All posts by Ashley Whittaker

Raspberry Pi enables world’s smallest iMac

Post Syndicated from Ashley Whittaker original https://www.raspberrypi.org/blog/raspberry-pi-enables-worlds-smallest-imac/

This project goes a step further than most custom-made Raspberry Pi cases: YouTuber Michael Pick hacked a Raspberry Pi 4 and stuffed it inside this Apple lookalike to create the world’s smallest ‘iMac’.

Michael designed and 3D printed this miniature ‘iMac’ with what he calls a “gently modified” Raspberry Pi 4 at the heart. Everything you see is hand-painted and -finished to achieve an authentic, sleek Apple look.

This is “gentle modification” we just mentioned

Even after all that power tool sparking, this miniature device is capable of playing Minecraft at 1000 frames per second. Michael was set on making the finished project as thin as possible, so he had to slice off a couple of his Raspberry Pi’s USB ports and the Ethernet socket to make everything fit inside the tiny, custom-made case. This hacked setup leaves you with Bluetooth and wireless internet connections, which, as Michael explains in the build video, “if you’re a Mac user, that’s all you’re ever going to need.”

We love watching 3D printer footage set to relaxed elevator music

This teeny yet impactful project has even been featured on forbes.com, and that’s where we learned how the tightly packed tech manages to work in such a restricted space:

“A wireless dongle is plugged into one of the remaining USB ports to ensure it’s capable of connecting to a wireless keyboard and mouse, and a low-profile ribbon cable is used to connect the display to the Raspberry Pi. Careful crimping of cables and adapters ensures the mini iMac can be powered from a USB-C extension cable that feeds in under the screen, while the device also includes a single USB 2 port.”

Barry Collins | forbes.com

The maker also told forbes.com that this build was inspired by an iRaspbian software article from tech writer Barry Collins. iRaspbian puts a Mac-like interface — including Dock, Launcher and even the default macOS wallpaper — on top of a Linux distro. We guess Michael just wanted the case to match the content, hey?

Check out Michael’s YouTube channel for more inexplicably cool builds, such as a one billion volt Thor hammer.

The post Raspberry Pi enables world’s smallest iMac appeared first on Raspberry Pi.

Global sunrise/sunset Raspberry Pi art installation

Post Syndicated from Ashley Whittaker original https://www.raspberrypi.org/blog/global-sunrise-sunset-raspberry-pi-art-installation/

24h Sunrise/Sunset is a digital art installation that displays a live sunset and sunrise happening somewhere in the world with the use of CCTV.

Image by fotoswiss.com

Artist Dries Depoorter wanted to prove that “CCTV cameras can show something beautiful”, and turned to Raspberry Pi to power this global project.

Image by fotoswiss.com

Harnessing CCTV

The arresting visuals are beamed to viewers using two Raspberry Pi 3B+ computers and an Arduino Nano Every that stream internet protocol (IP) cameras with the use of command line media player OMXPlayer.

Dual Raspberry Pi power

The two Raspberry Pis communicate with each other using the MQTT protocol — a standard messaging protocol for the Internet of Things (IoT) that’s ideal for connecting remote devices with a small code footprint and minimal network bandwidth.

One of the Raspberry Pis checks at which location in the world a sunrise or sunset is happening and streams the closest CCTV camera.

The insides of the sleek display screen…

Beam me out, Scotty

The big screens are connected with the I2C protocol to the Arduino, and the Arduino is connected serial with the second Raspberry Pi. Dries also made a custom printed circuit board (PCB) so the build looks cleaner.

All that hardware is powered by an industrial power supply, just because Dries liked the style of it.

Software

Everything is written in Python 3, and Dries harnessed the Python 3 libraries BeautifulSoup, Sun, Geopy, and Pytz to calculate sunrise and sunset times at specific locations. Google Firebase databases in the cloud help with admin by way of saving timestamps and the IP addresses of the cameras.

Hardware

The artist stood infront of the two large display screens
Image of the artist with his work by fotoswiss.com

And, lastly, Dries requested a shoutout for his favourite local Raspberry Pi shop Gotron in Ghent.

The post Global sunrise/sunset Raspberry Pi art installation appeared first on Raspberry Pi.

What the blink is my IP address?

Post Syndicated from Ashley Whittaker original https://www.raspberrypi.org/blog/what-the-blink-is-my-ip-address/

Picture the scene: you have a Raspberry Pi configured to run on your network, you power it up headless (without a monitor), and now you need to know which IP address it was assigned.

Matthias came up with this solution, which makes your Raspberry Pi blink its IP address, because he used a Raspberry Pi Zero W headless for most of his projects and got bored with having to look it up with his DHCP server or hunt for it by pinging different IP addresses.

How does it work?

A script runs when you start your Raspberry Pi and indicates which IP address is assigned to it by blinking it out on the device’s LED. The script comprises about 100 lines of Python, and you can get it on GitHub.

A screen running Python
Easy peasy GitHub breezy

The power/status LED on the edge of the Raspberry Pi blinks numbers in a Roman numeral-like scheme. You can tell which number it’s blinking based on the length of the blink and the gaps between each blink, rather than, for example, having to count nine blinks for a number nine.

Blinking in Roman numerals

Short, fast blinks represent the numbers one to four, depending on how many short, fast blinks you see. A gap between short, fast blinks means the LED is about to blink the next digit of the IP address, and a longer blink represents the number five. So reading the combination of short and long blinks will give you your device’s IP address.

You can see this in action at this exact point in the video. You’ll see the LED blink fast once, then leave a gap, blink fast once again, then leave a gap, then blink fast twice. That means the device’s IP address ends in 112.

What are octets?

Luckily, you usually only need to know the last three numbers of the IP address (the last octet), as the previous octets will almost always be the same for all other computers on the LAN.

