ensure that no managed endpoints in the virtual cluster are active. Terminating the last session-enabled virtual cluster automatically removes the Envoy router from the EKS cluster.

Availability and pricing

Spark Connect on Amazon EMR on EKS is available with EMR release 7.14 (Apache Spark 3.5) and emr-spark-8.1 (Apache Spark 4.1), in all AWS Regions where Amazon EMR on EKS is available, except the AWS GovCloud (US) Regions and the China Regions. The Amazon SageMaker Unified Studio experience is available in supported Regions.

There is no additional charge for Spark Connect managed endpoints beyond the standard Amazon EMR on EKS pricing. You pay for underlying Amazon EKS resources such as EC2 and ELB. For timed-out or terminated managed endpoints, EMR automatically removes their Spark pods from the EKS cluster.

Recommendations for cost efficiency:

  • Use Karpenter (or Cluster Autoscaler) to right-size cluster capacity to session workload demand. This provisions nodes when endpoints need them and removes them when idle, which keeps cost aligned to actual usage.
  • Schedule interactive session pods on On-Demand instances for persistent compute.
  • Use AWS Graviton processors for better performance on Spark workloads.
  • Activate Amazon EMR on EKS Cost Allocation tags to track per-team and per-project spending at granular level.
  • Keep a single, shared Envoy router and NLB serving all Spark Connect endpoints (the default) on the cluster. Right-size the router replica count (three by default) for your availability requirements.

Considerations and limitations

Before you build on Spark Connect for Amazon EMR on EKS, review the Considerations and limitations in the Amazon EMR on EKS documentation.

Conclusion

In this post, we showed how, with Spark Connect on Amazon EMR on EKS, you can build, test, and debug Spark applications from the tools you already use: IDEs, notebooks, Amazon SageMaker Unified Studio or Airflow. Your workloads run at scale on your existing Kubernetes clusters, with no application code changes.

For teams already running Amazon EMR on EKS, Spark Connect extends your virtual clusters to interactive and embedded workloads. The same virtual cluster that runs your batch StartJobRun jobs now also serves Spark Connect sessions. Each session runs as pods on your EKS cluster, inheriting your node groups, container images, and Spark configurations. Each session also carries its own IAM execution role and cost tags. This extends the security, multi-tenancy, and observability of your Amazon EMR on EKS investment to a broader set of users and use cases.

To get started, visit the Spark Connect on Amazon EMR on EKS documentation, try the Amazon SageMaker Unified Studio Getting Started guide, and review the Amazon EMR on EKS release notes for EMR 7.14.


About the authors

Amit Maindola

Amit Maindola

Amit is a Senior Data & AI Architect with AWS ProServe team focused on data engineering, analytics, and AI/ML at Amazon Web Services. He helps customers in their digital transformation journey and enables them to build highly scalable, robust, and secure cloud-based analytical solutions on AWS to gain timely insights and make critical business decisions.

Melody Yang

Melody Yang

Melody Yang is a Principal Analytics Specialist Solution Architect at AWS with expertise in Big Data technologies. She is an experienced analytics leader working with AWS customers to provide best practice guidance and technical advice in order to assist their success in data transformation. Her areas of interests are open-source frameworks and automation, data engineering and DataOps.

Al MS

Al MS

Al is a product manager for Amazon EMR at AWS.

Aurora PostgreSQL zero-ETL integration with Amazon SageMaker

Post Syndicated from Apurwa Pawar original https://aws.amazon.com/blogs/big-data/aurora-postgresql-zero-etl-integration-with-amazon-sagemaker/

When you need quick insights from your Amazon Aurora PostgreSQL operational data, traditional analytics approaches force you to build complex extract, transform, and load (ETL) pipelines. These pipelines introduce latency, operational overhead, and data silos, which slow down decision making and increase cost. AWS introduced the support for Amazon Aurora PostgreSQL zero-ETL integration with Amazon SageMaker, providing near real-time data availability for analytics workloads.

The zero-ETL integration automatically replicates the data from your Amazon Aurora PostgreSQL database into a target AWS Glue managed catalog, where it’s available as Apache Iceberg tables. You can then analyze this data through Amazon SageMaker alongside data from other sources using your preferred analytics and machine learning (ML) tools. The data is compatible with Apache Iceberg open standards, so you can use SQL, Apache Spark, business intelligence, and artificial intelligence and machine learning (AI/ML) tools.

In this post, you explore the benefits of this integration, the architectural concepts, and the underlying change data capture (CDC) mechanics. You also go through the setup process and learn how to query your Aurora PostgreSQL data in Amazon SageMaker AI.

Zero-ETL in the lakehouse architecture

The lakehouse architecture of Amazon SageMaker AI brings together data across Amazon Simple Storage Service (Amazon S3) data lakes and Amazon Redshift data warehouses. Because it’s built on open standards, you can build analytics and AI/ML applications on a single copy of data, without moving it between systems.

Amazon SageMaker AI uses AWS Glue Data Catalog and AWS Lake Formation to provide integrated access controls across S3 data lakes and Amazon Redshift data warehouses from a single governance plane.

Understanding change data capture mechanics

At its core, Aurora PostgreSQL zero-ETL integration is powered by CDC. CDC continuously monitors the database transaction log and streams every insert, update, and delete to a downstream target in near real time.

Aurora PostgreSQL uses enhanced logical replication as its CDC engine. Standard PostgreSQL logical replication publishes row-level changes from the write-ahead log (WAL). The enhanced logical replication in Aurora offers added capabilities that make it well-suited for zero-ETL integrations, including automatic DDL propagation and continuous streaming of transactional changes.

Solution overview

With Amazon Aurora PostgreSQL zero-ETL integration with Amazon SageMaker AI, you can:

  • Remove ETL complexity – Automatically replicate data without building custom ETL pipelines.
  • Near real-time analytics – Access operational data in Amazon SageMaker AI within seconds of changes in Aurora PostgreSQL.
  • Unify data analysis – Combine Aurora PostgreSQL data with data from other sources in a single lakehouse architecture.
  • Reduce costs – Minimize operational overhead and infrastructure costs associated with maintaining ETL pipelines.
  • Accelerate insights – Query data using familiar SQL tools and integrate with ML workflows in Amazon SageMaker AI.

The following diagram illustrates the architecture of this solution:

Aurora PostgreSQL zero-ETL integration replicating data into an AWS Glue managed catalog queried through Amazon SageMaker

Figure 1: Architecture of the Aurora PostgreSQL zero-ETL integration with Amazon SageMaker

The workflow includes the following steps:

  1. Your application writes data to an Amazon Aurora PostgreSQL database cluster.
  2. The zero-ETL integration automatically captures changes from the Aurora PostgreSQL database.
  3. Data is replicated to the target AWS Glue managed catalog in near real time.
  4. You can query and analyze the data using Amazon Athena, Amazon Redshift, or other analytics tools integrated with Amazon SageMaker AI.
  5. Data scientists can build and train ML models using Amazon SageMaker AI with direct access to the Apache Iceberg tables in the target AWS Glue managed catalog.

Prerequisites

Before setting up the zero-ETL integration, verify that you have the following:

Configure the source PostgreSQL database for zero-ETL integration

When you have all the prerequisites in place, you can configure the source PostgreSQL database for zero-ETL integration.

Create a custom Aurora PostgreSQL cluster parameter group

Your Aurora PostgreSQL database needs to have parameters configured for real-time replication. In this section, you will create the DB cluster parameter group and configure parameters. For more information, see Getting started with Aurora zero-ETL integrations.

Use the following AWS CLI command to create an Aurora PostgreSQL cluster parameter group:

aws rds create-db-cluster-parameter-group \
    --db-cluster-parameter-group-name aurora-pgsql-zetl-cluster-pg \
    --db-parameter-group-family aurora-postgresql16 \
    --description "Aurora PostgreSQL with enhanced logical replication" \
    --region us-east-1 --output json

Now set the parameters by modifying the parameter group:

aws rds modify-db-cluster-parameter-group --db-cluster-parameter-group-name <aurora-pgsql-zetl-cluster-pg> \
    --parameters \
    ParameterName=rds.logical_replication,ParameterValue=1,ApplyMethod=pending-reboot \
    ParameterName=aurora.enhanced_logical_replication,ParameterValue=1,ApplyMethod=pending-reboot \
    ParameterName=aurora.logical_replication_backup,ParameterValue=0,ApplyMethod=pending-reboot \
    ParameterName=aurora.logical_replication_globaldb,ParameterValue=0,ApplyMethod=pending-reboot \
    --region us-east-1 --output json

The parameter group is now fully configured and ready to be applied to your Aurora PostgreSQL cluster.

Select or create a source Aurora PostgreSQL cluster

If you already have an Aurora PostgreSQL cluster, you can use it, or you can create a new Aurora PostgreSQL cluster.

Note: Your source DB cluster must be running a supported version of Aurora PostgreSQL. For a list of supported versions, see Regions and database engines supported for Aurora zero-ETL integrations.

While creating an Aurora PostgreSQL cluster, use the parameter group (aurora-pgsql-zetl-cluster-pg) you created earlier:

Note: Throughout this post, make sure to replace the with your own information.

aws rds create-db-cluster \
    --db-cluster-identifier <aurora-pgsql-zetl> \
    --engine aurora-postgresql \
    --engine-version 16 \
    --master-username <admin> \
    --master-user-password <password> \
    --database-name <my_db> \
    --db-cluster-parameter-group-name <aurora-pgsql-zetl-cluster-pg> \
    --storage-encrypted \
    --kms-key-id alias/aws/rds \
    --backup-retention-period 7 \
    --db-subnet-group-name <dbsubnet> \
    --vpc-security-group-ids <sg-c14219ba> \
    --region <us-east-1> \
    --output json
aws rds create-db-instance \
    --db-instance-identifier <aurora-pgsql-zetl-instance-1> \
    --db-instance-class db.r5.large \
    --engine aurora-postgresql \
    --db-cluster-identifier <aurora-pgsql-zetl> \
    --region us-east-1 \
    --output json

If you’re creating a new Aurora PostgreSQL cluster, wait for your DB instance(s) to be in an “Available” status. You can verify DB instance status by using the describe-db-instances API call:

aws rds describe-db-instances --filters 'Name=db-cluster-id,Values=<aurora-pgsql-zetl>' --output json | grep -o '"DBInstanceStatus": "[^"]*"'
"DBInstanceStatus": "available"

Reboot the cluster to apply parameter changes

A cluster reboot is needed before zero-ETL integration can function correctly:

aws rds reboot-db-instance \
    --db-instance-identifier <aurora-pgsql-zetl-instance-1> \
    --region <us-east-1>

Wait until the cluster and the primary instance are back in Available status. For more information, see reboot-db-instance.

Create a target AWS Glue managed catalog

With your source PostgreSQL database configured for enhanced logical replication, the next step is setting up your target Amazon SageMaker AI. Zero-ETL integration uses AWS Glue Data Catalog backed by Amazon Redshift managed storage as its target. To have this functionality, you need to create a managed catalog, configure IAM permissions for Amazon SageMaker AI to access and query the managed catalog, and set up authorization for incoming integration requests from your source database.

Create an AWS Glue managed catalog

You must create a new catalog (if it doesn’t exist already) managed by AWS Glue to store table metadata and serve as the landing zone for your replicated datasets. Zero-ETL integration streams the data into Amazon Redshift managed storage, and AWS Glue keeps track of table definitions so that tools such as SageMaker AI, Athena, and Amazon Redshift Spectrum can query the data.

