Using VPC Sharing for a Cost-Effective Multi-Account Microservice Architecture

Post Syndicated from Anandprasanna Gaitonde original https://aws.amazon.com/blogs/architecture/using-vpc-sharing-for-a-cost-effective-multi-account-microservice-architecture/

Introduction

Many cloud-native organizations building modern applications have adopted a microservice architecture because of its flexibility, performance, and scalability. Even customers with legacy and monolithic application stacks are embarking on an application modernization journey and opting for this type of architecture. A microservice architecture allows applications to be composed of several loosely coupled discreet services that are independently deployable, scalable, and maintainable. These applications can comprise a large number of microservices, which often span multiple business units within an organization. These customers typically have a multi-account AWS environment with each AWS account belonging to an individual business unit. Their microservice implementations reside in the Virtual Public Clouds (VPCs) of their respective AWS accounts. You can set up multi-account AWS environment incorporating best practices using AWS Landing Zone or AWS Control Tower.

This type of multi-account, multi-VPC architecture provides a good boundary and isolation for individual microservices and achieves a highly available, scalable, and secure architecture. However, for microservices that require a high degree of interconnectivity and are within the same trust boundaries, you can use other AWS capabilities to optimize cost and network management complexity.

This blog presents a cost-effective approach that requires less VPC management while still using separate accounts for billing and access control. This approach does not sacrifice scalability, high availability, fault tolerance, and security. To achieve a similar microservice architecture, you can share a VPC across AWS accounts using AWS Resource Access Manager (AWS RAM) and Network Load Balancer (NLB) support in a shared Amazon Virtual Private Cloud (VPC). This allows multiple microservices to coexist in the same VPC, even though they are developed by different business units.

Microservices architecture in a multi-VPC approach

In this architecture, microservices deployed across multiple VPCs use privately exposed endpoints for better security posture instead of going over the internet. This requires the customers to enable inter-VPC communication using the various networking capabilities of AWS as shown below:

microservices deployed across multiple VPCs use privately exposed endpoints

In the above reference architecture, we created a VPC in Account A, which is hosting the front end of the application across a fleet of Amazon Elastic Compute Cloud (Amazon EC2) instances using an AWS Auto Scaling group. For simplicity, we’ve illustrated a single public and private subnet for the application front end. In reality, this spans across multiple subnets across multiple Availability Zones (AZ) to support a highly available and fault-tolerant configuration.

To ensure security, the application must communicate privately to microservices mS1 and mS2 deployed in VPC of Account B and Account C respectively. For high availability, these microservices are also implemented using a fleet of Amazon EC2 instances with the Auto Scaling group spanning across multiple subnets/availability zones. For high-performance load balancing, they are fronted by a Network Load Balancer.

While this architecture shows an implementation using Amazon EC2, it can also use containerized services deployed using Amazon Elastic Container Service (Amazon ECS) or Amazon Elastic Kubernetes Service (Amazon EKS). These microservices may have interdependencies and invoke each other’s’ APIs for servicing the requests of the application layer. This application to mS and mS to mS communication can be achieved using following possible connectivity options:

When only few VPC interconnections are required, Amazon VPC peering and AWS PrivateLink may be a viable option. For higher number of VPC interconnections, we recommend AWS Transit Gateway for better manageability of connections and routing through a centralized resource. However, based on the amount of traffic this can introduce significant costs to your architecture.

Alternative approach to microservice architecture using Network Load Balancers in a shared VPC

The above architecture pattern allows your individual microservice teams to continue to own their AWS resources that host their microservice implementation. But they can deploy them in a shared VPC owned by the central account, eliminating the need for inter-VPC network connections. You can share Amazon VPCs to use the implicit routing within a VPC for applications that require a high degree of interconnectivity and are within the same trust boundaries.

This architecture uses AWS RAM, which allows you to share the VPC Subnets from AWS Account A to participating AWS accounts within your AWS organization. When the subnets are shared, participant AWS accounts (Account B and Account C) can see the shared subnets in their own environment. They can then deploy their Amazon EC2 instances in those subnets. This is depicted in the diagram where the visibility of the shared subnets (SS1 and SS2) is extended to the participating accounts (Account B and Account C).

You can also deploy the NLB in these shared subnets. Then, each participant account owns all the AWS resources for their microservice stack, but it’s deployed in the VPC of Account A.

This allows your individual microservice teams to maintain control over load balancer configurations and Auto Scaling policies based for their specific microservices’ needs. At the same time, using the AWS RAM they are able to effectively use the existing VPC environment of Account A.

This architecture presents several benefits over the multi-VPC architecture discussed earlier:

  • You can deploy the entire application, including the individual microservices, into a single shared VPC. This is while still allowing individual microservice teams control over their AWS resources deployed in that VPC.
  • Since the entire architecture now resides in a single VPC, it doesn’t require other networking connectivity features. It can rely on intra-VPC traffic for communication between the application (API) layer and microservices.
  • This leads to reduction in cost of the architecture. While the AWS RAM functionality is free of charge, this also reduces the data transfer and per-connection costs incurred by other options such as VPC peering, AWS PrivateLink, and AWS Transit Gateway.
  • This maintains the isolation across the individual microservices and the application layer.  Participants can’t view, modify, or delete resources that belong to others or the VPC owner.
  • This also leads to effective utilization of your VPC CIDR block resources.
  • Since multiple subnets belonging to different Availability Zones are shared, the application and individual mS continues to take advantage of scalability, availability, and fault tolerance.