The script blinks out the last octet ten times, to give you plenty of chances to read it. Then it returns the LED to its default functionality.

Which LED on which Raspberry Pi?

On a Raspberry Pi Zero W, the script uses the green status/power LED, and on other Raspberry Pis it uses the green LED next to the red power LED.

The green LED blinking the IP address (the red power LED is slightly hidden by Matthias’ thumb)

Once you get the hang of the Morse code-like blinking style, this is a really nice quick solution to find your device’s IP address and get on with your project.

The post What the blink is my IP address? appeared first on Raspberry Pi.

Turn a watermelon into a RetroPie games console

Post Syndicated from Ashley Whittaker original https://www.raspberrypi.org/blog/turn-a-watermelon-into-a-retropie-games-console/

OK Cedrick, we don’t need to know why, but we have to know how you turned a watermelon into a games console.

This has got to be a world first. What started out as a regular RetroPie project has blown up reddit due to the unusual choice of casing for the games console: nearly 50,000 redditors upvoted this build within a week of Cedrick sharing it.

See, we’re not kidding

What’s inside?

  • Raspberry Pi 3
  • Jingo Dot power bank (that yellow thing you can see below)
  • Speakers
  • Buttons
  • Small 1.8″ screen
Cedric’s giggling really makes this video

Retropie

While this build looks epic, it isn’t too tricky to make. First, Cedrick flashed the RetroPie image onto an SD card, then he wired up a Raspberry Pi’s GPIO pins to the red console buttons, speakers, and the screen.

Cedrick achieved audio output by adding just a few lines of code to the config file, and he downloaded libraries for screen configuration and button input. That’s it! That’s all you need to get a games console up and running.

Cedrick just hanging on the train with his WaterBoy

Now for the messy bit

Cedrick had to gut an entire watermelon before he could start getting all the hardware in place. He power-drilled holes for the buttons to stick through, and a Stanley knife provided the precision he needed to get the right-sized gap for the screen.

A gutted watermelon with gaps cut to fit games console buttons and a screen

Rather than drill even more holes for the speakers, Cedrick stuck them in place inside the watermelon using toothpicks. He did try hot glue first but… yeah. Turns out fruit guts are impervious to glue.

Moisture was going to be a huge problem, so to protect all the hardware from the watermelon’s sticky insides, Cedric lined it with plastic clingfilm.

Infinite lives

And here’s how you can help: Cedrick is open to any tips as to how to preserve the perishable element of his project: the watermelon. Resin? Vaseline? Time machine? How can he keep the watermelon fresh?

Share your ideas on reddit or YouTube, and remember to subscribe to see more of Cedric’s maverick making in the wild.

The post Turn a watermelon into a RetroPie games console appeared first on Raspberry Pi.

It’s a brand-new NODE Mini Server!

Post Syndicated from Ashley Whittaker original https://www.raspberrypi.org/blog/its-a-brand-new-node-mini-server/

NODE has long been working to create open-source resources to help more people harness the decentralised internet, and their easily 3D-printed designs are perfect to optimise your Raspberry Pi.

NODE wanted to take advantage of the faster processor and up to 8GB RAM on Raspberry Pi 4 when it came out last year. Now that our tiny computer is more than capable of being used as as a general Linux desktop system, the NODE Mini Server version 3 has been born.

As for previous versions of NODE’s Mini Server, one of their main goals for this new iteration was to package Raspberry Pi in a way which makes it a little easier to use as a regular mini server or computer. In other words, it’s put inside a neat little box with all the ports accessible on one side.

Black is incredibly slimming

Slimmer and simpler

The latest design is simplified compared to previous versions. Everything lives in a 92mm × 92mm enclosure that isn’t much thicker than Raspberry Pi itself.

The slimmed-down new case comprises a single 3D-printed piece and a top cover made from a custom-designed printed circuit board (PCB) that has four brass-threaded inserts soldered into the corners, giving you a simple way to screw everything together.

The custom PCB cover

What are the new features?

Another goal for version 3 NODE’s Mini Server was to include as much modularity as possible. That’s why this new mini server requires no modifications to the Raspberry Pi itself, thanks to a range of custom-designed adapter boards. How to take advantage of all these new features is explained at this point in NODE’s YouTube video.

Ooh, shiny and new and new and shiny

Just like for previous versions, all the files and a list of the components you need to create your own Mini Server are available for free on the NODE website.

Leave comments on NODE’s YouTube video if you’d like to create and sell your own Mini Server kits or pre-made servers. NODE is totally open to showcasing any add-ons or extras you come up with yourself.

Looking ahead, making the Mini Server stackable and improving fan circulation is next on NODE’s agenda.

The post It’s a brand-new NODE Mini Server! appeared first on Raspberry Pi.

Give your voice assistant a retro Raspberry Pi makeover

Post Syndicated from Ashley Whittaker original https://www.raspberrypi.org/blog/give-your-voice-assistant-a-retro-raspberry-pi-makeover/

Do you feel weird asking the weather or seeking advice from a faceless device? Would you feel better about talking to a classic 1978 2-XL educational robot from Mego Corporation? Matt over at element14 Community, where tons of interesting stuff happens, has got your back.

Watch Matt explain how the 2-XL toy robot worked before he started tinkering with it. This robot works with Google Assistant on a Raspberry Pi, and answers to a custom wake word.

Kit list

Our recent blog about repurposing a Furby as a voice assistant device would have excited Noughties kids, but this one is mostly for our beautiful 1970s- and 1980s-born fanbase.

Time travel

2-XL, Wikipedia tells us, is considered the first “smart toy”, marketed way back in 1978, and exhibiting “rudimentary intelligence, memory, gameplay, and responsiveness”. 2-XL had a personality that kept kids’ attention, telling jokes and offering verbal support as they learned.