Create an IAM role for AWS Glue and Amazon Redshift to access the AWS Glue managed catalog

Now, use the following command to create an IAM role so that AWS Glue and Amazon Redshift can interact with the catalog. This role serves two key functions: It allows AWS Glue and Amazon Redshift to perform catalog operations, and it authorizes incoming integration requests from your source database.

aws iam create-role \
    --role-name <GlueDataCatalogDataTransferRole> \
    --assume-role-policy-document '{
        "Version": "2012-10-17",
        "Statement": [
            {
                "Effect": "Allow",
                "Principal": {
                    "Service": [
                        "glue.amazonaws.com",
                        "redshift.amazonaws.com"
                    ]
                },
                "Action": "sts:AssumeRole"
            }
        ]
    }'

Next, attach a policy to this IAM role that provides the minimum required permissions for AWS Glue and Amazon Redshift. This policy should also include the necessary permissions for encryption key actions to help maintain secure data handling throughout the integration process:

aws iam put-role-policy \
    --role-name <GlueDataCatalogDataTransferRole> \
    --policy-name <GlueDataTransferPolicy> \
    --policy-document '{
        "Version": "2012-10-17",
        "Statement": [
            {
                "Sid": "DataTransferRolePolicy",
                "Effect": "Allow",
                "Action": [
                    "kms:GenerateDataKey",
                    "kms:Decrypt",
                    "glue:GetDatabase",
                    "glue:GetCatalog"
                ],
                "Resource": ["*"]
            }
        ]
    }'

Set up AWS Lake Formation access

Before using the managed catalog for zero-ETL integration, you must configure data lake administrators in AWS Lake Formation who have administrative or read-only permissions on the managed resources. Additionally, you need to grant ReadOnlyAdmin permissions to the Amazon Redshift service-linked role, AWSServiceRoleForRedshift, in your account. If this role doesn’t exist in your account or you need to verify its permissions, see Using service-linked roles for Amazon Redshift.

aws lakeformation put-data-lake-settings \
    --region <us-east-1> \
    --cli-input-json '{
        "DataLakeSettings": {
            "DataLakeAdmins": [
                {
                    "DataLakePrincipalIdentifier": "<arn:aws:iam::111122223333:role/Admin>"
                }
            ],
            "ReadOnlyAdmins": [
                {
                    "DataLakePrincipalIdentifier": "<arn:aws:iam::111122223333:role/aws-service-role/redshift.amazonaws.com/AWSServiceRoleForRedshift>"
                }
            ],
            "CreateDatabaseDefaultPermissions": [],
            "CreateTableDefaultPermissions": [],
            "Parameters": {
                "CROSS_ACCOUNT_VERSION": "4",
                "SET_CONTEXT": "TRUE"
            },
            "AllowExternalDataFiltering": false,
            "ExternalDataFilteringAllowList": []
        }
    }'

Create the AWS Glue managed catalog backed by Amazon Redshift managed storage

Because you have configured IAM permissions and Lake Formation settings, you can now create the AWS Glue managed catalog.

aws glue create-catalog \
    --region <us-east-1> \
    --cli-input-json '{
        "Name": "<zetl-catalog>",
        "CatalogInput": {
            "Description": "A Glue Data Catalog backed by Redshift Managed Storage",
            "CreateDatabaseDefaultPermissions": [],
            "CreateTableDefaultPermissions": [],
            "CatalogProperties": {
                "DataLakeAccessProperties": {
                    "DataLakeAccess": true,
                    "DataTransferRole": "<arn:aws:iam::111122223333:role/GlueDataCatalogDataTransferRole>",
                    "CatalogType": "aws:redshift"
                }
            }
        }
    }'

Register the catalog as a zero-ETL integration target

To prepare your target AWS Glue managed catalog for zero-ETL integration, use the create-integration-resource-property command with these required parameters:

  • The –resource-arn parameter specifies the Amazon Resource Name (ARN) of your AWS Glue managed catalog that will serve as the integration target.
  • The –target-processing-properties parameter requires the ARN of an IAM role that has describe permissions on the target AWS Glue managed catalog.

You can use the GlueDataCatalogDataTransferRole created in the earlier step because it already includes the minimal describe permissions needed for this integration. Alternatively, you can create a new IAM role specifically for this purpose and attach the necessary minimal permissions to meet your company’s security requirements.

aws glue create-integration-resource-property \
    --region <us-east-1> \
    <arn:aws:glue:us-east-1:111122223333:catalog/zetl-catalog> \
    '{"RoleArn": "<arn:aws:iam::111122223333:role/GlueDataCatalogDataTransferRole>"}'

Example output:

{
    "ResourceArn": "arn:aws:glue:us-east-1:111122223333:catalog/zetl-catalog",
    "TargetProcessingProperties": {
        "RoleArn": "arn:aws:iam::111122223333:role/GlueDataCatalogDataTransferRole"
    }
}

Configure authorization for inbound integration requests

The last step in creating a target managed catalog is to define a resource-based access policy that authorizes zero-ETL integration to push data into your catalog. This policy grants AWS Glue the necessary permissions to create and authorize incoming integration requests from your source database. Apply this resource policy by using the AWS Glue put-resource-policy API call to complete the catalog configuration for your zero-ETL integration:

aws glue put-resource-policy \
    --region <us-east-1> \
    --policy-in-json '{
        "Version": "2012-10-17",
        "Statement": [
            {
                "Principal": {
                    "AWS": [
                        "111122223333"
                    ]
                },
                "Effect": "Allow",
                "Action": [
                    "glue:CreateInboundIntegration"
                ],
                "Resource": [
                    "arn:aws:glue:us-east-1:111122223333:catalog/zetl-catalog"
                ],
                "Condition": {
                    "StringEquals": {
                        "aws:SourceArn": "arn:aws:rds:us-east-1:111122223333:cluster:aurora-pgsql-zetl"
                    }
                }
            },
            {
                "Principal": {
                    "Service": [
                        "glue.amazonaws.com"
                    ]
                },
                "Effect": "Allow",
                "Action": [
                    "glue:AuthorizeInboundIntegration"
                ],
                "Resource": [
                    "arn:aws:glue:us-east-1:111122223333:catalog/zetl-catalog"
                ],
                "Condition": {
                    "StringEquals": {
                        "aws:SourceArn": "arn:aws:rds:us-east-1:111122223333:cluster:aurora-pgsql-zetl"
                    }
                }
            }
        ]
    }'

Your AWS Glue managed catalog is now ready to receive data from the zero-ETL integration.

Load data in the source Aurora PostgreSQL database

Now that your Aurora PostgreSQL database is configured and ready, you must populate it with sample data that serves as the historical baseline for your zero-ETL integration. This first dataset provides the foundation for testing and demonstrating the integration capabilities. After you set up the zero-ETL integration, subsequent database changes stream automatically in near real time to your target AWS Glue managed catalog.

Connect to the source Aurora PostgreSQL cluster

Use the following commands to create a connection to your source Aurora PostgreSQL cluster:

psql --host aurora-pgsql-zetl-xxxxx.us-east-1.rds.amazonaws.com --username admin --port 5432 --dbname my_db --password

Create a database and table

Create a table named products to store product information:

CREATE TABLE products (product_id SERIAL PRIMARY KEY,product_name VARCHAR(100) NOT NULL, description TEXT,category VARCHAR(50),price NUMERIC(10,2) NOT NULL,stock_quantity INTEGER DEFAULT 0,is_active BOOLEAN DEFAULT TRUE,created_at TIMESTAMP DEFAULT CURRENT_TIMESTAMP,updated_at TIMESTAMP DEFAULT CURRENT_TIMESTAMP );

Insert historical data

Use the following code to insert a row:

INSERT INTO products (product_name, description, category, price, stock_quantity) VALUES ('Laptop', 'High-performance laptop with 16GB RAM and 512GB SSD', 'Electronics', 1299.99, 50);

This table serves as a representative dataset to demonstrate the data capture and streaming capabilities of the zero-ETL integration. After your zero-ETL integration is active, all database changes, including inserts, updates, and deletes, are automatically captured and streamed to your AWS Glue managed catalog. This creates a data pipeline from your Aurora PostgreSQL database to your Amazon SageMaker for real-time analytics on your operational data.

Create a zero-ETL integration

Because your Aurora PostgreSQL database is now populated with historical data, you can set up the zero-ETL integration that continuously streams database changes to your AWS Glue managed catalog backed by Amazon Redshift managed storage.

Create the integration

Create the integration between your source PostgreSQL database and target AWS Glue catalog by using the aws rds create-integration AWS CLI command. You can customize the integration by specifying added configurations, such as data filters, to control which data gets replicated to your target environment:

aws rds create-integration \
    --source-arn <arn:aws:rds:us-east-1:111122223333:cluster:aurora-pgsql-zetl> \
    --target-arn <arn:aws:glue:us-east-1:111122223333:catalog/zetl-catalog> \
    --integration-name <zetl-test-integration> \
    --data-filter "include: *.*" \
    --region us-east-1

When you run the command, the zero-ETL integration begins provisioning and enters a ‘creating’ state. The AWS CLI response provides key details about the integration configuration.

Example CLI output:

{
    "SourceArn": "<arn:aws:rds:us-east-1:111122223333:cluster:aurora-pgsql-zetl>",
    "TargetArn": "<arn:aws:glue:us-east-1:111122223333:catalog/zetl-catalog>",
    "IntegrationName": "<zetl-test-integration>",
    "IntegrationArn": "<arn:aws:rds:us-east-1:111122223333:integration:4c4d81b9-xxxx>",
    "KMSKeyId": "<arn:aws:kms:us-east-1:111122223333:key/b9130ae1-exxxx>",
    "Status": "creating",
    "Tags": [],
    "CreateTime": "2025-07-04T05:42:56.841000+00:00",
    "DataFilter": "include: *.*"
}

When the integration status changes to “active”, your zero-ETL integration pipeline is fully operational.

Monitor the integration

Before generating new live data, verify that the integration has reached an “active” state by running the describe-integrations AWS CLI command. This monitoring step is important to confirm that changes from your source Aurora cluster are successfully streaming to the AWS Glue managed catalog without errors:

aws rds describe-integrations
{
    "Integrations": [
        {
            "SourceArn": "<arn:aws:rds:us-east-1:111122223333:cluster:aurora-pgsql-zetl>",
            "TargetArn": "<arn:aws:glue:us-east-1:111122223333:catalog/zetl-catalog>",
            "IntegrationName": "<zetl-test-integration>",
            "IntegrationArn": "<arn:aws:rds:us-east-1:111122223333:integration:4c4d81b9-xxxx>",
            "KMSKeyId": "<arn:aws:kms:us-east-1:111122223333:key/b9130ae1-xxxx>",
            "Status": "active",
            "Tags": [],
            "CreateTime": "2025-07-04T05:42:56.841000+00:00",
            "DataFilter": "include: *.*"
        }
    ]
}

Verify the zero-ETL integration

Now that your historical data is loaded and the zero-ETL integration is “active”, you must confirm that the data has been successfully replicated.

Grant Lake Formation permissions

Before you can query the AWS Glue managed catalog by using the Amazon Redshift Data API, you must make sure the IAM user or role has the right permissions to create and manage tables within the catalog. Use the Lake Formation grant-permissions API to provide these necessary permissions so that Amazon Redshift can access your AWS Glue managed catalog for the zero-ETL integration. For more information, see Creating an Amazon Redshift managed catalog in the AWS Glue Data Catalog.

aws lakeformation grant-permissions \
    --region <us-east-1> \
    --cli-input-json '{
        "Principal": {
            "DataLakePrincipalIdentifier": "<arn:aws:iam::111122223333:role/Admin>"
        },
        "Resource": {
            "Table": {
                "DatabaseName": "my_db",
                "CatalogId": "<111122223333:zetl-catalog/zetl_0dff6d97-xxxx>",
            },
            "Permissions": [
                "CREATE_CATALOG",
                "DESCRIBE",
                "CREATE_DATABASE",
                "DROP",
                "ALTER"
            ],
            "PermissionsWithGrantOption": [
                "CREATE_CATALOG",
                "DESCRIBE",
                "CREATE_DATABASE",
                "DROP",
                "ALTER"
            ]
        }'

These permissions allow for query execution and metadata inspection on the managed catalog.