The following illustration shows how you can configure AWS RAM to set up the VPC subnet resource shares between owner Account A and participating Account B. The example below shows the sharing of private subnet SS1 using this method:

(Click for larger image)

Accounts A and B Resource Share

Once this subnet is shared, the participating Account B can launch its Network Load Balancer of its microservice ms1 in the shared VPC subnet as shown below:

Account B can launch its Network Load Balancer of its microservice ms1 in the shared VPC subnet

While this architecture has many advantages, there are important considerations:

  • This style of architecture is suitable when you are certain that the number of microservices is small enough to coexist in a single VPC without depleting the CIDR block of the shared subnets of the VPC.
  • If the traffic between these microservices is in-significant, then the cost benefit of this architecture over other options may not be substantial. This is due to the effect of traffic flow on data transfer cost.

Conclusion

AWS Cloud provides several options to build a microservices architecture. It is important to look at the characteristics of your application to determine which architectural choices top opt for. The AWS RAM and the ability to deploy AWS resources (including Network Load Balancers in shared VPC) helps you eliminate inter-VPC traffic and associated networking costs. And this without sacrificing high availability, scalability, fault tolerance, and security for your application.

One to Many: Evolving VPC Design

Post Syndicated from Androski Spicer original https://aws.amazon.com/blogs/architecture/one-to-many-evolving-vpc-design/

Since its inception, the Amazon Virtual Private Cloud (VPC) has acted as the embodiment of security and privacy for customers who are looking to run their applications in a controlled, private, secure, and isolated environment.

This logically isolated space has evolved, and in its evolution has increased the avenues that customers can take to create and manage multi-tenant environments with multiple integration points for access to resources on-premises.

This blog is a two-part series that begins with a look at the Amazon VPC as a single unit of networking in the AWS Cloud but eventually takes you to a world in which simplified architectures for establishing a global network of VPCs are possible.

From One VPC: Single Unit of Networking

To be successful with the AWS Virtual Private Cloud you first have to define success for today and what success might look like as your organization’s adoption of the AWS cloud increases and matures. In essence, your VPCs should be designed to satisfy the needs of your applications today and must be scalable to accommodate future needs.

Classless Inter-Domain Routing (CIDR) notations are used to denote the size of your VPC. AWS allows you specify a CIDR block between /16 and /28. The largest, /16, provides you with 65,536 IP addresses and the smallest possible allowed CIDR block, /28, provides you with 16 IP addresses. Note, the first four IP addresses and the last IP address in each subnet CIDR block are not available for you to use, and cannot be assigned to an instance.

AWS VPC supports both IPv4 and IPv6. It is required that you specify an IPv4 CIDR range when creating a VPC. Specifying an IPv6 range is optional.

Customers can specify ANY IPv4 address space for their VPC. This includes but is not limited to RFC 1918 addresses.

After creating your VPC, you divide it into subnets. In an AWS VPC, subnets are not isolation boundaries around your application. Rather, they are containers for routing policies.

Isolation is achieved by attaching an AWS Security Group (SG) to the EC2 instances that host your application. SGs are stateful firewalls, meaning that connections are tracked to ensure return traffic is allowed. They control inbound and outbound access to the elastic network interfaces that are attached to an EC2 instance. These should be tightly configured, only allowing access as needed.

It is our best practice that subnets should be created in categories. There two main categories; public subnets and private subnets. At minimum they should be designed as outlined in the below diagrams for IPv4 and IPv6 subnet design.

Recommended IPv4 subnet design pattern

Recommended IPv6 subnet design pattern

Subnet types are denoted by the ability and inability for applications and users on the internet to directly initiate access to infrastructure within a subnet.

Public Subnets

Public subnets are attached to a route table that has a default route to the Internet via an Internet gateway.

Resources in a public subnet can have a public IP or Elastic IP (EIP) that has a NAT to the Elastic Network Interface (ENI) of the virtual machines or containers that hosts your application(s). This is a one-to-one NAT that is performed by the Internet gateway.

Illustration of public subnet access path to the Internet through the Internet Gateway (IGW)

Private Subnets

A private subnet contains infrastructure that isn’t directly accessible from the Internet. Unlike the public subnet, this infrastructure only has private IPs.

Infrastructure in a private subnet gain access to resources or users on the Internet through a NAT infrastructure of sorts.

AWS natively provides NAT capability through the use of the NAT Gateway service. Customers can also create NAT instances that they manage or leverage third-party NAT appliances from the AWS Marketplace.

In most scenarios, it is recommended to use the AWS NAT Gateway as it is highly available (in a single Availability Zone) and is provided as a managed service by AWS. It supports 5 Gbps of bandwidth per NAT gateway and automatically scales up to 45 Gbps.