Teardown

Delve under the robot’s armour to see how the toy was built, understand the basic working mechanism, and watch Matt attempt to diagnose why his 2-XL is not working.

Setting up Google Assistant

The Matrix Creator daughter board mentioned in the kit list is an ideal platform for developing your own AI assistant. It’s the daughter board’s 8-microphone array that makes it so brilliant for this task. Learn how to set up Google Assistant on the Matrix board in this video.

What if you don’t want to wake your retrofit voice assistant in the same way as all the other less dedicated users, the ones who didn’t spend hours of love and care refurbishing an old device? Instead of having your homemade voice assistant answer to “OK Google” or “Alexa”, you can train it to recognise a phrase of your choice. In this tutorial, Matt shows you how to set up a custom wake word with your voice assistant, using word detection software called Snowboy.

Keep an eye on element14 on YouTube for the next instalment of this excellent retrofit project.

The post Give your voice assistant a retro Raspberry Pi makeover appeared first on Raspberry Pi.

Nandu’s lockdown Raspberry Pi robot project

Post Syndicated from Ashley Whittaker original https://www.raspberrypi.org/blog/nandus-lockdown-raspberry-pi-robot-project/

Nandu Vadakkath was inspired by a line-following robot built (literally) entirely from salvage materials that could wait patiently and purchase beer for its maker in Tamil Nadu, India. So he set about making his own, but with the goal of making it capable of slightly more sophisticated tasks.

“Robot, can you play a song?”

Hardware

Robot comes when called, and recognises you as its special human

Software

Nandu had ambitious plans for his robot: navigation, speech and listening, recognition, and much more were on the list of things he wanted it to do. And in order to make it do everything he wanted, he incorporated a lot of software, including:

Robot shares Nandu’s astrological chart
  • Python 3
  • virtualenv, a tool for creating isolating virtual Python environments
  • the OpenCV open source computer vision library
  • the spaCy open source natural language processing library
  • the TensorFlow open source machine learning platform
  • Haar cascade algorithms for object detection
  • A ResNet neural network with the COCO dataset for object detection
  • DeepSpeech, an open source speech-to-text engine
  • eSpeak NG, an open source speech synthesiser
  • The MySQL database service

So how did Nandu go about trying to make the robot do some of the things on his wishlist?

Context and intents engine

The engine uses spaCy to analyse sentences, classify all the elements it identifies, and store all this information in a MySQL database. When the robot encounters a sentence with a series of possible corresponding actions, it weighs them to see what the most likely context is, based on sentences it has previously encountered.

Getting to know you

The robot has been trained to follow Nandu around but it can get to know other people too. When it meets a new person, it takes a series of photos and processes them in the background, so it learns to remember them.

Nandu's home made robot
There she blows!

Speech

Nandu didn’t like the thought of a basic robotic voice, so he searched high and low until he came across the MBROLA UK English voice. Have a listen in the videos above!

Object and people detection

The robot has an excellent group photo function: it looks for a person, calculates the distance between the top of their head and the top of the frame, then tilts the camera until this distance is about 60 pixels. This is a lot more effort than some human photographers put into getting all of everyone’s heads into the frame.

Nandu has created a YouTube channel for his robot companion, so be sure to keep up with its progress!

The post Nandu’s lockdown Raspberry Pi robot project appeared first on Raspberry Pi.

Raspberry Pi retro player

Post Syndicated from Ashley Whittaker original https://www.raspberrypi.org/blog/raspberry-pi-retro-player/

We found this project at TeCoEd and we loved the combination of an OLED display housed inside a retro Argus slide viewer. It uses a Raspberry Pi 3 with Python and OpenCV to pull out single frames from a video and write them to the display in real time.​

TeCoEd names this creation the Raspberry Pi Retro Player, or RPRP, or -- rather neatly -- RP squared. The Argus viewer, he tells us, was a charity-shop find that cost just 50p.  It sat collecting dust for a few years until he came across an OLED setup guide on hackster.io, which inspired the birth of the RPRP.

Timelapse of the build and walk-through of the code

At the heart of the project is a Raspberry Pi 3 which is running a Python program that uses the OpenCV computer vision library.  The code takes a video clip and breaks it down into individual frames. Then it resizes each frame and converts it to black and white, before writing it to the OLED display. The viewer sees the video play in pleasingly retro monochrome on the slide viewer.

Tiny but cute, like us!

TeCoEd ran into some frustrating problems with the OLED display, which, he discovered, uses the SH1106 driver, rather than the standard SH1306 driver that the Adafruit CircuitPython library expects. Many OLED displays use the SH1306 driver, but it turns out that cheaper displays like the one in this project use the SH1106. He has made a video to spare other makers this particular throw-it-all-in-the-bin moment.

Tutorial for using the SH1106 driver for cheap OLED displays

If you’d like to try this build for yourself, here’s all the code and setup advice on GitHub.

Wiring diagram

TeCoEd is, as ever, our favourite kind of maker -- the sharing kind! He has collated everything you’ll need to get to grips with OpenCV, connecting the SH1106 OLED screen over I2C, and more. He’s even told us where we can buy the OLED board.

The post Raspberry Pi retro player appeared first on Raspberry Pi.

Raspberry Pi + Furby = ‘Furlexa’ voice assistant

Post Syndicated from Ashley Whittaker original https://www.raspberrypi.org/blog/raspberry-pi-furby-furlexa-voice-assistant/

How can you turn a redundant, furry, slightly annoying tech pet into a useful home assistant? Zach took to howchoo to show you how to combine a Raspberry Pi Zero W with Amazon’s Alexa Voice Service software and a Furby to create Furlexa.