Query historical data by using the Amazon Redshift Data API

With the necessary permissions in place, you can now verify your historical data by querying the AWS Glue managed catalog through the Amazon Redshift execute-statement Data API. Begin this verification process by running a SELECT statement against the catalog:

aws redshift-data execute-statement --sql 'SELECT * FROM "zetl_0dff6d97-xxxx@zetl-catalog"."my_db"."products" LIMIT 10;' --database "<arn:aws:glue:us-east-1:111122223333:catalog/pg-zetl-catalog>"

The following command returns a unique query ID that you can use to monitor the execution status and retrieve results from your query:

{
    "CreatedAt": "2025-07-15T00:31:48.778000+00:00",
    "Database": "arn:aws:glue:us-east-1:111122223333:catalog/zetl-catalog",
    "DbUser": "IAMR:Admin",
    "Id": "ce1ff0el-xxxx",
}

Monitor your query’s progress by using the describe-statement API with the query ID. Continue checking until the status shows that your query has completed successfully:

//use the Id to make the describe-statement API call to verify execution status is Started
aws redshift-data describe-statement --id <ce1ff0el-xxxx>
{
    "CreatedAt": "2025-07-15T00:31:48.778000+00:00",
    "Database": "arn:aws:glue:us-east-1:111122223333:catalog/zetl-catalog",
    "DbUser": "IAMR:Admin",
    "Duration": 6238051060,
    "HasResultSet": true,
    "Id": "2ca8fedf-xxxx",
    "QueryString": "SELECT * FROM \"zetl_0dff6d97-xxxx_zeroetl@pg-zetl-catalog\".\"zetl_default\".\"products\" LIMIT 10;",
    "RedshiftPid": 1073791309,
    "RedshiftQueryId": 1018598,
    "ResultFormat": "json",
    "ResultRows": 1,
    "ResultSize": 149,
    "Status": "FINISHED",
    "UpdatedAt": "2025-07-15T00:31:55.491000+00:00"
}

To complete the verification process and view your historical data now available in Amazon SageMaker AI, retrieve the query results by using the get-statement-result API call:

aws redshift-data get-statement-result --id <ce1ff0el-xxxx>
{
    "Records": [
        [
            {
                "longValue": 1
            },
            {
                "stringValue": "Laptop"
            },
            {
                "stringValue": "High-performance laptop with 16GB RAM and 512GB SSD"
            },
            {
                "stringValue": "Electronics"
            },
            {
                "stringValue": "1299.99"
            },
            {
                "longValue": 50
            },
            {
                "booleanValue": true
            },
            {
                "stringValue": "2026-02-27 13:32:02.697117"
            },
            {
                "stringValue": "2026-02-27 13:32:02.697117"
            }
        ]
    ],
    "ColumnMetadata": [
        ....
        //Skipping metadata
    ],
    "TotalNumRows": 1
}

With your zero-ETL integration now active, you can demonstrate real-time data streaming by adding new data to your source Aurora PostgreSQL instance. Run the following INSERT query to add a new row, which shows how changes are automatically replicated in near real time:

INSERT INTO products (product_name, description, category, price, stock_quantity)
VALUES ('Wireless Mouse', 'Ergonomic wireless mouse with USB receiver and long battery life', 'Electronics', 29.99, 150);

You can verify that the recent changes from your source database have been replicated to the target environment within seconds. Use the same Amazon Redshift Data API workflow you used earlier to confirm the real-time replication:

aws redshift-data execute-statement --sql 'SELECT * FROM "zetl_0dff6d97-xxxx@zetl-catalog"."my_db"."products" LIMIT 10;' --database "<arn:aws:glue:us-east-1:111122223333:catalog/pg-zetl-catalog>"
{
    "CreatedAt": "2025-07-15T00:31:48.778000+00:00",
    "Database": "arn:aws:glue:us-east-1:111122223333:catalog/zetl-catalog",
    "DbUser": "IAMR:Admin",
    "Id": "2ca8fedf-a604-4c87-a183-3a553d62354c",
}

Use the describe-statement API call to monitor the query execution and confirm that the status shows ‘FINISHED’ before proceeding to retrieve the results:

aws redshift-data describe-statement --id <ce1ff0ef-xxxx>
{
    "CreatedAt": "2025-07-15T00:31:48.778000+00:00",
    "Database": "arn:aws:glue:us-east-1:111122223333:catalog/zetl-catalog",
    "DbUser": "IAMR:Admin",
    "Duration": 6238051060,
    "HasResultSet": true,
    "Id": "2ca8fedf-xxxx",
    "QueryString": "SELECT * FROM \"zetl_0dff6d97-xxxx_zeroetl@pg-zetl-catalog\".\"zetl_default\".\"products\" LIMIT 10;",
    "RedshiftPid": 1073791309,
    "RedshiftQueryId": 1018598,
    "ResultFormat": "json",
    "ResultRows": 2,
    "ResultSize": 317,
    "Status": "FINISHED",
    "UpdatedAt": "2025-07-15T00:31:55.491000+00:00"
}

Finally, retrieve the query results by using the get-statement-result API call:

aws redshift-data get-statement-result --id <ce1ff0ef-xxxx>
{
    "Records": [
        [
            {
                "longValue": 1
            },
            {
                "stringValue": "Laptop"
            },
            {
                "stringValue": "High-performance laptop with 16GB RAM and 512GB SSD"
            },
            {
                "stringValue": "Electronics"
            },
            {
                "stringValue": "1299.99"
            },
            {
                "longValue": 50
            },
            {
                "booleanValue": true
            },
            {
                "stringValue": "2026-02-27 13:32:02.697117"
            },
            {
                "stringValue": "2026-02-27 13:32:02.697117"
            }
        ],
        [
            {
                "longValue": 2
            },
            {
                "stringValue": "Wireless Mouse"
            },
            {
                "stringValue": "Ergonomic wireless mouse with USB receiver and long battery life"
            },
            {
                "stringValue": "Electronics"
            },
            {
                "stringValue": "29.99"
            },
            {
                "longValue": 150
            },
            {
                "booleanValue": true
            },
            {
                "stringValue": "2026-02-27 15:41:00.206273"
            },
            {
                "stringValue": "2026-02-27 15:41:00.206273"
            }
        ]
    ],
    "ColumnMetadata": [
        ....
        //Skipping metadata
    ],
    "TotalNumRows": 2
}

This verification process confirms that your zero-ETL integration from Aurora PostgreSQL to Amazon SageMaker AI is working and continuously replicating both historical and real-time data. Although zero-ETL integration significantly simplifies data replication, it’s important to understand certain limitations on supported data types, schema change handling, and data filtering capabilities. For more details about these considerations and best practices, see Aurora zero-ETL integrations and Amazon RDS zero-ETL integrations.

Clean up

This section guides you through the cleanup process to remove the resources and components you created during this walkthrough. When you delete a zero-ETL integration, Amazon Aurora removes it from the source Aurora DB cluster. Your transactional data isn’t removed from Amazon Aurora or the analytics destination, but Aurora doesn’t send new data to Amazon SageMaker AI.

Delete the zero-ETL integration: Begin the cleanup process by removing the integration between your source Amazon Relational Database Service (Amazon RDS) database and the AWS Glue managed catalog. Run the following command to delete the integration:

aws rds delete-integration --integration-identifier <arn:aws:rds:us-east-1:111122223333:integration:4c4d81b9-af2a-4b09-b922-007636ba7f66>

Delete the AWS Glue managed catalog: After you successfully delete the integration, delete the AWS Glue managed catalog that served as your zero-ETL target destination. Use the following command to remove the catalog:

aws glue delete-catalog --catalog-id <111122223333:zetl-catalog>

This permanently removes all associated table metadata and Amazon Redshift managed storage references.

Delete the Aurora DB cluster: If you created the source Aurora DB cluster for this demonstration and you no longer need it, you can complete the cleanup by deleting the entire DB cluster. By skipping the final snapshot option, you avoid retaining any test data and confirm complete resource removal:

aws rds delete-db-instance --db-instance-identifier <aurora-pgsql-zetl-instance-1> --skip-final-snapshot --region <us-east-1>

aws rds delete-db-cluster --db-cluster-identifier <aurora-pgsql-zetl> --skip-final-snapshot --region <us-east-1>

aws rds delete-db-cluster-parameter-group --db-cluster-parameter-group-name <aurora-zetl-cluster-pg> --region <us-east-1>

Conclusion

In this post, you learned how to configure zero-ETL integration between Aurora PostgreSQL and your Amazon SageMaker AI using AWS CLI. This integration automatically replicates your PostgreSQL data to a lakehouse in near real time, removing the need for custom ETL pipelines.

As you move forward, consider expanding this zero-ETL approach to more supported data sources, such as Amazon RDS for MySQL and Amazon DynamoDB. This creates a centralized data access strategy across your company. You can also explore advanced analytics scenarios by combining zero-ETL integrations with Amazon Redshift capabilities. These include large-scale SQL analytics, Amazon Redshift ML for in-database ML, and federated queries that span multiple data lakes and warehouses. These integrations provide the foundation for building a near real-time data platform that scales with your business needs.

To get started, see the AWS zero-ETL documentation for setup guidance, supported configurations, troubleshooting integrations, and architectural best practices.

Related posts and references:


About the authors

Apurwa Pawar

Apurwa Pawar

Apurwa is a Solutions Architect at AWS and a Data Analytics and AI enthusiast. She helps customers build their modern data strategy and cloud-native innovative solutions on AWS. She works with enterprise organizations across industries including healthcare, life sciences, financial services, and hospitality, partnering with engineering and business leadership to turn data into insight and action.

Sarika Subramaniam

Sarika Subramaniam

Sarika is a Solutions Architect at AWS, specializing in analytics and data platforms. She helps customers design scalable, secure, and cloud-based modern data architectures on AWS. She works with enterprise customers across industries, partnering with engineering teams to build innovative data solutions and drive business outcomes.

Building a Slack-powered AI development agent with Kiro CLI and headless authentication

Post Syndicated from Vishal Karlupia original https://aws.amazon.com/blogs/devops/building-a-slack-powered-ai-development-agent-with-kiro-cli-and-headless-authentication/

Every code review discussion, incident response thread, and standup happens in Slack. But when an engineer needs to analyze a service or debug a failing test, they leave Slack, open a terminal, navigate to the repository, run commands, and paste the output back. That round trip takes 30 seconds for someone who knows exactly where to look and 5 minutes for someone less familiar with the codebase. Across a team of 10 engineers doing this 15 times a day, that adds up to over 12 hours of lost engineering time per week.

This post walks through building a ChatOps integration that runs Kiro CLI from a Slack slash command. An engineer types /kiro analyze auth-service for memory leaks, and the results appear directly in the channel—no context switch required. The solution uses AWS Lambda, Amazon API Gateway, and AWS Secrets Manager, and it depends on Kiro CLI’s headless authentication to run without an interactive session.

In this post, you will learn how to:

  • Configure a Slack App with a slash command that triggers an AWS Lambda function
  • Authenticate Kiro CLI in a headless environment using API key-based authentication
  • Build and deploy a container image with Kiro CLI to Amazon Elastic Container Registry (Amazon ECR)
  • Deploy the full solution with AWS Serverless Application Model (AWS SAM)

Why headless authentication matters

A Slack slash command triggers a webhook. The webhook invokes a Lambda function. The Lambda function runs Kiro CLI. At no point in this chain is there a browser, a terminal, or a human session.