An AWS NAT gateway’s high availability is confined to a single Availability Zone. For high availability across AZs, it is recommended to have a minimum of two NAT gateways (in different AZs). This allows you to switch to an available NAT gateway in the event that one should become unavailable.

This approach allows you to zone your Internet traffic, reducing cross Availability Zone connections to the Internet. More details on NAT gateway are available here.

Illustration of an environment with a single NAT Gateway (NAT-GW)

Illustration of high availability with a multiple NAT Gateways (NAT-GW) attached to their own route table

Illustration of the failure of one NAT Gateway and the fail over to an available NAT Gateway by the manual changing of the default route next hop in private subnet A route table

AWS allocated IPv6 addresses are Global Unicast Addresses by default. That said, you can privatize these subnets by using an Egress-Only Internet Gateway (E-IGW), instead of a regular Internet gateway. E-IGWs are purposely built to prevents users and applications on the Internet from initiating access to infrastructure in your IPv6 subnet(s).

Illustration of internet access for hybrid IPv6 subnets through an Egress-Only Internet Gateway (E-IGW)

Applications hosted on instances living within a private subnet can have different access needs. Some require access to the Internet while others require access to databases, applications, and users that are on-premises. For this type of access, AWS provides two avenues: the Virtual Gateway and the Transit Gateway. The Virtual Gateway can only support a single VPC at a time, while the Transit Gateway is built to simplify the interconnectivity of tens to hundreds of VPCs and then aggregating their connectivity to resources on-premises. Given that we are looking at the VPC as a single unit of networking, all diagrams below contain illustrations of the Virtual Gateway which acts a WAN concentrator for your VPC.

Illustration of private subnets connecting to data center via a Virtual Gateway (VGW)



Illustration of private subnets connecting to Data Center via a VGW



Illustration of private subnets connecting to Data Center using AWS Direct Connect as primary and IPsec as backup

The above diagram illustrates a WAN connection between a VGW attached to a VPC and a customer’s data center.

AWS provides two options for establishing a private connectivity between your VPC and on-premises network: AWS Direct Connect and AWS Site-to-Site VPN.

AWS Site-to-Site VPN configuration leverages IPSec with each connection providing two redundant IPSec tunnels. AWS support both static routing and dynamic routing (through the use of BGP).

BGP is recommended, as it allows dynamic route advertisement, high availability through failure detection, and fail over between tunnels in addition to decreased management complexity.

VPC Endpoints: Gateway & Interface Endpoints

Applications running inside your subnet(s) may need to connect to AWS public services (like Amazon S3, Amazon Simple Notification Service (SNS), Amazon Simple Queue Service (SQS), Amazon API Gateway, etc.) or applications in another VPC that lives in another account. For example, you may have a database in another account that you would like to expose applications that lives in a completely different account and subnet.

For these scenarios you have the option to leverage an Amazon VPC Endpoint.

There are two types of VPC Endpoints: Gateway Endpoints and Interface Endpoints.

Gateway Endpoints only support Amazon S3 and Amazon DynamoDB. Upon creation, a gateway is added to your specified route table(s) and acts as the destination for all requests to the service it is created for.

Interface Endpoints differ significantly and can only be created for services that are powered by AWS PrivateLink.

Upon creation, AWS creates an interface endpoint consisting of one or more Elastic Network Interfaces (ENIs). Each AZ can support one interface endpoint ENI. This acts as a point of entry for all traffic destined to a specific PrivateLink service.

When an interface endpoint is created, associated DNS entries are created that point to the endpoint and each ENI that the endpoint contains. To access the PrivateLink service you must send your request to one of these hostnames.

As illustrated below, ensure the Private DNS feature is enabled for AWS public and Marketplace services:

Since interface endpoints leverage ENIs, customers can use cloud techniques they are already familiar with. The interface endpoint can be configured with a restrictive security group. These endpoints can also be easily accessed from both inside and outside the VPC. Access from outside a VPC can be accomplished through Direct Connect and VPN.

Illustration of a solution that leverages an interface and gateway endpoint

Customers can also create AWS Endpoint services for their applications or services running on-premises. This allows access to these services via an interface endpoint which can be extended to other VPCs (even if the VPCs themselves do not have Direct Connect configured).

VPC Sharing

At re:Invent 2018, AWS launched the feature VPC sharing, which helps customers control VPC sprawl by decoupling the boundary of an AWS account from the underlying VPC network that supports its infrastructure.

VPC sharing uses Amazon Resource Access Manager (RAM) to share subnets across accounts within the same AWS organization.

VPC sharing is defined as:

VPC sharing allows customers to centralize the management of network, its IP space and the access paths to resources external to the VPC. This method of centralization and reuse (of VPC components such as NAT Gateway and Direct Connect connections) results in a reduction of cost to manage and maintain this environment.

Great, but there are times when a customer needs to build networks with multiple VPCs in and across AWS regions. How should this be done and what are the best practices?

This will be answered in part two of this blog.