Furby was pretty impressive technology, considering that it’s over 20 years old. It could learn to speak English, sort of, by listening to humans. It communicated with other Furbies via infrared sensor. It even slept when its light sensor registered that it was dark.

Furby innards, exploded

Zach explains why Furby is so easy to hack:

Furby is comprised of a few primary components — a microprocessor, infrared and light sensors, microphone, speaker, and — most impressively — a single motor that uses an elaborate system of gears and cams to drive Furby’s ears, eyes, mouth and rocker. A cam position sensor (switch) tells the microprocessor what position the cam system is in. By driving the motor at varying speeds and directions and by tracking the cam position, the microprocessor can tell Furby to dance, sing, sleep, or whatever.

The original CPU and related circuitry were replaced with a Raspberry Pi Zero W

Zach continues: “Though the microprocessor isn’t worth messing around with (it’s buried inside a blob of resin to protect the IP), it would be easy to install a small Raspberry Pi computer inside of Furby, use it to run Alexa, and then track Alexa’s output to make Furby move.”

What you’ll need:

Harrowing

Running Alexa

The Raspberry Pi is running Alexa Voice Service (AVS) to provide full Amazon Echo functionality. Amazon AVS doesn’t officially support the tiny Raspberry Pi Zero, so lots of hacking was required. Point 10 on Zach’s original project walkthrough explains how to get AVS working with the Pimoroni Speaker pHAT.

Animating Furby

A small motor driver board is connected to the Raspberry Pi’s GPIO pins, and controls Furby’s original DC motor and gearbox: when Alexa speaks, so does Furby. The Raspberry Pi Zero can’t supply enough juice to power the motor, so instead, it’s powered by Furby’s original battery pack.

Software

There are three key pieces of software that make Furlexa possible:

  1. Amazon Alexa on Raspberry Pi -- there are tonnes of tutorials showing you how to get Amazon Alexa up and running on your Raspberry Pi. Try this one on instructables.
  2. A script to control Furby’s motor -- howchooer Tyler wrote the Python script that Zach is using to drive the motor, and you can copy and paste it from Zach’s howchoo walkthrough.
  3. A script that detects when Alexa is speaking and calls the motor program -- Furby detects when Alexa is speaking by monitoring the contents of a file whose contents change when audio is being output. Zach has written a separate guide for driving a DC motor based on Linux sound output.
Teeny tiny living space

The real challenge was cramming the Raspberry Pi Zero plus the Speaker pHAT, the motor controller board, and all the wiring back inside Furby, where space is at a premium. Soldering wires directly to the GPIO saved a bit of room, and foam tape holds everything above together nice and tightly. It’s a squeeze!

Zach is a maker extraordinaire, so check out his projects page on howchoo.

The post Raspberry Pi + Furby = ‘Furlexa’ voice assistant appeared first on Raspberry Pi.

Self-driving trash can controlled by Raspberry Pi

Post Syndicated from Ashley Whittaker original https://www.raspberrypi.org/blog/self-driving-trash-can-controlled-by-raspberry-pi/

YouTuber extraordinaire Ahad Cove HATES taking out the rubbish, so he decided to hack a rubbish bin/trash can -- let’s go with trash can from now on -- to take itself out to be picked up.

Sounds simple enough? The catch is that Ahad wanted to create an AI that can see when the garbage truck is approaching his house and trigger the garage door to open, then tell the trash can to drive itself out and stop in the right place. This way, Ahad doesn’t need to wake up early enough to spot the truck and manually trigger the trash can to drive itself.

Hardware

The trash can’s original wheels weren’t enough on their own, so Ahad brought in an electronic scooter wheel with a hub motor, powered by a 36V lithium ion battery, to guide and pull them. Check out this part of the video to hear how tricky it was for Ahad to install a braking system using a very strong servo motor.

The new wheel sits at the front of the trash can and drags the original wheels at the back along with

An affordable driver board controls the speed, power, and braking system of the garbage can.

The driver board

Tying everything together is a Raspberry Pi 3B+. Ahad uses one of the GPIO pins on the Raspberry Pi to send the signal to the driver board. He started off the project with a Raspberry Pi Zero W, but found that it was too fiddly to get it to handle the crazy braking power needed to stop the garbage can on his sloped driveway.

The Raspberry Pi Zero W, which ended up getting replaced in an upgrade

Everything is kept together and dry with a plastic snap-close food container Ahad lifted from his wife’s kitchen collection. Ssh, don’t tell.

Software

Ahad uses an object detection machine learning model to spot when the garbage truck passes his house. He handles this part of the project with an Nvidia Jetson Xavier NX board, connected to a webcam positioned to look out of the window watching for garbage trucks.

Object detected!

Opening the garage door

Ahad’s garage door has a wireless internet connection, so he connected the door to an app that communicates with his home assistant device. The app opens the garage door when the webcam and object detection software see the garbage truck turning into his street. All this works with the kit inside the trash can to get it to drive itself out to the end of Ahad’s driveway.

There she goes! (With her homemade paparazzi setup behind her)

Check out the end of Ahad’s YouTube video to see how human error managed to put a comical damper on the maiden voyage of this epic build.

The post Self-driving trash can controlled by Raspberry Pi appeared first on Raspberry Pi.

Boston Dynamics’ Handle robot recreated with Raspberry Pi

Post Syndicated from Ashley Whittaker original https://www.raspberrypi.org/blog/boston-dynamics-handle-robot-recreated-with-raspberry-pi/

You in the community seemed so impressed with this recent Boston Dynamics–inspired build that we decided to feature another. This time, maker Harry was inspired by Boston Dynamics’ research robot Handle, which stands 6.5 ft tall, travels at 9 mph and jumps 4​ ​feet vertically. Here’s how Harry made his miniature version, MABEL (Multi Axis Balancer Electronically Levelled).