Without headless authentication, this architecture does not work. Kiro CLI would require an interactive login, and a Lambda function has no display and no way to complete an OAuth flow.

With an API key, Kiro CLI authenticates silently:

export KIRO_API_KEY=ksk_xxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxx

kiro-cli chat --no-interactive "analyze auth-service for memory leaks"

The API key is stored in AWS Secrets Manager, fetched at runtime, and injected into the Lambda environment. The engineer in Slack never sees or manages the key.

Important: API key-based authentication is available for Kiro Pro, Pro+, and Power subscribers. If your subscription is managed by an administrator, your Kiro admin must enable API key authentication first. For details, see API key governance.

Architecture overview

architecture overview

The solution consists of two Lambda functions, an API Gateway endpoint, and AWS Secrets Manager. The request and response follow two separate paths:

  • Request path: Slack → API Gateway → Dispatcher Lambda → acknowledge back to Slack (under 3 seconds), then async invoke → Worker Lambda
  • Response path: Worker Lambda → Slack response_url (direct HTTPS POST, bypasses API Gateway)

Why two Lambda functions?

Slack requires a response within 3 seconds of a slash command. Kiro CLI analysis takes 10–60 seconds depending on the repository size and prompt complexity. The Dispatcher acknowledges the command immediately and invokes the Worker asynchronously. The Worker runs Kiro CLI and posts results back to Slack through the response_url provided in the original payload. This is a standard pattern for Slack integrations that perform long-running work.

A note on response_url limits: the webhook Slack provides in the slash command payload expires 30 minutes after the command is issued and accepts a maximum of 5 responses. The 10-minute Worker timeout and single response in this solution stay well inside both limits. If you raise the Lambda timeout beyond 30 minutes or add incremental progress updates, these POSTs begin to fail silently – switch to chat.postMessage with a bot token at that point.

Prerequisites

  • Before you begin, you need the following:
  • An AWS account with permissions to create Lambda functions, API Gateway, Amazon ECR repositories, Secrets Manager secrets, and IAM roles
  • An infrastructure-as-code tool for deploying serverless resources (this post uses AWS SAM CLI, but you can adapt the templates to AWS CDK, AWS CloudFormation, Terraform, or your preferred tool)
  • Finch or Docker installed for building container images
  • A Slack workspace where you have permission to create a Slack App
  • A Kiro Pro, Pro+, or Power subscription with API key authentication enabled

Step 1: Gather credentials

You need three credentials before deploying. Collect all of them first, then store them in Secrets Manager in Step 2.

Kiro API key

This authenticates Kiro CLI in headless mode.

  1. Sign in to app.kiro.dev
  2. Navigate to API Keys
  3. Create a new key named kiro-chatops
  4. Copy the key (starts with ksk_) – it is shown only once

get Kiro API key

Slack Signing Secret – This allows the Dispatcher to verify that incoming requests originate from Slack.

  1. Go to api.slack.com/apps and click Create New App → From scratch
  2. Name it Kiro Agent and select your workspace
  3. On the Basic Information page, scroll to App Credentials
  4. Copy the Signing Secret (32-character hex string)

create a slack app

Slack Bot Token – Optional

The Worker posts results using the response_url from the original slash command payload, which is a pre-authenticated webhook that does not require a bot token. Collect a bot token with the chat:write scope only if you extend the solution to post messages independently of a slash command response.

  1. In your Slack App settings, go to OAuth & Permissions
  2. Add the Bot Token Scope: chat:write
  3. Choose Install to Workspace and authorize
  4. Copy the Bot User OAuth Token (starts with xoxb-)

set up slack oauth token

While you are in the Slack App settings, also configure the slash command:

  1. Go to Slash Commands → Create New Command
  2. Set Command to /kiro
  3. Set Request URL to https://placeholder (update after deployment in Step 6)
  4. Set Short Description to Run Kiro-CLI development tasks
  5. Set Usage Hint to [analyze|review|debug|explain] <description>

define slack commands

Step 2: Store secrets in AWS Secrets Manager

Store each credential as a separate secret. The Lambda functions retrieve these at runtime using IAM-scoped access.

aws secretsmanager create-secret \
  --name kiro-chatops/kiro-api-key \
  --secret-string "<your-kiro-api-key>" \
  --region us-east-1

aws secretsmanager create-secret \
  --name kiro-chatops/slack-signing-secret \
  --secret-string "<your-signing-secret>" \
  --region us-east-1

aws secretsmanager create-secret \
  --name kiro-chatops/git-token \
  --secret-string "<your-github-pat>" \
  --region us-east-1

If your target repository is private, also store a GitHub Personal Access Token with repo scope. The Worker uses this token to clone the repository inside the Lambda execution environment.

Verify the secrets were created:

aws secretsmanager list-secrets \
  --filter Key="name",Values="kiro-chatops" \
  --query "SecretList[].Name" \
  --output table \
  --region us-east-1

Step 3: Build the Dispatcher Lambda

The Dispatcher has three responsibilities: verify that the request came from Slack, acknowledge the slash command within 3 seconds, and invoke the Worker asynchronously.

Request verification – Slack signs every request with HMAC-SHA256 using your app’s signing secret. The Dispatcher must validate this signature before processing payloads. The verification logic constructs a base string from the request timestamp and body, computes the HMAC, and compares it to the signature in the request header:

sig_basestring = f"v0:{timestamp}:{body}"
expected = "v0=" + hmac.new(
    signing_secret.encode(), sig_basestring.encode(), hashlib.sha256
).hexdigest()
return hmac.compare_digest(expected, signature)

Reject any request with a timestamp older than 5 minutes to prevent replay attacks. Normalize request headers to lowercase before reading them—API Gateway may preserve the original casing from the client.

Async handoff

After verifying the request, parse the slash command payload to extract text, user_name, and response_url. Then invoke the Worker Lambda with InvocationType="Event" (fire-and-forget) and immediately return an acknowledgment to Slack:

lambda_client.invoke(
   FunctionName=os.environ["WORKER_FUNCTION_NAME"],
    InvocationType="Event",
    Payload=json.dumps({
        "command_text": command_text,
        "user_name": user_name,
        "response_url": response_url,
    })
)

If the user sends /kiro with no arguments, return an ephemeral usage message with examples. The Dispatcher uses the standard Python 3.12 Lambda runtime and requires no container image.

Step 4: Build the Worker Lambda container image

The Worker runs Kiro CLI against a cloned repository and posts results to Slack. Because Kiro CLI depends on git, system libraries (NSS, X11, ALSA), and a binary that exceeds Lambda’s 250 MB layer limit, package the Worker as a container image.

Dockerfile structure

Start from the AWS Lambda Python 3.12 base image. Install git and the shared libraries that Kiro CLI requires, then install Kiro CLI itself:

FROM public.ecr.aws/lambda/python:3.12
RUN dnf install -y git unzip alsa-lib atk at-spi2-atk cups-libs \
    libdrm libXcomposite libXdamage libXrandr mesa-libgbm \
    pango nss nspr libXtst && dnf clean all
RUN curl -fsSL https://cli.kiro.dev/install | bash && \
    cp /root/.local/bin/kiro-cli* /usr/local/bin/ && \
    chmod +x /usr/local/bin/kiro-cli*
COPY index.py ${LAMBDA_TASK_ROOT}/
RUN pip install boto3 --target "${LAMBDA_TASK_ROOT}"
CMD ["index.handler"]

Two details matter here. First, copy the Kiro CLI binary to /usr/local/bin/ rather than leaving it in /root/.local/bin/—Lambda runs as a non-root user that cannot access /root/. Second, build with --platform linux/amd64 regardless of your local architecture, because Lambda defaults to x86_64.

Worker logic – The handler performs four steps:

  1. Fetch the Kiro API key (and optionally a Git token) from Secrets Manager
  2. Clone the repository to /tmp/repo using git clone --depth 1
  3. Run kiro-cli chat --no-interactive "<prompt>" with KIRO_API_KEY and HOME=/tmp set in the environment
  4. Post the output to Slack via the response_url

Setting HOME=/tmp is required because Kiro CLI writes a session database, and Lambda’s filesystem is read-only except for /tmp. Strip ANSI escape codes from the output before posting—Kiro CLI emits terminal colors that render as garbage in Slack.

The subprocess timeout should be shorter than the Lambda timeout to allow time for error handling and the Slack POST. Set the subprocess timeout explicitly to 540 seconds in the Worker code, rather than relying on the Lambda timeout alone. A 9-minute subprocess limit with a 10-minute Lambda timeout provides a 1-minute buffer.

Truncate output to 3,800 characters before posting. Slack’s message limit is 4,000 characters per block, and the surrounding formatting consumes part of that space.

Build and push to Amazon ECR

Clean up /tmp/repo at the end of every invocation. Lambda may reuse a warm execution environment, so anything left in /tmp persists into the next invocation. Removing the clone in a finally block helps prevent one user’s repository from leaking into a later request and keeps the 512 MB ephemeral storage from filling up across warm invocations.

AWS_ACCOUNT_ID=$(aws sts get-caller-identity --query Account --output text)
AWS_REGION=us-east-1
 # Create the ECR repository (first time only)
aws ecr create-repository --repository-name kiro-worker --region $AWS_REGION
 # Authenticate to ECR
aws ecr get-login-password --region $AWS_REGION | \
  finch login --username AWS --password-stdin \
  $AWS_ACCOUNT_ID.dkr.ecr.$AWS_REGION.amazonaws.com
 # Build for the correct architecture
cd worker
finch build --platform linux/amd64 -t kiro-worker:latest .
 # Tag and push
finch tag kiro-worker:latest \
  $AWS_ACCOUNT_ID.dkr.ecr.$AWS_REGION.amazonaws.com/kiro-worker:latest
finch push \
  $AWS_ACCOUNT_ID.dkr.ecr.$AWS_REGION.amazonaws.com/kiro-worker:latest

Step 5: Deploy with AWS SAM

The SAM template defines both Lambda functions, the API Gateway endpoint, and the IAM policies. The Dispatcher uses a standard Python runtime. The Worker references the container image you pushed to Amazon ECR.

Key resource configuration:

Resource Runtime Timeout Memory Package type
Dispatcher Python 3.12 10 s 256 MB Zip
Worker Container 600 s (10 min) 1024 MB Image

Both functions use AWSSecretsManagerGetSecretValuePolicy scoped to the kiro-chatops/* secret prefix. The Dispatcher also gets LambdaInvokePolicy for the Worker function. Neither function has broader AWS permissions.

The SAM template accepts the ECR image URI as a parameter:

Parameters:
  EcrImageUri:
    Type: String
    Description: ECR image URI for the Worker Lambda

Resources:
  WorkerFunction:
    Type: AWS::Serverless::Function
    Properties:
      PackageType: Image
      ImageUri: !Ref EcrImageUri
      Timeout: 600
      MemorySize: 1024

Deploy:

cd ..  # Back to the project root where template.yaml lives
sam build
sam deploy --guided \
  --stack-name kiro-chatops \
  --parameter-overrides \
    EcrImageUri=$AWS_ACCOUNT_ID.dkr.ecr.$AWS_REGION.amazonaws.com/kiro-worker:latest

SAM prompts you to confirm IAM role creation and acknowledge that the Dispatcher has no authentication (request verification happens in code via the Slack signing secret). After deployment completes, note the ApiEndpoint output value.