MABEL has individually articulated legs to enhance off-road stability, prevent it from tipping, and even make it jump (if you use some really fast servos). Harry is certain that anyone with a 3D printer and a “few bits” can build one.

MABEL builds on the open-source YABR project for its PID controller, and it’s got added servos and a Raspberry Pi that helps interface them and control everything.

Installing MABEL’s Raspberry Pi brain and wiring the servos

Thanks to a program based on the open-source YABR firmware, an Arduino handles all of the PID calculations using data from an MPU-6050 accelerometer/gyro. Raspberry Pi, using Python code, manages Bluetooth and servo control, running an inverse kinematics algorithm to translate the robot legs perfectly in two axes.

Kit list

If you want to attempt this project yourself, the files for all the hard 3D-printed bits are on Thingiverse, and all the soft insides are on GitHub.

IKSolve is the class that handles the inverse kinematics functionality for MABEL (IKSolve.py) and allows for the legs to be translated using (x, y) coordinates. It’s really simple to use: all that you need to specify are the home values of each servo (these are the angles that, when passed over to your servos, make the legs point directly and straight downwards at 90 degrees).

When MABEL was just a twinkle in Harry’s eye

MABEL is designed to work by listening to commands on the Arduino (PID contoller) end that are sent to it by Raspberry Pi over serial using pySerial. Joystick data is sent to Raspberry Pi using the Input Python library. Harry first tried to get the joystick data from an old PlayStation 3 controller, but went with the PiHut’s Raspberry Pi Compatible Wireless Gamepad in the end for ease.

Keep up with Harry’s blog or give Raspibotics a follow on Twitter, as part 3 of his build write-up should be dropping imminently, featuring updates that will hopefully get MABEL jumping!

The post Boston Dynamics’ Handle robot recreated with Raspberry Pi appeared first on Raspberry Pi.

Raspberry Pi listening posts ‘hear’ the Borneo rainforest

Post Syndicated from Ashley Whittaker original https://www.raspberrypi.org/blog/raspberry-pi-listening-posts-hear-the-borneo-rainforest/

These award-winning, solar-powered audio recorders, built on Raspberry Pi, have been installed in the Borneo rainforest so researchers can listen to the local ecosystem 24/7. The health of a forest ecosystem can often be gaged according to how much noise it creates, as this signals how many species are around.

And you can listen to the rainforest too! The SAFE Acoustics website, funded by the World Wide Fund for Nature (WWF), streams audio from recorders placed around a region of the Bornean rainforest in Southeast Asia. Visitors can listen to live audio or skip back through the day’s recording, for example to listen to the dawn chorus.

Listen in on the Imperial College podcast

What’s inside?

We borrowed this image of the flux tower from Sarab Sethi’s site

The device records data in the field and uploads it to a central server continuously and robustly over long time-periods. And it was built for around $305.

Here’s all the code for the platform, on GitHub.

The 12V-to-5V micro USB converter to the power socket of the Anker USB hub, which is connected to Raspberry Pi.

The Imperial College London team behind the project has provided really good step-by-step photo instructions for anyone interested in the fine details.

Here’s the full set up in the field. The Raspberry Pi-powered brains of the kit are safely inside the green box

The recorders have been installed by Imperial College London researchers as part of the SAFE Project – one of the largest ecological experiments in the world.

Screenshot of the SAFE Project website

Dr Sarab Sethi designed the audio recorders with Dr Lorenzo Picinali. They wanted to quantify the changes in rainforest soundscape as land use changes, for example when forests are logged. Sarab is currently working on algorithms to analyse the gathered data with Dr Nick Jones from the Department of Mathematics.

The lovely cross-disciplinary research team based at Imperial College London

Let the creators of the project tell you more on the Imperial College London website.

The post Raspberry Pi listening posts ‘hear’ the Borneo rainforest appeared first on Raspberry Pi.

Raspberry Pi Off-World Bartender

Post Syndicated from Ashley Whittaker original https://www.raspberrypi.org/blog/raspberry-pi-off-world-bartender/

Three things we like: Blade Runner, robots, and cocktails. That’s why we LOVE Donald Bell‘s Raspberry Pi–packed ‘VK-01 Off-World Bartender‘ cocktail making machine.

This machine was due to be Donald’s entry into the Cocktail Robotics Grand Challenge, an annual event in San Francisco. By the time the event was cancelled, he was too deep into his awesome build to give up, so he decided to share it with the Instructables community instead.

Donald wanted users to get as much interaction and feedback as possible, rather than simply pressing a button and receiving a random drink. So with this machine, the interaction comes in four ways: instructions provided on the screen, using a key card to bypass security, placing and removing a cup on the tray, and entering an order number on the keypad.

In addition to that, feedback is provided by way of lighting changes, music, video dialogue, pump motors whirring, and even the clicks of relays at each stage of the cocktail making process.

Ordering on the keypad

close up of the black keypad

The keypad allows people to punch in a number to trigger their order, like on a vending machine. The drink order is sent to the Hello Drinkbot software running on the Raspberry Pi 3B that controls the pumps.

Getting your cup filled

Inside the cup dispenser sensor showing the switch and LEDs
The switch under the lid and ring of LEDs on the base

In order for the machine to be able to tell when a vessel is placed under the dispenser spout, and when it’s removed, Donald built in a switch under a 3D-printed tray. Provided the vessel has at least one ice cube in it, even the lightest plastic up is heavy enough to trigger the switch.

The RFID card reader

Cocktail machine customers are asked to scan a special ID card to start. To make this work, Donald adapted a sample script that blinks the card reader’s internal LED when any RFID card is detected.

Interactive video screen

close up of the interactive screen on the machine showing Japanese style script

This bit is made possible by MP4Museum, a “bare-bones” kiosk video player software that the second Raspberry Pi inside the machine runs on boot. By connecting a switch to the Raspberry Pi’s GPIO, Donald enabled customers to advance through the videos one by one. And yes, that’s an official Raspberry Pi Touch Display.