Step 6: Connect Slack to the endpoint

  1. Go to api.slack.com/apps and select your Kiro Agent app
  2. Navigate to Slash Commands and edit /kiro
  3. Replace the Request URL with the ApiEndpoint value from the SAM deployment output
  4. Choose Save

slack endpoint integration

Step 7: Test the integration

Test directly from Slack by typing in any channel where the app is installed:

test slack integration

/kiro analyze auth-service for memory leaks

Expected behavior:

  1. Slack immediately displays: “@yourname requested: analyze auth-service for memory leaks – Kiro is working on it…”
  2. After 15–60 seconds, the analysis results appear in the channel

expected Kiro agent behaviour

Kiro agent results

You can also invoke the Worker Lambda directly for testing without Slack:

aws lambda invoke \
  --function-name <WorkerFunctionName-from-SAM-output> \
  --invocation-type RequestResponse \
  --cli-binary-format raw-in-base64-out \
  --payload '{"command_text": "explain what this repo does", "user_name": "test", "response_url": "https://hooks.slack.com/YOUR/URL"}' \
  response.json

Sending /kiro with no arguments returns a usage help message.

Complete sample code can be found at aws-samples github repository – https://github.com/aws-samples/sample-kiro-chatops-slack-integration

Practical slash command patterns

Once deployed, the value comes from the commands your team uses daily. These patterns map to real engineering workflows:

Category Example command
Code analysis /kiro analyze the payment module for error handling gaps
Code review /kiro review the last 3 commits on main for breaking changes
Debugging /kiro debug why the integration tests are failing
Knowledge /kiro explain how the authentication middleware works
Sprint support /kiro summarize all changes merged to main this week

The value compounds when results are visible to the entire channel. A junior engineer who might hesitate to open a CLI tool can type /kiro explain and get the same analysis and the rest of the team learns from it.

Extending the pattern

Multi-repository support – The basic implementation targets a single preconfigured repository. To support multiple repositories, parse a URL from the slash command text and clone it at runtime. This adds 5-15 seconds of latency and requires a Git token in Secrets Manager for private repositories.

Threaded responses – Post the acknowledgment as a channel message and the full results as a thread reply. This keeps the channel readable while preserving context for long analyses.

Approval workflows – For commands that modify code (for example, “create a PR that fixes this issue”), add a confirmation step. The Worker posts proposed changes with interactive buttons; the action executes only after explicit approval.

Audit logging – Log every invocation to Amazon DynamoDB: who ran it, what they asked, how long it took. This gives engineering leadership visibility into how the team uses AI-assisted development.

Constraints and trade-offs

Constraints:

  • Execution time – Lambda has a maximum 15-minute timeout. Complex analyses that exceed this will time out. The Worker is set to a 10-minute timeout with a 9-minute subprocess limit.
  • Ephemeral storage – The /tmp volume defaults to 512 MB. A shallow clone (–depth 1) strips Git history, but the working tree alone can exceed this for large monorepos or repositories with binary assets. You can increase ephemeral storage up to 10 GB by setting EphemeralStorage in the SAM template, or scope the clone to a subdirectory with –sparse-checkout for oversized repositories.
  • Slack message size – Each Block Kit text block is limited to 3,000 characters. Long outputs are truncated, with full results available in Amazon CloudWatch Logs.
  • Package size – Kiro CLI with its dependencies exceeds Lambda’s 250 MB layer limit. A container image (up to 10 GB) is required.

Trade-offs:

  • Lambda vs. Amazon ECS on AWS Fargate – Lambda is simpler and cheaper at the low-volume, bursty usage typical of a single team. Model your own break-even point with the AWS Pricing Calculator, since it shifts with average analysis duration and memory size. For high-volume teams, Fargate with a persistent container avoids cold starts. Start with Lambda and migrate if usage grows.
  • Public channel vs. ephemeral – Results are posted as in_channel (visible to everyone). For sensitive analyses, change response_type to ephemeral. Consider making this configurable per command.
  • Cost – Lambda compute is approximately $0.01-$0.05 per 10-minute execution at 1024 MB. The primary cost factor is Kiro CLI usage based on your subscription tier.

Security considerations

  • Request verification — The Dispatcher validates every request using HMAC-SHA256 with the Slack signing secret. Requests with timestamps older than 5 minutes are rejected.
  • Secrets management — Credentials are never hardcoded or stored in environment variables. They are fetched at runtime from Secrets Manager with IAM-scoped access.
  • Least-privilege IAM — The Dispatcher can only invoke the Worker and read secrets. The Worker can only read secrets. Neither has broader AWS permissions.
  • Audit trail — CloudWatch Logs capture every invocation including the command text, user, and Kiro CLI output. Enable AWS CloudTrail for API Gateway to track all incoming requests.

Cleaning up

To avoid ongoing charges, remove all resources when you are done testing:

sam delete --stack-name kiro-chatops
 aws ecr delete-repository \
  --repository-name kiro-worker --force --region us-east-1
 aws secretsmanager delete-secret \
  --secret-id kiro-chatops/kiro-api-key \
  --force-delete-without-recovery --region us-east-1
aws secretsmanager delete-secret \
  --secret-id kiro-chatops/slack-signing-secret \
  --force-delete-without-recovery --region us-east-1
aws secretsmanager delete-secret \
  --secret-id kiro-chatops/git-token \
  --force-delete-without-recovery --region us-east-1

To remove the Slack App, go to api.slack.com/apps, select Kiro Agent, and click Delete App.

Conclusion

This post demonstrated integrating Kiro CLI into Slack workflows using headless authentication, serverless functions, and secure credential management. The Dispatcher acknowledges instantly, the Worker runs Kiro CLI headless, and results appear in the channel where the team already communicates.

The architecture is deliberately simple – a slash command, an async handoff, and a container that runs a CLI tool. You can extend it with multi-repo support, threaded responses, or approval workflows as your team’s usage patterns emerge.

Start with a single slash command in one channel. The commands your team uses most will tell you where the friction was hiding.


About the authors

Vishal Karlupia
Vishal Karlupia is a Senior Technical Account Manager/Lead at Amazon Web Services, Chicago. He specializes in generative AI applications and helps customers build and scale their AI/ML workloads on AWS. Outside of work, he enjoys being outdoors and keeping bonfires alive.

Devi Nair
Devi Nair is a Technical Account Manager at Amazon Web Services, providing strategic guidance to enterprise customers as they build, operate, and optimize their workloads on AWS. She focuses on aligning cloud solutions with business objectives to drive long-term success and innovation.

Joanan Mpo
Joanan Mpo is a Technical Account Manager at AWS based in Montreal, Canada. He is helping enterprise financial services customers navigate the complexity of cloud at scale, bridging the gap between engineering teams and business outcomes.

Srinivas Ganapathi
Srinivas Ganapathi is a Principal Technical Account Manager at Amazon Web Services. He is based in Toronto, Canada, and works with games customers to run efficient workloads on AWS..

Accelerating development workflows with Kiro CLI as a Pre-Commit and Git Hook Agent

Post Syndicated from Vishal Karlupia original https://aws.amazon.com/blogs/devops/accelerating-development-workflows-with-kiro-cli-as-a-pre-commit-and-git-hook-agent/

Code review feedback is most valuable when it arrives early. A security vulnerability caught in a pull request saves hours. The same vulnerability caught in production costs days. But what if you could catch it before the code even leaves the developer’s machine – at the time of git commit?

Git hooks run automatically at specific points in the Git workflow: before a commit, before a push, after a merge. They execute locally, on the developer’s machine, with no CI/CD pipeline involved. The problem is that Git hooks run non-interactively. There is no browser or a terminal session waiting for input. Traditional Kiro CLI requires browser-based login, which makes it unusable in a hook.

Headless authentication changes this. With KIRO_API_KEY set as an environment variable, Kiro CLI runs in any non-interactive context, including Git hooks. This post shows how to wire Kiro CLI into your local Git workflow, so every commit and every push gets AI-powered analysis before it reaches your repository.

Why headless authentication matters here

Git hooks are scripts that Git executes automatically. They have no UI and are unable to open a browser or prompt for credentials. Running silently in the background, they either succeed with exit 0 or blocking the operation with exit non-zero.

# Added to your shell profile (~/.bashrc, ~/.zshrc)

export KIRO_API_KEY=your_api_key_here

The API key is inherited by child processes including Git hooks. If the key isn’t set, the hook skips the execution and fails gracefully rather than blocking commits.

Note on data privacy: These hooks send your staged code diffs to the Kiro API for analysis. Review your organization’s policies on sending source code to APIs before adopting this workflow. For sensitive repositories, consult your security team.

What this enables

  • Pre-commit hook: Scans your staged files for security issues, code smells and style violations. Problems get caught before the commit exists.
  • Commit-msg hook: Enforces your team’s commit message format (Conventional commits, Jira refs etc). Malformed messages get rejected instantly instead of cluttering the log.
  • Pre-push hook: Runs a full review across all commits you’re about to push. This is your last gate before CI picks it up – cheaper to fix it here than to wait for a pipeline failure.
  • Post-merge hook: After pulling changes, it analyzes incoming changes and flags anything that might conflict with your local work.

Prerequisites

  • Kiro CLI installed: curl -fsSL https://kiro.dev/install.sh | bash
  • Kiro API key : Generated from app.kiro.dev (Account → Settings → API Keys) and exported in your shell profile

    Note – Access to Kiro API depends on your organizations policies. Check your team’s configuration Or refer to API Key governance docs for details.

set up Kiro API key

  • Git repository: Any repository where you want local analysis

Verify your setup:

export KIRO_API_KEY=your_api_key_here

kiro-cli whoami

Expected output should confirm you are authenticated. If you see an error, verify your API key is valid and your network allows outbound connections to the Kiro API.

verify your identity

Try it yourself: scratch repo setup

To test the hooks without affecting an existing project, create a throwaway repository:

mkdir kiro-hooks-demo
cd kiro-hooks-demo
git init
git commit --allow-empty -m "feat: initial commit"

All hook examples below work in this scratch repo. For the pre-push hook, you will also need a remote – either create a throwaway repository on GitHub/GitLab or add a bare local remote:

# Option A: Use a throwaway GitHub/GitLab repo
git remote add origin [email protected]:youruser/kiro-hooks-demo.git

# Option B: Use a local bare repo (no network needed)
git init --bare /tmp/kiro-hooks-demo-remote.git
git remote add origin /tmp/kiro-hooks-demo-remote.git

Hook 1: Pre-commit – Catch issues before they become commits

The pre-commit hook runs after you type git commit but before Git creates the commit object. If the hook exits with a non-zero code, the commit is aborted.

Create .git/hooks/pre-commit:

#!/bin/bash
set -e
# Skip hook if KIRO_API_KEY is not set
if [ -z "$KIRO_API_KEY" ]; then
  echo "⚠  KIRO_API_KEY not set. Skipping Kiro pre-commit analysis."
  exit 0
fi

# Get list of staged files (only added, modified, or renamed)
STAGED_FILES=$(git diff --cached --name-only --diff-filter=AMR)

if [ -z "$STAGED_FILES" ]; then
  echo "No staged files to analyze."
  exit 0
fi

# Get the actual diff content for context
DIFF_CONTENT=$(git diff --cached)

echo "???? Kiro CLI: Analyzing $(echo "$STAGED_FILES" | wc -l | tr -d ' ') staged file(s)..."

# Run Kiro CLI analysis on staged changes (timeout after 30s to avoid hanging offline)
RESULT=$(timeout 30 kiro-cli chat --no-interactive "You are a pre-commit code reviewer. Analyze ONLY the following staged changes for critical issues that should block this commit.
STAGED FILES:$STAGED_FILES

DIFF:$DIFF_CONTENT

Check for:
1. SECURITY: Hardcoded secrets, API keys, passwords, tokens in the diff
2. SECURITY: SQL injection, XSS, or command injection vulnerabilities
3. BUGS: Obvious logic errors, null pointer risks, off-by-one errors
4. PERFORMANCE: Accidentally committed debug code, console.log statements, sleep calls

Rules:
- Only flag issues that are clearly problems. Do not flag style preferences.
- If you find a SECURITY issue, output a line starting with BLOCK: followed by the reason.
- If you find a BUG or PERFORMANCE issue, output a line starting with WARN: followed by the reason.
- If everything looks clean, output a single line: PASS

Be concise. This runs on every commit - speed matters." 2>&1) || {
  EXIT_CODE=$?
  if [ $EXIT_CODE -eq 124 ]; then
    echo "⚠  Kiro CLI timed out (network issue?). Allowing commit."
    exit 0
  fi
  echo "⚠  Kiro CLI returned an error. Allowing commit."
  exit 0
}

echo "$RESULT"

# Block commit if BLOCK issues found
if echo "$RESULT" | grep -q "BLOCK:"; then
  echo ""
  echo "❌ Commit blocked by Kiro CLI. Fix the issues above and try again."
  echo "   To bypass this hook: git commit --no-verify"
  exit 1
fi

# Warn but allow commit for non-blocking issues
if echo "$RESULT" | grep -q "WARN:"; then
  echo ""
  echo "⚠  Warnings found. Commit will proceed. Consider fixing before push."
fi

echo "✅ Kiro CLI pre-commit check passed."
exit 0

Make it executable:

chmod +x .git/hooks/pre-commit

Test it:

# Test 1: Commit a hardcoded secret (should be blocked)
echo 'AWS_SECRET_KEY = "AKIAIOSFODNN7EXAMPLE"' >> config.py
git add config.py
git commit -m "feat: add config"
# Expected: ❌ Commit blocked by Kiro CLI

# Clean up test file
git reset HEAD config.py && rm config.py

# Test 2: Commit clean code (should pass)
echo 'def hello(): return "world"' >> app.py
git add app.py
git commit -m "feat: add hello function"
# Expected: ✅ Kiro CLI pre-commit check passed

# Test 3: Bypass when needed
echo 'placeholder' >> temp.txt && git add temp.txt
git commit --no-verify -m "chore: emergency fix"
# Expected: Hook skipped entirely

# Clean up
rm -f temp.txt

Test 1 – Stages a file with hard-coded AWS secret key. Kiro CLI detects the credential and blocks the commit with BLOCK:, preventing the secret from entering git history.

Test 1 - Kiro blocks the commit

Test 2 – Stages a simple, clean Python function. Kiro CLI finds no issues and outputs PASS, allowing commit to proceed normally.

Test 2 - Kiro allows the commit

Test 3 – Uses git’s –no-verify flag to skip all hooks entirely. Demonstrates the escape hatch when developers need to commit without waiting for analysis (e.g, emergency fixes).

Test 3 - skip all git hooks

Trade-offs:

Speed vs. depth: The prompt is deliberately focused on critical issues only. A comprehensive review would take 15-30 seconds per commit – too slow for developer flow. This hook targets 3-8 seconds

False positives: Blocking commits on false positives destroys developer trust. The prompt is conservative – only BLOCK for clear security issues, WARN for everything else

Bypass escape hatch: git commit –no-verify skips all hooks. This is intentional – developers must never feel trapped. Document when bypassing is acceptable (e.g., emergency hotfixes)

Hook 2: Commit-msg – Enforce commit message conventions

The commit-msg hook runs after the developer writes their commit message. It receives the path to the temporary file containing the message.

Create .git/hooks/commit-msg:

#!/bin/bash

set -e
COMMIT_MSG_FILE="$1"
COMMIT_MSG=$(cat "$COMMIT_MSG_FILE")

# Skip hook if KIRO_API_KEY is not set
if [ -z "$KIRO_API_KEY" ]; then
exit 0
fi

# Skip for merge commits and fixup commits
if echo "$COMMIT_MSG" | grep -qE "^(Merge|fixup!|squash!)"; then
exit 0
fi

echo "???? Kiro CLI: Validating commit message..."

RESULT=$(timeout 15 kiro-cli chat --no-interactive "Validate this commit message against Conventional Commits format.
COMMIT MESSAGE:$COMMIT_MSG

Rules:1. Must start with a type: feat, fix, docs, style, refactor, perf, test, build, ci, chore, revert2. Type may have an optional scope in parentheses: feat(auth), fix(api)3. Must have a colon and space after type/scope: feat: or feat(auth):4. Description must start with lowercase letter5. Description must not end with a period6. Subject line must be under 72 characters7. If a Jira ticket pattern exists (e.g., PROJ-123), that is acceptable in the scope or body
If the message is valid, output exactly: VALIDIf the message is invalid, output: INVALID: followed by what is wrong and a corrected example.
Be concise. One line for valid, two lines max for invalid." 2>&1) || {
echo "⚠  Kiro CLI unavailable. Skipping commit message validation."
exit 0
}

echo "$RESULT"

if echo "$RESULT" | grep -q "INVALID:"; then
echo ""
echo "❌ Commit message does not follow conventions."
echo "   Examples: feat: add login page"
echo "             fix(auth): resolve token expiry bug"
echo "   To bypass: git commit --no-verify"
exit 1
fi

exit 0

Make it executable:

chmod +x .git/hooks/commit-msg

Test it:

# Test 1: Invalid message (should be blocked)
echo "hello" > test.txt && git add test.txt

git commit -m "updated stuff"
# Expected: ❌ Commit message does not follow conventions

# Test 2: Valid message (should pass)
git commit -m "feat: add user authentication module"
# Expected: passes

# Test 3: Valid with scope
echo "world" >> test.txt && git add test.txt

git commit -m "fix(api): resolve null pointer in user handler"
# Expected: passes

Test 1 – Commits with a non-conventional message (“Updated Stuff”). Kiro CLI detects it lacks required description format and blocks the commit.

Test 1 - Kiro blocks vague commit message

Test 2 – Commits with a properly formatted message. Kiro validates it against conventional commit rules and allows the commit.

Test 2 - Kiro checks rules and allows commit

Test 3 – Commits with a scoped conventional message (“fix(api): resolve null pointer in user handler”). Kiro confirms the “type(scope): description” format is valid and allows the commit.

Test 3 - Kiro validates format and allows commit

Hook 3: Pre-push – Comprehensive review before code leaves your machine

The pre-push hook runs after git push is called but before data is transferred to the remote. This is the last checkpoint before your code enters the shared repository.

Note: To test this hook, you need a remote configured. See the “Try it yourself” section above for setup options.

Create .git/hooks/pre-push:

#!/bin/bash

set -e
# Skip hook if KIRO_API_KEY is not set
if [ -z "$KIRO_API_KEY" ]; then
echo "⚠  KIRO_API_KEY not set. Skipping Kiro pre-push analysis."
exit 0
fi

# Read push information from stdin
while read LOCAL_REF LOCAL_SHA REMOTE_REF REMOTE_SHA; do
# Skip delete pushes
if [ "$LOCAL_SHA" = "0000000000000000000000000000000000000000" ]; then
continue

fi

# Determine the range of commits being pushed
if [ "$REMOTE_SHA" = "0000000000000000000000000000000000000000" ]; then
# New branch - analyze all commits not yet on any remote
COMMITS=$(git log --oneline "$LOCAL_SHA" --not --remotes 2>/dev/null | head -20)
else
# Existing branch - analyze only new commits
COMMIT_RANGE="$REMOTE_SHA..$LOCAL_SHA"
COMMITS=$(git log --oneline "$COMMIT_RANGE" 2>/dev/null | head -20)
fi

if [ -z "$COMMITS" ]; then
echo "No new commits to analyze."
exit 0
fi

COMMIT_COUNT=$(echo "$COMMITS" | wc -l | tr -d ' ')
echo "???? Kiro CLI: Reviewing $COMMIT_COUNT commit(s) before push..."

# Get the diff and changed files
if [ "$REMOTE_SHA" = "0000000000000000000000000000000000000000" ]; then
DIFF=$(git diff --stat HEAD~"$COMMIT_COUNT" "$LOCAL_SHA" 2>/dev/null || git show --stat "$LOCAL_SHA")
CHANGED_FILES=$(git diff --name-only HEAD~"$COMMIT_COUNT" "$LOCAL_SHA" 2>/dev/null || echo "Unable to determine changed files")
else
DIFF=$(git diff --stat "$REMOTE_SHA" "$LOCAL_SHA" 2>/dev/null)
CHANGED_FILES=$(git diff --name-only "$REMOTE_SHA" "$LOCAL_SHA" 2>/dev/null)
fi

RESULT=$(timeout 60 kiro-cli chat --no-interactive "You are a pre-push code reviewer. These commits are about to be pushed to the remote repository. Perform a comprehensive review.
COMMITS:$COMMITS

CHANGED FILES:$CHANGED_FILES

DIFF STATS:$DIFF

Check for:1. SECURITY: Any secrets, credentials, or API keys in the commits2. SECURITY: Vulnerability patterns (injection, XSS, insecure deserialization)3. QUALITY: Test files included for new functionality4. QUALITY: Large files or binary files that should not be in the repo5. ARCHITECTURE: Breaking changes that should be documented6. DEPENDENCIES: New dependencies added - any known vulnerabilities
If you find a critical SECURITY issue, output: BLOCK: followed by the reason.If you find quality or architecture concerns, output: WARN: followed by the reason.If everything looks good, output: PASS
Provide a brief summary (3-5 lines max). Speed matters." 2>&amp;1) || {
EXIT_CODE=$?
if [ $EXIT_CODE -eq 124 ]; then
echo "⚠  Kiro CLI timed out. Allowing push."
exit 0
fi
echo "⚠  Kiro CLI returned an error. Allowing push."
exit 0
}

echo "$RESULT"

if echo "$RESULT" | grep -q "BLOCK:"; then
echo ""
echo "❌ Push blocked by Kiro CLI. Fix the issues above and try again."
echo "   To bypass: git push --no-verify"
exit 1
fi

if echo "$RESULT" | grep -q "WARN:"; then
echo ""
echo "⚠  Warnings found. Push will proceed. Consider addressing before PR."
fi

done

echo "✅ Kiro CLI pre-push check passed."
exit 0

Make it executable:

chmod +x .git/hooks/pre-push

Test it:

# Test 1: Push commits with a secret (should be blocked)
echo 'DB_PASSWORD="supersecret123"' >> config.env

git add config.envgit commit --no-verify -m "chore: add config"
git push origin main

# Expected: ❌ Push blocked by Kiro CLI

# Test 2: Push clean commits (should pass)
git reset --hard HEAD~1echo 'DB_PASSWORD=${DB_PASSWORD}' >> config.env

git add config.env

git commit -m "chore: add config template with env var reference"
git push origin main

# Expected: ✅ Kiro-CLI pre-push check passed

Test 1 – Commits a file containing hard coded database password and attempts to push. Kiro CLI performs a review of the outgoing commit, detects a plaintext credential in config.env file and blocks the push before the secret reaches remote repository.

Test 1 - Kiro blocks hard coded credentials

Test 2 – Commits a config template using and environment variable reference “${DATABASE_URL}” instead of real secret. Kiro CLI reviews the commit, confirms no hardcoded credentials are present and allows the commit to proceed.

Test 2 - Kiro allows config push

Trade-off:

The pre-push hook is more thorough than pre-commit because it reviews all commits being pushed at once. This means it takes longer (10-20 seconds) but runs less frequently. Developers push less often than they commit, so this is an acceptable trade-off.