Behind the scenes of the interactive screen with the Raspberry Pi wired up
Behind the scenes of the screen with the Raspberry Pi A+ running the show

The Hello Drinkbot ‘bartender’

screen grab of the hello drinkbot web interface

Donald used the Python-based Hello Drinkbot software as the brains of the machine. With it, you can configure which liquors or juices are connected to which pumps, and send instructions on exactly how much to pour of each ingredient. Everything is configured via a web interface.

Via a bank of relays, microcontrollers connect all the signals from the Touch Display, keypad, RFID card reader, and switch under the spout.

Here’s the Fritzing diagram for this beast

Supplies

Donald shared an exhaustive kit list on his original post, but basically, what you’re looking at is…

Pencil sketches of the machine from different angles
Donald’s friend Jim Burke‘s beautiful concept sketches

And finally, check out the Raspberry Pi–based Hello Drinkbot project by Rich Gibson, which inspired Donald’s build.

The post Raspberry Pi Off-World Bartender appeared first on Raspberry Pi.

Steampunk ‘Help is coming’ Raspberry Pi alert system

Post Syndicated from Ashley Whittaker original https://www.raspberrypi.org/blog/steampunk-help-is-coming-raspberry-pi-alert-system/

Tom Lee decided to combine his household with his sister-in-law during lockdown so that she could help him make childcare more manageable. The problem was, Tom’s household was a smidge frantic in the mornings, as the family struggled to be up and ready in time for his sister-in-law’s arrival.

Enter this Raspberry Pi–powered tracking device, which tells Tom when the family car is on its way with childcare support. The DIY appliance helps his household manage childcare routines like clockwork.

The magic is in the wooden box, but the light cage and electrical meter are all part of the show

When the family car is moving, a light turns on, and an antique electrical meter points to 30…20…10 to show the estimated minutes until the driver arrives. The movements of the car come in from a cellular Sinotrack OBD2 dongle pointed at a traccar server running on Raspberry Pi 3.

We see you in there, Raspberry Pi…

Tom explains: “I have not found traccar to be the greatest to work with, but you can make it forward everything it decodes to your own script pretty easily.”

Materials:

  • Arduino microcontrollers (ATMega328P & ESP8266 based)
  • Raspberry Pi (Model 1 and 3)
  • Dongle device in car (with SIM card and cellular service)
  • Light device with bulb and solid state relay
  • Antique electrical meter (for the steampunks among you – any similar device will do the job!)
The light safety cage was rescued from an old workshop

The case (below) is a lasercut design Tom had made by online laser cutting business Ponoko.

Inside there’s a solid state relay and a first-generation Raspberry Pi (hidden under the black cable in the photo below). This Raspberry Pi model doesn’t have wireless connectivity, and Tom found that getting wireless working was a bit tricky for this project.

Tom produced a nice long webinar to show you exactly how this all works. So if you’d like to give this project a try, watch it for yourself.

You’ll learn how to…

Code resources

Oh, and he’s only gone and uploaded every single bit of code you’ll need on GitHub (what an angel):

The post Steampunk ‘Help is coming’ Raspberry Pi alert system appeared first on Raspberry Pi.

Teaching pigeons with Raspberry Pi

Post Syndicated from Ashley Whittaker original https://www.raspberrypi.org/blog/teaching-pigeons-with-raspberry-pi/

It’s been a long lockdown for one of our favourite makers, Pi & Chips. Like most of us (probably), they have turned their hand to training small animals that wander into their garden to pass the time — in this case, pigeons. I myself enjoy raising my glass to the squirrel that runs along my back fence every evening at 7pm.

Of course, Pi & Chips has taken this one step further and created a food dispenser including motion-activated camera with a Raspberry Pi 3B+ to test the intelligence of these garden critters and capture their efforts live.

Bird behaviour

Looking into the cognitive behaviour of birds (and finding the brilliantly titled paper Maladaptive gambling by pigeons), Pi & Chips discovered that pigeons can, with practice, recognise objects including buttons and then make the mental leap to realise that touching these buttons actually results in something happening. So they set about building a project to see this in action.

Enter the ‘SmartFrank 3000’, named after the bossiest bird to grace Pi & Chips’s shed roof over the summer.

Steppers and servos

The build itself is a simple combo of a switch and dispenser. But it quickly became apparent that any old servo wasn’t going to be up to the job — it couldn’t move fast enough to open and close a hatch quickly or strongly enough.

The motor setup

Running a few tests with a stepper motor confirmed that this was the perfect choice, as it could move quickly enough, and was strong enough to hold back a fair weight of seed when not in operation.

It took a while to get the timing on the stepper just right to give a pretty consistent delivery of the seed…

A 3D-printed flap for the stepper was also fashioned, plus a nozzle that fits over the neck of a two-litre drinks bottle, and some laser-cut pieces to make a frame to hold it all together.

The switch

Now for the switch that Frank the pigeon was going to have to touch if it wanted any bird seed. Pi & Chips came up with this design made from 3mm ply and some sponge as the spring.

They soldered some wires to a spring clip from an old photo frame and added a bolt and two nuts. The second nut allowed very fine adjustment of the distance to make sure the switch could be triggered by as light a touch as possible.

Behind the scenes

Behind the scenes setup

Behind the scenes there’s a Raspberry Pi 3B+ running the show, together with a motor controller board for the stepper motor. This board runs from its own battery pack, as it needs 12V power and is therefore too heavy for Raspberry Pi to handle directly. A Raspberry Pi Camera Module has also been added and runs this motion detection script to start recording whenever a likely bird candidate steps up to the plate for dinner. Hopefully, we can soon get some footage of Frank the pigeon learning and earning!