Automating hook installation across your team

Git hooks live in .git/hooks/, which is not tracked by Git. To share hooks across your team, use one of these approaches:

Approach A – Shared hooks directory (recommended)

Store hooks in a tracked directory and configure Git to use it:

# Create a hooks directory in your repo
mkdir -p .githooks
# Copy your hooks there
cp .git/hooks/pre-commit .githooks/pre-commitcp .git/hooks/commit-msg .githooks/commit-msgcp .git/hooks/pre-push .githooks/pre-push
# Commit the hooks
git add .githooks/git commit -m "chore: add Kiro-CLI git hooks for local code analysis"

Each developer runs once after cloning:

git config core.hooksPath .githooks

To automate this, add it to your project’s setup script or Makefile:

# Makefilesetup:    @echo "Configuring git hooks..."    git config core.hooksPath .githooks    @echo "Verifying Kiro CLI..."    @kiro-cli whoami || echo "⚠  Set KIRO_API_KEY in your shell profile"    @echo "✅ Setup complete"

Approach B – Install script

Create a scripts/install-hooks.sh that developers run once:

#!/bin/bashset -e
echo "Installing Kiro CLI git hooks..."

# Check prerequisites
if ! command -v kiro-cli &> /dev/null; then
echo "Installing Kiro-CLI..."
curl -fsSL https://kiro.dev/install.sh | bash  export PATH="$HOME/.kiro/bin:$PATH"
fi

if [ -z "$KIRO_API_KEY" ]; then
echo ""
echo "⚠  KIRO_API_KEY is not set."
echo "   1. Generate a key at https://app.kiro.dev (Account → Settings → API Keys)"
echo "   2. Add to your shell profile:"
echo "      echo 'export KIRO_API_KEY=your_key_here' >> ~/.zshrc"
echo "   3. Restart your terminal or run: source ~/.zshrc"
echo ""
echo "Hooks installed but will be skipped until KIRO_API_KEY is set."
fi

# Configure hooks path
git config core.hooksPath .githooksecho "✅ Git hooks configured. Kiro CLI will analyze commits and pushes."

Approach C – Pre-commit framework integration

If your team already uses the pre-commit framework, create a .pre-commit-config.yaml:

repos:
- repo: local
hooks:
- id: kiro-security-check
name: Kiro-CLI Security Check
entry: bash -c '
if [ -z "$KIRO_API_KEY" ]; then exit 0; fi
STAGED=$(git diff --cached --name-only --diff-filter=AMR)
if [ -z "$STAGED" ]; then exit 0; fi
DIFF=$(git diff --cached)
RESULT=$(timeout 30 kiro-cli chat --no-interactive "Analyze these staged changes for hardcoded secrets, credentials, and security vulnerabilities ONLY. Files: $STAGED. Diff: $DIFF. Output BLOCK: if critical security issue found, otherwise PASS." 2>&1) || exit 0
echo "$RESULT"
if echo "$RESULT" | grep -q "BLOCK:"; then exit 1; fi
'        language: system        stages: [commit]        pass_filenames: false
- id: kiro-commit-msg        name: Kiro-CLI Commit Message Check        entry: bash -c '
if [ -z "$KIRO_API_KEY" ]; then exit 0; fi
MSG=$(cat "$1")
if echo "$MSG" | grep -qE "^(Merge|fixup!|squash!)"; then exit 0; fi
RESULT=$(timeout 15 kiro-cli chat --no-interactive "Is this commit message valid Conventional Commits format? Message: $MSG. Output VALID or INVALID: reason." 2>&1) || exit 0
echo "$RESULT"
if echo "$RESULT" | grep -q "INVALID:"; then exit 1; fi
'
language: system
stages: [commit-msg]
pass_filenames: true

Constraints, trade-offs, and assumptions

Constraints:

  • Git hooks run locally – they depend on the developer having Kiro CLI installed and KIRO_API_KEY set
  • Hooks add latency to git commit and git push operations (3-8 seconds for pre-commit, 10-20 seconds for pre-push)
  • --no-verify bypasses all hooks – this is a native Git feature

Trade-offs:

  • Speed vs. thoroughness: Pre-commit checks only critical issues (secrets, obvious bugs) to stay under 8 seconds. Pre-push does a broader review because it runs less frequently.
  • Blocking vs. warning: Only security issues should block commits – everything else warns – because overly aggressive blocking erodes developer trust and leads to permanent bypasses.
  • Local vs. CI/CD: Git hooks complement CI/CD, they do not replace it. CI/CD runs in a controlled environment with full test suites. Hooks provide fast, early feedback on the developer’s machine.
  • Team adoption: Hooks are opt-in per developer (they must set KIRO_API_KEY). This is intentional – forcing hooks on developers who don’t want them creates resentment.
  • Network dependency: Hooks require internet connectivity. The timeout wrapper ensures they fail gracefully when offline rather than blocking commits indefinitely

Assumptions:

  • Developers have Kiro CLI installed locally (curl -fsSL https://kiro.dev/install.sh | bash)
  • KIRO_API_KEY is exported in the developer’s shell profile
  • The repository uses a branching strategy where developers commit to feature branches and push to remote

Measuring impact

Track these metrics before and after adopting Kiro CLI git hooks:

  • PR review cycle time: Measure time from PR open to first approval. If hooks are doing their job, reviewers spend less time on nits and more on logic, shortening the feedback loop.
  • CI/CD failure rate: Track pipeline failures caused by code quality issues that hooks would have caught (lint errors, formatting, missing tests).
  • Developer satisfaction: Survey developers after 2 weeks. Key question: “Do the hooks save you time or slow you down?”
  • Bypass rate: Monitor how often –no-verify is used. A high bypass rate signals the hooks are too aggressive or too slow

Cleanup

To remove the hooks and test artifacts:

# Reset hooks path to default
git config --unset core.hooksPath

# Or remove individual hooks
rm .git/hooks/pre-commitrm .git/hooks/commit-msgrm .git/hooks/pre-push

# If using the scratch repo from "Try it yourself"
cd .. && rm -rf kiro-hooks-demorm -rf /tmp/kiro-hooks-demo-remote.git

Conclusion

Headless authentication makes Kiro CLI available in contexts where no browser exists and Git hooks are one of the most valuable of those contexts.

A hardcoded secret caught at git commit takes 10 seconds to fix versus minutes in CI/CD or days in a security audit – start with the pre-commit hook as the highest-value, lowest-friction entry point, and share hooks across your team to standardize developer workflows.


Vishal Karlupia
Vishal Karlupia is a Senior Technical Account Manager/Lead at Amazon Web Services, Chicago. He specializes in generative AI applications and helps customers build and scale their AI/ML workloads on AWS. Outside of work, he enjoys being outdoors and keeping bonfires alive.

Anil Machavaram
Anil Machavaram is a Senior Technical Account Manager at AWS Enterprise Support with close to two decades of experience. He works closely with Financial Services Industry (FSI) customers, helping them design resilient, secure and efficient cloud environments while navigating complex customer challenges and large-scale infrastructure migrations.

Srinivas Ganapathi
Srinivas Ganapathi is a Principal Technical Account Manager at Amazon Web Services. He is based in Toronto, Canada, and works with games customers to run efficient workloads on AWS..

Frozen package management for air-gapped RHEL-family AMIs

Post Syndicated from Anand Krishna Varanasi original https://aws.amazon.com/blogs/compute/frozen-package-management-for-air-gapped-rhel-family-amis/

If you run a regulated, air-gapped compute fleet on RHEL-family instances, you have probably felt three requirements pulling against each other. Your organization must configure the network to remove internet access from the instances. Your team must review and approve new packages or version upgrades before you adopt them. Your team removes public repository definitions, restricts network paths, and configures instances to use only the internal repository your team has approved. Teams in chip design, finance, healthcare, defense, and the public sector often face this combination while still needing operating system updates.

This post describes a two-account pattern that separates the connected package-ingestion path from the air-gapped fleet. You create an authorized initial baseline and approve later changes to form a versioned package snapshot in Amazon Simple Storage Service (Amazon S3). EC2 Image Builder uses the frozen snapshot to build Amazon Machine Images (AMIs). Your team configures AWS Systems Manager Patch Manager to patch the instances your organization runs from the same internal package source.

The accompanying reference implementation demonstrates the pattern for RPM-based RHEL-family systems (AlmaLinux for example). It is a reference, not a substitute for distribution of licensing, vulnerability analysis, testing, or an organization’s change-management process.

The challenge: Getting packages into an air-gapped approval-gated fleet

Common delivery models each assume something an air-gapped fleet might not provide:

  • Red Hat Update Infrastructure (RHUI) expects each instance to reach the service. A fleet with no internet egress needs a different content path.
  • Red Hat Satellite supports disconnected content management, but it is a separate product and operational footprint. Teams that need a custom package-level approval workflow must integrate that workflow with their content-management process.
  • The Red Hat CDN requires a connected, entitled content-management path. Centralizing that path changes the network architecture, not the customer’s Red Hat subscription obligations.

The objective is not to replace these products universally. It is to show a serverless AWS pattern for teams that need an authorized repository baseline, explicit approval for later package changes, and a fleet with no public package source.

How the pattern works

The pattern combines three controls:

  1. A frozen package repository on Amazon S3: The pattern stores a deployment-authorized baseline and subsequent approved package changes in versioned, per-OS repository prefixes. The repository manifest records the package inventory for each state.
  2. EC2 Image Builder Orchestration builds AMIs from that repository: The build helps remove upstream repository definitions and configures the internal frozen mirror to be used for all package operations.
  3. The launched fleet has no internet egress: The dnf operations are configured to resolve the internal mirror. Patch Manager uses the same repository source, so image builds and in-place patching draw from one frozen snapshot.

Choosing the upstream source

Choose one package lineage end to end. The parent AMI, repository content, and trusted signing keys must belong to that same lineage.

The reference implementation defaults to AlmaLinux vault content plus EPEL and an AlmaLinux parent AMI. The AlmaLinux OS Foundation states that AlmaLinux aims for binary and application binary interface (ABI) compatibility with RHEL. This is an AlmaLinux compatibility goal, not a Red Hat certification, and it does not make repository mixing a supported practice.

For genuine RHEL systems, use a Red Hat parent AMI, entitled Red Hat repositories, and Red Hat signing keys. A connected content-management host can retrieve content for the isolated environment. This centralizes the network path but does not reduce or change the customer’s Red Hat subscription obligations. Confirm those obligations against the applicable Red Hat agreement.

Do not pair AlmaLinux repositories with genuine RHEL hosts, or Red Hat repositories with AlmaLinux hosts. Mixed-vendor package lineages can create support, stability, and maintainability problems even when the RPMs appear mechanically compatible.

Architecture and workflow

The account boundary provides a primary security boundary for this architecture. The following diagram shows the connected Distribution account, the read-only Workload account, and an example cross-Region layout.

Two-account architecture showing the connected Distribution account with the control plane and internet path, and the air-gapped read-only Workload account, spanning two Regions

Figure 1: Two-account, cross-Region architecture separating the connected Distribution account from the air-gapped Workload account

The Distribution account owns the writable control plane and the only internet path. It runs Amazon EventBridge, three AWS Lambda functions, Amazon DynamoDB, Amazon Simple Notification Service (Amazon SNS), and the AWS Fargate sync task. It also owns the frozen S3 repository and its AWS Key Management Service (AWS KMS) key.

The Workload account is air-gapped and read-only with respect to the repository. It runs the internal HTTPS mirror, EC2 Image Builder, Patch Manager, and the compute fleet. Its mirror task role can read and decrypt frozen content but cannot write it.

The sample repository places the Distribution control plane in US East (N. Virginia), the frozen store in US West (Oregon), and the Workload resources in US West (Oregon) to demonstrate API-only cross-account and cross-Region operation. This Region split is not required. In most deployments, place the Distribution control plane and frozen store in the same Region unless data residency, disaster recovery, or an existing regional footprint justifies the additional latency, transfer cost, and KMS policy complexity.