The post Teaching pigeons with Raspberry Pi appeared first on Raspberry Pi.

Remote teams ring office bell with Raspberry Pi and Slack

Post Syndicated from Ashley Whittaker original https://www.raspberrypi.org/blog/remote-teams-ring-office-bell-with-raspberry-pi-and-slack/

Bustling offices… remember those? It feels like we’ve all been working from home forever, and it’s going to be a while yet before everyone is back at their desks in the same place. And when that does happen, if your workplace is anything like Raspberry Pi Towers, there will still be lots of people in your team who are based in different countries or have always worked from home.

This office bell, built by a person called Alex, is powered by a Raspberry Pi 3B+ and is linked to Slack, so when a milestone or achievement is announced on the chat platform by a remote team member, they get to experience ringing the office bell for themselves, no matter where in the world they are working from.

Kit list:

Close-up of the servo wired to the Raspberry Pi pins

Integrating with Slack

To get the Raspberry Pi talking to Slack, Alex used the slackclient module (Python 3.6+ only), which makes use of the Slack Real Time Messaging (RTM) API. This is a websocket-based API that allows you to receive events from Slack in real time and send messages as users.

With the Slack RTM API, you create an RTM client and register a callback function that the client executes every time a specific Slack event occurs. When staff tell the @pibot on Slack it’s ‘belltime’, the Raspberry Pi tells the servo to ring the bell in the office.

Alex also configured it to always respond with an emoji reaction when someone successfully rings the bell, so remote employees get some actual feedback that it worked. Here’s the script for that bit.

Alex also figured out how to get around WiFi connectivity drops: they created a cronjob that runs a bash script every 15 minutes to check if the bell ringer is running. If it isn’t running, the bash script starts it.

At the end of Alex’s original post, they’ve concluded that using a HAT would allow for more control of the servo and avoid frying the Raspberry Pi. They also cleaned up their set-up recently and switched the Raspberry Pi 3B+ out for a Raspberry Pi Zero, which is perfectly capable of this simple job.

The post Remote teams ring office bell with Raspberry Pi and Slack appeared first on Raspberry Pi.

Mini Raspberry Pi Boston Dynamics–inspired robot

Post Syndicated from Ashley Whittaker original https://www.raspberrypi.org/blog/mini-raspberry-pi-boston-dynamics-inspired-robot/

This is a ‘Spot Micro’ walking quadruped robot running on Raspberry Pi 3B. By building this project, redditor /thetrueonion (aka Mike) wanted to teach themself robotic software development in C++ and Python, get the robot walking, and master velocity and directional control.

Mike was inspired by Spot, one of Boston Dynamics’ robots developed for industry to perform remote operation and autonomous sensing.

What’s it made of?

  • Raspberry Pi 3B
  • Servo control board: PCA9685, controlled via I2C
  • Servos: 12 × PDI-HV5523MG
  • LCD Panel: 16×2 I2C LCD panel
  • Battery: 2s 4000 mAh LiPo, direct connection to power servos
  • UBEC: HKU5 5V/5A ubec, used as 5V voltage regulator to power Raspberry Pi, LCD panel, PCA9685 control board
  • Thingiverse 3D-printed Spot Micro frame

How does it walk?

The mini ‘Spot Micro’ bot rocks a three-axis angle command/body pose control mode via keyboard and can achieve ‘trot gait’ or ‘walk gait’. The former is a four-phase gait with symmetric motion of two legs at a time (like a horse trotting). The latter is an eight-phase gait with one leg swinging at a time and a body shift in between for balance (like humans walking).

Mike breaks down how they got the robot walking, right down to the order the servos need to be connected to the PCA9685 control board, in this extensive walkthrough.

Here’s the code

And yes, this is one of those magical projects with all the code you need stored on GitHub. The software is implemented on a Raspberry Pi 3B running Ubuntu 16.04. It’s composed on C++ and Python nodes in a ROS framework.

What’s next?

Mike isn’t finished yet: they are looking to improve their yellow beast by incorporating a lidar to achieve simple 2D mapping of a room. Also on the list is developing an autonomous motion-planning module to guide the robot to execute a simple task around a sensed 2D environment. And finally, adding a camera or webcam to conduct basic image classification would finesse their creation.

The post Mini Raspberry Pi Boston Dynamics–inspired robot appeared first on Raspberry Pi.

Track your punches with Raspberry Pi

Post Syndicated from Ashley Whittaker original https://www.raspberrypi.org/blog/track-your-punches-with-raspberry-pi/

‘Track-o-punches’ tracks the number of punches thrown during workouts with Raspberry Pi and a Realsense camera, and it also displays your progress and sets challenges on a touchscreen.

In this video, Cisco shows you how to set up the Realsense camera and a Python virtual environment, and how to install dependencies and OpenCV for Python on your Raspberry Pi.

How it works

A Realsense robotic camera tracks the boxing glove as it enters and leaves the frame. Colour segmentation means the camera can more precisely pick up when Cisco’s white boxing glove is in frame. He walks you through how to threshold images for colour segmentation at this point in the video.

Testing the tracking

All this data is then crunched on Raspberry Pi. Cisco’s code counts the consecutive frames that the segmented object is present; if that number is greater than a threshold, the code sees this as a particular action.

Raspberry Pi 4 being mounted on the Raspberry Pi 7″ Touch Display

Cisco used this data to set punch goals for the user. The Raspberry Pi computer is connected to an official Raspberry Pi 7″ Touch Display in order to display “success” and “fail” messages as well as the countdown clock. Once a goal is reached, the touchscreen tells the boxer that they’ve successfully hit their target. Then the counter resets and a new goal is displayed. You can manipulate the code to set a time limit to reach a punch goal, but setting a countdown timer was the hardest bit to code for Cisco.