The two accounts do not need Amazon Virtual Private Cloud (VPC) peering or a transit gateway. Cross-account access uses S3, KMS, and IAM policies. The VPC address ranges can overlap because no VPC-to-VPC route is required.

Package baseline and scheduled upgrade workflow

Before the scheduled workflow begins, your organization must authorize and run a full sync to establish the initial repository baseline. This bootstrap does not provide package-by-package approval. If your organization requires individual approval for every initial RPM, your team should generate and review the baseline manifest before promotion instead of relying solely on deployment authorization.

After the baseline, the detector runs on a customer-defined schedule. The reference implementation defaults to monthly. The following diagram shows the bootstrap distinction and the selective approval flow.

Workflow diagram distinguishing the initial baseline bootstrap sync from the recurring detect, request approval, review, record, selective sync, and manifest update steps

Figure 2: Package baseline bootstrap and the scheduled selective approval workflow

  1. Detect. Amazon EventBridge invokes the detector Lambda function on the configured schedule. The detector compares upstream repository metadata with manifest.json, which records the current frozen inventory. It classifies a newer version as an upgrade and an absent package as new.
  2. Request approval. The detector writes candidates to S3, creates a KMS-protected review token carrying the request ID and expiry, and is designed to send a review link through SNS. The detector can use kms:Encrypt but not kms:Decrypt.
  3. Review. A human opens the review page through an Amazon API Gateway HTTP API, reviews the proposed package versions, and chooses which changes to approve. The approver can use kms:Decrypt but not kms:Encrypt.
  4. Record and start. A conditional DynamoDB update changes a request from pending to approved only once. The approver then starts the Fargate sync task and passes the request ID.
  5. Selective sync. The task reads the approved package list, downloads those package versions, is designed to perform verification checks, and regenerates repository metadata.
  6. Update the manifest. When the task stops, Amazon EventBridge invokes the manifest-updater Lambda function. It archives the outgoing manifest and records the resulting repository inventory.

The approval decision controls adoption. It does not prove that package code is safe. Advisory review, vulnerability scanning, testing, and staged rollout remain in separate controls.

Evidence from the approval workflow

The token ties a review action to a specific request and expiry. Separating kms:Encrypt from kms:Decrypt prevents either Lambda function from performing both token roles. The conditional DynamoDB write makes the approval transition single-use.

DynamoDB records request state, AWS CloudTrail records control-plane API activity, and manifest history records repository inventory changes. These service records can feed the organization’s existing audit and evidence-management workflow. Object-level S3 access auditing requires CloudTrail S3 data events. KMS activity alone is not a substitute for those events.

The frozen package repository on Amazon S3

The following diagram shows the per-OS, per-component prefix layout, and manifest objects.

Amazon S3 prefix layout with one prefix per operating system version, each holding BaseOS, AppStream, and EPEL components with Packages and repodata trees plus manifest objects

Figure 3: Per-OS, per-component prefix layout of the frozen repository on Amazon S3

Each pinned operating system version receives its own prefix. Repository components such as BaseOS, AppStream, and EPEL contain Packages/ and repodata/ trees. manifest.json records the active inventory, and archived manifests preserve historical evidence and comparison points.

Your organization configures the bucket with versioning and SSE-KMS. Public RPM content does not require a customer-managed KMS key for confidentiality, so your organization could instead configure SSE-S3 for encryption at rest. However, SSE-S3 would remove the separate cross-account authorization control provided by the customer-managed KMS key policy. The customer managed key is used here for explicit cross-account key-policy control and revocation, and the manifests reveal the fleet’s exact software inventory. S3 Bucket Keys reduce KMS request volume. If object-level access evidence is required, enable CloudTrail S3 data events.

A rollback must restore a coherent repository state, including metadata and any required object versions. Restoring only manifest.json does not roll back repository contents.

Building, patching, and running the fleet

At AMI build time, an Image Builder component installs the configured repository keys, moves existing repository definitions aside, and writes one frozen repository definition per component. It locks the package manager to the frozen repository directory, fetches metadata through the internal mirror, and fails the build if the mirror validation step fails. An optional curated package list demonstrates that the AMI can install real packages through the frozen path.

Patch Manager uses the same mirror for the running fleet. A host created from an older AMI and a newly built host are therefore patched toward the same frozen snapshot. Instances run without an Amazon VPC NAT gateway, public IP, or an Amazon VPC internet gateway route in the Workload VPC, and their repository configuration contains no public fallback.

The intended verification model is defense in depth: the sync task helps verify a vendor’s signature before content enters the trusted repository, and the system verifies it again at installation through dnf. The ingestion gate helps reject digest-only results and can be configured to help confirm that only valid package signatures from a trusted lineage key are accepted.

The package mirror

Nginx fronts aws-sigv4-proxy, which signs cross-account S3 GET requests using the mirror task role. To a client, the service appears as a standard HTTPS package repository behind an internal Application Load Balancer and private DNS name.

Use the latest version of aws-sigv4-proxy (current latest is v1.12). This version 1.12 contains the fix for signing S3 paths (or the OS package names) with special characters such as +. Earlier versions can return SignatureDoesNotMatch. The reference implementation pins the reviewed v1.12 release commit immutably. Keep it current through dependency-update reviews.

Security boundaries and limits

The design provides the following controls:

  • No automatic public-repository adoption: A new upstream version enters the selective path only after an explicit, recorded decision by the user.
  • Repository ingestion and installation checks: You configure strict sync-time signature validation to help validate content before it enters the trusted store. dnf verifies again during installation.
  • No package-channel egress: Workload instances are configured to prevent access to public package sources.
  • A read-only workload boundary: A Workload-account principal cannot modify the frozen repository.

Human approval is not a malware detection. A reviewer cannot reliably identify a backdoor in a legitimately signed package merely by seeing its name, version, or changelog. Use vulnerability intelligence, scanning, pre-production tests, and staged deployment as additional controls.

The approval state, manifests, and CloudTrail records can help support evidence for control frameworks such as SOC 2 change management, ISO 27001 patch-management controls, and FDA 21 CFR Part 11 electronic records. Applicability depends on the organization’s environment, audit scope, and assessor. Confirm it with the compliance team under the AWS shared responsibility model.

Cost and operations

Cost depends on the amount of repository content and the chosen networking and availability design. Components can include S3 storage and requests, KMS requests, Lambda invocations, DynamoDB, SNS, Fargate tasks, the internal load balancer, Distribution-account internet egress, Amazon VPC endpoints, and AMI snapshots. A three-task always-on mirror costs more than an S3 bucket alone. Estimate the target topology with current AWS pricing rather than applying a fixed monthly figure from the sample.

Run detection and review at an interval defined by patch policy and risk tolerance. The supplied default is monthly, but the Terraform input is configurable. If a package change must be reversed, restore a tested, coherent repository version and rebuild or patch affected hosts as appropriate.

Prerequisites

To set up the reference implementation, work through these in order:

  1. Two AWS accounts: a connected Distribution account and an air-gapped Workload account.
  2. Deployment tools: Terraform 1.5 or later, Terragrunt, Finch or Docker, and Python with pip.
  3. AWS Command Line Interface (AWS CLI): one named profile per account.
  4. Distribution networking: private subnets with internet egress that works without public IPs, security-group egress on port 443, and DNS resolution for public names.
  5. Workload networking: VPC interface endpoints for ssm, ssmmessages, ec2messages, logs, kms, and imagebuilder, plus an S3 gateway endpoint.
  6. Internal mirror identity: an AWS Certificate Manager (ACM) certificate and a private hosted zone. If the parent AMI does not trust the issuing CA, configure the CA file so the build installs the trust anchor.
  7. Package lineage: a parent AMI, repositories, and signing keys from the same distribution lineage. A RHEL subscription is required when retrieving genuine entitled Red Hat content.
  8. Optional deployment roles: otherwise, the stack uses each profile’s credentials.

The deployment creates state backend and Amazon Elastic Container Registry (ECR) repositories. Do not create those ECR repositories separately before applying their own Terraform units.

Reference implementation

The companion repository provides Terraform modules, Lambda handlers, two container images, a Terragrunt two-account layout, and Makefile targets for deployment and verification. The shipped alma810 example defaults to the AlmaLinux lineage (RHEL family).

Choose one distribution lineage before deployment:

  • AlmaLinux Parent Image default: use an AlmaLinux parent AMI, AlmaLinux vault repositories, EPEL, and the included AlmaLinux and EPEL signing keys. No Red Hat subscription is required.
  • Genuine RHEL Parent Image: use a Red Hat parent AMI, an entitled Red Hat content source, and Red Hat signing keys. The customer supplies the Red Hat subscription and content-access integration.

Note: The reference implementation only provides AlmaLinux lineage setup, not genuine RHEL. If you choose to use a genuine RHEL parent image lineage, only the reference implementation code needs to be updated to fetch the Red Hat credentials or subscription access, and the rest of the workflow remains the same.

Please follow the repository README for detailed setup instructions:

  1. Fill in environments/config.hcl and both account files with the two accounts, networking, mirror certificate, package lineage, and parent AMI.
  2. Create the Terraform state backend with make bootstrap DIST_PROFILE=<dist> WORK_PROFILE=<work>.
  3. Review both account plans with make plan DIST_PROFILE=<dist> WORK_PROFILE=<work>.
  4. Deploy in dependency order with make all BASELINE_APPROVED=true DIST_PROFILE=<dist> WORK_PROFILE=<work>. The baseline sync can take several hours.

Validate the internal package management workflow

Validation begins by running the AlmaLinux EC2 Image Builder pipeline. A successful build produces private, encrypted AMIs in the configured AWS Regions. To validate the configuration, launch a test instance from the generated AMI in a no-egress Workload subnet and verify that the instance is connected to the internal frozen repository for all package management workflow.

Terminal output listing only the internal frozen-baseos, frozen-appstream, and frozen-epel repositories enabled, with dnf makecache downloading metadata through the private mirror

Figure 4: Instance showing only the internal frozen repositories enabled, with no public repository configured

The output confirms that only the internal frozen AlmaLinux repositories are enabled: frozen-baseos, frozen-appstream, and frozen-epel. The dnf makecache command successfully downloads metadata for all three repositories through the private mirror. No public repository is configured or used.

Now try installing, upgrading, or installing a new package to test that package operations are served by the internal frozen repository.

Terminal output showing a package install and upgrade completing successfully through the internal frozen repository mirror

Figure 5: Package install and upgrade served by the internal frozen repository

  • Fail closed on approval data. If the approved package list cannot be retrieved, stop the sync task and avoid substituting a full sync.
  • Govern the initial baseline. Record who authorized the bootstrap full sync, or require explicit review of its manifest before promotion.
  • Require vendor signatures at ingestion. Do not treat a valid package digest as equivalent to a trusted signature.
  • Keep package lineages consistent. Parent AMI, repository content, and signing keys must come from the same distribution lineage.
  • Use a customer-defined review cadence. Monthly is only the sample default.
  • Use immutable dependency references with active updates. Require aws-sigv4-proxy v1.12 or later, pin the reviewed artifact by digest or full SHA, and automate update proposals.
  • Test rollback as a repository operation. Restore metadata and objects together, then validate the mirror before using the restored state.

Clean up

The walkthrough deploys billable resources in both accounts. Please follow the repository README for detailed setup cleanup instructions.

Conclusion

This pattern separates connected package ingestion from an air-gapped fleet, provides an authorized package baseline and an explicit decision point for later package changes or upgrades, and keeps image builds and running hosts on one frozen repository snapshot. To learn more, visit the EC2 Image Builder service page, the EC2 Image Builder documentation, the Patch Manager documentation, and the Amazon S3 user guide. The reference implementation is available in aws-samples.