Kit list

Jeeeez, it’s hard to get a screen grab of Cisco’s fists of fury

A mobile power source makes it easier to set up a Raspberry Pi wherever you want to work out. Cisco 3D-printed a mount for the Realsense camera and secured it on the ceiling so it could look down on him while he punched.

The post Track your punches with Raspberry Pi appeared first on Raspberry Pi.

New twist on Raspberry Pi experimental resin 3D printer

Post Syndicated from Ashley Whittaker original https://www.raspberrypi.org/blog/new-twist-on-raspberry-pi-experimental-resin-3d-printer/

Element14’s Clem previously built a giant Raspberry Pi-powered resin-based 3D printer and here, he’s flipped the concept upside down.

The new Raspberry Pi 4 8GB reduces slicing times and makes for a more responsive GUI on this experimental 3D printer. Let’s take a look at what Clem changed and how…

The previous iteration of his build was “huge”, mainly because the only suitable screen Clem had to hand was a big 4K monitor. This new build flips the previous concept upside down by reducing the base size and the amount of resin needed.

Breaking out of the axis

To resize the project effectively, Clem came out of an X,Y axis and into Z, reducing the surface area but still allowing for scaling up, well, upwards! The resized, flipped version of this project also reduces the cost (resin is expensive stuff) and makes the whole thing more portable than a traditional, clunky 3D printer.

Look how slim and portable it is!

How it works

Now for the brains of the thing: nanodlip is free (but not open source) software which Clem ran on a Raspberry Pi 4. Using an 8GB Raspberry Pi will get you faster slicing times, so go big if you can.

A 5V and 12V switch volt power supply sorts out the Nanotec stepper motor. To get the signal from the Raspberry Pi GPIO pins to the stepper driver and to the motor, the pins are configured in nanodlp; Clem has shared his settings if you’d like to copy them (scroll down on this page to find a ‘Resources’ zip file just under the ‘Bill of Materials’ list).

Raspberry Pi working together with the display

For the display, there’s a Midas screen and an official Raspberry Pi 7″ Touchscreen Display, both of which work perfectly with nanodlip.

At 9:15 minutes in to the project video, Clem shows you around Fusion 360 and how he designed, printed, assembled, and tested the build’s engineering.

A bit of Fusion 360

Experimental resin

Now for the fancy, groundbreaking bit: Clem chose very specialised photocentric, high-tensile daylight resin so he can use LEDs with a daylight spectrum. This type of resin also has a lower density, so the liquid does not need to be suspended by surface tension (as in traditional 3D printers), rather it floats because of its own buoyancy. This way, you’ll need less resin to start with, and you’ll waste less too whenever you make a mistake. At 13:30 minutes into the project video, Clem shares the secret of how you achieve an ‘Oversaturated Solution’ in order to get your resin to float.

Now for the science bit…

Materials

It’s not perfect but, if Clem’s happy, we’re happy.

Join the conversation on YouTube if you’ve got an idea that could improve this unique approach to building 3D printers.

The post New twist on Raspberry Pi experimental resin 3D printer appeared first on Raspberry Pi.

Raspberry Pi calls out your custom workout routine

Post Syndicated from Ashley Whittaker original https://www.raspberrypi.org/blog/raspberry-pi-calls-out-your-custom-workout-routine/

If you don’t want to be tied to a video screen during home workouts, Llum AcostaSamreen Islam, and Alfred Gonzalez shared this great Raspberry Pi–powered alternative on hackster.io: their voice-activated project announces each move of your workout routine and how long you need to do it for.

This LED-lit, compact solution means you don’t need to squeeze yourself in front of a TV or crane to see what your video instructor is doing next. Instead you can be out in the garden or at a local park and complete your own, personalised workout on your own terms.

Kit list:

Raspberry Pi and MATRIX Device

The makers shared these setup guides to get MATRIX working with your Raspberry Pi. Our tiny computer doesn’t have a built-in microphone, so here’s where the two need to work together.

MATRIX, meet Raspberry Pi

Once that’s set up, ensure you enable SSH on your Raspberry Pi.

Click, click. Simple

The three sweet Hackster angels shared a four-step guide to running the software of your own customisable workout routine buddy in their original post. Happy hacking!

1. Install MATRIX Libraries and Rhasspy

Follow the steps below in order for Rhasspy to work on your Raspberry Pi.

2. Creating an intent

Access Rhasspy’s web interface by opening a browser and navigating to http://YOUR_PI_IP_HERE:12101. Then click on the Sentences tab. All intents and sentences are defined here.

By default, there are a few example sentences in the text box. Remove the default intents and add the following:

[Workout]start [my] workout

Once created, click on Save Sentences and wait for Rhasspy to finish training.

Here, Workout is an intent. You can change the wording to anything that works for you as long as you keep [Workout] the same, because this intent name will be used in the code.

3. Catching the intent

Install git on your Raspberry Pi.

sudo apt install git

Download the repository.

git clone https://github.com/matrix-io/rhasspy-workout-timer

Navigate to the folder and install the project dependencies.

cd rhasspy-workout-timernpm install

Run the program.

node index.js

4. Using and customizing the project

To change the workout to your desired routine, head into the project folder and open workout.txt. There, you’ll see:

jumping jacks 12,plank 15, test 14

To make your own workout routine, type an exercise name followed by the number of seconds to do it for. Repeat that for each exercise you want to do, separating each combo using a comma.

Whenever you want to use the Rhasspy Assistant, run the file and say “Start my workout” (or whatever it is you have it set to).

And now you’re all done — happy working out. Make sure to visit the makers’ original post on hackster.io and give it a like.

The post Raspberry Pi calls out your custom workout routine appeared first on Raspberry Pi.
